Sharp DK-UH2 Manuel utilisateur

Locking tab

Back of remote control

USB STEREO SPEAKER

Accessories

Remote control x 1 AC/DC adaptor x 1

RADPAA039AWZZ (DK-UH2)

RADPAA036AWZZ (DK-UH2(BK))

AC power lead x 1 USB cable x 1

Before using remote control

Before using remote control, please remove plastic shield

at battery holder.

Remote control battery installation

1Whilst pushing the locking tab towards the centre of

the remote control, slide out the battery holder.

2Remove the old battery from the battery holder, insert

the new battery and then slide the battery holder back

into the remote control.

Use the “CR 2025”, coin lithium battery.

Power source

HUsing with the AC/DC adaptor

1Plug the AC power lead into the AC/DC adaptor.

2Plug the AC/DC adaptor cable into the DC Input socket

on the unit.

3Plug the AC power lead and switch on the power

supply. The display indicator lights up when the AC

power is applied. The POWER indicator will turn BLUE

when the system is “ON”.

Battery holder

Locking tab

Positive (+)

side up

Polarity (+)

symbol

Battery type

DCIN6V

AUXIN

DC IN 6V

AUX IN

AC/DC adaptor cable

DC INPUT socket

(DC 6V)

AC power lead

AC/DC adaptor

Wall socket

(AC 100 - 240 V ~ 50/60 Hz)

Battery holder

Plastic shield

Remote control

DK-UH2 QG 8/20/07, 3:59 PM1

TINSEA209AWZZ

07H R KI 1

DK-UH2

This quick Start Guide will help you to correctly install and operate your system.

Illustrations printed in this quick guide are for the model DK-UH2.

MODEL

USB

Listening to USB mass storage

device/MP3 player

Turn on your system

The first time the unit is plugged in, the unit will enter the

demonstration mode. You will see words scroll.

1Press the E SOUND/DEMO button to cancel the

demonstration mode.

2Press the ON/STAND-BY button to turn the power

on. The POWER indicator lights up.

FUNCTION

CLOCK

SLEEP TIMER

SNOOZE/

DIMMER

VOL

MEMORY DISPLAY

PLAY

MODE

E SOUND

/DEMO

FOLDER

DK-UH2

SNOOZE/DIMMER

ON/ST

AND-BY

VOL

CLOCK

OUND/DEMO

FUNCTION

CLOCK

SLEEPTIMER

SNOOZE/

DIMMER

VOL

MEMORY DISPLAY

PLAY

MODE

E SOUND

/DEMO

FOLDER

USB

To remove USB memory device

1Press the 77

7button on the main unit or remote control.

Wait until “UNPLUG OK” appears on FL display.

2Disconnect USB memory device from the USB

terminal.

HIf trouble occurs

When this product is subjected to strong external interference

(mechanical shock, excessive static electricity, abnormal supply

voltage due to lightning, etc.) or if it is operated incorrectly, it

may malfunction.

If such a problem occurs, do the following:

1. Set the unit to the power stand-by mode and turn the

power on again.

2. If the unit is not restored in the previous operation,

unplug and plug in the unit, and then turn the power

on.

Note:

If neither operation above restores the unit, clear all the memory

by resetting it.

HFactory reset, clearing all memory

1. Press the ON/STAND-BY button to enter the power

stand-by mode.

2. Whilst pressing down the E SOUND/DEMO button and

the ON/STAND-BY button, press the 33

388

8button until

“CLEAR ALL” appears.

Caution:

This operation will erase all data stored in memory including

clock and timer settings.

HMaintenance

Routine maintenance is required for continued optimum

performance, refer to the operation manual.

1Press the FUNCTION button at remote control.

Connect the USB memory device that has MP3/WMA

format files on the unit.

2Press the FOLDER button, and press the ∞∞

∞∞

∞or 55

button to select desired playback folder. (Folder mode

on)

3Select desired file to be played back by pressing the

4or ¢¢

¢¢

¢button. Proceed to step 5.

4Select desired file to be played back by pressing the

4or ¢¢

¢¢

¢button. (Folder mode off)

5Press the 33

3/ 88

8button. Playback will start and the track

number and time counter will be displayed.

Notes:

•This product is not compatible with MTP and AAC file

systems.

•Do not connect the audio cable to AUX IN socket during

USB playback. Otherwise, it will enter the AUX function

automatically.

DK-UH2 QG 8/20/07, 3:59 PM2
