SELFSAT-H10D

SELFSAT-H21D

Flat Satellite Antenna

with

Dual Linear Polarization

SELFSAT-H10D/H21D

User’s manual

What is SELFSAT-H10D/H21D?

Contents

.............................................................................What is SELFSAT-H10D/H21D? 3

Safety Instructions

..........................................................................................Safety Instructions 4

Box Content

................................................................................................Box Content 5

Troubleshooting Check List for Initial Installation

.........................................................Troubleshooting Check List for Initial Installation 16

Loss of Signal / Rain Fade

..................................................................................Loss of Signal / Rain Fade 17

Installation Using Long Cable

.............................................................................Installation Using Long Cable 17

Install

..............................................................................................

...................................................................................

.............................................................................

....................................................

..........................................................................

..........................

...........................

............................................................

..................................................................................

.........................................................................................

..............................................................................

...........................................................................

...................................

......................................................................

.......................................................................................

...............................................................................................

How to Install?

Step 1 : Where to Install?

Step 2 : Installation Choice

Step 3 : Connecting the Antenna and the Set top box

Step 4 : Antenna Pointing Menu

Step 5 : Pointing and location the Signal (rst without Attenuation Thin Pad)

Step 6 : Optimum Pointing & Finding the Signal (with Attenuation Thin Pad)

A) Table Stand Type (On a Horizontal Plain)

B) Wall Mounting Type

C) Window Type

D) Clamp on Balcony Type

A) How to prepare the cable?

B) How to connect the cable to the antenna and the set top box?

A) Cross Polarization (Skew Angle)

B) Elevation Angle

C) Azimuth

SELFSAT-H10D/H21D

English

SELFSAT-H10D/H21D

What is SELFSAT-H10D/H21D?

SELFSAT-H10D/H21D is a Horn Array Type Satellite Antenna with Dual Linear Polarization, it

can receive signal from major Satellites and would replace a normal former Parabolic Dish.

Small, discreet and easy to use, it can be installed in a few minutes and used as a portable

antenna for all satellite receptions.

SELFSAT-H10D/H21D can be used for both free to Air and encrypted (requiring a subscrip-

tion with an operator) channel reception; it can also receive all High Denition channels

with a superior image quality.

For the use and installation, please read the following instructions and installation materials

carefully.

Product introduction

Do you have a TV’s at home more than one?

Then, take SELFSAT built in multi LNB output

Watching 2 channels is possible through H10D2/H21D2

Even enjoying 4 channels is possible through H21D4

H10D2

/ H21D2 H21D4

Built in Twin LNB output Built in Quad LNB output

SELFSAT-H10D/H21D

www.self-sat.com 4

English

Warning

Antennas improperly installed or installed to an inadequate structure are very susceptible to

wind damage. This damage can be very serious or even life threatening. The owner and installer

assumes full responsibility that the installation is structurally sound to support all loads (weight,

wind & ice) and properly sealed against leaks. The manufacturer will not accept liability for any

damage caused by a satellite system due to the many unknown variable applications.

Before using this product please read this manual carefully and follow exactly all installation,

mounting & orientation instructions.

All the instructions should be followed in order to avoid any technical problems.

Any electric or magnetic eld close to the SELFSAT-H10D/H21D may cause a bad reception or even

cut o the signal completely.

Do not drill the plastic cover of the antenna, which seals the antenna from moisture.

Handle the antenna with care as any impact will cause damage to the electronics.

Do not open the cover, any attempt to repair by a non-qualied person can be dangerous and void

the warranty.

Any obstacle (buildings, trees, etc....) will block the reception of the signal from the satellite to the

antenna.

Do not paint or add any substance on the antenna cover, this will block the reception of the signal

from the satellite.

The cable between the antenna and the Satellite receiver should not exceed 30m as it will decrease

the quality of the signal.

The use non- isolated jacks will result in a loss of the signal level.

For an optimum signal reception please use the Attenuation Thin Pad for the rst installation.

(for more details, please refer to step 6)

Do not forget to adjust the antenna and the bracket to the cross-polarity (skew angle please refer

to step 5).

Tighten all the screws of the antenna once you have nished the adjustments.

This product contains one universal LNB, it is forbidden to add, change or modify the LNB.

For more precise details on the above points or for any information, please ask your retailer or

customer service.

•

Safety Instructions

SELFSAT-H10D/H21D

1 1

SELFSAT-H21DSELFSAT-H10D

Antenna

Body

2 1

Attenuation

PAD

AT-PAD

B1 1

Angle

Bracket

4B2 1

Main

Support

5B3 1

Window

Bracket A

6B4 1

Window

Bracket B

Fix

Bracket A

Fix

Bracket B

7B5 1

8B6 1

Symbol Part name Image Quantity

9B7 1

Spanner

Box Content

SELFSAT-H10D/H21D

www.self-sat.com 6

English

10 1

Hex Bolt

M6x18 SEMS2

11 4

Hex Bolt

M4X10 SEMS2

Hex Bolt

M6X50 SEMS2

Round Head

SquareNeck Bolt

M6x50

Round Head

SquareNeck Bolt

M6x30

14 1

Flanged Nut

15 S5 3

16 S6 2

U-Bolt

M6x85

17 N1 7

18 E1 4Rubber

Symbol Part name Image Quantity

SELFSAT-H10D/H21D

Compass

How to Install?

By following the instructions step by step you can proceed easily to install SELFSAT-H10D/H21D by

yourself or with the help of a professional antenna installer.

Step 1: Where to Install?

Bad Quality Singnal Reception

Note

In order to receive a signal from the Satellite, SELFSAT-H10D/H21D is to be installed in an open loop

space (outside the house or the apartment), in the direction of the satellite towards the equator, for

which, you will need a compass to exactly orient SELFSAT-H10D/H21D toward the satellite (Note;

please take reference to the table of the Azimuth angles specied in the back pages of this manual)

Make sure that there are no obstacles in front of SELFSAT-

H10D/H21D which can decrease the signal reception quality, such as buildings, or trees (you may

keep in mind that trees will grow and may block the signal).

In order to be able to x and install your antenna easily you might choose an easily accessible place

without any potential danger for installation.

Think about the way you might pass your cable in a discreet way from the SELFSAT-H10D/H21D to

your Set top Box. The antenna should not be too distant from your satellite receiver; a cable longer

than 30 meters can decrease the quality of the signal.

Before installing your antenna, you check that SELFSAT-H10D/H21D box contains all the items listed

above in the ‘Box Content’. In the event of any missing parts, please contact your distributor.

To ensure an accurate compass reading, stay away from large

metal objects, specically electrical cables and then make

multiple readings

BAD!BAD!

Install

SELFSAT-H10D/H21D

www.self-sat.com 8

English

Step 2: Installation Choice

A) Table Stand Type (on a Horizontal Plain)

B1 B5

A1 S1

S2 S4

Depending on the choice of installation position for the SELFSAT-H10D/H21D, you can then decide

on the mounting type, all parts are included.

Good Quality Singnal Reception

GOOD!GOOD!

SELFSAT-H10D/H21D

C) Window Type

B) Wall Mounting Type

Attention

Part number B6 bracket has 2 holes for H10D model & 4 holes for H21D model respectively.

SELFSAT-H10D/H21D

S4N1
