Sharp E630U Manuel utilisateur
1
VL-E630U/T
VL-E680U
VL-E685U/T
In the interests of user-safety (Required by safety regula-
tions in some countries) the set should be restored to its
originalconditionandonlypartsidenticaltothosespecified
be used.
Page
2. SPECIFICATIONS .............................................................................................................................. 2
4. DISASSEMBLY OF THE SET............................................................................................................. 3
5. MECHANISM ADJUSTMENT ............................................................................................................. 4
6. ADJUSTMENT OF VCR...................................................................................................................... 5
8. SCHEMATIC DIAGRAMS .................................................................................................................. 8
11.REPLACEMENT PARTS LIST.......................................................................................................... 29
12.PACKING OF THE SET .................................................................................................................... 35
SY8A5VL-E630U
CONTENTS
MODELS
SERVICE MANUAL
LIQUID CRYSTAL CAMCORDER 8 NTSC
VL-E630U/T
VL-E680U
VL-E685U/T
In this Service Manual, only the differences from VL-E610U/660U/665U
(S28L7VL-E610U) are described.
Therefore, for the parts which are not described in this Service Manual, refer
to the Service Manual for VL-E610U/660U/665U (S28L7VL-E610U) and its
supplement version (S38N9VL-E610U).
This document has been published to be used for
after sales service only.
Thecontentsaresubjecttochangewithoutnotice.
SHARP CORPORATION
VL-E630U/T
VL-E680U
VL-E685U/T
8
8MODELS VL-E630U/T/E680U/E685U/TLIQUID CRYSTAL CAMCORDER NTSC
SERVICE MANUAL
2
VL-E630U/T
VL-E680U
VL-E685U/T
Signal System: NTSC standard
Recording System: 2 rotary heads, helical scanning system
Cassette: 8 mm video tape, MP type
Recording/Playback Time: 120 minutes (P6-120)
Tape Speed: 14.345 mm/second
Pickup Device: 1/4" (6.4mm, effective size: 4.5 mm) CCD image sensor with approx.
270,000 pixels including optical black
Lens: 16 ×power zoom lens (F1.4, f=4.0-64.0 mm) and full-range auto focus
Lens Filter Diameter: 46 mm
Monitor: 3" (7.5 cm)—full-color LCD screen (TFT active matrix)
Microphone: Electret monaural microphone
Color Temperature Compensation: Auto white balance
Minimum Illumination: 0.8 lux (5 lux measured by EIA standard) (with gain-up, F1.4)
Video Output Level: 1.0 Vp-p 75-ohm unbalanced
Audio Output Level: –8 dBs, impedance less than 2.2 kohms
Speaker Output: 200 mW
Power Requirement: DC 3.6V
Power Consumption:
E630U:4.8W (during camera recording in full auto mode with zoom
motor off, and backlight in normal mode)
E680U/E685U:4.9W (during camera recording in full auto mode with
zoom motor off, Extend Zoom, DIS and Snapshot functions off, and
backlight in normal mode)
Operating Temperature: 0°C to + 40°C (32°F to 104°F)
Operating Humidity: 30% to 80%
Storage Temperature: –20°C to +60°C (–4°F to 140°F)
Dimensions (approx.): 7 5/32" (W) ×4 9/32" (H) ×3 7/8" (D)
[182 mm (W) ×109 mm (H) ×99 mm (D)]
Weight (approx.): 1.52lbs (690g)
(without battery pack, lithium battery, video cassette, and lens cap)
Battery Pack BT-H22
DC Output: 3.6V
Dimensions (approx.): 2 1/8" (W) ×3/4" (H) ×2 7/32" (D)
[54 mm (W) ×19 mm (H) ×
56 mm (D)]
Weight (approx.): 0.30 lbs (136 g)
AC Adapter/Battery Charger
UADP-0274TAZZ(VL-E630U/680U/685U)
UADP-0275TAZZ(VL-E630T/685T)
Power Requirement: AC 110-240 V, 50/60 Hz
DC Output: 4.5 V
Power Consumption: 16 W
Dimensions (approx.): 2 31/32" (W) ×2" (H) ×5 5/16" (D)
[75 mm (W) ×51 mm (H) ×
135 mm (D)]
Weight (approx.): 0.65 lbs (295 g)
2. SPECIFICATIONS
Specifications are subject to change without notice.
*Minimum illumination: Since there is no widely accepted testing procedure for determining minimum illumina-
tion capability, lux ratings are comparable only between models from the same
manufacturer.
SERVICE INFORMATION (For the U.S.)
ForthelocationofthenearestSharpAuthorizedService,ortoobtainproductliterature,accessories,
supplies or customer assistance, please call 1-800-BE SHARP (1-800-237-4277) or visit SHARP's
web site (http://www.sharp-usa.com)
3
VL-E630U/T
VL-E680U
VL-E685U/T
4. DISASSEMBLY OFTHE SET
4-2. Disassembly of the VCR main body
1. Removal of the VCR lid shaft
(1)Remove one screw ((j)LX-HZ0063TAFC).
Area A
(j)
4-3. REPLACEMENT OF CCD SENSOR
4-3-1. BEFORE REPLACEMENT
1) The CCD image sensor is more sensitive to electrostatic breakage than C-MOS LSI. Therefore sufficient means to
prevent electrostatic damage must be taken when it is replaced.
•Ground the soldering iron.
•Ground also the human body, using the wrist strap(through an 1 Mohm resistor).
•Until the CCDsensor is mounted on the PWB, fit it to the conductive sponge, and short-circuit the foot lead.
2) Takeutmost care sothat the surfaceglass of CCD sensorand optical filterare not contaminatedand damaged. If any
contamination is found, for example fingerprint, wipe it off with silicon paper or clean chamois skin.
3) When replacing the CCD sensor, use the antistaic grounded soldring iron, and perform quickly soldering.
JAPAN
SHARP
Index Mark
LZ2413H5
YYWWXXX
17
14 8
4-4. INITIAL SETTING OF E2PROM IC
4-4-2. IC702 (E2PROM)
When the IC702 has been replaced, make the following settings and adjustments.
1. Remove the backup battery (CR2025)
2. Turn power switch to CAMERA
3. Setting up the V ADJ mode as follows.
* After press the CONTINUE key, press the VCR ADJ key on service remote control (RRMCG0033TASA).
E630U E680U E685U E630T E685T
address data data data data data
03 8D F8 FA 8C FE
0B 72 07 05 73 01
01 00 00 00 00 00
09 FF FF FF FF FF
04 00 00 00 00 00
0C FF FF FF FF FF
02 01 01 01 07 07
0A FE FE FE F8 F8
05 40 40
0D BF BF
4. After setting the above data, clear the V ADJ mode and turn off the power by pull out the battery pack or DC cable.
Neglect about 30 seconds after turned of power, because data of address becomes effective after microcomputer is
reset.
Now the setting of data is completion.
Adjustments to follow
Make the system controller servo, VCR, and LCD adjustments according to their respective instructions.
4
VL-E630U/T
VL-E680U
VL-E685U/T
5. MECHANISM ADJUSTMENT
5-2. Items and timings of inspection and maintenance
5-2-1. Inspection and maintenance list
Tape travelling route
(Refer to Section)
Drum (Refer to Section)
Remarks
Rollers
• Ifabnormalrotationor
deflection (signifi-
cant)isfound,replace
the roller.
Other than rollers
•Clean the tape con-
tactingareas.Besure
to use the specified
cleaning agent.
Possible symptom
encountered
•Lateral noise
•Unclean head
•Screen shaking
Usage time (hrs.)
500 1,000 1,500 2,000 3,000
Checking/Maintenance point
Tape travel system
•Improper S/N ratio
•No color appears.
Video head
Timing belt
Pinch roller
Capstan D.D. motor
Relay Pulle shaft
Pulle gear shaft
Drive gear shaft
•Tape does not run.
•Tape slackens.
•Screen shakes.
•Abnormal sound •Apply oil.
(Oil: )
•Replace if failure is
found.
★★★
∆∆∆
Driving system
∆∆∆
Loading motor •Replace if failure (ab-
normal sound) is de-
tected.
Abnormal sound
PB/VS-REWtake-uptorque
PB/VS-REW back tension
torque
Tu brake
•Not ejectable
• Thespecificmodecan-
not be set.
• If conformance to the
standard is not en-
sured, replace part.
★★★★★
★★★
★★★
★★★
★★★
Performance check
Note:
After oil is applied to
the drive gear shaft,
slightly wipe it off with
swab.
HC (Head Cleaner)
Oil:
Grease: MORYCOAT YM-103/X5-6020
Screw locking agent: THERE BOND 1401B
Cleaning liquid: Industrial-use ethyl alcohol
: Replace.
: Clean. ∆: Apply oil.
★: Check.
5-4. ADJUSTMENT OF MECHANISM TAPE TRAVEL SYSTEM
5-4-3. Adjusting the Si roller height
(2)Adjusting the Si roller
1 Playback the tape such to set the V/SR mode.
5
VL-E630U/T
VL-E680U
VL-E685U/T
6. ADJUSTMENT OF VCR
6-1. ADJUSTMENT OF VCR SECTION
6-1-5. Y/C circuit adjustment method
5. Adjustment of Y-FM deviation
Measuring instrument
Oscilloscope
Mode REC/PB (self-playback/recording)
Input signal Color bar
Measuring point TL801
Adjustment address 34
Adjustment level 500 ±20 mVp-p
500±20mVp-p
3. Adjustment of playback Y level
Measuring instrument Oscilloscope
Mode PB
Playback signal Color bar (JiGWR5-5NSP)
Measuring point TL801
Adjustment address 27
Adjustment level 500 ±20 mVp-p
500±20mVp-p
Measuring point LCD panel display surface
Address 11, 12
Mode VCR AV input
Adjusting method Set the data of address 11 and 12.
Adjustment standard
11=BD
12=8E
Remarks ———————
6-1-7. Adjustment of LCD display circuit
9. Inverter input voltage setting
6-2. ADJUSTMENT OF CAMERA SECTION
• Connections for Camera Section Servicing
20pin SC2 19pin
SC6
20pin
SC4
CCD PWB
19pin
LENS SC3
15pin
17pin
Connect FPC
between the
camera and
the VCR.
SC2 19 pin
SC3 15 pin
SC4 17 pin
SC6 20 pin
QPWBH2814TAZZ
QPWBH2815TAZZ
6
VL-E630U/T
VL-E680U
VL-E685U/T
★Preparation for 6-2-2-3~6-2-2-9; set up the camera signal adjustment mode. (Write 00 to the address 1FE.)
6-2-2-3.
Before starting these adjustments, set up the auto focus adjust.
•Sync level adjustment
Measuring instrument
Oscilloscope
Subject Anything
Tape —
Test point
VIDEO OUT (Terminated in 75Ω)
Adjustment address 1FE
Adjustment level 286mVp-p
1) ConnecttheoscilloscopetotheVIDEO-OUT.Adjustthe
sync level to 286mVp-p.
1H
Video
SYNC
286mVp-p
6-2-2-9.
•Auto white balance adjustment
Measuring instrument
Subject Gray scale
Tape —
Test point
VIDEO OUT (Terminated in 75 Ω)
Adjustment address R-OUT DOOR 016
B-OUT DOOR 018
Adjustment level R-OUT DOOR; 0 ±3 %
B-OUT DOOR; 0 ±3 %
Vector scope
1) Attach the color temperature conversion filter (JIGHOYA-LB165) to the front of the lens.
2) Using the addresses R-OUT DOOR 016 and B-OUT DOOR 018, adjust the spot to the center.
3) Take off the color temperature conversion filter.
★Write FF to the address 1FE to the address 1FE to exit the camera adjustment mode.
Center point
Spot
R-Y
B-Y
7
VL-E630U/T
VL-E680U
VL-E685U/T
- M E M O -
VL-E630U/T
VL-E680U
VL-E685U/T
VL-E630U/T
VL-E680U
VL-E685U/T
1234567891011 12 13 14 15 16 17 18 19 20
A
B
C
D
E
F
G
H
I
J
8~11
å
å
åAND SHADED COMPONENTS=SAFETY RELATED PARTS
8. SCHEMATIC DIAGRAM
8-2. POWER CIRCUIT SCHEMATIC DIAGRAM
12
A
B
C
D
E
F
G
H
1234567
VL-E630U/T
VL-E680U
VL-E685U/T
8-3. AUDIO CIRCUIT SCHEMATIC DIAGRAM
13
78910111213
VL-E630U/T
VL-E680U
VL-E685U/T
A
B
C
D
E
F
G
H
1234567
8-4. MOTOR DRIVER SCHEMATIC DIAGRAM
Ce manuel convient aux modèles suivants
4
Table des matières
Autres manuels Sharp caméscope
Sharp
Sharp Viewcam VL-WD450U Manuel utilisateur
Sharp
Sharp 8C-B30A Mode d’emploi
Sharp
Sharp ViewCam Slim VL-ME100S Manuel utilisateur
Sharp
Sharp VL-AD260U Manuel utilisateur
Sharp
Sharp ViewCam VL-E89E Manuel utilisateur
Sharp
Sharp VC-C50SA Manuel utilisateur
Sharp
Sharp Viewcam VL-H410X Manuel utilisateur
Sharp
Sharp Viewcam VL-Z1U Manuel utilisateur
Sharp
Sharp ViewCam VL-AH131S Manuel utilisateur
Sharp
Sharp VL-C750S Manuel utilisateur
Sharp
Sharp VL-SD20U Manuel utilisateur
Sharp
Sharp Zoom 8 VL-E30S Manuel utilisateur
Sharp
Sharp VL-AX1U Manuel utilisateur
Sharp
Sharp VL-E78E Manuel utilisateur
Sharp
Sharp Viewcam VL-Z400H-T Manuel utilisateur
Sharp
Sharp VIEWCAM VL-SD20S Manuel utilisateur
Sharp
Sharp ViewcamZ VL-Z3S Manuel utilisateur
Sharp
Sharp VL-C8000S Manuel utilisateur
Sharp
Sharp ViewCam VL-H850S Manuel utilisateur
Sharp
Sharp ViewcamZ VL-Z100S-S Manuel utilisateur
Manuels caméscope populaires d'autres marques
Panasonic
Panasonic AG-HMC152EN Manuel utilisateur
Insignia
Insignia NS-DCC5HB09 - Camcorder - 720p Manuel utilisateur
MYDLINK
MYDLINK DCS-6100LH Manuel utilisateur
Sony
Sony video Hi8 Handycam CCD-TR555 Manuel utilisateur
SECURECOM
SECURECOM V-5014B Manuel utilisateur
Panasonic
Panasonic HDC-SD100 Manuel utilisateur
