MKE 1 - Care and Cleaning Instructions

The MKE 1 is a high-quality, sub-miniature clip-on microphone which combines

outstanding sound quality and rugged design with extremely small dimensions.

To ensure continuous optimum performance, please observe the following care and

cleaning instructions.

General care instructions

Use the MZC 1-1 and MZC 1-2 frequency response caps and

the MZC 1-3 make-up protectors to avoid soiling and dysfun-

ctions.

Store the MKE 1 in a dry, dust-free environment.

Avoid extreme bending and tearing of the cable.

Avoid knots in the cable.

Frequency response cap

Make-up protector

Mikrophone sound inlet

Mikrophone head

Anti-kink sleeve

Connector

The MZC 1-1 and MZC 1-2 frequency response caps

To wear the MKE 1 directly on the skin, use the large MZC 1-2 frequency response

cap which offers an extended protection against the ingress of sweat.

Regularly clean or replace the frequency response caps to avoid sound alterations.

Cleaning after use

Remove the frequency response cap from the microphone capsule. Hold the micro-

phone by the cable and not by the anti-kink sleeve.

Use a fine bristle brush and isopropyl alcohol to remove make-up residues and

other buildup from the gauze.

Gauze

MKE 1 - Cleaning instructions 1/2

The microphone capsule

The microphone capsule features an overmold which only serves as an anti-kink sleeve.

The microphone capsule itself is protected from moisture.

Cleaning after use

Remove the frequency response cap from the microphone

capsule. Hold the microphone by the cable and not by the

anti-kink sleeve.

Shake the microphone capsule to remove excess moisture.

Aqua

dest

Bathe the microphone capsule in isopropyl alcohol to loosen

make-up residues and other soiling.

Do not use a cloth or a bristle brush to clean the micro-

phone sound inlet.

Dry the microphone for approx. 12 hours. The microphone

sound inlet has to point downwards during drying.

The cable

The anti-kink sleeve on the connector and the microphone is designed to meet the highest

requirements in quality. The use of additional adhesive tapes or shrink-on tubes can dam-

age the material and reduce the service life of the cable.

Onlyuselavaliertape(LAV-Tape)toattachthecabletotheskin.

Lavalier tape (LAV-Tape) is available as an original Sennhei-

ser accessory.

Cleaning after use

Use a cloth or a ﬁne bristle brush and isopropyl alcohol to

remove make-up residues or other soiling.

NOTE: Particular hints for MKE 1 - musical (M) variants

Only use destilled water and a slightly damp cloth for

cleaning the cable.

When cleaning be extremely careful, only use low

pressure, only clean little sections at a time.

Otherwise beads may occur.

Do not use isopropanol! It may damage the surface of the

cable.

Aqua

dest

MKE 1 - Cleaning instructions 2/2

Sennheiser electronic GmbH & Co. KG

Am Labor 1, 30900 Wedemark, Germany, www.sennheiser.com

Printed in Germany, Publ. 09/19, 540099/A03

12 h
