Sena RC4 Manuel utilisateur
2
Installation
Remove the plastic tape from the battery slot to
begin using the RC4.
RC4
Quick Start Guide
Getting Started
Replacing the Battery
17.Jan
1
Center Button
Battery Slot
(-) Button
(+) Button
Multifunction
Button
200 220
180
160
140
120
100
80
60
40 20 1
240
260
Note:
If your handlebar requires better grip for holding
the RC4 in place, apply the rubber band around
the handlebar.
Button Operation
Press for 1 sec
1”
Tapping
Tap
Double Tapping
Tap
2
Installation
Remove the plastic tape from the battery slot to
begin using the RC4.
RC4
Quick Start Guide
Getting Started
Replacing the Battery
17.Jan
1
Center Button
Battery Slot
(-) Button
(+) Button
Multifunction
Button
200 220
180
160
140
120
100
80
60
40 20 1
240
260
Note:
If your handlebar requires better grip for holding
the RC4 in place, apply the rubber band around
the handlebar.
Button Operation
Press for 1 sec
1”
Tapping
Tap
Double Tapping
Tap
Battery Check
70 ~ 100%
30 ~ 70%
0 ~ 30%
Power On
LED
Bluetooth Pairing
8”
Press
(+) Button
Remote Control Pairing
Headset
Pairing
Note:
• You can control the headset using the RC4 only
after you pair them together.
• The RC4 supports Sena headsets with Bluetooth
4.1 or higher.
Factory Reset
1”
Press
(-) Button
(+) Button
+ +
Center
Button
Headset Control
To control your headset using the RC4, please refer to the
Quick Reference Guide for button operations on functions
such as phone, music, and intercom.
Sena Technologies, Inc.
www.sena.com
Customer Support: support.sena.com
E-mail: suppor[email protected]
3
Power On/Off
Tap
Power On
Center
Button
Deep Sleep
1”
Press
(+) Button
+
Center
Button
Note:
The Multifunction Button remotely controls special
buttons such as the Ambient Mode Button of the
20S and the Camera Button of the 10C. Please refer
to the Quick Reference Guide for more details.
Battery Check
70 ~ 100%
30 ~ 70%
0 ~ 30%
Power On
LED
Bluetooth Pairing
8”
Press
(+) Button
Remote Control Pairing
Headset
Pairing
Note:
• You can control the headset using the RC4 only
after you pair them together.
• The RC4 supports Sena headsets with Bluetooth
4.1 or higher.
Factory Reset
1”
Press
(-) Button
(+) Button
+ +
Center
Button
Headset Control
To control your headset using the RC4, please refer to the
Quick Reference Guide for button operations on functions
such as phone, music, and intercom.
Sena Technologies, Inc.
www.sena.com
Customer Support: support.sena.com
E-mail: [email protected]
3
Power On/Off
Tap
Power On
Center
Button
Deep Sleep
1”
Press
(+) Button
+
Center
Button
Note:
The Multifunction Button remotely controls special
buttons such as the Ambient Mode Button of the
20S and the Camera Button of the 10C. Please refer
to the Quick Reference Guide for more details.
Type Operation Button Command
Basic
Operation
Volume
adjustment Tap the (+) Button or the (-) Button
Configuration
menu
Press the Center Button for
10 seconds
Mobile
Phone
Answer phone call Tap the Center Button
End phone call Press the Center Button for
2 seconds
Voice dial Press the Center Button for
3 seconds
Speed dial Press the (+) Button for 3 seconds
Reject incoming
call
Press the Center Button for
2 seconds
Intercom
Intercom pairing
Press the Center Button for
5 seconds
Tap the Center Button of any one of
the two Remotes
Start/end each
intercom Tap the Center Button
Start Group
Intercom Tap the (+) Button and the (-) Button
End all intercoms Press the Center Button for 1 second
Music
Play/pause
Bluetooth music Press the Center Button for 1 second
Track forward/
back
Press the (+) Button or the (-) Button
for 1 second
FM Radio
FM radio on/off Press the (-) Button for 1 second
Select preset Press the Center Button for 1 second
Seek stations Double tap the (+) Button or
the (-) Button
Scan up FM band Press the (+) Button for 1 second
Stop scanning Press the (+) Button for 1 second
Save preset while
scanning Tap the Center Button
RC4 Remote Control
Operation for Headset
www.sena.com
Product Operation Button Command
20S
Ambient Mode Double tap the Multifunction
Button
Voice command Tap the Multifunction Button
Start Group
Intercom
Press the Multifunction Button for
1 second
10C
Camera on Tap the Multifunction Button
Camera off Tap the Multifunction Button and
the (-) Button
Start/stop video
recording
Press the Multifunction Button for
1 second
Take photo Tap the Multifunction Button
Enter Video
Tagging mode
Press the Multifunction Button for
3 seconds
Start Video
Tagging
Press the Multifunction Button for
1 second
Exit Video Tagging
mode
Press the Multifunction Button for
3 seconds
Enter camera
configuration
menu
Press the Multifunction Button for
8 seconds
Exit camera
configuration
menu
Tap the Multifunction Button
Tufftalk
Ambient Mode Double tap the Multifunction
Button
Start Group
Intercom
Press the Multifunction Button for
1 second
Others Start Group
Intercom
Press the Multifunction Button for
1 second
RC4 Multifunction Button
Operation for Headset
www.sena.com
