CHARACTERISTICS CHARACTERISTICS
The audio signal input stage uses the ECC803 tube for differential voltage amplification,
and famous transistors for second-stage differential voltage amplification.The final stage is
composed of 24 high-power transistors to form a 0dB powerful power output stage, which
can easily drive floor standspeakers with an impedance as low as 2 ohms.
The independent mono balanced amplification structure is adopted to effectively
eliminate the problem of dynamic crosstalk interference, so that the performance indicators
such as sound field positioning, analysis power and sound energy stability are greatly
improved.
The power supply part is composed of a 1500W toroidal transformer, 120,000 micro-farad
audio special electrolytic capacitors, witha huge aluminum heat sink. Alarge amount of
audio special materialsgivesa strong driving and control effect on the speaker.
Within 100W, it is a Class A output state, and the sound is delicate and thick. When it
exceeds 100W, it will automatically switch to Class A and B output mode, making it a
powerful force when playing big dynamic music software.
The balanced and unbalanced signal input options connect two preamplifiers with
different tones.
Theselection of Class A or Class AB outputis not only convenient for adjusting the tone,
but also save power consumption to greatly reduce the heat, so that you can choose a
suitable working modewhen listening to different music contents.
Both the unbalanced signal input terminal and the speaker connection terminal apply the
German WBT sockets, and the balanced signal input terminal adopts Swiss Neutrick
products; the internal audio signal connection wire applyAmerican Kimber Kable, so that
the audio signal can be transmitted more ideally.
The power input socket is Japanese Furutechgold-plated, and the fuse adopts imported
products.
The panel is equipped with an output power indicator, which enables users to instantly
observe the power output value of the machine; it is very fashionable, dynamic and
ornamental.
The main purpose of the appearance design is to reflect the connotation of the product.
The details are rich and elegant. Every detail is derived from the inside to the outside and
from the big to the small. It is naturally wonderful and unpretentious. The whole machine
adopts black in a large area, and is decorated with a small amount of stainless steel
gold-plated parts, which not only enhances the visual impact, so that the black has an
unprecedented charm; the stability and the relationship between the whole and the details
are very wonderful, beautiful, and very attractive. Demonstrate luxurious temperament.
