CHAPTER 1. SPECIFICATIONS

[1] SPECIFICATIONS .................................................

1-1

CHAPTER 2. IMPORTANT SERVICE NOTES

[1] IMPORTANT SERVICE NOTE ..............................

2-1

CHAPTER 3. ADJUSTMENT PRECAUTIONS

[1] ADJUSTMENT PRECAUTIONS ...........................

3-1

[2] ADJUSTMENT ......................................................

3-15

CHAPTER 4. TROUBLE SHOOTING FLOWCHART

[1] TROUBLE SHOOTING FLOWCHART..................

4-1

CHAPTER 5. SOLID STATE DEVICE BASE DIAGRAM

[1] SOLID STATE DEVICE BASE DIAGRAM .............

5-1

CHAPTER 6. CHASSIS LAYOUT

[1] CHASSIS LAYOUT................................................

6-1

CHAPTER 7. DESCRIPTION OF SCHEMATIC DIAGRAM

[1] DESCRIPTION OF SCHEMATIC DIAGRAM ........

7-1

CHAPTER 8. BLOCK DIAGRAM

[1] BLOCK DIAGRAM : MAIN UNIT ...........................

8-1

CHAPTER 9. WAVEFORM

[1] WAVEFORM..........................................................

9-1

CHAPTER 10. SCHEMATIC DIAGRAM

[1] SCHEMATIC DIAGRAM : CRT UNIT ....................

10-1

[2] SCHEMATIC DIAGRAM : MAIN UNIT ..................

10-2

CHAPTER 11. PRINTED WIRING BOARD ASSEMBLIES

[1] PWB-A : MAIN UNIT .............................................

11-1

[2] PWB-B : CRT UNIT...............................................

11-5

NTSC System

125-CH Program Memory

AV Mode (Standard/Dynamic/Soft)

CATV Hyper Band Ready

4 Line Digital Comb Filter

Blue/Black Stretch Circuit

Picture Noise Reduction

White Temp. Select

Aperture Control

Gamma Correction

Dual Language OSD (English/Spanish)

Demo

Selectable Audio Output - FAO/VAO

Close Caption

SERVICE MANUAL

29L-FG1L

COLOUR TELEVISION

Chassis No. GB-5

MODEL

CONTENTS

WARNING

The chassis in this receiver is partially hot. Use an isolation transformer between the line cord plug and

power receptacle, when servicing this chassis. To prevent electric shock, do not remove cover. No user -

serviceable parts inside. Refer servicing to qualified service personnel.

29L-FG1L

In the interests of user safety (Required by safety regulations in some countries) the set should be restored to its original

condition and only parts indentical to those specified should be used.

On/Off/Reminder Timer (with beep sound)

Rear AV-IN 1, AV Output (Monitor Out), Headphone

and Front AV-IN 2

Power Save

AFT

Component Input Terminal (share with AV1)

MTS Stereo Decoder

Child Lock

Graphic Equalizer

Sound Mode (Music/Movie/News/Custom)

Hotel Mode

EZ Setup

16 : 9 Mode

S677529LFG1L

Parts Guide

1st Edition

29L-FG1L

1 – 1

TV29L-FG1LService Manual29L-FG1LMarketE

CHAPTER 1. SPECIFICATIONS

[1] SPECIFICATIONS

SPECIFICATIONS

Focus ..................................................................... Bi-Potential, Uni-Potential Electrostatic

Sweep Deflection ................................................................................................... Magnetic

Intermediate Frequencies

Picture IF Carrier ................................................................................................ 38.9MHz

Sound IF Carrier

Colour Sub-Carrier

Power Input ................................................................................... 110 ~ 220V AC 50/60 Hz

Power Consumption ..................................................................................................... 138W

Audio Power Output Rating ...................................................................... 7.5W x 2 (at Max.)

Speaker

Size........................................................................................................... 8 cm round x 2

Aerial Input Impedance

VHF/UHF ......................................................................................... 75 ohms Unbalanced

Receiving Channels

VHF

................................................................................................................

2thru13

UHF .............................................................................................................. 14 thru 69

CATV .................................................................................................................. 1 thru 125

Digital Terrestrial Broadcast (VHF/UHF) ............................................................ 2 thru 69

(EIA, Channel Plan U.S.A.)

Receiving Frequency ................................................................ 55.25 MHz thru 801.25 MHz

Dimensions ..................................................................................................... Width: 810mm

Height: 618mm

Depth: 516.5mm

Weight(approx): 41.0 kg

Cabinet material .................................................................................................. All Plastics

Specifications are subject to change without prior notice.

Convergence ............................................................................... Self Convergence System

................................................................................................ 34.4MHz

................................................................................................ 35.32MHz

29L-FG1L

2 – 1

TV29L-FG1LService Manual29L-FG1LMarketE

CHAPTER 2. IMPORTANT SERVICE NOTES

[1] IMPORTANT SERVICE NOTE

IMPORTANT SERVICE NOTES

Maintenance and repairing of this receiver should be done by

qualified service personnel only.

SERVICE OF HIGH VOLTAGE SYSTEM AND

PICTURE TUBE

When servicing the high voltage system, remove static charge from it by

connecting a 10K ohm resistor in series with an insulated wire (such as a test

probe) between picture tube dag and 2nd anode lead. (AC line cord should

be disconnected from AC outlet.)

1. Picture tube in this receiver employs integral implosion protection.

2. Replace with the same type number of picture tube for continued safety.

3. Do not lift picture tube by the neck.

4. Handle the picture tube only when wearing shatterproof goggles and after discharging

the high voltage completely.

X-RAY

This receiver is designed so that any X-Ray radiation is kept to an absolute

minimum. Since certain malfunctions or servicing may produce potentially

hazardous radiation with prolonged exposure at close range, the following

precautions should be observed:

1. When repairing the circuit, please make sure do not increase the high voltage of the set

to more then 34.0kV (at beam 0 A).

2. To keep the set in a normal operation, please make sure it's function at 30.0kV 1.5kV

(at beam 1700 A). The set has been factory - adjusted to the above-mentioned high voltage.

*If there is a possibility that the high voltage fluctuates as a result of the repaires,

never forget to check for such high voltage after the work.

3. Do not substitute a picture tube with unauthorized types and/or brands which may cause

excessive X-ray radiation.

BEFORE RETURNING THE RECEIVER

Before returning the receiver to the user, perform the following safety checks.

1. Inspect all lead dress to make certain that leads are not pinched or that hardware is not

lodged between the chassis and other metal parts in the receiver.

2. Inspect all protective devices such as non-metal control knobs, insulating fishpapers,

cabinet backs, adjustment and compartment covers or shields, isolation resistor- ca-

pacity networks, mechanical insulators etc.

29L-FG1L

3 – 1

TV29L-FG1LService Manual29L-FG1LMarketE

CHAPTER 3. ADJUSTMENT PRECAUTIONS

[1] ADJUSTMENT PRECAUTIONS

ADJUSTMENT PRECAUTIONS

This model's setting are adjusted in two different ways: through the I2C bus control and in the

conventional analog manner. The adjustments via the I2C bus control include preset-only items and

variable data.

1. Setting the service mode by the microprocessor.

(1). Press and hold the local key "VOL DOWN" & "CH UP" when power on the main switch,

TV will enter into the SERVICE MODE.(The initial value of EEPROM are automatically

preset when new EEPROM is used)

(2). Press the CH DOWN / UP key on the remote controller to get ready to select the mode

one by one.

(3). Press the CH DOWN / UP key on the remote controller to select the modes reversibly

one by one.

(4). Using the VOLUME UP/ DOWN key on the remote controller, the data can be modified.

(5). When press the local key "VOL DOWN" & "CH UP" at the same time,

it will be released from the service mode.

2. Factory Presetting.

(1). After enter into the SERVICE MODE, at "INIT EEPROM" service item (which is under

"CHECK MODE" section) press remote controller key of code "ED", the initial

values are automatically preset.

(2). The initial data are preset as listed in page 4 to 12.

(3). Make sure whether the data need to modify or not (Initial data).

Note: Once the chassis has been assembly together and in ready condition, please make

sure it's go through initialize process (see sect 2-(1) above)

Precaution:If haven't done this initialization, malfunction might be happen.

29L-FG1L

3 – 2

1) In the Service Mode, key is use to select the mode in the following order.

SETTING MODE 1


Setting

SETTING MODE 3

Audio

Setting

CHECK MODE

OPTION MODE

Function Setting

MENU button

of R/C

MENU button

of R/C

MENU button

of R/C

MENU button

of R/C

ADJUSTMENT MODE

RF AGC

50Hz/60Hz

GEOMETRIC ADJ

CUT OFF/

WHITE BALANCE ADJ


SUB ADJ

MENU button

of R/C

29L-FG1L

3 – 3

ADJUSTMENT MODE ITEMS SEQUENCE

Notes:

FORWARD : CH UP KEY

REVERSE : CH DOWN KEY

VX-43COMP-P60

EW-W-P60

E/W-PAR-P60

HOR-SHI-P60

VER-AMP-P60

DRI-BS-DVD

DRI-GS-DVD

SUB-TINT

SUB-SHARP

SUB-CON-DVD

SUB-TINT-DVD

SUB-BRI

SUB-BRI-DVD

SUB-COL

SUB-CON

DRI-RS-DVD

CUT-GW

DRI-GW

DRI-BW

CUT-RW

DRI-RW

CUT-RC

CUT-GC

DRI-GC

DRI-BC

CUT-GS

DRI-RC

DRI-RS

DRI-GS

CUT-RS

DRI-BS

S-COR

LOCOR-PAR

E/W-TRAP

V-SCROLL

VX-NORMAL

VER-SHI-F60

VER-AMP-F60

HOR-SHI-F60

CUT-RS-DVD

H-BOW

VER-SHI-P60

V-LIN

UPCOR-PAR

CUT-GS-DVD

DRI-RC-DVD

DRI-GC-DVD

DRI-BC-DVD

CUT-RC-DVD

CUT-GC-DVD

DRI-RW-DVD

DRI-GW-DVD

CUT-GW-DVD

DRI-BW-DVD

CUT-RW-DVD

VSLOPE

H-PAR

EW-W-F60

E/W-PAR-F60

GEOMETRIC

ADJ MODE

WHITE POINT

ADJ MODE

PICTURE SUB ADJ

MODE

29L-FG1L

3 – 4

OPTION MODE MENU

0001 Option Mode Picture Tube Used Type TUBE-TYPE

0002 PIF Frequency Setting PIF

0003 Sound M SND-M

0004 Sound DK SND-DK

0005 Sound I SND-I

0006 Sound BG SND-BG

0007 Colour System SECAM SECAM

0008 Colour System NTSC358 NTSC358

0009 Colour System NTSC443 NTSC443

0010 Audio Configuration AUDIO-CFG

0011 Mono Bilingual BILINGUAL

0012 Equalizer EQUALIZER

0013 Sub Woofer WOOFER

0014 Hotel Mode HOTEL

0015 Hotel Volume HTL-VOL

0016 Hotel Program Number HTL-PRG

0017 HTL-USE-LAST HTL-USE-LAST

0018 Childlock CHILD

0019 Wide Screen Signalling WSS

0020 Golden SCART GLD-SCART

0021 Power On Last Status PW-LAST

0022 AV1-IN AV1-IN

0023 Component Input DVD1-IN

0024 AV2-IN AV2-IN

0025 INCL-AV INCL-AV

0026 Reminder Timer TIM-REMINDER

0027 Off Timer TIM-OFF

0028 Commercial Skip Timer TIM-SKIP

0029 Virgin Mode VIRGIN MODE

0030 ERR-1-8-SUP ERR-1-8-SUP

0031 ERR-XRAY ERR-XRAY

0032 ERR-SUPVOL ERR-SUPVOL

0033 ERR-VERTG ERR-VERTG

0034 ARROW-ENTER-KEY ARROW-ENTER-KEY

0035 Teletext Pan-european TXTEURO-UNUSED

0036 Teletext Western TXTWEST-UNUSED

0037 Teletext On TXT ON-UNUSED

0038 Variable Audio Out VAO

0039 BASS-EFFECT BASS-EFFECT

0040 TB-EFF-NOT-USED TREBLE-EFFECT

0041 Spanish OSD Language SPANISH

0042

0043

0044

INITIAL DATA

0/1

0..7

0/1

0..2

0/1

0...60

0...99

0/1

0..2

0/1

ITEM

SERVICE MODE

EEPROM ITEM

OSD

0/1

DATA

SETTING DATA

IO-EXP-NOT-USED

0/1

DEMO

0/1

Close Caption

0/1

29L-FG1L

3 – 5

Adjustment Mode Items

ITEM EEPROM SETTING DATA RANGE IC OSD INITIAL DATA SETTING DATA

A001 RF-AGC 0…63 UOC-TV RF-AGC 23 23

A002 V SLOPE 0…63 UOC-TV V SLOPE 35 35

A003 VER-SHI-F50 0…63 UOC-TV VER-SHI-F50 39 35

A004 VER-AMP-F50 0…63 UOC-TV VER-AMP-F50 35 31

A005 HOR-SHI-F50 0…63 UOC-TV HOR-SHI-F50 31 39

A006 EW-W-F50 0…63 UOC-TV EW-W-F50 11 28

A007 E/W-PAR-F50 0…63 UOC-TV E/W-PAR-F50 32 40

A008 H-PAR 0…63 UOC-TV H-PAR 30 30

A009 H-BOW 0…63 UOC-TV H-BOW 31 32

A010 UPCOR-PAR 0…63 UOC-TV UPCOR-PAR 40 43

A011 LOCOR-PAR 0…63 UOC-TV LOCOR-PAR 41 45

A012 E/W-TRAP 0…63 UOC-TV E/W-TRAP 32 26

A013 V-SCROLL 0…63 UOC-TV V-SCROLL 33 33

A014 VX-NORMAL 0…63 UOC-TV VX-NORMAL 25 25

A015 V-LIN 0…63 UOC-TV V-LIN 35 39

A016 S-COR 0…63 UOC-TV S-COR 32 32

A017 DRI-RS 0…63 UOC-TV DRI-RS 32 32

A018 DRI-GS 0…63 UOC-TV DRI-GS 32 32

A019 DRI-BS 0…63 UOC-TV DRI-BS 32 32

A020 CUT-RS 0…63 UOC-TV CUT-RS 32 32

A021 CUT-GS 0…63 UOC-TV CUT-GS 32 32

A022 SUB-BRI 0…63 UOC-TV SUB-BRI 34 34

A023 SUB-CON 0…63 UOC-TV SUB-CON 48 48

A024 SUB-COL 0…63 UOC-TV SUB-COL 10 26

A025 SUB-TINT 0…63 UOC-TV SUB-TINT 38 28

A026 SUB-SHARP 0…63 UOC-TV SUB-SHARP 32 32

A027 DRI-RS-DVD 0…63 UOC-TV DRI-RS-DVD 32 32

A028 DRI-GS-DVD 0…63 UOC-TV DRI-GS-DVD 32 32

A029 DRI-BS-DVD 0…63 UOC-TV DRI-BS-DVD 32 32

A030 CUT-RS-DVD 0…63 UOC-TV CUT-RS-DVD 32 32

A031 CUT-GS-DVD 0…63 UOC-TV CUT-GS-DVD 32 32

A032 SUB-BRI-DVD 0…63 UOC-TV SUB-BRI-DVD 35 35

A033 SUB-CON-DVD 0…63 UOC-TV SUB-CON-DVD 48 48

A034 SUB-TINT-DVD 0…63 UOC-TV SUB-TINT-DVD 32 32

A035 DRI-RC 0…63 UOC-TV DRI-RC 32 32

A036 DRI-GC 0…63 UOC-TV DRI-GC 32 32

A037 DRI-BC 0…63 UOC-TV DRI-BC 32 32

A038 CUT-RC 0…63 UOC-TV CUT-RC 32 32

A039 CUT-GC 0…63 UOC-TV CUT-GC 32 32

A040 DRI-RW 0…63 UOC-TV DRI-RW 32 32

A041 DRI-GW 0…63 UOC-TV DRI-GW 32 32

A042 DRI-BW 0…63 UOC-TV DRI-BW 32 32

A043 CUT-RW 0…63 UOC-TV CUT-RW 32 32

A044 CUT-GW 0…63 UOC-TV CUT-GW 32 32

A045 DRI-RC-DVD 0…63 UOC-TV DRI-RC-DVD 32 32

A046 DRI-GC-DVD 0…63 UOC-TV DRI-GC-DVD 32 32

A047 DRI-BC-DVD 0…63 UOC-TV DRI-BC-DVD 32 32

A048 CUT-RC-DVD 0…63 UOC-TV CUT-RC-DVD 32 32

A049 CUT-GC-DVD 0…63 UOC-TV CUT-GC-DVD 32 32

A050 DRI-RW-DVD 0…63 UOC-TV DRI-RW-DVD 32 32

A051 DRI-GW-DVD 0…63 UOC-TV DRI-GW-DVD 32 32

A052 DRI-BW-DVD 0…63 UOC-TV DRI-BW-DVD 32 32

A053 CUT-RW-DVD 0…63 UOC-TV CUT-RW-DVD 32 32

A054 CUT-GW-DVD 0…63 UOC-TV CUT-GW-DVD 32 32

A055 VER-SHI-N50 0…63 UOC-TV VER-SHI-N50 15 15

A056 VER-AMP-N50 0…63 UOC-TV VER-AMP-N50 28 28

A057 HOR-SHI-N50 0…63 UOC-TV HOR-SHI-N50 44 44

A058 EW-W-N50 0…63 UOC-TV EW-W-N50 29 29

29L-FG1L

3 – 6

ITEM EEPROM SETTING DATA RANGE IC OSD INITIAL DATA SETTING DATA

A059 E/W-PAR-N50 0…63 UOC-TV E/WPAR-N50 25 25

A060 VER-SHI-S50 0…63 UOC-TV VER-SHI-S50 13 13

A061 VER-AMP-S50 0…63 UOC-TV VER-AMP-S50 22 22

A062 HOR-SHI-S50 0…63 UOC-TV HOR-SHI-S50 44 44

A063 EW-W-S50 0…63 UOC-TV EW-W-S50 29 29

A064 E/W-PAR-S50 0…63 UOC-TV E/W-PAR-S50 22 22

A065 SUB-SCROLL-S 0…63 UOC-TV SUB-SCROLL-S 31 31

A066

SUB-VX-S50 0…63 UOC-TV SUB-VX-S50 43 43

A066

SUB-VX-S50-NIL 0 UOC-TV SUB-VX-S50-NIL 0 0

A067 VER-SHI-C50 0…63 UOC-TV VER-SHI-C50 14 14

A068 VER-AMP-C50 0…63 UOC-TV VER-AMP-C50 23 23

A069 HOR-SHI-C50 0…63 UOC-TV HOR-SHI-C50 44 44

A070 EW-W-C50 0…63 UOC-TV EW-W-C50 29 29

A071 E/W-PAR-C50 0…63 UOC-TV E/W-PAR-C50 22 22

A072 SUB-SCROLL-C 0…63 UOC-TV SUB-SCROLL-C 31 31

A073

SUB-VX-C50 0…63 UOC-TV SUB-VX-C50 49 49

A073

SUB-VX-C50-NIL 0 UOC-TV SUB-VX-C50-NIL 0 0

A074 VER-SHI-P50 0…63 UOC-TV VER-SHI-P50 39 35

A075 VER-AMP-P50 0…63 UOC-TV VER-AMP-P50 35 31

A076 HOR-SHI-P50 0…63 UOC-TV HOR-SHI-P50 31 39

A077 EW-W-P50 0…63 UOC-TV EW-W-P50 11 28

A078 E/W-PAR-P50 0…63 UOC-TV E/W-PAR-P50 32 40

A079 VX-43COMP-P50 0…63 UOC-TV VX-43COMP-P50 5 5

A080 VER-SHI-F60 0…63 UOC-TV VER-SHI-F60 36 34

A081 VER-AMP-F60 0…63 UOC-TV VER-AMP-F60 37 33

A082 HOR-SHI-F60 0…63 UOC-TV HOR-SHI-F60 37 46

A083 EW-W-F60 0…63 UOC-TV EW-W-F60 10 27

A084 E/W-PAR-F60 0…63 UOC-TV E/W-PAR-F60 34 41

A085 VER-SHI-N60 0…63 UOC-TV VER-SHI-N60 13 13

A086 VER-AMP-N60 0…63 UOC-TV VER-AMP-N60 29 29

A087 HOR-SHI-N60 0…63 UOC-TV HOR-SHI-N60 46 46

A088 EW-W-N60 0…63 UOC-TV EW-W-N60 29 29

A089 E/W-PAR-N60 0…63 UOC-TV E/W-PAR-N60 22 22

A090 VER-SHI-S60 0…63 UOC-TV VER-SHI-S60 12 12

A091 VER-AMP-S60 0…63 UOC-TV VER-AMP-S60 20 20

A092 HOR-SHI-S60 0…63 UOC-TV HOR-SHI-S60 52 52

A093 EW-W-S60 0…63 UOC-TV EW-W-S60 28 28

A094 E/W-PAR-S60 0…63 UOC-TV E/W-PAR-S60 22 22

A095

SUB-VX-S60 0…63 UOC-TV SUB-VX-S60 45 45

A095

SUB-VX-S60-NIL 0 UOC-TV SUB-VX-S60-NIL 0 0

A096 VER-SHI-C60 0…63 UOC-TV VER-SHI-C60 11 11

A097 VER-AMP-C60 0…63 UOC-TV VER-AMP-C60 20 20

A098 HOR-SHI-C60 0…63 UOC-TV HOR-SHI-C60 51 51

A099 EW-W-C60 0…63 UOC-TV EW-W-C60 29 29

A100 E/W-PAR-C60 0…63 UOC-TV E/W-PAR-C60 22 22

A101

SUB-VX-C60 0…63 UOC-TV SUB-VX-C60 51 51

A101

SUB-VX-C60-NIL 0 UOC-TV SUB-VX-C60-NIL 0 0

A102 VER-SHI-P60 0…63 UOC-TV VER-SHI-P60 36 34

A103 VER-AMP-P60 0…63 UOC-TV VER-AMP-P60 37 33

A104 HOR-SHI-P60 0…63 UOC-TV HOR-SHI-P60 37 46

A105 EW-W-P60 0…63 UOC-TV EW-W-P60 10 27

A106 E/W-PAR-P60 0…63 UOC-TV E/W-PAR-P60 30 41

A107 VX-43COMP-P60 0…63 UOC-TV VX-43COMP-P60 5 5

A108 VSD 0/1 UOC-TV VSD 0 0

A109 CUT OFF 0…63 UOC-TV CUT OFF 11 *1

A110 VG2 0/1 UOC-TV VG2 0 0

A111 DCXO 0…127 UOC-SSD DCXO 57 76

A112 DCXO-AUTO 0/1 UOC-SSD DCXO-AUTO 0 0

NOTE : (A---

) - Data for 29L-FG1MX ; (A---

) - Data for 29L-FG1L

SETTING DATA CUT OFF FOR DIFFERENT CRT

SETTING

DATA

LG CRT MTPD CRT

*1 A109 15 13

CUT OFF

ITEM

EEPROM

SETTING DATA

SETTING

29L-FG1L

3 – 7

Setting Mode 1 Items

ITEM IC

INITIAL DATA SETTING DATA

S001 UOC-TV

S002

UOC-TV 32 32

S003

UOC-TV 1 3

S004

UOC-TV 12 14

S005

UOC-TV 1 0

S006

UOC-TV 1 1

S007

UOC-TV 0 0

S008

UOC-TV 0 0

S009

UOC-TV 11 11

S010

UOC-TV 11 11

S011

UOC-TV 9 9

S012

UOC-TV 7 7

S013

UOC-TV 7 7

S014

UOC-TV 7 7

S015

UOC-TV 7 7

S016

UOC-TV 7 7

S017

UOC-TV 7 7

S018

UOC-TV 7 7

S019

UOC-TV 7 7

S020

UOC-TV 7 7

S021

UOC-TV 7 7

S022

UOC-TV 7 7

S023

UOC-TV 7 7

S024

UOC-TV 7 7

S025

UOC-TV 1 1

S026

UOC-TV 1 1

S027

UOC-TV 0 0

S028

UOC-TV 1 1

S029

UOC-TV 1 1

S030

UOC-TV 1 1

S031

UOC-TV 1 1

S031

UOC-TV 0 0

S032

UOC-TV 1 1

S033

UOC-TV 0 0

S034

UOC-TV 1 1

S035

UOC-TV 7 7

S036

UOC-TV 1 1

S037

UOC-TV 1 1

S038

UOC-TV 0 0

S039

UOC-TV 1 1

S040

UOC-TV 1 0

S041

UOC-TV 1 0

S042

UOC-TV 1 0

NOTE : (S031

) - Data for 29L-FG1MX ; (S031

) - Data for 29L-FG1L

WHITE LMT

0…15

WHITE LMT

0…63

IFPLL

0…3

SOC1-0

DATA RANGE

OSD

0…2

V-LINCTRL

EEPROM SETTING

V-LINCTRL

IFPLL

SOC1-0

0/1

AGC0-1

0…3

AGC0-1

FFI

0/1

FFI

CFA0

0/1

CFA0

YD PAL

0…15

YD PAL

YD SECAM

0…15

YD SECAM

YD N358

0…15

YD N358

YD N443

0…15

YD N443

YD AV-PAL

0…15

YD AV-PAL

YD AV-SECAM

0…15

YD AV-SECAM

YD AV-N358

0…15

YD AV-N358

YD AV-N443

0…15

YD AV-N443

YD SAV-PAL

0…15

YD SAV-PAL

YD SAV-SECAM

0…15

YD SAV-SECAM

YD SAV-N358

0…15

YD SAV-N358

YD SAV-N443

0…15

YD SAV-N443

YD COMP-PAL

0…15

YD COMP-PAL

YD COMP-SECAM

0…15

YD COMP-SECAM

YD COMP-N358

0…15

YD COMP-N358

YD COMP-N443

0…15

YD COMP-N443

SBO1-0

0…3

SBO1-0

CHSE1-0

0…3

CHSE1-0

FCO

0/1

FCO

OSO

0/1

OSO

DFL

0/1

DFL

EVG

0/1

EVG

HCO

0/1

HCO

SVMA

0/1

SVMA

HCO-NIL

FBC

0/1

FBC

SLG1-0

0…3

SLG1-0

CL3-0

0…15

CL3-0

GAM

0/1

GAM

TFR

0/1

TFR

CLD

0/1

CLD

BKS

0/1

BKS

BSD

0/1

BSD

AAS1-0

0…3

AAS1-0

DSK-NOT-PAL-AV

0/1

DSK-NOT-PAL-AV

Table des matières

Autres manuels Sharp TV

Sharp

Sharp 33ML400 Manuel utilisateur

Sharp

Sharp 2T-C40AE1X Manuel utilisateur

Sharp

Sharp 27R-S100 Manuel utilisateur

Sharp

Sharp AQUOS LC-22DV27U Manuel utilisateur

Sharp

Sharp Aquos LC-20S1M Manuel utilisateur

Sharp

Sharp LC-32CFG6241KF Manuel utilisateur

Sharp

Sharp 27U-S650 Manuel utilisateur

Sharp

Sharp LC-40FI6522KF Manuel utilisateur

Sharp

Sharp AQUOS LC-32LE700UN Manuel utilisateur

Sharp

Sharp Aquos LC-60LE751K Manuel utilisateur

Sharp

Sharp LC-32WD1E/S/RU Manuel utilisateur

Sharp

Sharp 21HS-50H Manuel utilisateur

Sharp

Sharp 21M-FG1L Manuel utilisateur

Sharp

Sharp 19R-M100S Manuel utilisateur

Sharp

Sharp LC-70LE735M Manuel utilisateur

Sharp

Sharp LC-65UI7252K Manuel utilisateur

Sharp

Sharp 20BM2-GMK2 Manuel utilisateur

Sharp

Sharp 28JW-74H Manuel utilisateur

Sharp

Sharp 37EM-33S Manuel utilisateur

Sharp

Sharp 54GS-61S Manuel utilisateur

Sharp

Sharp 29K-FD5RU Manuel utilisateur

Sharp

Sharp 28LF-96EC Manuel utilisateur

Sharp

Sharp 20AG1-SS Manuel utilisateur

Sharp

Sharp R771M-006 Manuel utilisateur

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur
