Sennheiser WICOS AP Dimensions
Conference Systems | WiCOS
Features
jInterference resistant transmission in the 2,4 and 5 GHz band
j128-bit key encrypted communication
jTransmission radius of 30 meters
jThree status LEDs
jEthernet configuration socket RJ45 for integrated webserver
jSDC 8200 CU connection socket RJ45 (in/out)
jDC input hollow jack socket 5.5 x 2.1 mm
jwall, tripod or table mounting
jDelivery Includes: WiCOS AP access point
3 rod antennas
User manual CD-ROM
Quick-Guide
1m CAT5 network cable
Recommended Accessories
jWiCOS transport case
Rollable hardcase for 12 delegate units,
1 WiCOS AP and accessories Art.-No. 502071
jWiCOS NT-AP
DC Adaptor Art.-No. 502897
General Description
The small stand-alone access point is the central interface of WiCOS. It establishes
a wireless RF link on the basis of the WLAN protocols 802.11 a / g enhanced with
further security layers to provide maximum protection from other devices. One of
the three antennas is dedicated to continuously scan for RF interference. In order to
avoid disturbance by RF interference the WiCOS AP automatically switches between
the 2.4 GHz and 5 GHz band. Thus stable wireless communication can be assured. A
128-bit key encrypted transmission is always active, which means that the confe-
rence is safe from unauthorized listeners. The access point can be operated straight
out of the box or configured by customers needs. A password-secured advanced
set-up menu provides the complete system configuration accessible with a standard
internet browser. For advanced features like e.g. simultaneous translation and PC
control the Access Point can be connected to the wired SDC 8200 conference system.
Technical Data
Frequency response ...........................150 Hz.....15,000 Hz
RF frequency bands......................................2,4 GHz; 5 GHz
Signal-to-noise ratio ......................................... > 70 dB (A)
Power supply...............................................................24 V DC
Current consumption ...................................................... 6 W
Operating temperature .....................................+5 - +45 °C
Colour........................................................................RAL 7035
Dimensions............................................ 260 x 230 x 38 mm
Weight............................................................approx. 1220 g
WiCOS AP
Art.-No. 502068
Profile
An access point for wireless conference application, easy
to operate and set up, shall work safely encrypted in both,
the 2,4 GHz and 5 GHz band to avoid interference from
other devices. It shall ensure a stable RF link to delegate
or chairman units within a radius of 30 meters. LEDs shall
provide status indication. It shall operate safely without
customer configuration but offer as well extensive opera-
tion settings configurable via Ethernet. All setup configu-
rations shall be accessible with a standard web browser.
The access point works seamlessly in conjunction with a
cable bound conference system.
