4
Contents
! Warnings, Cautions and Notes ......................................................... 2
Introduction ...................................................................................... 6
1.1
Standard accessories..........................................................................................................9
1.2
Optional accessories..................................................................................................9
2
Camera overview ....................................................................... 10
2.1
Function keys .............................................................................................................10
2.2
Interface.......................................................................................................................14
3
Basic operation .......................................................................... 15
3.1
Battery Installation and Replacement ..............................................................15
3.1.1
Inserting or removing battery .....................................................................15
3.1.2
Replacing battery..............................................................................................16
3.2
Battery safety and usage ......................................................................................17
3.3
Quick access...............................................................................................................18
3.3.1
Capture an image.............................................................................................18
3.3.2
Temperature measurement ..........................................................................18
3.3.3
Freeze and save image...................................................................................20
3.3.4
Viewing stored Images...................................................................................20
3.3.5
Export saved images.......................................................................................21
3.3.6
LED screen settings .........................................................................................21
3.3.7
Menu operating instructions.........................................................................21
4
Operation guide ......................................................................... 22
4.1
Graphic interface description ...............................................................................22
4.1.1
Screen graphic interface..............................................................................22
4.1.2
Floating bar interface......................................................................................24
4.1.3
Main menu...........................................................................................................24
4.1.4
Sub menu interface......................................................................................25
4.2
Measurement Object Adding................................................................................25
4.3
Recording.....................................................................................................................26
4.4
Photo .............................................................................................................................26
4.5
Preview.........................................................................................................................27
4.6
Settings ........................................................................................................................28
4.6.1
General setting ..................................................................................................28
4.6.2
Temperature measurement setting ...........................................................32
4.6.3
Adjustment..........................................................................................................33
4.6.4
Image settings...................................................................................................34
4.6.5
Network settings...............................................................................................37
4.6.6
SD card management .....................................................................................37
