Sennheiser Evolution e 904 Manuel utilisateur

e 904

Bedienungsanleitung

Instruction manual

Notice d‘emploi

Istruzioni per l‘uso

Instrucciones de uso

Manual de utilização

Gebruiksaanwijzing

Инструкция по эксплуатации

使用说明

Stage Microphones







1 2 3

125 Hz

250 Hz

500 Hz

1,000 Hz

2,000 Hz

4,000 Hz

8,000 Hz

16,000 Hz

30°

0°

180°

150°

120°

60°

90°

30°

0°

180°

150°

120°

60°

90°

- 50

- 60

- 70

- 80

- 90

- 40

dBV

0°, 1 m

+ +

XLR6.3 mm

XLR

6.3 mm

symmetrical

XLR

ENFRITPTNLRUZH ES DE

Important safety information

• Please read this instruction manual carefully and completely before

using the product.

• Make this instruction manual easily accessible to all users at all

times.

• Always include this instruction manual when passing the product on

to third parties.

Before operation

• Never open the housing of the product. If products are opened by

customers in breach of this instruction, the warranty becomes null

and void.

• Only use attachments, accessories or spare parts specified by

Sennheiser.

During operation

• Liquids entering the product can short-circuit the electronics or

damage the mechanics. Keep all liquids away from the product.

• Solvents or cleansing agents can damage the surface of the product.

Only use a soft, slightly damp cloth to clean the product.

• Do not expose the product to extreme temperatures.

After operation

• Handle the product with care and store it in a clean, dust-free

environment.

Intended use

Intended use includes:

• having read this instruction manual, especially the chapter “Impor-

tant safety information”,

• using the product within the operating conditions and limitations

described in this instruction manual.

“Improper use” means using the product other than as described in

this instruction manual, or under operating conditions which differ

from those described herein.

The e 904

Full of sound – full of life

With its consistent frequency response, the e 904 creates a sound that

is as transparent as it is harmonic and that can be wonderfully shaped.

It can be cleanly embedded in the drum mix thanks to its precise

attacks and voluminous body.

The set receives an extremely energetic and defined sound with this

microphone. The e 904 reliably withstands even the hardest direct

hits. Thanks to its practical clip, it is child‘s play to attach to the rims

of snares and tom-toms. And, with its compact form, it takes up a very

small amount of space.

Features

• Compact dynamic microphone

• Consistent frequency response offers wide flexibility for individual

sound designs

• Very quick transient response delivers precise attacks

• Extremely simple handling and flexible positioning

• Humbucking coil

• Extremely rugged metal housing

Package contents

1 microphone e 904

1 MZH 604 microphone clamp

1 pouch

1 user manual

Product overview A*

1 Sound inlet basket

2 Microphone clamp

3 XLR-3 connector

Diagrams can be found on the cover pages.

ENFRITPTNLRUZH ES DE

Using the microphone

Positioning the microphone on a drum B

XUse the microphone clamp 2to attach the e 904 to the rim of the

drum.

Pos. Resulting sound Commentary

B.1 • More fundamental

• Little overtones

Position on the drum:

3–5 cm above the batter head, the

fundamental tone to overtones ratio

can be adjusted via the angle.

The most balanced results are obtai-

ned at an angle of 30–60°.

B.2 • Less fundamental

• Many overtones

B.3 Use of a second e 904 for picking up

the resonant head and the snares. If

necessary, activate phase reversing for

one of the microphones.

Positioning the monitor loudspeakers

XTo prevent feedback and crosstalk, postion your monitor loudspea-

kers in the angle area of the highest cancellation of the microphone

(approx. 180°).

Cleaning and maintaining the e 904

Caution Liquids can damage the electronics of the product!

Liquids entering the housing of the product can cause a

short-circuit and damage the electronics.

XKeep all liquids away from the product.

XDo not use any solvents or cleansing agents.

XOnly use a soft, slightly damp cloth to clean the product.

Specifications

Transducer principle dynamic

Frequency response 40 ... 18,000 Hz

Pick-up pattern cardioid

Sensitivity

(free field, no load at 1 kHz)

2.0 mV/Pa

Nominal impedance (at 1 kHz) 350 Ω

Min. terminating impedance 1 kΩ

Connector XLR-3

Dimensions Ø 41 x L 63 mm

Weight 125 g

The polar diagram and the frequency response curve Ccan be found on

the cover pages.

The XLR-3 connector assignment Dcan be found on the cover pages.

ENFRITPTNLRUZH ES DE

Manufacturer Declarations

Warranty

Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months

on this product.

For the current warranty conditions, please visit our website at

www.sennheiser.com or contact your Sennheiser partner.

FOR AUSTRALIA ONLY

Sennheiser goods come with guarantees that cannot be excluded

under the Australian Consumer Law. You are entitled to a replacement

or refund for a major failure and compensation for any other reaso-

nably foreseeable loss or damage. You are also entitled to have the

goods repaired or replaced if the goods fail to be of acceptable quality

and the failure does not amount to a major failure.

This warranty is in addition to other rights or remedies under law.

Nothing in this warranty excludes, limits or modifies any liability of

Sennheiser which is imposed by law, or limits or modifies any remedy

available to the consumer which is granted by law.

To make a claim under this warranty, contact

Sennheiser Australia Pty Ltd, Unit 3, 31 Gibbes Street Chatswood NSW

2067, AUSTRALIA.

Phone: (02) 9910 6700, email: [email protected].

All expenses of claiming the warranty will be borne by the person

making the claim.

The Sennheiser International Warranty is provided by Sennheiser

Australia Pty Ltd (ABN 68 165 388 312), Unit 3, 31 Gibbes Street

Chatswood NSW 2067 Australia.

In compliance with the following requirements

• WEEE Directive (2012/19/EU)

Please dispose of this product at the end of its operational lifetime

by taking it to your local collection point or recycling center for such

equipment.

CE Declaration of Conformity

• RoHS Directive (2011/65/EU)

The declaration is available at www.sennheiser.com/download.

e 608

e 614

e 609 silver

e 604

e 602-II

e 835

e 845

e 865

e 901

e 902

e 904

e 906

e 908

e 914

e 935

e 945

e 965

Sennheiser electronic GmbH & Co. KG

Am Labor 1, 30900 Wedemark, Germany

www.sennheiser.com

Printed in Germany, Publ. 12/16, 094274/A03
