DW Ofﬁce USB ML

Headband

Ear hook

DW Ofﬁce USB ML

Single-sided DECT headset

Enjoy your calls in HD voice clarity and get

natural high-deﬁnition sound for superior

voice clarity. Work safely ensured that the

ActiveGard™ technology will protect your

hearing.

Imagine making every call in comfort, and

being able to focus on what’s important:

the CONVERSATION.

Beneﬁts and Features:

Optimized for Microsoft Lync

Iconic design – crafted for best comfort

Sennheiser HD voice clarity – wideband

sound for natural listening experiences

igh comfort wearing styles - choose be-

tween ear hook and headband wearing style

Noise-canceling microphone ﬁlters out

unwanted background noise

Pairing for desk sharing and phone

conferences – intuitive and easy to set up

Microphone mute and volume up and

down – intuitive user interface

Full workday talk time – 8 hours in wide-

band sound mode and 12 hours in

narrowband sound mode

Re-charge 50% of your battery in

20 minutes – intelligent fast charging

Long distance wireless range – in typical

ofﬁce building: up to 55 m and in

line of sight: up to 180 m

ActiveGard™ technology – protects your

hearing against acoustic shock

Product name DW Ofﬁce USB ML - EU DW Ofﬁce USB ML - UK DW Ofﬁce USB ML- US DW Ofﬁce USB ML - AUS

Order name

EAN No.

DW 10 USB ML – EU DW 10 USB ML – UK DW 10 USB ML – US DW 10 USB ML – AUS

40 44155 05200 8 40 44155 05202 2 40 44155 05201 5 40 44155 05203 9

UPC No. 6 15104 18203 5 6 15104 18206 6 6 15104 18204 2 6 15104 18208 0

Art. No. 504466 504468 504467 504469

Technical Data

DECT for EU, UK, AUS DECT CAT-iq (1.880 to 1.900 MHz)

DECT for US DECT 6.0 (1.920 to 1.930 MHz)

GAP compatible Yes (Headset)

Headset Connect to Base

Base Station Connect to softphone

Headset Auto Link to Base Yes, can be activated on the base station

Firmware Requirement V. 89 or higher for headset and base

MS Communicator 2007 R2 certiﬁed/

optimized

Yes

MS Lync certiﬁed/optimized Yes

Microphone

Frequency response Wideband

Mode

150 Hz – 6.8 KHz

Frequency response Narrowband

Mode

300 Hz – 3.5 KHz

Mute Microphone Yes

Speaker

Speaker type Neodynium Magnet Speaker

Frequency response Wideband

Mode

150 Hz – 6.8 KHz

Frequency response Narrowband

Mode

300 Hz – 3.5 KHz

All acoustic parts observe the TIA-920 wideband standards

Product Information

General Data

Operational temperature range +5 °C to + 45 °C (+41 °F to +113 °F)

Storage temperature range -20 °C to + 70 °C (-4 °F to +158 °F)

Weight, ear hook version 22 g

Weight, headband version 50 g

Ear pad size ø 50 mm / 1.96 inches

Battery (Lithium Polymer) Exchangeable for service (see manual)

Personalization Yes with nameplate on headset

Range – line of sight 180 m

Range – in typical ofﬁce building 55 m

Automatic power adjustment Yes (distance between headset and base)

Talk time in Wideband Mode Up to 8 hours

Talk time in Narrowband Mode Up to 12 hours

Stand by time Up to 100 Hours

Auto – headset OFF when out of

range

Yes ➠after 30 minutes

Charge time 0 – 50% 20 minutes

Charge time 0 – 100% 1 hour

Packaging

Package dimensions (H x W x D) 16.5 cm x 16 cm x 16 cm

Package weight 940 g

Units in distributor master carton 8

Master carton dimensions

(H x W x D)

36 x 38 x 38 cm

Master carton weight 8.85 kg

Safety

Automatic Acoustic Shock

Protection

YES ➠ActiveGard™

EU/AUS Limiter YES ➠Activation by dip switch

Delivery content

Headset (with name plate for ear hook and distance holder)

Base Station

Power supply

USB cable

Headband

1 bendable ear hook (mounted on headset)

Name plate holder for headband and name plate instruction

Printed QuickGuide

CD with Manual, QuickGuide, nameplate template and HeadSetup Installation Program

Printed safety guide

Accessories

Order name Art. No EAN No. UPC No.

Spare earhook set EH set DW 10 F 504352 40 44155 050868 6 15104 18035 2

Headset charger CH 10 504366 40 44155 050998 6 15104 18053 6

Spare HS Charger - USB CH 10 USB 504365 40 44155 051001 6 15104 18055 0

Multi USB Power Source MCH 7 504348 40 44155 050820 6 15104 18030 7

Single components

Headset and base station can be purchased separately. This allows a 2nd headset to be added to any DW Series base station or used as a spare.

Order name Art. No EAN No. UPC No.

Single headset of DW 10 DW 10 HS 504324 40 44155 050585 6 15104 17992 9

DW Base set USB ML DW BS USB ML - EU 504482 40 44155 052169 6 15104 18221 9

DW Base set USB ML DW BS USB ML - UK 504484 40 44155 052183 6 15104 18223 3

DW Base set USB ML DW BS USB ML - US 504483 40 44155 052176 6 15104 18222 6

DW Base set USB ML DW BS USB ML - AUS 504485 40 44155 052190 6 15104 18224 0

Base including power supply and USB cable

Product Information

Spare parts

Order name Art. No EAN No. UPC No.

Power supply US UNI PS US 01 92893 40 12418 928933 6 15104 92893 0

Power supply AUS UNI PS AUS 01 520334 40 44156 023083 6 15104 13459 1

Power supply UK UNI PS UK 01 92892 40 12418 928926 6 15104 92892 3

Power supply EU UNI PS EU 01 94707 40 12418 947071 6 15104 94707 8

Spare battery DW BATT 03 504374 40 44155 051087 6 15104 18067 3

Headband SHS 02 DW 10 spare 504344 40 44155 050783 6 15104 18024 6

Earpad HZP 25 DW 10 504349 40 44155 050837 6 15104 18031 4

Earhook bendable EH DW 10 B 504370 40 44155 051049 6 15104 18062 8

Name plate set Name plate set, DW 10 504353 40 44155 050875 6 15104 18036 9

USB cable USB cable - DW 504363 40 44155 050974 6 15104 18051 2

Type approvals

Worldwide TCO ‘07

EMC - EN 301489-6

RADIO - EN 301406

Safety - EN 60950-1

SAR (headset) - EN 50360 ref. EN 62209-1

This product meets the safety requirements of CSA

No. 231437

Europe

USA:

Approved by

Canada: Industry Canada RSS 213 Issue 2

IC ID 2099 D-TDB1 (base station)

IC ID 2099 D-TDH1 (headset)

FCC 47 CFR Part 15 (d)

FCC ID: DMOCDBDIB (base station)

FCC ID: DMOCDHDKB (headset)

AS/ACIF S004

USA:

Australia
