Shaq SHL-90 Manuel utilisateur

Juicer

Save These Instructions – For Household Use Only

Owner’s Manual

MODEL: SHL-90

When using electrical appliances, basic

safety precautions should always be

followed. Do not use the Shaq Juicer™

until you have read this manual thoroughly.

Visit TristarCares.com for tutorial

videos, product details, and more.

Guarantee Information Inside

Table of Contents

BEFORE YOU BEGIN

The Shaq Juicer™will provide you many years

of healthy juicing. But before you begin, it’s

very important that you read this entire manual,

making certain that you are totally familiar with

this appliance’s operation and precautions.

Shaq Juicer

IMPORTANT SAFEGUARDS ............................ 4

Parts & Accessories .................................... 6

Disassembly ............................................. 7

Assembly ................................................. 8

Instructions for Use ..................................... 9

Juicing Guidelines .......................................10

Juicing Chart .............................................12

Care & Cleaning ..........................................13

Troubleshooting ......................................... 14

60-Day Money-Back Guarantee ......................15

4SHAQ Juicer SHAQ Juicer 5

When using electrical appliances,

basic safety precautions should

always be followed, including:

1. Read all instructions.

2. NOT FOR USE BY CHILDREN!

Keep out of the reach of

children to avoid injury.

3. The Shaq Juicer has a polarized

plug. To reduce the risk of electric

shock, this plug will t in an outlet

only one way. If the plug does

not t fully in the outlet, reverse

the plug. If it still does not t,

do not use the appliance and

consult an electrician.

4. DO NOT operate this or any

appliance with a damaged

AC cord or plug.

5. Unplug from outlet when not

in use.

6. DO NOT operate if appliance

malfunctions, has been

dropped or appears

damaged

in any manner. Never attempt

home repairs. Only a qualied

appliance technician should

repair appliance before re-use.

7. DO NOT USE any attachments

or utensils that were not

recommended or supplied

by the marketer. The use of

attachments not recommended

or sold by the manufacturer

may cause serious hazardous

situations including re, electric

shock or personal injury.

8. To protect against risk of

electrical shock or injury, never

immerse power cord, plug,

or main appliance in water, or

other liquids.

9. DO NOT let Power Cord hang

over the edge of table, counter,

or come in direct contact with

hot surfaces such as stoves.

10.Make sure the lid is attached

properly and is securely locked

before operating the Fusion

Juicer. (See Assembly Step 4)

11.Make sure the motor stops

completely and the appliance

is unplugged from the electrical

outlet before disassembling,

assembling or cleaning.

12.Should juicer suddenly stop

or develop excessive vibration

or unusually loud noise, shut

off and unplug appliance

immediately, wait for blade to

stop running, then disassemble,

clean thoroughly and reassemble.

IMPORTANT SAFEGUARDS IMPORTANT SAFEGUARDS

WARNING

PREVENT INJURIES! CAREFULLY READ ALL

INSTRUCTIONS BEFORE USE!

13.To avoid risk of personal injury

keep hands and utensils out of

the juicer and away from its sharp

Blade during operation. Use the

Pusher, not ngers or utensils, to

insert food into the juicer.

14.NEVER disengage the Locking

Bar during operation.

ANYONE WHO HAS NOT FULLY READ

AND UNDERSTOOD ALL OPERATING AND

SAFETY INSTRUCTIONS CONTAINED

IN THIS MANUAL IS NOT QUALIFIED TO

OPERATE OR CLEAN THIS APPLIANCE.

SAVE THESE INSTRUCTIONS –

FOR HOUSEHOLD USE ONLY

Safety Features

The Shaq Juicer was designed with

safety in mind. We have added two

important safety features:

Built-In Automatic Shut Off System

The Shaq Juicer is equipped with

a special feature that automatically

shuts off the motor should the

appliance become jammed or

overheated during the juicing

process. Prior to shut down, you will

most likely hear the juicer get louder.

This will indicate that something has

caused the motor to strain. Should

this happen, simply turn the Power

Switch off and unplug the appliance.

Follow the Disassembly, Cleaning

and Assembly procedures. Then,

allow the appliance to cool for 10

minutes. The appliance will reset

and you will be able to resume the

juicing process.

The Locking Bar

When in the upright and locked

position, this feature holds the

Juicer Lid/Pulp Guard in place. If

the Locking Bar is not in its proper

position, the motor will not engage

and the blade will not spin.

CAUTION

6SHAQ Juicer SHAQ Juicer 7

IMPORTANT: Your Shaq Juicer has been shipped with the components

shown below. Check everything carefully before use. If any part is missing

or damaged, do not use this product and contact Customer Service using

the contact information located on the back of this manual.

Pusher

Lid and Pulp Guard

Chute

Pulp Collector

Power Base

Cleaning Brush

Receptacle

Blade/Filter

Spout

Locking

Bar

IMPORTANT: Before disassembly, make certain appliance is shut off

and the power cord is unplugged from the power outlet.

Parts & Accessories Disassembly

1. Lift and remove the Pusher

from the Chute.

2. Grasp the Locking Bar

and rotate downward. This

will release all components

for easy disassembly.

3. Lift and remove the

Lid and Pulp guard.

4. Lift and remove the

Receptacle, which

contains the Blade/Filter.

At this point, you can

separate the Blade/Filter

from the Receptacle.

5. NOTE: The Pulp Collector

is now free from the

appliance.

8SHAQ Juicer SHAQ Juicer 9

1. Align the three tabs on the bottom

of the Receptacle with the matching

tabs on the top of the Power Base

and set the Receptacle down.

2. Insert the Blade/Filter into the

Receptacle and set the Blade/Filter

in place with a slow clockwise

motion. Now, place the Pulp

Collector under the back lip of the

Receptacle (see Fig. A).

3. Place the Lid on the Receptacle

so that the Lid is stable and unable

to rotate.

4. Lift the Locking Bar so that it comes

over the top of the Lid and locks,

holding the appliance together.

5. The Pusher must

be used to guide

fruits and veggies

through the Chute.

NOTE: The

Pusher has a

groove along one

side that must be

aligned to a tab in

the Chute when

in use (see Fig. B).

Match tabs

with Receptacle

Before First Use

Ensure that all packing materials

have been removed. Running

the appliance with any of this

material still intact may cause

serious damage. Disassemble

the appliance (see Disassembly,

p. 7). Clean the appliance (see

Care & Cleaning, p. 13). Dry all

parts thoroughly before use.

Assemble the appliance (see

Assembly, p. 8).

1. Clean and cut ingredients to

a size that will t in the Chute.

Ensure all pits and large stems

are removed. Small seeds and

skins should not be a problem

if you wish to use them.

2. Place the appliance on a stable

countertop or table. Plug the

power cord into a 110V outlet.

Select the speed you wish to

use and allow the appliance to

run for a few seconds.

Instructions for UseAssembly

Fig. B

Fig. A

Fig. C

3. Use the Pusher to guide the

ingredients into the Chute

with a smooth, steady motion.

You should see the juice

beginning to ow into your

glass or container, and the pulp

will begin to collect on the

Lid and in the Pulp Collector.

4. Immediately after use, clean

the appliance (see Care &

Cleaning, p. 13).

NOTE: Sometimes, you may need

to remove excess food when making

large quantities of juice. To remove

excess food, unplug the appliance,

remove the Lid, and clean the

Blade/Filter and Pulp Chute.

NOTE: Before juicing, ensure the

Spout is pointed downward and

properly aligned with your glass or

container (see Fig. C).

10 SHAQ Juicer SHAQ Juicer 11

Juicing should be done in

conjunction with your regular

daily consumption of fruits and

vegetables. Consuming whole

fruits and vegetables daily helps

you get much-needed ber.

Juicing is a quicker way to get

many of the health benets you

need from fresh food, including

antioxidants and nutrients.

We recommend juicing produce

items that you would normally

consume. Before juicing any

produce, it is important to wash

it thoroughly to remove all

contaminants, including soil

and pesticides.

SKINS, STEMS, AND SEEDS

Skins: Juicing with the skins

on is a personal preference with

most produce.

Stems: The only stems that are

benecial to process are grape

stems. All others should be removed.

Seeds: Removing seeds is

discretionary due to certain health

risks associated with certain produce.

CARROTS

Due to the irregular size and shape

of carrots, care must be taken

when juicing. Do not overll the

chute. Allow room for the carrots to

move and be pushed into the juicer.

Use the Pusher to guide the carrots

and prevent them from bouncing

out of the chute.

CITRUS FRUITS

We recommend the removal of

the skin from citrus fruits. The skin

will provide a tart avor to the juice.

The skin can also be difcult to

process. Juicing with or without the

skin is a personal preference.

MANGOES, APRICOTS,

AND PEACHES

Important: Always remove large

pits. Do not put any produce in

the juicer with large pits. Pits will

damage the blade and possibly

seize the motor.

Do Not Juice

Juicing Guidelines Juicing Guidelines

POMEGRANATES AND

CHERRIES

These wonder fruits can absolutely

be juiced. When juicing cherries,

remove the pits. When juicing

pomegranates, only the seeds may

be used. You must remove the outer

skin and the inner membrane.

PINEAPPLE AND MELONS

Although the juicer can process

the rind from these items, we

recommend removing the rind.

Pineapple is stringy in nature and

can cause a blockage at the opening

of the Spout. Monitor juice ow and

juicing progress to avoid blockages,

which can cause the Receptacle

to overow.

BERRIES AND SMALL FRUITS

When juicing berries (except

cranberries), you need to add other

juicier fruits (such as apples or

oranges) that produce more juice

to push the juice through the juicer.

Strawberries contain the most

juice because they tend to be large.

For example, rst process the berries

(you may not see a lot of juice).

Then, add an apple or an orange –

something that will increase the

volume of juice.

KEEP THE PULP

COLLECTOR CLEAN

When juicing, be sure to monitor

the Pulp Collector and empty it

before it is full. If the Pulp Collector

lls and pulp backs up into Filter,

the motor will shut off. The pulp

can be used for recipes or thrown

away. You can place a plastic bag

in the Pulp Collector to aid with

clean-up.

Some varieties of produce are

more difcult to process than

others. The amount of juice you

process depends on which fruits

and vegetables you select. Produce

such as oranges, apples, melons,

and cucumbers tends to yield

more juice and should be mixed

with those that yield less juice. The

Juicing Chart (see p. 12) can help

take the guesswork out of juicing.

DO NOT JUICE avocados, bananas,

or coconuts because they do not

contain juice. Juicing rhubarb is not

recommended due to toxins.

Get the Most from Your Juicer

The Benets of Juicing

12 SHAQ Juicer SHAQ Juicer 13

Harder Fruits & Vegetables Ideal For Juicing

Apples

Asparagus

Brussels sprouts

Cabbages

Cantaloupe

Celery

Cherries (pitted)

Clementines

Cranberries

Cucumber

Fennel

Garlic

Ginger

Grapefruits

Grapes

Guava

Honeydew Melon

Horseradish

Jicama

Kiwi

Kohlrabi

Lemon

Lettuces

Lime

Nectarines

Onion

Oranges

Parsnip

Peaches (harder)

Pears (harder)

Peppers

Pineapple

Pomegranate seeds

Potatoes

Pumpkin

Radicchio

Radishes

Squashes

Strawberries

Tangerines

Tomatoes

Watermelon

Softer Fruits & Vegetables More Challenging For Juicing

Apricot

Basil

Beets

Blackberries

Blueberries

Broccoli

Carrots

Cauliower

Collard greens

Dandelion greens

Endive

Green beans

Green peas

Kale

Kiwi (very ripe)

Leafy greens

Leeks

Mango

Mint

Mushroom

Mustard greens

Nectarines (very ripe)

Okra (skin removed)

Papaya

Parsley

Passion fruit

Peaches (very ripe)

Pears (very ripe)

Peppermint

Pineapple (very ripe)

Plums

Raspberries

Spinach

Swiss chard

Tomatoes (very ripe)

Turnip

Watercress

Wheat grass

Fruits & Vegetables With Greater Juice Content

Apples

Cantaloupe

Celery

Clementines

Cranberries

Cucumber

Grapefruits

Grapes

Honeydew Melon

Lemon

Lime

Oranges

Peppers

Pineapple

Tangerines

Tomatoes

Watermelon

With the exception of the Motor

Base, all the components can be

put in your home dishwasher. We

recommend top rack placement.*

1. Turn off the power switch

and wait until the motor stops

completely.

2. With dry hands, unplug the

power cord from electrical

outlet.

3. Disassemble the machine

(see Disassembly, p. 7).

4. Wipe the outside of the Power

Base with a warm, moist cloth

and mild detergent. Do not

submerge the Power Base in

water. Do not spray with water

or any other liquid. The Power

Base is not dishwasher safe.

IMPORTANT: Do not use

abrasive sponges, cloths, or

cleansers as these can damage

the nish.

5. Hold the Filter/Blade under

warm running water. Use the

supplied cleaning brush to

loosen the leftover bers that

may be stuck to the Filter/

Blade before placing the

Filter/Blade in the dishwasher.

Never use a wire brush.

Rinse the Filter/Blade from the

outside under running water.

A sink’s spray hose attachment

is especially effective for

loosening ber from the

Filter/Blade.

6. Clean all other parts with a

warm, moist cloth and mild

detergent. Rinse well and dry

thoroughly.

7. Dry the components

thoroughly, reassemble the

machine (see Assembly, p. 8),

and turn on the power to spin

out any excess water.

8. Ensure the appliance and its

parts are completely dry before

storing in a cool, dry place.

*CAUTION: Some commercial

and foreign-made dishwashers may

reach internal temperatures that are

higher than machines made for home

use by US standards. Do not use

these dishwashers with your Shaq

Juicer. The higher temperatures

may cause damage to appliance and

can void your guarantee. Check

with your dishwasher manufacturer

before using.

Care & CleaningJuicing Chart

14 SHAQ Juicer

60-Day Money-Back Guarantee

If you decide that you don’t love this product, your order is covered

by our 60-Day Money-Back Guarantee. You have 60 days from the day

you receive your product to request a replacement product or refund of the

purchase price minus processing and handling fees. To receive a refund or

replacement, you must return the product to us at your expense.

Replacement Guarantee Policy

Our products, when purchased from an authorized retailer, include a

1-year replacement guarantee if your product or component part does not

perform as expected, The guarantee extends only to the original purchaser

and is not transferable. If you experience an issue with one of our products

within 1 year of purchase, return the product or the component part

for replacement with a functionally equivalent new product or part. The

original proof of purchase is required, and you are responsible to pay

to return the unit to us. In the event a replacement unit is issued, the

guarantee coverage ends six (6) months following the receipt date of the

replacement unit or the remainder of the existing guarantee, whichever

is later. Tristar reserves the right to replace the unit with one of equal or

greater value.

To return the product, call customer service at 1-973-287-5113 and

request a return merchandise authorization number. Pack the product

carefully and include in the package a note with (1) your name,

(2) mailing address, (3) phone number, (4) email address, (5) reason for

return, and (6) proof of purchase or order number, and (7) specify on the

note whether you are requesting a refund or replacement. Write the return

merchandise authorization number on the outside of the package.

Send the product to the following return address:

Shaq Juicer

Tristar Products, Inc.

500 Returns Road

Wallingford, CT 06495

Juicer

Troubleshooting

Symptom Possible Cause/Solution

Appliance does not run

when switched on

Check to see if the appliance is plugged in.

Locking bar is not locked in place properly.

Check if all parts are assembled.

Check if there is any residue left between the blade and the receptacle.

Make sure you wait 5-10 minutes to restart if the appliance

automatically shuts down.

Motor is unusually

loud and vibrating

Check that all parts are assembled properly and in the correct position.

Juicing overripe fruit may result in too much pulp and will clog the lter.

Turn the appliance off and clean the lter.

The motor overheats

causing the power to

automatically shut off

Applying too much pressure with the Pusher while processing can

cause the motor to overheat, which activates the built-in thermal cut-off

switch. The motor will stop working for approximately 10 minutes to

cool down (see Safety Features, p. 5).

The fruits and vegetables may be soft or overripe.

There may be too much pulp in the lter. Turn the appliance off

and clean the lter.

No juice is coming

out of the Spout

Make sure the Spout is facing downward while juicing.

If the Spout is facing upward, juice will not come out of the Spout

and may overow out of the bottom sides.

Some produce, such as berries, may not be juicy enough.

Add juicier produce, such as apples and oranges, to the juicer

to help push the juice through the juicer.

Distributed by:

Tristar Products, Inc.

Faireld, NJ 07004

Made in China

SHAQ_JUICER_IB_S_B423210_ENG_V1_200210

We are very proud of

the design and quality of our

SHAQ JuicerTM.

This product has been manufactured

to the highest standards. Should you have any questions,

our friendly customer service staff

is here to help you.

Visit us at www.TristarCares.com,

email us at [email protected],

or call us at 973-287-5113.

Juicer

Table des matières

Manuels presse-agrumes populaires d'autres marques

GE 169201 Manuel utilisateur

Exquisit

Exquisit ZP 3001 WET Manuel utilisateur

Philips

Philips HR1851 Manuel utilisateur

Sam Cook

Sam Cook MASTERCHEF EXECUTIVE PSC-50 Manuel utilisateur

Termozeta

Termozeta spremiagrumi Manuel utilisateur

ElectrIQ

ElectrIQ WF1000 Manuel utilisateur

Bella

Bella WHOLE FRUIT JUICER Manuel utilisateur

HAEGER

HAEGER Little Juice CJ-025 006A Manuel utilisateur

Havells

Havells Fusion Manuel utilisateur

Siemens

Siemens MK554 SERIES Manuel utilisateur

Beper

Beper 90.302B Guide rapide

NATURSAFT

NATURSAFT 015.401.3 Manuel utilisateur

Moulinex

Moulinex BKB 2 Manuel utilisateur

Royal Catering

Royal Catering RCJU-01 Manuel utilisateur

camry

camry CR 4002 Manuel utilisateur

AIGOSTAR

AIGOSTAR 30HIM Manuel utilisateur

ZUMEX

ZUMEX MINEX Manuel utilisateur

Skymsen

Skymsen EX Manuel utilisateur
