Sharp BIG PAD PN-65HC1 Guide de l'utilisateur

４K BIG PAD

Application Guide

【Wireless Casting】

Product：

PN-65HC1

PN-75HC1

PN-86HC1

PN-70HC1E

First edition published

March 2021

Introduction

【About EShare】

The screen can be shared and displayed mutually between the BIG PAD and the device.

The BIG PAD and the device to be connected must be connected to the same network.

*Connection to all devices is not guaranteed. *A router or access point is required.

【Main Features】

Feature About supported

devices

Share Screen Share the client device screen to the BIG PAD.

Android devices are not supported for Audio transmission.

Touchback is only available on Windows and macOS devices.

All devices

Mirroring Mirror the BIG PAD to the client device.

(External input and media player screens cannot be shared.

All devices

File sharing Share audio, video and photo file from smart devices to BIG

PAD.

Smart

devices

Wireless camera

and microphone

Share the images or audio from phone camera or

microphone to the BIG PAD in real time.

Smart

devices

Multiple screens Share multiple device screens to BIG PAD at the same time,

and the screen of BIG PAD will be split automatically. (Max.

4 screens)

All devices

Display group Users can share their screen from 1 client device to multiple

BIG PAD wirelessly.

All devices

device type OS supported version

PC Windows Windows 8.1/10

macOS macOS v10.15/v11.0

Smart device

(Smartphone,

tablet PC)

Android Android 8/9/10

iOS/iPadOS iOS 13/14

iPadOS 13/14

【Supported devices】

*The supported versions of each OS are displayed on the EShare download page in the BIG PAD that

appears in step 4 on p.3-5, but please use the version listed in the table. The download page will be

updated in the future update.

*The download page for the client app shows a link for Chrome OS, but it is not supported.

Preparation (BIG PAD)

【BIG PAD】

5. Enable “Wireless LAN” and connect to the access

point.

(1)Windows … p.3

(2)macOS … p.4

(3)Android … p.5

(4)iOS/iPadOS … p.5

■How to set up each device

4. Select “Network”.

Press the INPUT button on the remote control

or the bottom of the BIG PAD to change the

input mode to APPLICATION and display the

home screen.

Make preparations for network connection and

application installation on each device.

■How to use each device

For detail on how to share the screen on each

device, please refer to the following page.

(1)Windows … p.6

(2)macOS … p.7

(3)Android … p.8

(4)iOS/iPadOS … p.9

First, connect to a wireless network.

1. Connect the supplied wireless adapter to the

USB port on the rear panel as shown below.

2. On the BIG PAD, select “Apps” on home screen

in APPLICATION mode.

3.Select “Settings”.

Preparation (Windows)

1. On the BIG PAD, select “Apps” on home screen

in APPLICATION mode.

2.Select “EShareServer”.

【Windows PC】

５.Follow the instructions in the installer to install

EShare.

Connect to an access point on the same network as the BIG PAD

４.Select “EShare for Windows” on the PC.

■Install “EShare for SH”. (First time only)

３.Access the address displayed on the

screen of the BIG PAD from your PC.

■Configure the wireless LAN connection settings of the

PC (The following screens are on windows 10 1903)

Turn on the wireless LAN

Preparation (macOS)

1. On the BIG PAD, select “Apps” on home

screen in APPLICATION mode.

2.Select “EShareServer”.

【macOS PC】

５. Follow the instructions in the installer to install

EShare.

４.Select “EShare for macOS” on the PC.

■Install “EShare for SH”. (First time only)

３. Access the address displayed on the screen of

the BIG PAD from your PC.

■Configure the wireless LAN connection settings of

the PC (The following screens are on macOS v10.15)

■Touch back

To enable the function of receiving touches to the

BIG PAD as touches to the device while the device is

transmitting the screen, you need to change the

setting.

1. Click “System Preferences”.

2. Select “Security & Privacy”.

3. Select “Privacy”,

Select “Accessibility”,

Click on the lock icon in the lower left corner.

4. Input the user name and the password.

5. Click “EShare for SH” check box.

Turn on the wireless LAN

Connect to an access point on the same network as the BIG

PAD

Preparation (Android/iOS,iPadOS)

【iOS/iPadOS device】

４. Select “EShare for Android” on the android device.

2. Select “EShareServer”.

1. On the BIG PAD, select “Apps” on home

screen in APPLICATION mode.

■Install “EShare for SH”. (First time only)

5. Download and install the app.

３. Access the address displayed on the screen of

the BIG PAD from your device.

【Android device】

■Configure the wireless LAN connection settings

of the device

(The following screens are on Android 9) ■Configure the wireless LAN connection settings

of the device

(The following screens are on iOS/iPadOS 14)

Connect to an access point on the same network as the BIG PAD

1. On the BIG PAD, select “Apps” on home

screen in APPLICATION mode.

■Install “EShare for SH”. (First time only)

Connect to an access point on the same network as the BIG PAD

2. Select “EShareServer”.

３. Access the address displayed on the screen of

the BIG PAD from your device.

４. Select “EShare for iOS” on the iOS/iPadOS device

(connect to an external site).

5. Download and install the app.

*To wirelessly connect the iOS/iPadOS device to the

BIG PAD, you will need to connect to the internet for

the first time.

Press and hold to open Wi-Fi setting screen

【Windows PC】

■Operate “EShare for SH” on the Windows PC

1.Click “Eshare for SH”

3. To display the screen of your PC on the BIG PAD,

select “Share Screen”.

Select “Stop Sharing” to stop screen sharing.

４.To display the BIG PAD screen on your PC, select

“Screen Mirror”.

The BIG PAD screen will

appear on your PC.

Click the “×” in the upper right corner of the

windows to stop screen mirroring.

Wireless Connection (Windows)

2.Select the BIG PAD you want to send and receive

screen from the device list.

【macOS PC】

1.Click “Eshare for SH”

2.Select the BIG PAD you want to send and receive

screen from the device list.

Wireless Connection (macOS)

■When the following message is displayed, please refer

to page 4 to enable touchback.

If you do not want to use touchback, you do not need

to enable it.

■Operate “EShare for SH” on the macOS PC

3. To display the screen of your PC on the BIG PAD,

select “Share Screen”.

Select “Stop Sharing” to stop screen sharing.

４.To display the BIG PAD screen on your PC, select

“Screen Mirror”.

The BIG PAD screen will

appear on your PC.

Click the red “●”in the upper left corner of the

EShare window to stop screen mirroring.

1.Open Application list, tap “EShare for SH”

【Android device】

2. If a message appears asking for permission, follow

the on-screen instructions to allow it.

■Operate “EShare for SH” on the Android device

To stop screen sharing, slide the top of

your Android device down to show the

notification list, and select Share

Screen(toggle switch).

Click the “×” in the upper left

corner to stop mirroring.

【received image】

Wireless Connection (Android)

5. If you want to use the wireless camera/microphone

function, select “Camera”.

microphone ON/OFF

mobile light ON/OFF

switch between

in/out camera

shutter button

Press the shutter button to take a still image, which will remain

on the BIG PAD screen. The captured still image will be saved

as an image file on the device.

6. If you want to use the file sharing function, select

the file you want to share from within the screen.

The remote control will appear on the screen during

file sharing.

quit camera function

Image Music Video

3. To display the screen of your device on the BIG

PAD, select “TV Mirror”.

４.To display the BIG PAD screen on your device,

select “Share Screen”.

【iOS/iPadOS device】

■Operate “EShare for SH” on the iOS/iPadOS device

1. Tap “EShare fo SH”.

3. To display the screen of your device on the BIG

PAD, select “Share Screen”.

5.To display the BIG PAD screen on your device,

select “TV Mirror”.

4. Select "Start Broadcast" to start sending after 3

counts. Press the home button to switch the application

and display the content you want to send.

If there is a red line at the top of the screen, EShare is

running.

To stop the screen

transmission, select

the red line on the

screen and select

"OK" to stop the

screen broadcast.

【Receiving image】

◎③②①●

Wireless Connection (iOS/iPadOS)

6. If you want to use the wireless camera/microphone

function, select “Camera”.

7. If you want to use the file sharing function, select

“Photo” or “Music/Video”.

2.Select the BIG PAD you want to send and receive

screen from the device list.

Click the “×” in the

upper left corner to

stop screen mirroring.

microphone ON/OFF

mobile light ON/OFF

switch between in/out camera

shutter button

quit camera function

The remote control will appear on the screen during

file sharing.

Press the shutter button to take a still

image, which will remain on the BIG PAD

screen. The captured still image will be

saved as an image file on the device.

Photo Music Video
