Sena M1 EVO Manuel utilisateur
SMART MOUNTAIN BIKE HELMET
1.0.0
SENA
QUICK START GUIDE
ENGLISH
The M1 EVO is comfortable and protective mountain
bike helmet. The M1 EVO with built-in Bluetooth®
capabilities allows you to hear GPS navigation, take
phone calls and listen to your favorite tunes. You can
use the Mesh Intercom™ to communicate with other
M1 EVO users and use the LED Taillight to ride safely.
Bluetooth®4.1
Mesh Intercom™
up to 900 m (0.5 mi)*
Taillight
Voice Command
* in open terrain
RIDE CONNECTED
GETTING STARTEDM1 E V O
SENA Technologies, Inc.
Customer Support: sena.com
1. This product comes with a Quick Start Guide, which
is a basic version of the User’s Guide. A FULL
VERSION OF THE USER’S GUIDE CAN BE
DOWNLOADED AT SENA.COM.
2. Update this product for free with the latest firmware
to fully enjoy the new advanced features built into this
product. Visit sena.com to see how to update your
product.
3. Users can follow Sena on Facebook, YouTube,
Twitter and Instagram to receive the most up to
date information on products, helpful tips and all
other announcements regarding Sena products.
GETTING STARTED
GETTING STARTED
How to Use This Guide
The legend and callouts are here to help you read the illustrations.
New technology can be confusing, but we’ve created a simple way to
perform actions using illustrations.
=1s
HOLD
Function = Button(s) to Tap or Hold
Icon Legend
1x
TAP Tap button the specified
number of times 10s
HOLD Press and Hold button for the
specified amount of time
“Hello” Audible prompt
Buttons
Bluetooth System’s Buttons
Center Button
(-) Button
(+) Button
Blue/
Red/Green
LED Lights
SENA Button
QUICK START GUIDEM1 E V O
Product Details
Speakers
Bluetooth System's Buttons
Microphone
(-) Button
(+) Button
Blue/
Red/Green
LED Lights
Center
Button
Fault Reset Button
DC Power Charging &
Firmware Upgrade Port
SENA Button
QUICK START GUIDE
QUICK START GUIDE
How To Wear the Helmet
1. Position the helmet on your head with the front
covering your forehead.
2. Position the strap adjuster centered, just below
your ears.
3. Position the helmet low on your forehead with the
buckle under the chin and back against the throat.
The straps should fit comfortably around both ears.
4. After removing the chinstrap pad, adjust the
chinstrap tension at the buckle so the chinstrap is
tight and comfortable by pulling the chinstrap end
through the buckle to either tighten or loosen as
needed.
Chinstrap
Strap Adjuster
Buckle
Chinstrap Pad
O-Ring
QUICK START GUIDE
5. Secure the excess strap with O-ring and then attach
the chinstrap pad.
Note: Check the chinstrap’s
position and tension regularly to
ensure proper fit.
6. Turn the retention system knob clockwise to tighten
or counterclockwise to loosen.
7. To change the height of the retention system, firmly
pull or push the retention system upward or
downward to a different position.
Retention System Knob Retention System
WARNING: For maximum protection, this helmet must be fitted
and attached properly to the wearer’s head in accordance with the
following instructions. If after adjustment the helmet does not fit
properly, do not use the helmet. Return it to the retailer or Sena.
QUICK START GUIDE
Sena Cycling App
By simply pairing your phone with your Bluetooth system, you
can use the Sena Cycling App for quicker and easier set up and
management.
• App Features
- Mesh Intercom, Music, FM Radio, LED Taillight, Device settings,
Quick Start Guide, and User’s Guide.
• Download
- Android: Google Play Store > ‘Sena Cycling’
- iOS: App Store > ‘Sena Cycling’
Sena Device Manager
The Sena Device Manager allows you to upgrade the firmware
and configure its settings directly from your PC or Apple computer.
Download the Sena Device Manager from sena.com.
QUICK START GUIDE
Basic Operations
Powering On
=1s
HOLD
Volume Up
=1x
TAP
Powering Off
=1x
TAP
Volume Down
=1x
TAP
Checking the Battery Level
Instruction is for when powering the Bluetooth system on.
Visual Method
=1s
HOLD
=
=
=
QUICK START GUIDE
Phone Pairing
There are three ways to pair the phone.
Initially Pairing the M1 EVO
The Bluetooth system will automatically enter the phone pairing mode
when you initially turn on the Bluetooth system or in the following
situation:
• Rebooting after executing Factory Reset
=1s
HOLD
=
Alternating blue and red flashing lights indicate the device is
now discoverable. With your mobile phone in Bluetooth-pairing
mode, select M1 EVO in the list of devices detected.
LED
STATUS
=
PIN
NUMBER
Note:
• The phone pairing mode lasts for 3 minutes.
• To cancel phone pairing, tap the Center Button.
