Shelly Shelly Motion Manuel utilisateur

1. Shelly Motion Initial Set Up..........................................3
1.1. Pictures....................................................................3
1.2. EN ............................................................................5
1.3. DE.............................................................................9
1.4. IT............................................................................13
1.5. ES...........................................................................17
1.6. PT ..........................................................................21
1.7. FR...........................................................................25
2. Shelly Application......................................................29

User and Safety guide2

3User and Safety guide
g. 2g. 1
g. 4
g. 5
g. 3

User and Safety guide4
8m/25ft
8m/25ft
8m/25ft
Detection area
Detection area
Detection area
2.2m/7,2ft-2.5m/8.2ft
1m
g. 6
g. 7
g. 8

5User and Safety guide EN
ENGLISH
SHELLY MOTION WIFI SENSOR
Introduction to Shelly
Shelly® is a family of innovative Devices, which allow remote
control of electric appliances through mobile phone, PC or home
automation system. Shelly® Devices use WiFi connectivity, and
they can be controlled from the same network or through remote
access (any internet connection). Shelly® Devices may work
standalone on the local WiFi network, without being managed by
a home automation controller, or it can also work through home
automation cloud services, accessing remotely from wherever
the User has Internet connectivity. Shelly® has an integrated web
server, through which the User may adjust, control and monitor
the Device. Shelly® has two WiFi modes - access Point (AP) and
Client mode (CM). To operate in Client Mode, a WiFi router must
be located within the range of the Device. Shelly® devices can
communicate directly with other WiFi devices through HTTP
protocol. An API can be provided by the Manufacturer. Shelly®
devices may be available for monitor and control even if the User
is outside the range of the local WiFi network, as long as the WiFi
router is connected to the Internet. The cloud function could be
used, which is activated through the web server of the Device or
through the settings in the Shelly Cloud mobile application. The
User can register and access Shelly Cloud, using either Android or
iOS mobile applications, or any internet browser and the web site:
https://my.shelly.cloud/
What is Shelly Motion
Shelly Motion is high sensitivity ultra-low power consuming WiFi
Motion sensor which stays connected to internet 24/7 and no ad-
ditional HUB is required to control it. Shelly Motion sends notica-
tion once motion is detected or it will instantly turn on the lights.
It has built-in accelerometer providing protection when someone
tries to dislocate or move the device. The built-in light sensor
gives additional opportunities for home or oce automation.

User and Safety guide EN6
ENGLISH
Shelly Motion has a built-in 6500mAh rechargeable battery which
allows the sensor to be connected to the Internet (standby mode)
for up to 3 years without recharging, and in active transmission
(approx. 6 hours/day motion detected) estimated between 12 and
18 months.
Specication
• Working temperature -10 ÷ 50°C
• Radio protocol WiFi 802.11 b/g/n
• Frequency 2400 – 2500 MHz
• Operational range (depending on local construction) up to 50 m
outdoors or up to 30 m indoors
• Battery - 6500mAh 3,7V
Visual indications
The Motion Sensor is equipped with a LED diode, signaling sen-
sor’s operating modes and alarms.
Blue light non blinking Inclusion mode
Red light blink Motion detected and reported
Green light blink
Motion detected, reporting disabled
Blue/Green/Red sequence
Reboot or Vibration detected
Blue light blink Firmware update
Blue light single blink Settings change
Button user interaction
Use pin to press the button as shown at the picture
• Short press (AP mode) - wake-up from AP sleep mode (AP is
only for 3 minute and device power OFF, battery save transpor-
tation mode)
• Short press (STA MODE) - send status
• Long press 5 sec (STA mode) - AP mode
• Long press 10 sec (STA mode) - Factory reset

7User and Safety guide EN
ENGLISH
Installation Instructions
⚠CAUTION! Before beginning the installation please read the
accompanying documentation carefully and completely. Failure
to follow recommended procedures could lead to malfunction,
danger to your life or violation of the law. Allterco Robotics is not
responsible for any loss or damage in case of incorrect installation
or operation of this device.
⚠CAUTION! Do not allow children to play with the device, espe-
cially with the Power Button. Keep the devices for remote control of
Shelly (mobile phones, tablets, PCs) away from children.
How to assemble and mount the Shelly Motion
1. In your package as seen in g. 1 you will nd the body of the
Shelly Motion, ball arm plate and wall plate.
2. Place the ball arm plate onto the body of Shelly Motion as seen
in g. 2.
3. Twist the ball arm plate in clock-wise direction as seen in g. 3.
4. Place the wall plate onto the ball arm plate - g. 4.
5. The assembled Shelly Motion sensor should look like g. 5.
6. Use the locking dowel provided in this package to mount your
Shelly Motion on to the wall.
Shelly Motion area of detection
Shelly Motion has range of 8m or 25ft. Optimal height for mount-
ing is between 2,2m/7,2ft and 2,5m/8,2ft.

User and Safety guide EN8
ENGLISH
⚠CAUTION! Shelly Motion has “No detection“ area one meter in
front of the sensor - g. 6
⚠CAUTION! Shelly Motion has “No detection“ area one meter be-
hind solid objects (sofa, closet, etc.) - g. 7 and g. 8
⚠CAUTION! Shelly Motion cannot detect movement through
transparent objects.
⚠CAUTION! Direct sun light or close heating sources can trigger
false motion detection.
Declaration of conformity
Hereby, Allterco Robotics EOOD declares that the radio equipment
type Shelly Motion is in compliance with Directive 2014/53/EU,
2014/35/EU, 2004/108/WE, 2011/65/UE. The full text of the EU
declaration of conformity is available at the following internet ad-
dress: https://shelly.cloud/declaration-of-conformity/
Manufacturer: Allterco Robotics EOOD
Address: Soa, 1407, 103 Cherni vrah Blvd.
Tel.: +359 2 988 7435
E-mail: support@shelly.cloud
Web: http://www.shelly.cloud
Changes in the contact data are published by the Manufacturer at
the ocial website of the Device
http://www.shelly.cloud
The User is obliged to stay informed for any amendments of these
warranty terms before exercising his/her rights against the Man-
ufacturer.
All rights to trademarks She® and Shelly® , and other intellectu-
al rights associated with this Device belong to Allterco Robotics
EOOD.

9Benutzer- und Sicherheitshandbuch
DEUTSCH
SHELLY MOTION WLAN-SENSOR
Einführung in die Produktwelt von Shelly
Shelly® ist eine Familie innovativer Geräte, die die Fernsteuerung
von Elektrogeräten über Mobiltelefone, PCs oder Hausautoma-
tionssysteme ermöglichen. Shelly®-Geräte verwenden WiFi-Kon-
nektivität und können über dasselbe Netzwerk oder über Fernzu-
griff (jede Internetverbindung) gesteuert werden. Shelly®-Geräte
können im lokalen WiFi-Netzwerk eigenständig arbeiten, ohne von
einem Hausautomationscontroller verwaltet zu werden, oder sie
können auch über Cloud-Dienste für die Hausautomation arbeiten
und von jedem Ort aus, an dem der Benutzer über eine Internet-
verbindung verfügt, remote zugreifen. Shelly® verfügt über einen
integrierten Webserver, über den der Benutzer das Gerät anpassen,
steuern und überwachen kann. Shelly® verfügt über zwei WiFi-Mo-
di - Access Point (AP) und Client-Modus (CM). Um im Client-Mo-
dus arbeiten zu können, muss sich ein WLAN-Router in Reichweite
des Geräts benden. Shelly®-Geräte können über das HTTP-Pro-
tokoll direkt mit anderen WiFi-Geräten kommunizieren. Eine API
kann vom Hersteller bereitgestellt werden. Shelly®-Geräte können
möglicherweise überwacht und gesteuert werden, auch wenn sich
der Benutzer außerhalb der Reichweite des lokalen WLAN-Netz-
werks bendet, solange der WLAN-Router mit dem Internet ver-
bunden ist. Die Cloud-Funktion kann verwendet werden, die über
den Webserver des Geräts oder über die Einstellungen in der mobi-
len Shelly Cloud-Anwendung aktiviert wird. Der Benutzer kann sich
mit mobilen Android- oder iOS-Anwendungen oder einem beliebi-
gen Internetbrowser und der Website registrieren und auf Shelly
Cloud zugreifen: https://my.shelly.cloud/
Was ist Shelly Motion?
Benachrichtigung, sobald eine Bewegung erkannt wird, oder
schaltet das Licht sofort ein. Der eingebaute Beschleunigungs-
messer bietet Schutz, wenn jemand versucht, das Gerät zu ver-
schieben oder zu bewegen. Der eingebaute Lichtsensor bietet

Benutzer- und Sicherheitshandbuch10
DEUTSCH
zusätzliche Möglichkeiten für die Heim- oder Büroautomation.
Shelly Motion verfügt über einen eingebauten 6500-mAh-Akku,
mit dem der Sensor bis zu 3 Jahre lang ohne Auaden mit dem
Internet verbunden werden kann (Standby-Modus) und bei aktiver
Übertragung (ca. 6 Stunden / Tag Bewegung erkannt) zwischen
12 und 18 Monate.
Spezikation
• Arbeitstemperatur -10 ÷ 50 ° C.
• Funkprotokoll WiFi 802.11 b / g / n
• Frequenz 2400 - 2500 MHz
• Betriebsreichweite (abhängig von der örtlichen Konstruktion)
bis zu 50 m im Freien oder bis zu 30 m im Innenbereich
• Batterie - 6500mAh 3,7V
Visuelle Angaben
Der Bewegungssensor ist mit einer LED-Diode ausgestattet, die
die Betriebsarten und Alarme des Sensors signalisiert.
Blaues Licht blinkt nicht Einschlussmodus
Rotes Licht blinkt Bewegung erkannt und gemeldet
Grünes Licht blinkt
Bewegung erkannt, Berichterstellung
deaktiviert
Blau / Grün / Rot-Sequenz
Neustart oder Vibration erkannt
Blaues Licht blinkt Firmware Update
Blaues Licht einmal blinken
Einstellungen ändern sich
Tastenbenutzerinterkation
Drücken Sie die Taste mit dem Stift wie gezeigt
• Kurzes Drücken (AP-Modus) - Aufwecken aus dem AP-Schlaf-
modus (AP ist nur für 3 Minuten und Gerät ausgeschaltet, Akku
spart Transportmodus)
• Kurz drücken (STA MODE) - Sendestatus
• 5 Sekunden lang drücken (STA-Modus) - AP-Modus
• Langes Drücken 10 Sek. (STA-Modus) - Werksreset
