Sharp SJ-C20 SL Series Manuel utilisateur

SERVICE MANUAL

This document has been published to be used for

after sales service only.

The contents are subject to change without notice.

CHAPTER 1. SPECIFICATION

CHAPTER 2. DESIGNATION OF VARIOUS PARTS

[1] EXTERNAL DESCRIPTION........................... 2-1

2-2...............................SNOITCURTSNOC]2[ .........

CHAPTER 3. DIMENTIONS

[1] OUTER DIMENTIONS AND

3-1........................................ECNARAELC .........

[2] INNER DIMENTIONS .................................... 3-2

CHAPTER 4. LIST OF ELECTORICAL PARTS

CHAPTER 5. WIRING DIAGRAM

[1] WIRING DIAGRAM ........................................ 5-1

[2] ELECTRIC ACCESSORIES LAYOUT ........... 5-2

CHAPTER 6. FAILURE DIAGNOSIS

[1] OUTLINE OF CONTROL ............................... 6-1

[2] CHECK MODE OF DEFROST HEATER

(Forced Defrosting) ........................................ 6-1

[3] RE-SETTING OF MICROCOMPUTER AT

POWER FAILURE.......................................... 6-1

[4] DIAGNOSIS METHOD OF FAILURE ............6-2

[5] CONVERSION TABLE ..................................6-3

[6] CIRCUIT DIAGRAM OF MAIN PWB .............6-4

CHAPTER 7. FUNCTIONS

[1] ADJUSTABLE TEMPERATURE

CONTROL .....................................................7-1

CHAPTER 8. ASSEMBLI NG PROCEDURES OF

MAIN PARTS AND CAUTIONS

[2] R CONTROL COV. ASS'Y.............................8-4

[3] HOW TO REPLACE THE LAMP ...................8-6

[4] DEFROST HEATER ......................................8-7

CHAPTER 9. COOLING UNIT

[1] COOLING UNIT.............................................9-1

[2] LOCATION ....................................................9-2

Parts Guide

CONTENTS

SJ-C19SS/C20XX

No.S1042SJ17GHZTT

Refrigerator-freezer

MODELS

SJ-C19SS-SL/SLG/GR/BL

SJ-C20XX-SL

Refer to "HFC-134a COOLING UNIT" Service Manual for handling this refrigerant.

Refrigerant; HFC-134a

DESTINATION.........T

[1] F-LOUVER ASS'Y .........................................8-1

[3] PRECAUTIONS FORUSING LEAD-FREE

SOLDER......................................................... 5-3

SJ-C20XX SJ-C19SS

1 – 1

CHAPTER 1. SPECIFICATION

RATING

Outer dimensions Height

Depth

Rate gross volume Total

Freezer

Refrigerator

Defrosting System

Start

Finish

Freezer Compartment F-shelf

Ice cube tray

Ice storage box

Door pocket

Refrigerator Compartment Fresh case

RV-glass shelf ass’y

Vegetable case

Egg pocket

Bottle pocket

Door pocket

Automatic (Adjustable)

Yes

1 (LED)

2-Door

Heater system

Automatic

Items

Type

No-frost freezer

Interior lamp

Evaporating pan

Temperature control

SJ-C19SS

Rated voltage (V~)

Rated frequency (Hz)

Climate class

Rated power input (W)

Rated current (A)

Rated input of heating system (W)

Defrosting input (W)

Net Weight (kg)

Items

Refrigerant (Charging quantity) [Non-flammable]

101

0.85

121

HFC-134a(70 g)

220

Insulation blowing gas [Flammable]

Cyclo pentane (HC)

Deodorizer unit 1 (Honeycomb type)

1365mm(53.7")

535mm(21.1 )

560mm(22.0")

167liter(5.9cu.ft)

36liter(1.3cu.ft)

131liter(4.6cu.ft)

Width

RV shelf

SJ-C20XX

SJ-C19SS SJ-C20XX

COLOR

Items -SL

Outside color Silver

Inside color White

PLUG TYPE

Plug cord 2 pin

Plug type -

Destination mark T

-BL

Blue

-SIL

Silver

-GR

Green

SJ-C19SS/C20XX

2 – 1

.TSILSTRAPTNEMECALPERehtnidesusnoitanimonedehtera"]["sisehtnerapnisemanehT

SJ-C20XX

1. Freezer shelf [ F-shelf ]

2. Ice cube tray

3. Ice cube box [ Ice storage box ]

4. Freezer temp.control knob

5. Fresh room

6. Express ice making button

7. LED Light [ Lamp ]

8. Refrigerator temp.control knob

9. Refrigerator shelf

[ RV glass shelf ass’y SJ-C20XX ; 2 pcs.

RV shelf SJ-C19SS ; 2 pcs. ]

11. Vegetable crisper [ Vegetable case ]

12. Stand

13. Magnetic door seal [ Door packing ]

14. Door pocket

15. Egg pocket

16. Light switch

17. Bottle pocket

CHAPTER 2. DESIGNATION OF VARIOUS PARTS

[1] EXTERNAL DESCRIPTION

10. Vegetable shelf

[ RV glass shelf ass’y SJ-C20XX

RV shelf SJ-C19SS ]

SJ-C19SS/C20XX

Fan motor

Def-thermistor

F-temp. control knob

R-temp. control knob

Evaporator

Defrost heater

Deodorizing unit

R-thermistor

PWB L ass'y

LED Lamp

Compressor

Starting relay

Protector

Evaporating pan

Mark : Cold air flow

Fuse ass'y

[2] CONSTRUCTION

Stand

2 - 2

LED PWB

Running capacitor

SJ-C19SS/C20XX

3 – 1

[1] OUTER DIMENTIONS AND CLEARANCE

1. SJ-C20XX

2. SJ-C19SS

(Unit:mm)

560

1032

535

1092

362

957

535

395

823

1365

6060

130

(Unit:mm)

1032

535

1092

362

957

535

395

823

1365

130

560

615

CHAPTER 3. DIMENTIONS

SJ-C19SS/C20XX

3 – 2

[2] INNER DIMENTIONS

(Unit:mm)

380

360

260

375 45

415

105

170

395

370

175

400

390

115

175

200

100

190

100

115

225

380

220

395 225

190 144 81

1. SJ-C20XX

2. SJ-C19SS

(Unit:mm)

380

360

260

375 45

415

105

170

395

370

175

400

390

115

175

200

100

190

100

115

225

380

220

395 225

190 144 81

SJ-C19SS/C20XX

4 – 1

Common

Aux. coil Main coil

ITEMS TYPE NAME RATING SPECIFICATIONS

R Thermistor

Defrost Thermistor

―

DC 5V

R0 = 6.4 k , B(0) = 3811

Thermo. fuse 12Y

Defrost heater ―220 - 240V 392 135W at 230V

Fan motor 3R00121 AC 200-240V,50Hz

Door switch SDKNA20101 250V 0.25A

125V 0.5 A

3 Terminals push-botton type

Compressor C-BZN100L5L 220-240V/50Hz Cooling capacity : 106 W (50Hz)

Main coil : 23.1

Aux. coil : 28.9

(at 75 °C)

Starting Relay PTH7M220 50/60 Hz 22 ± 4.4 (at 25 °C)

Overload

Relay(Protector) 4TM-189RHBYY-53 Open/ Close : 130 ± 5.0 / 61 ± 9.0°C

Main PWB FPWB-A706CBKZ 220-

240V ―

PXN-36D

250V 2A Working temp. : 76 °C

LED PWB FPWB-A709CBKZ 12V DC Maximum 100 mA , White LED

CHAPTER 4. LIST OF ELECTRICAL PARTS

Running Capacitor RC-EZA249CBZZ 400V 4 F

―

250V 20A

5 – 1

CHAPTER 5. WIRING DIAGRAM

[1] WIRING DIAGRAM

Be sure to replace the electrical parts with specified ones for maintaining the safety and performance of the set.

* Note : R-th assembly on LED PWB

SJ-C19SS/C20XX

5 – 2

[2] ELECTRIC ACCESSORIES LAYOUT

SJ-C19SS/C20XX

1. Employing lead-free solder

The PWB of this model employs lead-free solder. This is indicated by the "LF" symbol printed on the PWB and in the service manual. The suffix letter

indicates the alloy type of the solder.

Example:

2. Using lead-free wire solder

When repairing a PWB with the "LF" symbol, only lead-free solder should be used. (Using normal tin/lead alloy solder may result in cold soldered

joints and damage to printed patterns.)

As the melting point of lead-free solder is approximately 40°C higher than tin/lead alloy solder, it is recommend that a dedicated bit is used, and that

the iron temperature is adjusted accordingly.

3. Soldering

As the melting point of lead-free solder (Sn-Ag-Cu) is higher and has poorer wettability, (flow), to prevent damage to the land of the PWB, extreme

care should be taken not to leave the bit in contact with the PWB for an extended period of time. Remove the bit as soon as a good flow is achieved.

The high content of tin in lead free solder will cause premature corrosion of the bit. To reduce wear on the bit, reduce the temperature or turn off the

iron when it is not required.

Leaving different types of solder on the bit will cause conta

mination of the different alloys, which will alter their characteristics, making good soldering

more difficult. It will be necessary to clean and replace bits more often when using lead-free solder. To reduce bit wear, care should be taken to clean

the bit thoroughly after each use.

Indicates lead-free solder of tin, silver and copper

[3] PRECAUTIONS FOR USING LEAD-FREE SOLDER

5 - 3

SJ-C19SS/C20XX
