PN-CD701 Dismantle Instruction

Dismantle Instruction

LCD MONITOR

MODEL

PN-CD701

PN-CD701 Dismantle Instruction



Table of contents


Scope.................................................................................................................. 3
Tools for dismantling............................................................................................... 3
Dismantle Procedure .............................................................................................. 3
Back covers .......................................................................................................... 4
Printed circuit boards ............................................................................................. 5
Battery................................................................................................................ 6
LCD Module .......................................................................................................... 7
Capacitors............................................................................................................ 8
Parts List ............................................................................................................. 9




PN-CD701 Dismantle Instruction

1. Scope

This document describes dismantling instruction according to Annex VII of Directive 2012/19/EU.

2. Tools for dismantling

Below tools are required to dismantle this product.

- Screw Driver

- Nipper

3. Dismantle Procedure

This product can be dismantled by below steps.

1. Remove Back covers (section 4)

2. Remove the shielding.

3. Remove Printed circuit boards (section 5)

4. Remove Battery (section 6)

5. Dismantle LCD (section 7)

6. Remove Electrolyte Capacitors (section 8)

PN-CD701 Dismantle Instruction

4. Back covers

2 back covers (right/left) can be removed by screw driver.

PN-CD701 Dismantle Instruction

5. Printed circuit boards

All PWBs can be removed by screw driver.

Power PWB (1pcs) LED Driver PWB (1pcs) Pre scaler PWB (1pcs)

Scaler PWB (1pcs) T-CON PWB (1pcs) Side IO PWB (1pcs)

SOC PWB (1pcs) Audio PWB (1pcs) Top IO PWB (1pcs)

Service port PWB (1pcs) Touch DBE PWB (1pcs) Touch AFE PWB (1pcs)

PN-CD701 Dismantle Instruction

Front USB PWB (1pcs) Wi-Fi module PWB (1pcs) Source LED PWB (4pcs)

Win button + mic-array PWB (1pcs) Key PWB (1pcs)

6. Battery

This model uses only CR2032 Lithium Coin battery on Pre scaler PWB.

Battery CR2032 can easily be removed from the battery holder.

PN-CD701 Dismantle Instruction

7. LCD Module

- LCD Dismantle procedure

Due to direct bonding technology the front glass cannot be removed from the LCD.

After you have removed the PWB´s please take out the cables from the LCD module.

LCD

PN-CD701 Dismantle Instruction

8. Capacitors

Electrolyte Capacitors which diameter/height is larger than 25mm is installed on Power PWB.

These capacitors can be removed by using nipper to cut the leads.

PN-CD701 Dismantle Instruction

9. Parts List

Parts described in Annex VII of directive 2012/19/EU are as below.

Parts

Note

LCD

70inch LCD module

Printed Circuit Boards

Power PWB

LED driver PWB

Pre scaler PWB

Scaler PWB

T-CON PWB

Side IO PWB

SOC PWB

Audio PWB

Top IO PWB

Service port PWB

Touch DBE PWB

Touch AFE PWB

Front USB PWB

Wi-Fi module PWB

Source LED PWB

Win button + mic-array PWB

Key PWB

Battery

Lithium Coin Battery CR2032

Electrolyte capacitors

(height >25mm, diameter >25mm)

On Power PWB

External electric cables

2 kinds of Power Cord

- CEE 7 (for EU)

- Type-BF (for UK)
