Sharp XL-1500H Manuel utilisateur

– 1 –

XL-1500H

COMPACT AUDIO SYSTEM

If you require any advice or assistance

regarding your Sharp product, please

visit our web-site www.sharp.co.uk/

support.

Customers without internet access may

telephone 08705 274277 during office

hours (or (01) 676 0648 if telephoning

from Ireland).

This Quick Guide will help you to correctly

install and operate your system.

TINSE0093SJZZ A0112.TO

Accessories

AM loop aerial × 1AC power lead × 1 Remote control × 1

123

Battery installation of remote control

Use 2 “AAA” size batteries (UM-4, R03, HP-16 or similar).

Batteries are not included.

Remove the Insert the batteries Replace the cover.

battery cover. as shown.

FM aerial × 1Speaker wire × 2

XL1500_QG 01.12.17, 2:20 PM1

–2 –

System Connections

Right speaker

Left

speaker

Connection cable

for digital recording

(not supplied)

MD recorder

To the optical line

input socket

Wall socket

(AC 230 V, 50 Hz)

To the line

output sockets

RCA lead

(not supplied)

FM aerial

AM loop aerial VCR, DVD, etc.

Right speaker Left speaker

Black

White line

Headphones

XL1500_QG 01.12.17, 2:20 PM2

–3 –

Press the ON/STAND-BY button to turn the power on.

Turn on your System

Listening to a CD

1Press the FUNCTION button until “CD STOP”appears on

the display.

2Press the 77

7OPEN/CLOSE button to open the CD com-

partment.

3Place a CD on the spindle, label side up.

4Press the 77

7OPEN/CLOSE

button to close the CD com-

partment.

The CD playback will start automatically.

XL1500_QG 01.12.17, 2:20 PM3

–4 –

FM stereo mode indicator

FM stereo receiving indicator

■If trouble occurs

When this product is subjected to strong external interference (mechanical shock, excessive static

electricity, abnormal supply voltage due to lightning, etc.) or if it is operated incorrectly, it may mal-

function.

If such a problem occurs, do the following:

1. Set the unit to the stand-by mode and turn the power

on again.

2. If the unit is not restored in step 1, unplug and plug in

the unit, and then turn the power on.

3. If neither step 1 nor 2 restores the unit, do the following:

1 Press the ON/STAND-BY button to enter the power

stand-by mode.

2 Unplug the AC power lead from the AC INPUT socket

on the unit.

3 Whilst pressing down the MEMORY/SET button and the

0606

06 button, plug the AC power lead into the AC INPUT

socket on the unit.

■Maintenance

Do not touch the laser pickup lens. If fingerprints or dust accu-

mulate on the pickup, clean it gently with a dry cotton swab.

AC INPUT

Listening to the Radio

1Press the FUNCTION button until “FM”or “AM”appears

on the display.

2Press the TUNING (XX

Xor WW

W) button to tune in to the de-

sired station.

When the TUNING button is pressed for more than 0.5 seconds, scan-

ning will start automatically and the tuner will stop at the first receivable

broadcast station.

3To receive an FM stereo

transmission:

Press the FUNCTION but-

ton to display the “ST”in-

dicator.

●“j”will appear when an

FM broadcast is in stereo.

XL1500_QG 01.12.17, 2:20 PM4
