Serpent S400 Manuel utilisateur

INSTRUCTION MANUAL

& REFERENCE GUIDE

INTRODUCTION

Serpent enters the competitive electric touring car market

with the S400, which like all our previous cars, has been

designed to win straight from the box. Featuring an

ultra low center of gravity, optimised weight distribution,

high performance geometry and top quality materials

throughout, the S400 should see you in the winners circle

in no time. In fact everything associated with this car is

of the highest quality, from the packaging and supplied

manuals, right through to the product and race support.

INSTRUCTIONS

Serpent’s long tradition of excellence extends to their

instruction manuals, and this instruction manual is no

exception. The easy-to-follow layout is richly illustrated

with 3D-rendered full-color images to make your building

experience quick and easy. Following the instructions will

result in a well-built, high-performance racecar that will

soon be able to unleash its full potential at the racetrack.

SETUP

In certain assembly steps you need to make basic

adjustments, which will give you a good initial setup for

your Serpent S400. Fine-tuning the initial setup is an

essential part of building a high-performance racecar like

your S400. The seperate Serpent S400 Setup Book is an

excellent resource to aid you in making those adjustments

on your car.

EXPLODED VIEWS AND PARTS LIST

The exploded views and parts lists for the Serpent S400

are presented in the Reference Guide section in the back

of this manual. The exploded views show all the parts of

a particular assembly step along with the Serpent part

number. The parts lists indicate the part number and name

of each part for easy reference when ordering.

SAFETY

Included with your Serpent S400 kit is a document entitled

“Read This First” that covers safety precautions for the

assembly and use of this product. We strongly recommend

that you thoroughly read and understand that document,

and follow all the precautions.

The printed instruction manual included with your Serpent

S400 kit is very complete, though due to continuous

product development, more up-to-date information may

be provided at our Serpent.com website.

All information about the Serpent S400 is accessible from

the Serpent S400 product page found on Serpent.com

and can be accessed by simply typing serpent.com/

400001 into your web browsers address bar.

From the Serpent S400 product page you will find the

very latest information about your Serpent S400: reports

by team drivers and other experts, tips and tricks, setups,

image gallery and downloadable files including the latest

version of the instruction manual will be made available

as downloadable PDF files.

ASSEMBLY INSTRUCTIONS

A REAR ASSEMBLY 6

B CENTRAL ASSEMBLY 16

C FRONT ASSEMBLY 19

D LINKAGE ASSEMBLY 24

E SHOCK ASSEMBLY & MOUNTING 31

F FINAL ASSEMBLY 37

SERPENT.COM

CONTENTS

REFERENCE GUIDE

> REAR ASSEMBLY 45

> CENTRAL ASSEMBLY 46

> FRONT ASSEMBLY 47

> LINKAGE ASSEMBLY 48

> SHOCK ASSEMBLY 49

> TOWER MOUNTING 50

> FINAL ASSEMBLY 51

> PARTS LIST 52

Length after assembly / Gap between two items

Assembly path of one item into another

Group of items (within lines) should be assembled first

Direction the item should be moved

Glue one item to another

Press/Insert one item into another

Connect one item to another

Apply transmission grease (Grey), threadlock* (Blue), CA glue* (Red)

or differential grease (Orange). (*Items not included.)

Step number; the order in which you should assemble the

indicated parts

USING THE MANUAL

ASSEMBLY INSTRUCTIONS

Page

6Page

Page

CA Glue

To protect the batteries when mounted in the

chassis, you should lightly le the battery slots

as shown in red in image A below.

Note. The cells should not sit any lower than

the bottom of the chassis plate, as shown in

image B.

A B

To prevent the risk of the

carbon bre splitting in the

event of a crash you should

apply CA Glue around the

chassis’ edge and battery

slots as shown in red below.

Page

6Page

Page

Bag

Transmission Grease

M3x8

M3x10

M3x8

M3x10

M3x8

M3x10 M3x8

1:1

Fasteners

Apply the grease AFTER step 5

Page

8Page

Page

Bag

0.0°

3.0°

Transmission Grease

M3x8

1:1

Fasteners

Page

8Page

Page

Bag

Differential Grease

CA Glue

Refer to the Setup book for detailed

differential setting explanation.

5x8

Transmission Grease

Page

10 Page

Page

Bag

M3x8

1:1

Fasteners

10x15
