Sharp Aquos Manuel utilisateur

<< Contents

1. Part Names

1-1. TV (For PN-LE601/701/801 models)

1-2. TV (For PN-LE901 model)

1-3. Remote Control Unit

2. Introduction

2-1. Displaying an External Equipment Image

2-2. Initial Installation

3. Direct Button Operation

3-1. Changing Channels

3-2. Changing Volume

3-3. MUTE

3-4. APPS

3-5. AUDIO

3-6. Sleep Timer

4. On-Screen Display Menu

4-1. Introduction

4-3. On-Screen Display Menu Operation

4-4. Menu Operation Buttons

4-5. Initial Setup

4-13. Information

4-16. Picture Settings

4-20. Audio Settings

4-21. Network Settings

4-23. System Options

5. Enjoying Photo/Music/Video Playback

5-1. Preparation

5-2. Selecting the Folders to Play Back

5-4. Playing Back Files on a USB Memory Device/Home

Network Server

6. Using LINK Operation

6-1. Controlling HDMI Equipment Using LINK Operation

6-3. Link Operation Menu

6-5. Using a Smartphone with the TV

7. Using a PC

7-1. Adjusting the PC Image

7-2. Setting Audio Input

7-3. Control of the TV

7-9. PC Compatibility Chart

8. Using the Internet

8-1. Connecting to the Internet

8-2. Entering Text (Software Keyboard)

8-4. Using the Browser

8-8. Using Keyboard and Mouse

9. Using the Miracast devices

9-1. Miracast devices

10. Appendix

10-1. Removing the Stand

10-2. Setting the TV on the Wall

10-6. Troubleshooting

11. Specifications

11-1. TV (For PN-LE901 model)

11-2. TV (For PN-LE801/701/601 models)

11-3. Wireless LAN

12. Trademarks

13. Dimensional Drawings

14. Software License

ENG Contents

ENG Important1

ENG Important2

ENG Important3

ENG Important4

<< Part Names

TV (For PN-LE601/701/801 models)

(Front)

See page 4-17.

See page 4-27.

(Side)

See pages 2-1 and 4-4 for button operations.

(Rear)

*1 See the Setup Guide.

And see page 6-1 for external equipment connection.

See page 7-2. for details on the Audio Select function.

See page 6-2. for details on the Audio Return Channel.

See page 6-5. for details on the MHL function.

See page 4-12. for details on the Input Select function.

The illustrations and on-screen displays in this operation manual are for explanation purposes

and may vary slightly from the actual operations.

The examples used throughout this manual are based on the PN-LE601 model.

ENG 1-1

<< Part Names

TV (For PN-LE901 model)

(Front)

See page 4-17.

See page 4-27.

(Side)

See pages 2-1 and 4-4 for button operations.

(Rear)

*1 See the Setup Guide.

And see page 6-1 for external equipment connection.

See page 7-2 for details on the Audio Select function.

See page 6-2. for details on the Audio Return Channel.

See page 6-5. for details on the MHL function.

See page 4-12 for details on the Input Select function.

The illustrations and on-screen displays in this operation manual are for explanation purposes

and may vary slightly from the actual operations.

ENG 1-2

<< Part Names

Remote Control Unit

POWER: Switch the TV power on or enter standby.

DISPLAY: Display the channel information.

SLEEP: Set the sleep timer

(See page 3-6.)

4 0

–9: Set the channel.

(See pages 3-1.)

5 •

(DOT): Set the channel.

(See pages 3-1.)

6 OPTION:

Display the Link Operation Menu screen. This button will function only when LINK

Operation is used.

(See page 6-1 to 6-15.)

VOL+/-: Set the volume.

(See page 3-2.)

AUDIO: Select the MTS/SAP or the audio mode during multichannel audio broadcast.

(See page 3-5.)

MUTE:Mute the sound.

(See page 3-3.)

/ / / , (ENTER): Select a desired item on the screen.

EXIT: Turn off the menu screen.

A/B/C/D: Select 4 preset favorite channels in 4 different categories.

(See page 4-6.)

MANUAL: Display the operation manual.

(See page 4-15.)

APPS: Display the application window.

(See page 8-4.)

INPUT: Select a TV input source.

(See page 2-1.)

CH: Select the channel.

(See page 3-1.)

MENU: Display the menu screen.

(See page 4-1.)

RETURN: Return to previous menu screen.

ENG 1-3

NOTE

When using the remote control unit,

point it at the TV.

<< Introduction

Example 1Press INPUT.

The INPUT list screen displays.

2Press / to select the input source.

An image from the selected source

automatically displays.

Displaying an External Equipment Image

To view external source images, select the input source by pressing

INPUT on the remote control

unit or on the TV.

ENG 2-1

You can also select the input source by pressing INPUT.

Each time INPUT is pressed, the input source toggles.
