Legal regulations and standards:
•Electrical connection of the detector may only be carried out by a competent person with electrician qualification who
is familiarized with the "Instruction Manual" in detail.
•The Instruction Manual is part of the product and it is necessary to keep it for the entire service life of the product.
•The Instruction Manual must be transferred to any other owner or user of the product.
•The disposal must be performed in compliance with the Directive 2008/98/ECof the European Parliament and of the
Council - on waste and the Directive 2012/19/EU of the European Parliament and of the Council – on waste electrical
and electronic equipment (WEEE), as amended.
•The sensors are delivered in packages, which guarantee resistance to mechanical influences and that meet the
conditions with the European Parliament and Council Directive 94/62/ECon packaging and packaging waste), as
amended.
•The final metrological inspection – comparison with standards or working instruments – is carried out for all the
products. Continuity of the standards and working measuring instruments is ensured within the meaning of the
Section 5 of Act no.505/1990 on metrology. The manufacturer offers a possibility to supply the sensors calibrated in
SENSIT s.r.o. laboratory (according to EN ISO/IEC 17025 standard) or in an Accredited laboratory.
Application:
The temperature sensors PTS310A are designed for temperature measurements of gaseous substances in outdoor on
the wall of buildings and in rooms, offices, or even production halls.The temperature range for application of the sensor
is – 30°C to 100 °C.The sensors may be used for all control systems compatible with the Pt 1000 temperature sensor
with a temperature coefficient of 3850 ppm /°C.The sensor meet the ingress protection IP65 according to the
EN 60 529 standard. The sensors are suitable for temperature measurement in chemically non-aggressive
environments.
Recommended use and location of sensors:
•The temperature measuring in outdoor
- the recommended location of the sensor is on the coldest side of the building (north or northwest), without direct
sunlight, in 2/3 the height of the building wall
•The temperature measuring in rooms, offices, or even production halls
- the recommended location of the sensor is on the inner wall at a height of 1.5 m, in place with the movement of the
people, out of place with sunshine influence and out of places with the influence of temperature radiators or lighting
Warnings and restrictions:
The sensors must not be used for measuring in locations
•Where the specified technical parameters and operating conditions are not adhered
•Where the sensor is exposed to mechanical action
•With explosion hazard
•With chemically aggressive environment that does not correspond the used metal materials
•Where the sensor is exposed to prolonged immersion in liquid or intense jetting liquid
It is not suitable to use the sensors for measuring temperature in locations:
•Where exposure to direct heat radiation from surroundings or to sunlight may occur
•Where there is not free access of air and where there are some barrier of flow (area under the windows, niches in the
wall space close to furniture, etc.)
•where regarding to warm air from the interior space there could be occur a measurement error (the space above the
windows, doors and ventilation openings)
•on the facade with the large thermal capacity, on the wall in which is placed for example chimney
•Where the sensor might be exposed to effects of strong organic and inorganic acids with medium and strong
concentrations at high temperatures, weak organic acids with high concentrations and high temperatures, chlorinated
hydrocarbons, and undiluted alkaline substances.
Failure to follow the said recommendations will negatively affect measurement accuracy, reliability and service life of the
Declaration of conformity:
SENSIT s.r.o. provides the product with the EU Declaration of Conformity issued according to Act No. 91/2016 Coll.
and Act No. 22/1997 Coll., as subsequently amended. The product is in accordance with the following directives:
•European Parliament and Council Directive 2011/65/EU of 8 June 2011 on the restriction of the use of certain
hazardous substances in electrical and electronic equipment and Commission delegated Directive 2015/863/EU
of 31 March 2015 amending annex II to Directive 2011/65/EU, as amended
Product safety and technical parameters were evaluated according to the following standards and norms, as amended:
•EN 60730-1, EN 60730-2-9, EN 60751, EN 60 529
