MX-4141N

MX-5141N

Technical Handy Guide

September 2013

Content

Machine Specification

MX-EB12N Mirroring Kit

Machine Options

SD Card Replacement Procedure

Consumables

CF Card Replacement Procedure

Initial Set-up

Firmware & Print Driver Revision

Colour Calibration

Test Simulation

Maintenance

Trouble Codes

Operating System Support

Sensor Location

Electrical

Jam Cause Codes

Coin Vend Interface

Repair Hints

Firmware Upgrade

Technical Bulletin Index

E-Manual Update

Document Reference

Watermark Update

Notes

HDD Replacement Procedure

Machine Specification

SHARP

Document Solution Centre

MX-4141N

MX-5141N

General Specification

Original paper size:

Max. A3

Printed Paper Size:

Tray : A3-A5R, Bypass : A3W-A5R; Long Paper (Max. 1200mm x 320mm)

Standard Paper Capacity:

1,100 (500-sheet x 2, 100-sheet Multi bypass)

Maximum Paper Capacity:

6600 (100-sheet Multi bypass, 500-sheet x 2, 1150 + 850 tandem, 3500 LCC)

Paper Weight:

Tray : 60g/m2-220g/m2 Bypass : 55g/m2-300g/m2

Output Capacity:

400-sheet (centre: STD) Opt: MX-TRX2 100-sheet right tray

Warm-up Time:

28 sec

30 sec

Operation Panel:

10.1” Colour WSVGA

Resolution (Max):

9,600 (equivalent) x 600 dpi (Copy),

9,600 (equivalent) x 600 dpi or 1200x1200dpi (Printer)

Memory:

SD Card: 4 GB (STD), CF Card 8GB (STD), MFP 1GB + 3GB (SOC)

HDD Capacity:

320GB

Duplex:

STD (60g/m2-220g/m2)

Dimensions (WDH):

648 x 764 x 960 mm

Weight:

125kg

126kg

Average Monthly Volume:

30-70K, Max 100K

40-80K, Max 150K

Environmental

Power Consumption:

Max. 1.84kW

TEC Value (Measured):

3.11kWh

4.11kWh

Noise (Measured):

Ready Mode: 39.2db, Operating 57.8db (Max 72db),

Copier Specification

Copy Speed (Max.):

41 ppm (A4), 19 ppm (A3)

51 ppm (A4), 23 ppm (A3)

E-Sort / SOPM:

Yes / Yes (Colour and B/W)

First Copy Time (OC):

B/W: 4.7sec, Col 6.7sec

B/W: 4.1sec, Col 5.7sec

First Copy Time (DSPF):

B/W: 7.4sec, Col 10.3sec

B/W: 6.7sec, Col 9.2sec

Continuous Copy:

Max 999

Scan Resolution:

Colour: 600 x 600 dpi, B/W: 600 x 400 dpi (OC), 600 x 400 dpi / 600 x 600 dpi

Zoom Range:

25 - 400% (DSPF 25 - 200%)

Tandem Copy:

STD (with MX-4141/5141N series only)

Document Feeder

STD: DSPF

Original capacity:

Max 150 sheets (80 g/m2)

Max Replacement Speed:

Copy Mode: 85 opm (B/W &Colour); Image Send: 85 opm (B/W & Colour)

Document Filing

STD

Capacity:

10GB (Quick Folder) + 95GB (Main/Custom Folder)

Quick/Main Folder:

Quick Folder: Max: 10,000 pages or 1000 files

Main/Custom: Max. 20,000 pages or 3,000 files

User Registrations:

1000

Preview Thumbnails:

Supported (includes Advanced Edit Mode)

Facsimile

Requirement:

Opt: MX-FX11

Communication Formula:

Super G3

Transmission Speed:

2sec.range(Super G3/JBIG) 6sec.range(G3/ECM)

Dial Registration:

Max 2000

Document Size:

A3 - A5,

Compression:

MH,MR,MMR,JBIG

Inbound Routing:

Yes (TIFF, XPS & PDF Format)

PC Fax:

Yes (For Windows only)

Machine Specification

SHARP

Document Solution Centre

MX-4141N

MX-5141N

Printer Specification

Print Speed (Max.):

41 ppm (A4), 19 ppm (A3)

51 ppm (A4), 23 ppm (A3)

PDL (Emulation):

STD: PCL6, Adobe® PostScript®3, Opt: XPS [MX-PUX1]]

Interface:

USB2.0, 10Base-T / 100Base-TX / 1000BaseT, Wireless LAN

Protocol:

TCP/IP (IPv4, IPv6), IPX/SPX (Netware), Ether Talk

Supported OS:

Windows® XP*, Windows® Vista*, Windows® 7*, Windows® 8*

Windows® Server 2003* / 2008* / 2008R2 / 2012 (*32/64bit).

Mac OS X10.4.x, 10.5.x, 10.6.x, 10.7.x, 10.8.x.

XPS - Windows Vista only (Opt: MX-PUX1)

Bundled Utility Software

Status Monitor

USB Direct Print (Pull):

STD: JPEG, TIFF, PRN, PCL.PDF, Encrypted PDF & PS:

XPS: MX-PUX1 is required.

Tandem Print:

Supported (with MX-4141/5141N series only)

Pantone Colour (LUT):

TBD

Airprint Support:

From Q3/13 (Running change)

Sharpdesk Mobile:

Supported

Network Scanner

STD: Colour

Resolution:

100, 150, 200, 300, 400, 600 dpi

Format:

Mono: TIFF, XPS, PDF, PDF/A & Encrypted PDF,

Colour: TIFF, JPEG, XPS, PDF, PDF/A, Encrypted PDF & Compact PDF

Destination:

Desktop (Sharpdesk), FTP, E-Mail, SMB Folder, USB Memory, HDD,

TWAIN / WIA compliant, I-Fax (SMTP)

User Registrations:

Max 500 (one touch), 500 (group)

Bundled Utility Software:

Network Scan Tool, Sharpdesk v3.3 (1 license)

Wireless LAN

STD

Compliant Regulation:

IEEE802.11n/g/b

Transmission Method:

IEEE802.11n/g: OFDM, IEEE802.11b: DSSS

Access Mode:

Infrastructure mode, Software AP mode

Security:

WEP, WPA Personal, WPA Enterprise*, WPA2 Personal, WPA2 Enterprise*

* Not applicable to Software AP mode

Center Frequency/ Channel:

IEEE802.11 n/g/b: 2.4 GHz / 1-13ch

Transmission R

ate:

IEEE802.11n max 150M bps

IEEE802.11g max. 54M bps

IEEE802.11b max 11 M bps

Output Device

Model:

Opt: MXFNX9

Opt: MXFN10

Opt: MXFN11

Opt: MXFN18

Type:

Inner Finisher

Saddle Finisher

4K Staple Finisher

4K Saddle Finisher

Output Capacity:

500 sheets

1000 sheets

4000 sheets

Functionality:

50 sheets

multi-staple

A4: 50sheets /

A3: 30sheets) ,

Off-set shifting

Opt

: Hole Punch

[MXPNX1]

50 sheets

multi-staple

A4 : 50sheets /

A3: 25sheets) ,

Off-set shifting

Opt

: Hole

Punch

[MXPNX5]

50 sheets multi-

staple

A4 : 50 sheets /

A3 : 30 sheets) ,

Off-set shifting

Opt: Hole Punch

[MXPNX6]

50 sheets multi-

staple

A4 : 50 sheets /

A3 : 30 sheets) ,

Off-set shifting

Opt: Hole Punch

[MXPNX6]

Saddle Stitch Ability:

N/A 15

sheets Max.

N/A

15 sheets Max.

Machine Options

SHARP

Document Solution Centre

MX-FNX9

Inner Finisher

-PNX1 A/B/C/D

Hole Punch

MX-TRX2

Exit Tray Unit

MX-DE23

2 x 500 sheet Desk

MX-KB11N

Keyboard

MX-LT10

Long Paper Feed

Tray

MX-DE21

2000 sheet A4 Tandem

Desk

MX-AMX1

Application Integration Module

-AMX2

Application Communication Module

-AMX3

External Account Module

MX-FR42U

Data Security Kit

MX-RB20

Paper Pass Unit

MX-FN10

Saddle Finisher

-PNX5 A/B/C/D

Hole Punch

MX-FN11

Finisher (4K)

-PNX6 A/B/C/D

Hole Punch

MX-FN18

Saddle Finisher (4K)

-PNX6 A/B/C/D

Hole Punch

MX-LC11

A4 LCC

MX-PUX1

XPS Expansion

MX-PF10

Barcode Font

MX-FX11

Fax Expansion

MX-FWX1

Internet Fax Kit

MX-AM10

Web Browsing Kit

MX-EB12N

Mirroring Kit (HDD)

Machine Options

SHARP

Document Solution Centre

MACHINE OPTIONS

Model

Description

Comment

MX-DE21

Stand/2000 tandem sheet paper drawer

Cannot install with MXDE22/23

Stand/500x2 sheet paper drawer

Cannot install with MXDE21/22

MX-LC11

3,500 sheets large capacity tray

MX-TRX2

Exit tray unit

MX-LT10

Long paper feeding tray

For Main Unit Bypass Tray only

MX-RB20

Paper pass unit

MX-FNX9

Inner finisher

MX-PNX1

Punch module (A: 2, B: 3, C: 4, D: 4 wide)

For MX-FNX9

MX-FN10

Saddle finisher

Requires MX-RB20

MX-PNX5

Punch module (A: 2, B: 3, C: 4, D: 4 wide)

For MXFN10

MX-FN11

Finisher (4000 sheets)

Requires MX-RB20

MX-FN18

Saddle finisher (4000 sheets)

Requires MX-RB20

MX-PNX6

Punch module (A: 2, B: 3, C: 4, D: 4 wide)

For MX-FN11 & MX-FN18

MX-PUX1

XPS expansion kit

MX-PF10

Barcode font kit

MX-FX11

Facsimile expansion kit

MX-FWX1

Internet-Fax expansion kit

AR-SU1

Stamp unit

MX-EB12N

Mirroring kit

MX-AM10

Web browsing kit

MX-KB11N

Keyboard unit N

MX-AMX1

Application integration module

MX-AMX2

Application communication module

MX-AMX3

External account module

MX-FR42U

Data security kit (Commercial version)

MX-USX1

Sharpdesk Additional license kit (1 license)

MX-USX5

Sharpdesk Additional license kit (5 licenses)

MX-US10

Sharpdesk Additional license kit (10 licenses)

MX-US50

Sharpdesk Additional license kit (50 licenses)

MX-USA0

Sharpdesk Additional license kit (100 licenses)

MX-UN01A

Sharp OSA-Network Scanner Tool (1 license)

MX-AMX2 is required:

MX-UN05A

Sharp OSA-Network Scanner Tool (5 licenses)

MX-UN10A

Sharp OSA-Network Scanner Tool (10 licenses)

MX-UN50A

Sharp OSA-Network Scanner Tool (50 licenses)

MX-UN1HA

Sharp OSA-Network Scanner Tool (100 licenses)

Stand/500x1sheet paper drawer

MX DE23

MX-DE22

Consumables

SHARP

Document Solution Centre

CONSUMABLES

MX-4141N, MX-5141N

Product Code

Description / Contents

Approx. Life

MX-51GTBA

Black Toner

Cartridge

(A4 @ 5%)

40k

MX-51GTCA

Cyan Toner

Cartridge

(A4 @ 5%)

18kMX-51GTMA

Magenta Toner Cartridge

(A4 @ 5%)

MX-51GTYA

Yellow Toner Cartridge

(A4 @ 5%)

PROCESS UNIT:

MX-51GVBA

Black Developer

170k *

MX-51GVSA

Colour Developer Kit (CMY)

140k *

MX-51GUSA

Drum Unit (Complete):

170k (Mono) *

140k (Colour) *

MX-31GRSA

OPC Drum

MX-510MK

Main Charge Kit:-

xMain charge unit

xCleaning blade AR

xCleaning gum AS

MX-510CU

PTC Kit:-

xPTC unit.

300k

MX-510HB

Waste Toner Collector:-

xIncludes LSU cleaner x 3

50k (approx.)

MX-C31FL

Ozone Filter Kit:-

xOzone filter.

360k

FUSING UNIT:

MX-361FB

MX-510FB

Fusing Belt Kit:-

xFusing belt.

xMeandering Suppress collar x 2.

300k

MX-510LH

Pressure Roller Kit:-

xFusing roller.

xPressure roller.

300k

MX-510WB

Web Cleaning Kit:-

xWeb roller.

xWeb guide shaft x 2.

xWeb pressure roller.

xWeb pressure roller bearing x 2

300k

TRANSFER SECTION:

MX-510B1

Primary Transfer Belt Kit:-

xPrimary transfer belt AR.

300k

MX-510TL

Primary Transfer Blade Kit:-

xPrimary transfer blade AR.

300k

MX-310B2

Secondary Transfer Belt Kit:-

xSecondary transfer belt D3.

300k

Consumables

SHARP

Document Solution Centre

CONSUMABLES:

MX-4141N, MX-5141N

Product Code

Description / Contents

Approx. Life

MX-SCX1

Staple Cartridge (for MX

-FNX9 & MX-FN10) 5000 staples (x 3)

AR-SC2

Staple Cartridge (for MX

-FN11 & MX-FN18) 5000 staples (x 3)

AR-SC3

Saddle Staple Cartridge (for MX

-FN10 & MX-FN18) 2000 staples (x 3)

AR-SV1

Stamp Cartridge (for AR

-SU1) 2 cartridges

SERVICE ROTATION:

MX-510U1

Primary T

ransfer Belt Unit

For Service RotationMX-410U2

Secondary T

ransfer Belt Unit

MX-511FU

Fusing Unit (230v)

Notes:

* The consumable life is specified by 840K rotations therefore, the page count life indicated above is for

approx. guidance only.

Also, the consumable life may vary, depending on the document density, temperature, humidity and

machine operation.

Initial Setup

SHARP

Document Solution Centre

DEVELOPER SET-UP

Sim 25-02 Auto Developer Adjustment - Select CMYK.

Toner Installation must be performed after Auto Developer Adjustment is

completed.

**For optimum image quality & performance, it is recommended to setup &

install developer at the customer site.

Clean LSU Dust Proof Glass.

TONER INSTALLATION & REPLENISHMENT

Install CMYK Toner Cartridges

Caution:

DO NOT open any Exterior Cover, Power OFF/ON or enter Simulation Mode

during Initial Toner Replenishment.

PRODUCT ACTIVATION & FIRMWARE UPGRADE

Activation of Optional Product(s):-

System Settings – Administrator Mode – Product Key.

Sim 22-05 Check Firmware version(s):- Upgrade to latest version.

INITIAL SETUP

Sim 26-01 Right Tray Installation Yes/No.

Sim 26-02 LCC Installation (Paper Size):- A4.

Sim 26-06 Machine Destination.

Sim 26-35 Set Multi Error Counter Set to 1 (Multi Count).

Sim 26-50 Long Paper Support (up to 1200mm), 0 = Disable, 1 = Enable.

Sim 26-52 Non Printed Paper Counter Set-up.

Sim 55-03 Process Mixed Original Printing for Duplex:-

SSW 3-6, 0 = Disable, 1 = Enable.

Sim 55-03 Toner Remain Status Display: SSW 22-5, 0 = Disable, 1 = Enable.

System Settings: Adjust Date/Time (Inc. Daylight Saving setting).

Set cassette size by adjusting the guides in the cassette.

Paper Size & Type Setting:- System Settings – Paper Tray Settings.

Initial Setup

SHARP

Document Solution Centre

PRINT IMAGE POSITION & MAGNIFICATION

Automatic Adjustment:-

Sim 50-28 BK MAG ADJ (Main Scan Mag).

SETUP/PRINT ADJ (Lead, Offset or All).

Manual Adjustment:-

Sim 50-10 BK MAG (inside dimension) to 240mm.

Sim 50-10 Image Off Centre Adjustment.

Sim 50-05 Printer Lead Edge & Void Adjust.

IMAGE SKEW & COLOUR REGISTRATION

Sim 61-04 Image Skew Adjustment (Black) Select A3 Paper.

Sim 50-22 Colour Registration/Skew & OPC Drum Phase Adjustment

Check/Adjust SKEW (CMY) so value is Close to 0 as possible

(Result=OK).

HALF TONE COLOUR CALIBRATION

Sim 46-74 Engine & Printer Colour Calibration Select FACTORY Mode.

COPY IMAGE QUALITY

Check Image Quality (Copy Mode) – Density, Magnification, Lead Edge & Void.

If NG, perform the following adjustments as required:-

Sim 46-01 Copy Density Adjust. (Colour).

Sim 46-02 Copy Density Adjust. (B/W).

Sim 46-09 SPF Copy Density Adjust.

Sim 50-28 OC ADJUST (Lead, Offset & Mag).

SPF ADJ:(Lead, Offset & Sub scan).

Manual Adjustment (Magnification, Lead Edge, Void, Off Centre etc).:

Sim 48-01 Magnification Adjustment (OC & SPF).

Sim 50-01 Lead/Rear Edge, Loss & Void Adjust.

Sim 50-12 OC & SPF Off Centre Adjust.

PRINT IMAGE QUALITY

Check Image Quality (Print Mode) – Density.

Sim 64-05 PCL Density Test Page

Sim 64-06 PS Density Test Page

Initial Setup

SHARP

Document Solution Centre

PERIPHERAL / OPTION CONFIGURATION

FAX OPTION – MX-FX11

Sim 66-02 Fax SW Setting (Destination).

Sim 66-10 Fax Memory Clear (For Extended Memory).

Sim 66-39 Fax Destination Set.

FINISHER OPTION – MX-FNX9, MX-FN10, MX-FN11, MX-FN18

Sim 03-10 Saddle Fold/Staple Position Adjustment [MX-FN10/18 only]

Sim 26-65 Finisher Alarm Mode:-

Limit number of Copies in staple mode (ON/OFF).

EXTERNAL KEYBOARD – MX-KB11N

Keyboard Language Setting:

System Settings – Default Settings – Keyboard Select: Select English(US).

EXTERNAL ACCOUNTING MODULE – MX-AMX3

Sim 55-03 Auto clear function before Copy job execution:-

SSW1-50 = Disable, 1 = Enable.

Sim 55-03 USB Card Reader detection control:-

SSW6-80 = Disable, 1 = Enable.

Sim 55-03 Continuous print mode (job queuing for OSA):-

SSW24-70 = Disable, 1 = Enable.

MFP DATA BACKUP

Sim 22-06 Data Simulation Print.

Device Clone & Storage Backup.

Sim 56-01 Backup EEPROM Data to HDD.

Autres manuels pour MX-4141N

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sharp Imprimante tout-en-un

Sharp

Sharp MX-M550N Manuel utilisateur

Sharp

Sharp MX-C528F Manuel utilisateur

Sharp

Sharp MX-M363F Manuel

Sharp

Sharp MX-M200D Manuel utilisateur

Sharp

Sharp MX-C380 Manuel utilisateur

Sharp

Sharp MX-M7570 Manuel utilisateur

Sharp

Sharp MX 5500N - Color Laser - Copier Manuel utilisateur

Sharp

Sharp AL-1556 Manuel utilisateur

Sharp

Sharp AR-M257 - Digital Imager B/W Laser Manuel utilisateur

Sharp

Sharp AR-F152 Manuel utilisateur

Sharp

Sharp MX-M182 Manuel utilisateur

Sharp

Sharp MX-B402SC Manuel utilisateur

Sharp

Sharp MX-C381 Manuel d'installation et d'exploitation

Sharp

Sharp MX-M2630 Manuel utilisateur

Sharp

Sharp AJ-5030 Manuel utilisateur

Sharp

Sharp AR-C260 Instructions d'installation et d'entretien

Sharp

Sharp AL-841 Manuel utilisateur

Sharp

Sharp MX-3114N Operation Manuel

Sharp

Sharp AL-2061 Mode d’emploi

Sharp

Sharp MX 5500N - Color Laser - Copier Manuel utilisateur

Sharp

Sharp AR-BC320 Manuel utilisateur

Sharp

Sharp MX-4100N Manuel utilisateur

Sharp

Sharp FO-3800M Instructions de construction

Sharp

Sharp FO-2080 Guide de configuration

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Aficio

Aficio 200 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Manuel

Ricoh

Ricoh Pro C900 Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur

Oce

Oce VarioLink 5022 Manuel utilisateur
