SENKO C-20 Manuel utilisateur

Central heating

COOKERS

C-20 and C-30

SN-EN-09/13

SENKO cookers C-20 and C-30 –Instruction manual 1

Dear client, thank you for choosing a SENKO cooker !

This product was designed and manufactured to its minutest

details in order to fulfill your every need for functionality and

safety.

This Instruction manual will teach you to operate your cooker

properly, so please read the manual carefully before using the

cooker.

Senko management

Symbols used in this INSTRUCTION MANUAL :

ATTENTION WARNING

SAFETY ADVICE AND RECOMMENDATIONS

SENKO cookers C-20 and C-30 –Instruction manual 2

CONTENTS

1. GENERAL…………………….………………………………………………4

1.1. FUEL……………………………………..………………………………..6

1.2. FEEDING………………………………………………………………….6

1.3. CHIMNEY………………………………………………………………….7

1.3.1. CHIMNEY CAP ……………………………………………………...7

1.3.2. CHIMNEY FUNCTION …………………………………...…………..8

1.4. INSULATION……………………………….……………………….…...10

2. WARNINGS AND SAFETY……………………………………..…..…….10

3. TECHNICAL FEATURES…………………………………...…….………11

4. INSTALLATION……………………………………………………………14

4.1. POSITIONING………………………………………………………...…14

4.2. CHIMNEY PREPARATION AND CONTROL …………………………..15

4.3. CONNECTING TO CHIMNEY …………………………………………..15

4.4. FRESH AIR VENTS ……………………………….……………………18

4.5. CENTRAL HEATING SYSTEM CONNECTION ………………………...18

4.5.1. COOKER THERMAL PROTECTION ………………………………...20

4.5.1.1. Thermal two-way safety valve …………………….……………21

4.5.1.2. Thermal safety valve …………………….………………….…22

4.5.1.3. Anti-freezing protection …………………………………..….…23

4.5.1.4. Heat exchanger ……………………..…………………..…....24

4.5.2. INSTALLATION TESTING …………………………………………..25

4.5.3. RECEIVING AND MAINTAINING THE INSTALLATION ……………....25

5. HANDLING THE PRODUCT ……………………………………………..26

5.1. DIRECTING THE FLUE GAS …………………………...............…..…26

5.2. AIR ADJUSTMENT AND REGULATION..............................................26

5.3. FIREBOX GRATE.............................................................................28

5.4. FIRING ……………………………...………………………………..…29

5.4.1. PROCEDURE……………………………………………………...29

SENKO cookers C-20 and C-30 –Instruction manual 3

5.4.2. OPTIMUM USE VALUES …………………………………………...30

5.4.3. ADDING FUEL …………………..…………………………………31

5.4.4. FEEDING IN TRANSITION PERIOD ……………………………..….32

6. CLEANING……………………………...…………...............................…32

6.1. CLEANING THE COOKER.................................................................32

6.2. CLEANING THE FLUE GAS CHANNEL..............................................33

7. MAINTENANCE ………………………………………........................…33

7.1. AUTOMATIC REGULATOR...............................................................34

7.2. FIRING REGIME SWITCH MECHANISM............................................35

7.3. OLD COOKER DISPOSAL …………………...........................……….35

7.4. SPARE PARTS ……………………………….…………………………35

8. MALFUNCTIONS / CAUSES / SOLUTIONS …………………………..36

9. TECHNICAL SUPPORT ………………………………………………....38

10. TECHNICAL DATA …………………………………………………..……39

11. TERMS OF WARRANTY …………………………………………………40

WARRANTY …………………………………………………………….………41

INSTALLATION REPORT ………………………………………...…….…….42

CE MARKING ………………………………….……………………………….43

SENKO cookers C-20 and C-30 –Instruction manual 4

1. GENERAL

Solid fuel central heating cookers without oven

E2320L C-20 inox lux

E2320D C-20 inox lux

E2330L C-30 inox lux

E2330D C-30 inox lux

are models from the SENKO cookers palette which can accommodate your

needs in the best possible way. Therefore, we ask you to CAREFULLY

READ THESE INSTRUCTIONS, which will help you to achieve the best

possible results already during the initial use.

The manufacturer is not responsible for any consequences (people

or animal injuries or property damages) resulting from failure to comply

with this Manual.The cooker is hot during operation and the use of

protective heat insulated gloves is compulsory during handling.

Children and infirm individuals are not allowed to handle the cooker.

The external appearance of the cooker is shown on the first page of this

Manual. Cooker principal parts are made of stainless steel boiler plates and

castings of quality grey cast. The cookers are produced with flue gas

connection point on the left or the right side. When ordering the cooker or

the spare parts, it is necessary to state its full designation, for

example: cooker E2320D C-20 inox lux; which means that the flue gas

connection is on the right side, if the stove is observed frontally.

The cookers are manufactured and certified in accordance with the EN

12815 standard and comply with all the requirements set by this standard.

These SENKO cookers are intended for cooking, space heating and

central heating !

SENKO cookers C-20 and C-30 –Instruction manual 5

figure 1

The cooker is packaged in a EURO pallet. During transport, the cooker

must be properly fastened in order to prevent tumbling or damages. The

standard delivered cooker set consists from:

cooker,

instruction manual,

chimney terminal extension (23),

firing regime adjustment –grate lifting spanner (24),

cooker cleaning tool (25),

CF agent for removal of soot and grease from glass surfaces (26).

CAUTION! The cooker weighs between 150 and 200 kg. Extra

caution is necessary when unloading, transferring, moving and

installing the cooker in order to avoid physical injury.

SENKO cookers C-20 and C-30 –Instruction manual 6

1.1. FUEL

The use of moist and low-calorie wood is not recommended. The wood

moisture must be lesser than 17%. The energy content of moist wood is

low, at approx. 2,3 kWh/kg and it greatly pollutes the door glass, as well as

the chimney and the cooker.

Use only recommended fuel :

wood: common beech, common hornbeam, oak, black locust

air dried for a minimum of 2 years

relative humidity 15-17%, energy content at approx. 4,2 kWh/kg

wood briquettes: energy content at approx. 4,4 kWh/kg

1.2. FEEDING

manually when necessary

we recommend the logs to be of 50 x 50 mm vertical cut, up to

2/3 of the firebox length

use smaller logs for a more intensive fire, and more massive logs to

maintain fire

the minimum distance between the logs must be 1 cm, the same

distance of 1 cm applies for the briquettes

it is necessary to use protective heat insulated gloves when

adding fuel to the firebox

protective heat insulated gloves must also be used when opening

and closing firebox door and removing the ash box

SENKO cookers C-20 and C-30 –Instruction manual 7

1.3. CHIMNEY

The cooker is connected to the chimney via 130 mm diameter sliding

rosette. It is necessary to execute the connection of the rosette and the

chimney tightly and impermeably. If the cooker is separated from the

chimney opening (not recommended) the connection is made via

standard 130 mm diameter smoke venting pipe.

We also advise to equip the chimney with solid material and

possible condensation products collection chamber and to install the

chamber in question beneath the smoke channel inlet, in a manner which

allows easy access and inspection via impermeable door.

1.3.1. CHIMNEY CAP

Chimney cap must fulfill the following prerequisites:

identical internal cross-section to that of the chimney,

operational exit cross-section no less than the double inner

cross-section of the chimney,

constructed to prevent rain, snow, leaves and other foreign

bodies from entering the chimney,

constructed to enable expulsion of combustion products in

case of wind from any direction and incline,

installed to enable proper dispersion and dilution of

combustion products outside the reflux zone (backflow)

because the counter pressure occurs here. Therefore, it is

necessary to adhere to limitations listed in figure 2,

mechanical appliances for flue gases suction are not allowed.

SENKO cookers C-20 and C-30 –Instruction manual 8

1.3.2. CHIMNEY FUNCTION

Among all the meteorological and geographical factors that influence the

chimney function (rain, fog, snow, insolation period, etc.) the wind is most

certainly the crucial one. Apart from the pressure caused by the

temperature difference between the flue gases and the outer chimney air,

there is another type of pressure –wind dynamic pressure.

Roof

slope

Distance between the

roof ridge and the

chimney

Minimum chimney height

(measured from the roof

surface)



A, m

Hmin, m

15°

< 1,85

0,5 m above the roof ridge

> 1,85

1 m from the roof

30°

< 1,5

0,5 m above the roof ridge

> 1,5

1,3 m from the roof

45°

< 1,3

0,5 m above the roof ridge

> 1,3

2 m from the roof

60°

< 1,2

0,5 m above the roof ridge

> 1,2

2,6 m from the roof

figure 2

FLAT ROOF

PITCHED ROOF

Z=REFLUX ZONE

SENKO cookers C-20 and C-30 –Instruction manual 9

Ascending wind ALWAYS has the effect of increasing the pressure,

i.e., underpressure (flue draught), provided the chimney is properly

installed. Descending wind ALWAYS has the effect of decreasing the

draught overpressure occurs. Apart from wind direction and velocity,

chimney position in relation to the house roof and surrounding area is also

important (figure 3).

The wind also influences the chimney function indirectly by creating

areas of high (overpressure) and low (underpressure) pressure, both inside

and outside the residential area (figure 4).

Pressure that facilitates chimney function can occur in rooms directly

exposed to the wind (B), but it can also adversely affect the chimney

through external pressure if the chimney is situated on the side exposed to

wind (A). Contrary to that, underpressure can occur in lee rooms (C),

adversely affecting functions of the chimney situated on the opposite side

(D) from the wind direction.

figure 3

wind

Unfavorable

position

Favorable

position

Horizontal wind 8 m/s

underpressure of

30 Pa

Descending wind under



angle and 8 m/s 

overpressure of 17 Pa

High (positive)

pressure zone

OVERPRESSURE

Low (negative)

pressure zone

UNDERPRESSURE

Flue

gases

from the

cooker
