Sena Parani A20 Manuel utilisateur

1.2.0

USER’S GUIDE

ENGLISH

Motorcycle Intercom

GETTING STARTED

Update this product for free with the latest

ﬁrmware to fully enjoy the new advanced

features built into this product. Visit parani.com

to see how to update your product.

PRODUCT FEATURES

Blast your favorite tunes, talk over the intercom

with your buddies, hear directions from your

GPS and more, all through your A20 Bluetooth®

headset. With built-in Bluetooth®capabilities,

HD Intercom, technology has never felt so

minimal or freeing.

Bluetooth

Integrated

Intercom up to 1 km (0.6 mi)*

Four-way Intercom

LCD Display

Firmware Upgradeable

*in open terrain

parani.com

TABLE OF CONTENTS

3.3 Charging the Headset 12

3.4 Powering On and Off 13

3.5 Adjusting the Volume 13

3.6 Downloadable Parani Software 13

3.6.1 Parani Device Manager 13

4 PAIRING YOUR HEADSET WITH

OTHER BLUETOOTH DEVICES 14

4.1 Phone Pairing 14

4.1.1 Initially Pairing the A20 14

4.1.2 Pairing When the A20 is Turned Off 15

4.1.3 Pairing When the A20 is Turned On 16

4.2 Second Mobile Phone Pairing 16

5 MOBILE PHONE USAGE 17

5.1 Using Phone Functions 17

1 BEFORE STARTING 5

1.1 Product Details 5

1.2 Package Contents 5

2 INSTALLING THE HEADSET ON

YOUR HELMET 6

2.1 Using the Clamp 6

2.2 Using the Glued Surface Mounting

Adapter 7

2.3 Installing the Speakers 8

2.4 Installing the Wired Boom

Microphone 9

2.5 Installing the Wired Microphone 10

3 GETTING STARTED 11

3.1 Button 11

3.2 LCD Display 12

8 GENERAL SETTINGS 25

8.1 Function Priority 25

8.2 Conﬁguration Menu 25

8.2.1 Assigning Speed Dial 27

8.2.2 Voice Prompt (Default: Enable) 28

8.2.3 Delete All Pairings 28

8.3 Firmware Upgrades 28

9 TROUBLESHOOTING 28

9.1 Fault Reset 28

9.2 Factory reset 29

5.2 Speed Dialing 18

5.2.1 Assigning Speed Dial Presets 18

5.2.2 Using Speed Dial Presets 18

6 STEREO MUSIC 19

7 BLUETOOTH INTERCOM 20

7.1 Intercom Pairing 20

7.2 Two-way Intercom 21

7.2.1 HD Intercom 22

7.3 Multi-Way Intercom 22

7.3.1 Start a Three-Way Intercom

Conference 22

7.3.2 Starting a Four-Way Intercom

Conference 24

7.3.3 Ending Multi-Way Intercom 24

1 BEFORE STARTING

1.1 Product Details

(-) Button(+) Button

Multi-function Button

DC Power Charging &

Firmware Upgrade Port

Speakers and

Microphone Port

LCD Display

1.2 Package Contents

• Headset Main Unit

• Clamp

• Glued Surface Mounting Adapter

• Speakers and

Microphone Cable

• Speaker Pads (2)

• Hook and Loop Fasteners

for Speakers (2)

2 INSTALLING THE HEADSET ON

YOUR HELMET

Before installing the headset, you need to choose

between the clamp and the glued surface mounting

adapter. To install the headset to the helmet, follow

the steps below:

2.1 Using the Clamp

1. Insert the main module into the clamp using

the two connecting slots on the back.

2. Insert the headset into the helmet using the

clamp.

Wired Boom Microphone

• Wired Boom Microphone

• Microphone sponge (2)

• Hook and Loop Fastener for

Boom Microphone

• Wired Boom Microphone Holder

• Hook and Loop Fastener for

Boom Microphone Holder

Wired Microphone

• Wired Microphone

• Hook and Loop Fastener for

Wired Microphone

Others

• USB Power & Data Cable

(USB-C)

2. Remove the cover of the adhesive sticker

on the back to glue the headset on to the

helmet.

3. Attach the headset on the left side of the

helmet.

4. Insert the speaker and microphone plug into

the headset.

3. Insert the speaker and microphone plug into

the headset.

2.2 Using the Glued Surface

Mounting Adapter

1. Insert the main module into the glued

surface mounting adapter using the two

connecting slots on the back.

Note: If the helmet has deep ear pockets, you can

use the speaker pads to bring the speakers closer

to your ears.

2.3 Installing the Speakers

1. Attach the hook and loop fasteners for

speakers to the ear pockets inside the helmet.

2. Attach the speakers to the hook and loop

fasteners for speakers inside the helmet.

Tab

2.4 Installing the Wired Boom

Microphone

1. Attach the hook and loop fastener for wired

boom microphone on the inside surface of

the left external shell.

2. Attach the wired boom microphone’s mounting

plate to the hook and loop fastener.

3. Adjust the head of the microphone so that

the tab is facing away from your mouth.

4. Align the arrows on the main unit and

microphone cables and insert the microphone

cable into the microphone connector.

2.5 Installing the Wired Microphone

If you have a full face helmet, you can use the wired

microphone.

1. Peel off the cover of the hook and loop

fastener for wired microphone to expose the

adhesive tape. Then, attach the hook and

loop fastener on the inside of the helmet’s

chin guard.

2. Attach the wired microphone to the hook

and loop fastener for wired microphone.

Note:

•

You can use the boom microphone holder after

attaching the hook and loop fastener for boom

microphone holder on it to ensure secure

installation.

•

Make sure that the microphone is located

properly close to your mouth when you wear the

helmet. Adjust the direction of the microphone

so that the n side of the microphone is facing

outward, away from your lips.

Fin
