e 835

Instruction manual

Stage Microphones

Important safety information

• Please read this instruction manual carefully and completely

before using the product.

• Make this instruction manual easily accessible to all users at all

times.

• Always include this instruction manual when passing the product

on to third parties.

Before operation

• Never open the housing of the product. If products are opened by

customers in breach of this instruction, the warranty becomes null

and void.

During operation

• Liquids entering the product can short-circuit the electronics or

damage the mechanics. Keep all liquids away from the product.

• Solvents or cleansing agents can damage the surface of the

product. Only use a soft, slightly damp cloth to clean the product.

• Do not expose the product to extreme temperatures.

After operation

• Handle the product with care and store it in a clean, dust-free

environment.

Intended use

Intended use includes:

• having read this instruction manual, especially the chapter

“Important safety information”,

• using the product within the operating conditions and limitations

described in this instruction manual.

“Improper use” means using the product other than as described in

this instruction manual, or under operating conditions which differ

from those described herein.

The e 835

Thee835isacardioidleadvocalstagemicrophonespeciallydesigned

toperformunderpressure.

Cardioidisthemostcommonlyusedpick-uppatternforlivePA

applications.Itprovidesgoodon-stagefreedomandalsopicksup

soundfromthesides.The“dead”sideisattherear.Thispatternis

goodforpickingupseveralvocalistsatonce,e.g.achoirorensemble.

Thee835’sbalancedfrequencyresponsemaintainssignalquality

whenmovingonandoffaxisduringperformance.Thegentlepresence

boostensuresvocalclarityandprojection.Theminimalproximity

effectprovidesforconsistentlyclearbass-endperformancewhensing-

ingcloserto,orfurtherfromthemicrophone.

Thecardioidpick-uppatternprovidesexcellentfeedbackrejection,

enablingthemicrophonetohandlehighersoundpressurelevels.The

ruggedmetalconstructionandinternaldampingisolateshandling

noise.

Thee835Svariantfeaturesasilenton/offswitch.

Features

• Dynamiccardioidmicrophoneforspeechandvocals

• Clearreproductionwithahighpresence

• Consistentsoundqualityatvaryingdistancesorwhenoffaxis

• Highsoundpressurehandlingcapability

• Optionalsilenton/offswitch

• Shock-mountedcapsuleprovidesexcellentsuppressionofhandling

noise

• Excellentfeedbackrejection

• Humbuckingcoil

• Ruggedmetalbody

Package contents

1 e835/e835Smicrophone

1 MZQ800microphoneclamp

1 pouch

1 instructionmanual

Product overview A*

1 Soundinletbasket

2 XLR-3connector

3 On/offswitch(e835Sonly)

4 Screw(e835Sonly)

Diagramscanbefoundonthecoverpages.

Using the microphone

Switching the e 835 S on/off

XUsetheon/offswitchtoswitchthethee835Sonoroff.

XIfnecessary,usethescrew4tolocktheon/offswitch3 inthe

“on”position.

Positioning the microphone C

Pos. Resulting sound Commentary

C.1• Highproximityeffect

(largebassboost)

• Powerful,directsound

Verylittlecrosstalk

fromothersound

sources

C.2• Lessproximityeffect

(lessbassboost)

• Someroomambience,

natural,balancedsound

Morecrosstalkfrom

othersoundsources

C.3 • Verylittleproximityeffect

(minimalbassboost)

• Moreroomambience,

indirectsound

Highercrosstalkfrom

othersoundsources

Ifsibilanceoccurs:

XPositionthemicrophoneslightlytothesideandnotdirectlyinfront

ofthemouth.

Positioning the monitor loudspeakers B

XTopreventfeedbackandcrosstalk,postionyourmonitorloudspeak-

ersintheangleareaofthehighestcancellationofthemicrophone

(approx.180°).

Cleaning and maintaining the e 835

Caution Liquids can damage the electronics of the product!

Liquidsenteringthehousingoftheproductcancause

ashort-circuitanddamagetheelectronics.

X

Keepallliquidsawayfromtheproduct.

X

Donotuseanysolventsorcleansingagents

XUnscrewthesoundinletbasket1.

XRemovethefoaminsertfromthesoundinletbasket1.

XUseaslightlydampclothtocleanthesoundinletbasket1 from

theinsideandouside.

XReinsertthefoaminsertintothesoundinletbasket1andreplace

thesoundinletbasketonthemicrophoneandscrewittight.

Specifications

Transducerprinciple dynamic

Frequencyresponse 40…16,000Hz

Pick-uppattern cardioid

Sensitivity

(freefield,noloadat1kHz)



2.7mV/Pa

Nominalimpedance(at1kHz) approx.350Ω

Min.terminatingimpedance 1kΩ

Connector XLR-3

Temperaturerange 0°Cto+40°C

Dimensions Ø48xL180mm

Weight 330g

ThepolardiagramandthefrequencyresponsecurveDcanbefoundon

thecoverpages.

Connector assignment

+ +

.3 mm

XLR

6.3 mm

symmetrical

XLR

Manufacturer Declarations

Warranty

SennheiserelectronicGmbH&Co.KGgivesawarrantyof24monthson

thisproduct.

Forthecurrentwarrantyconditions,pleasevisitourwebsiteat

www.sennheiser.comorcontactyourSennheiserpartner.

In compliance with the following requirements

• WEEEDirective(2012/19/EU)

• Pleasedisposeofthisproductattheendofitsoperationallifetime

bytakingittoyourlocalcollectionpointorrecyclingcenterforsuch

equipment.

CE Declaration of Conformity

• RoHSDirective(2011/65/EU)

• EMCDirective(2004/108/EC)

Thedeclarationisavailableatwww.sennheiser.com.

5-10 cm

>10 cm







e 835

e 835 S

125 Hz

250 Hz

500 Hz

1,000 Hz

2,000 Hz

4,000 Hz

8,000 Hz

16,000 Hz

30°

0°

180°

150°

120°

60°

90°

30°

0°

180°

150°

120°

60°

90°

-40

-50

-60

-70

-80

-90

0°, 1 m

100

200

500

1,000

2,000

5,000

10,000

20,000

dBV

e 608

e 614

e 609 silver

e 604

e 602-II

e 835

e 845

e 865

e 901

e 902

e 904

e 906

e 908

e 914

e 935

e 945

e 965

e 608

e 614

e 609 silver

e 604

e 602-II

e 835

e 845

e 865

e 901

e 902

e 904

e 906

e 908

e 914

e 935

e 945

e 965
