Setma E06FO100001 Manuel utilisateur

1/10

E06FO100001

This interface can insert high definition RGB navigation video, DVR,360 parking

system and reverse camera video onto Sync3 car screens. The car models are 2016

Lincoln, Fordmustang andsome othermodels. TheE06FO10001 has the built‐in GPS

module which drastically reduces the installation work. The E06FO... has

built‐in Androidnavigation which can be installed with live‐traffic on‐line

navigation software, also phonemirrorfunctiontodisplaythephone’sinformation

ontocarscreen.

TheOEMtouchfoilisusedtocontroltheinstallednavigation,phonemirrorand

otherfunctions.

Thefeaturesare：

TheOEMtouchfoilisusedtocontroltheinstallednavigationandandroidphone.WiththeLVDScableinstalledbetween

the parts, the installer can immediately add hand‐touch android navi, DVR, 360

surroundviewandothervideosources.

The Call‐Off is used long press to switch the inputs. Plug‐n‐play harness is used

behindtheHeadunit,theinstallerdoesnotneedtocutanywires.

E06FO10001 products: has Internal Digital navigation of winCE module, which makes the

picture very clearly displayed on OEM screen. it has mirror function of Android

phonesandhasMP5playersinside.

E06FO...‐products:hasInternalDigitalnavigationofAndroidmodule,whichmakesthe

pictureveryclearlydisplayedonOEMscreen.TheinternalwifiandGPSmakesall

popular on‐line navigation like WAZE/google map works very nice. it has mirror

functionofAndroidandiPhonesandhasMP5playersinside

2/10

1． Connections:

Themap‐SDcard

External navigation or other high-definition video sources.

USBformapupdate

orMP5files

Whenthemonitoristakendown

fromthecar,theconnectorsbehindare

likethis:

TheLVDSplug‐socketshouldbe

re‐insertedontotheplugbehindthe

LCD,notthealuminumpiece.

Thepowerharnessshouldbe

insertedontothepowerplugbehind

themonitor.

Thisharnessshouldbeinsertedbehindthemonitor,the4‐DIPSshouldallbeUP[off]

Theoutputsare:

Yellow/Red:areBatt/ACC,forpowersupplyofthisinterface.

Blackforground.

Greenwireforreversedisplay.

Whitewireforswitchingtheinputs.

Theotherwiresmaybeleavealone.

3/10

TheCVBSinputcable:

2． DIPsettings:

DIP =ONside（DOWN）=OFFside（UP）

1RGBEnabledRGBdisabled

2,AV1enabledAV1disabled

3AV2enabledAV2disabled

4RGB=HighdefinitionRGBRGBinput=1080pinputwithseparateH.Vsync.

5Reversesignal（greenwire=12V）switchtoCAM

video

Reversesignal（greenwire=12V）switchtoOEMvideo

6Nofunction,shouldbeatOFF.

7,8Nofunction,shouldbeatOFF.

3. the3sidekeybuttons

Theinputboxhas3sidekeys,theinstallermayuseittotunethe

picturedisplay,andtouchfunctionfortheconnectedDVDorotherdevices.

The3keysare:menu,+,‐.Thefirst5optionshasseparatestatememory.

Themodificationofoneinputisdifferentnotaffectingothers.



The3sidekeysare:menu,+,‐respectively.Whenmenuispress,OSDstringswillpopuponscreen,andtheinstallermay

adjustthebestvideoeffect.The+/‐willchangethevalue.

Thebrightness/contrast/saturationtunesthecolorofthecurrentvideoinput.

ThepositionH,positionVsettheimagepositiononscreen.

TheDVD/TUNER/NAVIistosettheIRcodeoutputtotheinstalleddevice,sopeopleuseoriginalknobortouchscreento

controltheinstalleddeviceinAV1/2mode.Left/rightpushwillpopuptheMMIicons,andpushwillexecutetheselected

icon.

Whensetto“none”，thecontroliconswillnotpopout

Whensetto“Prog”，theinstallercanuseDIP6=DowntoprogramtheIRcodeintotheinterface,soextranew

devicescanbecontrolled.

Externalvideoinputsockets：

Yellow：AV1’svideoinput.

White：AV2’svideoinput

Red：reversevideoinput.

Gray：IRoutputtocontrolDVD/TVininsertedvideo

mode.

4/10

TheGuideoptions:

Guide‐CTRL：shouldbesettoOFFinthismodel.

Guide‐L：nofunction。

Guide‐R：nofunction.

5．E06FO10001‐productManual

（1）theMainPage.

WhenthemoduleisjuststartedwithoutSDcardintheSD

slot,thepagewillshowacrossonwhitescreen,theinstaller

justclickonthecrosstomakethetouchcalibration.

WhenCalibrationisdone,themainpagewillbeshown.

Theinstallercanclickoneachicontogototheirrespective

functions.

Whenfirstcometomap,theuserwillbeaskedwherethenavigation

softwareis,bypoppingupthispictureontheleft.Aftertheuserentersthe

address,thenthemapsoftwarewillbeexecuted.

（2）theSettingspage.

Thispageisshownontherightside.Theusermaypress

theleft‐topicontogobacktothemainpage.

Thereare8‐iconsonthispage：

Navigationsetup:thelocationofEXEfileofthe

navigationsoftware,whenitisset,thenexttime

willtheunitwillpowerupwiththatsoftware.

GPSsystemmonitor：tocheckthesignal

receptionofnavigationsatellites。Thismodule

uses9600bps，COM2,itisautocompatiblewiththenavigationsoftware.

SystemSetup：itisusedtosetthelanguageofthismodule,e.g.ChineseorEnglish,etc.

Tou ch ‐Screencalibration：thisiconistomakethetouchpreciselydone,heclickthisicon,andcrosswill

beshownandhetouchthecrosstotillitdisappears.

Screenadjustment：thisiconisusedtosetthebrightness/Contrast,alsolocationofthepicture,this

moduledoesnotusethisfunctionsinceitisdigitalinside.

Volume：WhentheusertouchestheLCD,themodulemaybegiveabeep,heneedstoturnthisoptionoff

toremovethissound.

Systemtime：tosetthetimeofthisunit.Itmaybe

notneeded,becausetheunitmayalsogetthetime

fromtheGPS.

5/10

（3）Mediapage

ThemoduleinsidehasverypowerfulA6processorandmultimediaco‐processor,itcanplayMP3orMP5files

verysmoothly.TheAUXcablecanbeusedsothestereosoundgoestotheAUXportofthecarandgoesoutonthe

OEMspeakers.

whentheUSBcableisconnected,filesonitcanalsobe

played.

(4) Phone‐LinkPage

Thismodulehasverynicelytunedphone‐mirrorfunctionforandroidphones,alsothetouchfunctioncanalso

bedelived.[thismeans,theusercantouchtheOEMfoiltoselectthewantedmusic,goaroundonthemapdisplay,etc.]

ThemoduleisbasedonwinCEoperationsystem.

SETMAhasanotherE06FO...‐product,whichisbasedonandroidsystem,itcanmirrorbothandroidandiPhone

displayontocarscreen.

4.1thesoftwareupdateofthismodule

IftheinstallerneedstoupgradetheOSfirmware,heshouldinsertthe

upgradeSDcard,thenpoweritup,hewillseethiskindofre‐flashingpictures

andwaittillthecalibrationcrossisshown.

5. Parameters

No.nameparameter

1RGBmapresolution800X480HDsuggested.

2Av1,AV2,camvideo 0.7Vppwith75ohmimpedance

NTSC/PAL/SECAMautomaticswitch

3GPSantenna5Vactiveantennafromthegoldenfingerconnector.

4ReverseControlwire>5Vwillforceintocameramode.

Allthesewirescantolerate12Vfor<10seconds.

5NormalPowerconsumption4.8W

6Standbycurrent<10uA

7Reversetriggerthreshold>5Vtrigger

8Worktemperature ‐40~+85C

9 Size 15.2*9*2.1CM

10Workingtemperature ‐40~+85C.

11USB OTGfunction,1Aoutputwithsurgeof3A.

12CompatiblewithmapsNavione,navitel,Igo,Primo.sygic,etc.

14TheHDMIresolutioninputfromRGBportCompatiblewith800X600，1024X768，1280X720，720P，1080P.etc.

Autorecognitionsoftwareinside.

Navigationmouduleparameter

1CPUSiRFatlasVI（800MCortexA9+300MDSP）

2RAM256MBDDR3

6/10

3FLASH128MB

4StorageofmapSDcard

5OSWINCE6.0CORE

6Audiosupported|ape|flac|aac|wav|mp3|wma|ogg|

7Videosupported|rmvb|mp4|3gp|mov|avi|divx|xvid|wmv|mpg|rm|flv|mkv|

8Videodecoder.QVGA>25frame/sec

7/10

6．E06FO...productuser’smanual

FaNserieshas4‐corehighspeedinsidewith3GRAMandhigh‐sensitivityGPSreceiver,alloperationonitisjustlike

annormalandroidphone,itisdesignedforcarusage:

Ithasinternalphone‐mirrorfunction,AndroidandiPhonedisplaycanbothbemirroredtothecarscreen.

Ithasinternalwifimodule,whichcanbeconnectedtothehot‐spotofaphone,thuson‐linetraffic

informationcanbeoffered.Alsoon‐linenavigationlikeWAZEcanberunonit.

InternalBluetoothcanbeconnectedtothecarwithdatacommunication,andinternalaudioof

media/navigationcangototheOEMspeakers.Theuser’shands‐freefunctioncanalsobeused.

TheOEMtouchfoilcanbeusedtocontrolthenaviormirroredandroidphone,theinstallerdoesnotneed

toaddanotherfoil.

（1）Themainpage.

WhenthismodulestartsonthefirsttimewithoutaSD

cardintheslot,thecalibrationpagewillbeshown,the

installershouldtouchthecrosstillthepageisfinished.Then

thispagewillbeshown.

Eachiconhashisspecificfunction,therowonthe

bottomisforandroidoperation.whentheuserslidefrom

belowtotop,thisstringofcontroliconswillshowup.

（2）theLivetrafficicon.

Thefirsticonis“Livetraffic”,theinstallermayinstallmanyon‐linenavigationinthismodule,likeWAZEor

googlemap,hecanclickthisicontoexecutethewantednavigationsoftware.Hemayneedtosetthewifitohis

phone’shot‐spotforlivetrafficinformation.

Topickupjustonenavigationsoftwarefortheiconof“live‐traffic”,theinstallershouldgotosettings,thengo

to“GPS”，andonthefirstrow”GPSchoice”,hemaypickupthewantedsoftware.The2ndoptionisfornavi‐sound

onlyornavisoundmixedwhenGPSsoundandmediasoundaresenttogether.

Whentrafficinformationisdisplayed: Redfortrafficjam，Yellowslowlymovefarward，Greennicetraffic

condition.

8/10

(3) Themusicicon

Clickthemusicicon,thenapagelikethiswillbeshown：

ThisplayercaneitherplaythemusicontheSDcard,orthe

musicintheUSBdisk.Theusercanre‐insertaUSBdiskontothe

USBportanytime.

(4) Thesettingsicon

Theinstallercansetthewifi,andBluetoothofthis

module.Heshouldenablethehot‐spotofhisphone,and

makethemoduleconnectedtothatspotbywifi.

Theinstallercanalsosetthelanguage,displayand

manyotherfeatureinsidethispage.

WheninBluetoothconnection,theinstallershouldmakethemodule

connectedtocarbydataport.[seeleftpicture].Nowalmostallcarshas

dataportandhand‐freeport,whichisshownby2iconslikethepicture.

Whenthismoduleisconnectedtocar’sBluetooth,heshouldclick

thehandsfreeOFF,andmusic‐ON.Thenhemaystillusehisphonewhen

heislisteningtothismodule’saudiooutput.

TheaudiooutputofthismodulecanalsogototheAUXportofthecar.

(5) TheAPPsicon

Whenthisiconisclicked,apagelikerightsideis

shown,theusercangetalltheappshewant,hecanalso

installextraappsonit.

Alltheappsherearejustlikeandroidphoneusage.

(6) thephone‐mirroricon

Whenthisiconisclicked,thepageontherightsidewillbe

shown,thefirst2iconsareforandroidphoneconnection,ithas

9/10

imagemirroring,alsotheoemtouchcanbeusedtocontrolthephone.The3rdiconisforiPhoneconnection.Only

thepictureofiPhonewillbemirroredontocarscreen.

ForAndroidphones,itissuggestedtousethefirsticon,sincethismodethephoneischargedallthetime.

A．Android‐USBicon：

6.1Whentheandroidphoneisfirstconnected,thepictureonthe

rightsidewillbeshown,thentheuserconnecttheUSBcabletothe

phoneandthemodulebytheUSBport.Thephonewillasktheuserifhe

accept“debugmode”.HeselectsOK,thenthepictureofthephonewill

bemirroredontothecarscreen.

6.2AndroidUserinterface

Whenthephoneisconnected,theinterfacewillpushasoftwareontothephone,likethepicturehere.Itmakesthe

phoneshowsthesameUIasthecarscreen.Anditmaketheuserfeelsveryeasytopickuptheshortcutofapplicationhe

wantstoexecute.

Theusermayclickeveryicontomakeitexecute.Likethemusicandtelephoneicon.Hemayalsoholdononeicon,

theadialogwindowwillshowup,andhemaychoosetheappforthaticon.

6.3Navigation/Music/etcpages

Whenthe“musicicon”isclicked，themusicplayerinthephonewillbeexecuted,theusercanselectallmusic

inthephone.

Whenthe“navigationicon”isclicked，thenavigationinsidethephonewillbeexecuted,theusercanoperate

onthecartouchscreen,alltheoperationisjustliketouchingthephoneitself.Thiswaycanfreethedriver’shand

fromholdingthephone,alsotheimagequalityisreallynicesincetheconnectionistotallydigitalandhasnodetail

lossinthedisplay.

10/10

B．connectingtoandroidphonewithwifimode：

Thedisplayonthecarscreenisalready

self‐expanatory.

Makethemoduleconnectedtothehotspotofthe

phone,thenthedisplaywillbemirroredandtouch

operationoncarscreenwillbedonetothephoneaswell.

thefirsttimethephoneisconnectedtothismodule,

pleaseusetheUSBcable,sincethismoduleneedstopush

asoftwareonthephonetomakethis2screenshavethe

sameUI.

Thenlatertimes,theUSBconnectionisnotneeded

anymore.

C．UseWIFItoconnecttoaniPhone：

Firstenablethehot‐spotofthephone,andmakethismoduleconnectedtothatspot.

ThenclickontheairplayoftheiPhonetomirrorthepictureoftheiPhonetothecarscreen.

7. TheFaNParameters.

CPU RK3188/T four core ， 1.6G

RAM 1G DDRIII ，optionally 2G DDRIII

FLASH 8G EMMC Flash,max64G

WIFI RTL8188/RTL8723（with BT data delivery）

GPS reception HV5820

GPS Antenna 3V active，usually positioned within 30Seconds

Operation system Android 4.4

size Suitable for FOSP interfaces inside.

USB Compatible with several HUB，

Compatible with several USB camera，with fosp software for DVR function.

Compatible with several 3G/4G dongle.

GPSfrequency1575.42MHz

GPSrefreshspeed1Hz

GPSChannels66

GPSsensitivity ‐161dBm

GPSPrecision3.0mCEP

Voltin10~15V

Powerconsumption2.4W

Workingtemperature ‐20~85C

Table des matières

Autres manuels Setma Système de navigation automobile

Setma

Setma E06FO10000 Manuel utilisateur

Setma

Setma PCM4.1 Manuel utilisateur

Manuels Système de navigation automobile populaires d'autres marques

Clarion

Clarion Navigation In-Car Entertainment Manuel utilisateur

Rosen

Rosen DP-1001 Manuel utilisateur

Alpine

Alpine INE-W970HD Manuel utilisateur

Skoda

Skoda AMUNDSEN+ Manuel utilisateur

Blaupunkt

Blaupunkt TravelPilot DX-N Manuel utilisateur

Pioneer

Pioneer MZ360500EX Manuel utilisateur

Sanyo

Sanyo NVM-4030 - Easy Street - Automotive GPS... Manuel utilisateur

Kenwood

Kenwood DNN991HD Manuel utilisateur

AvMap

AvMap Geosat 2C Manuel utilisateur

Eonon

Eonon GE01B Manuel utilisateur

Pioneer

Pioneer AVIC-Z920DAB Manuel utilisateur

Nextar

Nextar M3-MX - Automotive GPS Receiver Manuel utilisateur

Furrion

Furrion NV2200 Manuel utilisateur

Mio

Mio MOOV 200-Series Manuel utilisateur

Prestigio

Prestigio GeoVision 5150 Manuel utilisateur

Hummer

Hummer 2006 H3 Manuel utilisateur

Magellan

Magellan Maestro 4210 - Automotive GPS Receiver Guide de configuration

Garmin

Garmin StreetPilot c510 Manuel utilisateur
