Seiko 7T11 Manuel utilisateur

Cal. 7T11

INSTRUCTIONS (P. 3)

BEDIENUNGSANLEITUNG (S. 19)

INSTRUCTIONS (P. 35)

ISTRUZIONI (P. 51)

INSTRUCCIONES (P. 67)

INSTRUÇÕES (P. 83)

(99 )

ENGLISH

CONTENTS

Page

DISPLAY & BUTTONS ................................................................................. 4

SETTING THE TIME AND ADJUSTING THE STOPWATCH HAND POSITION

..... 5

STOPWATCH................................................................................................ 8

SCREW-LOCK-TYPE CROWN..................................................................... 11

TACHYMETER.............................................................................................. 12

TELEMETER ................................................................................................ 14

BATTERY CHANGE...................................................................................... 16

SPECIFICATIONS......................................................................................... 18

IFor the care of your watch, see “TO PRESERVE THE QUALITY OF YOUR

WATCH” in the attached Worldwide Guarantee and Instruction Booklet.

You are now the proud owner of a SEIKO Analogue Quartz Watch Cal. 7T11. To ensure its

optimum performance, please read the instructions in this booklet carefully before using it.

Please keep this manual handy for ready reference.

Sie sind jetz t stolzer Besit zer ein es SEIKO Analog -Quarzuhr Kal. 7T11. Lesen Sie diese

Bedienungsanleitung vor der Verwendung aufmerksam durch, um Ihre Uhr optimal zu nutzen.

Heben Sie diese Bedienungsanleitung gut auf, um jederzeit wieder nachlesen zu können.

Vous voici l'heureux propriétaire d'une montre quartz analogique SEIKO Cal. 7T11. Pour en

obtenir des performances optimales, veuillez lire attentivement cette brochure avant d'utiliser

la montre. Conservez ce manuel pour vous y référer en cas de besoin.

Grazie di aver acquistato questo orologio SEIKO Analogico al Quarzo Cal. 7T11. Per poter

utilizzare l’orologio al massimo delle sue prestazioni leggere attentamente questo manuale di

istruzioni prima di passare all’uso dell’orologio stesso, e conservarlo poi per qualsiasi eventuale

futura consultazione.

Usted es ahora el orgulloso propietario de un reloj SEIKO analógico de cuarzo Cal. 7T11. Para

asegurar el óptimo rendimiento de su reloj, sírvase leer cuidadosamente las instrucciones

contenidas en este manual antes de su uso. Guarde este manual en un lugar muy accesible para

la rápida referencia.

Você poderá sentir-se orgulhoso de possuir um Relógio SEIKO Quartz Análogo Cal. 7T11. Para

garantir o seu excelente rendimento, leia atentamente as instruções contidas neste opúsculo

antes de usá-lo. Conserve este manual à mão para consultas futuras.

7T11

100

120

140

160

180

200

English

CAL. 7T11

DISPLAY & BUTTONS

Hour hand

Small second hand

STOPWATCH hour hand

Minute hand

a: Normal position

b: Extended position

time setting, STOPWATCH

hand position adjustment

STOPWATCH minute hand

STOPWATCH second hand

24-hour hand

nTIME

24-hour, hour, minute and small second hands

nSTOPWATCH

12-hour stopwatch in 1-second increments

When the measurement reaches 12 hours, the stopwatch automatically stops.

• Some models may have a screw-lock-type crown. If your watch does, refer to the

“SCREW- LOCK-TYPE CROWN” on page 11.

• Simpliﬁed illustrations may be used in the following sections of this manual.

a b

CROWN

100

120

140

160

180

200

lThis watch is designed so that the following adjustments are made with the

crown at the extended position:

1) time setting

2) stopwatch hand position adjustment

Once the crown is pulled out, be sure to make both the above adjustments

before pushing the crown in.

SETTING THE TIME AND

ADJUSTING THE STOPWATCH HAND POSITION

Minute hand

Hour hand

CROWN Pull it out when the small second hand is at the 12 o’clock position.

The small second hand will stop on the spot.

CROWN Tu rn to s e t the 24 - ho ur,

hour and minute hands.

Small second

hand

1. TIME SETTING

24-hour hand

100

120

140

160

180

200

100

120

140

160

180

200

English

1. If the crown is pulled out while the stopwatch is measuring, the STOPWATCH hands will be

automatically reset.

2. It is recommended that the hands be set to the time a few minutes ahead of the current time,

taking into consideration the time required to adjust the STOPWATCH hand position.

3. When setting the hour hand, make sure that AM/PM is correctly set, checking the position of the

24-hour hand.

4. When setting the minute hand, ﬁrst advance it 4 to 5 minutes ahead of the desired time, and then

turn it back to the exact minute.

STOPWATCH second hand

IIf the STOPWATCH hands are not in the 0 position, follow the procedure below to set them

to the 0 position.

2. STOPWATCH HAND POSITION ADJUSTMENT

Press for 2 seconds or longer again.

The STOPWATCH second hand turns a

full circle.

Press for 2 seconds or longer.

The watch enters the STOPWATCH hand

position setting mode.

Press repeatedly to set the STOPWATCH

second hand to the 0position.

The hand moves quickly if Button B is

kept pressed.

APress for 2 seconds or longer.

Press repeatedly to set the STOPWATCH

hour and minute hands to the 0 position.

The STOPWATCH hour and minute hands

turn a full circle.

• The hands move quickly if Button B is

kept pressed.

• The movement of the STOPWATCH

hour hand and STOPWATCH minute

hand are interlocked.

• Do not keep pressing down Button

A for longer than 2 seconds after

setting the STOPWATCH hour, minute

and second hands. If you do so by

mistake, push the crown back to the

normal position and carry out the same

procedure from the beginning once

again.

CROWN A f t e r a l l t h e a d j u s t m e n t s a r e

completed, push the crown back in to

the normal position.

STOPWATCH second hand

STOPWATCH hour and minute hands

100

120

140

160

180

200

English

STOPWATCH

lThe stopwatch can measure up to 12 hours in 1-second increments.

When the measurement reaches 12 hours, the stopwatch automatically

stops.

lThe measured time is indicated by the STOPWATCH second hand on the

main dial and the STOPWATCH hour and minute hands on the sub dial at

the 6 o’clock position.

lSplit time measurement is possible.

The measured time is indicated by the three STOPWATCH hands: the STOPWATCH

second hand, the STOPWATCH minute hand and the STOPWATCH hour hand.

STOPWATCH hour hand

STOPWATCH second hand

STOPWATCH minute hand

[1 hour 48 minutes and 10 seconds]

While the STOPWATCH hands are moving:

1. Press Button A to stop the stopwatch.

2. Press Button B to reset the stopwatch.

While the STOPWATCH hands are stopped:

Press Button B to reset the stopwatch.

[When the split time measurement is displayed while the stopwatch is

measuring.]

1. Press Button B to fast-forward the STOPWATCH hands. Subsequently, the

STOPWATCH hands return to the ongoing measurement movement.

2. Press Button A to stop the stopwatch.

3. Press Button B to reset the stopwatch.

[When the split time measurement is displayed and the stopwatch is stopped]

1. Press Button B to fast-forward the STOPWATCH hands. Subsequently, the

STOPWATCH hands will stop.

2. Press Button B to reset the stopwatch.

• If the STOPWATCH hands do not return to the 0 position when the stopwatch is reset , follow the

procedure in "SETTING THE TIME AND ADJUSTING THE STOPWATCH HAND POSITION."

• Stopwatch hand position adjustment should be done at the same time when the time is set.

English

STOP RESET

START

STOP RESTART STOP RESET

SPLIT SPLIT

RELEASE

STOP RESET

FINISH TIME

OF 1ST

COMPETITOR

2ND

COMPETITOR

FINISHES

FINISH TIME

OF 2ND

COMPETITOR

RESET

AAAB

BBB

* Restart and stop can be repeated as many times as required by pressing Button A.

* Measurement and release of the split times can be repeated as many times as required by

pressing Button B.

STOPWATCH OPERATION

SCREW-LOCK-TYPE CROWN

uSome models may have a screw-lock mechanism that can securely lock the

crown by a screw when they are not being operated.

uLocking the crown will help to prevent operational errors and enhance the

water resistant quality of the watch.

uIt is necessary to unlock the screw-lock-type crown before operating it.

Once you have ﬁnished operating the crown, make sure to relock it.

lHow to use the screw-lock-type crown

Keep the crown securely locked unless you need to operate it.

* When locking the crown, turn it slowly with care, ensuring that the

screw is properly engaged. Be careful not to forcibly push it in, as

doing so may damage the screw hole in the case.

[How to unlock it]

Turn the crown counterclockwise.

The crown is unlocked and can then be operated.

[How to lock it]

Once you have finished operating the crown, turn it

clockwise while gently pressing it in toward the watch

body until it stops.

English

100

120

140

160

180

200

100

120

140

160

180

200

TACHYMETER

(for models with tachymeter scale)

lTachymeter scale can be used only when the time required is less than 60 seconds.

To measure the hourly average speed of a vehicle

Use the stopwatch to determine

how many seconds it takes to go

1 km or 1 mile.

Tachymeter scale indicated by

the STOPWATCH second hand

gi ve s the avera ge sp eed p e r

hour.

Ex. 1

STOPWATCH

second hand:

40 seconds

Tachymeter scale:

“ 90”

“90” (tachymeter scale ﬁgure) x 1 (km or mile)

= 90 km/h or mph

Ex. 1: If the measuring distance is extended to 2 km or miles or shortened to 0.5 km or

miles and STOPWATCH second hand indicates “90” on tachymeter scale:

“90” (tachymeter scale ﬁgure) x 2 (km or mile) = 180 km/h or mph

“90” (tachymeter scale ﬁgure) x 0.5 (km or mile) = 45 km/h or mph

To measure the hourly rate of operation

Use the stopwatch to measure

the time required to complete

one job.

Tachymeter scale indicated by

the STOPWATCH second hand

gives the average number of

jobs accomplished per hour.

Ex. 2

STOPWATCH

second hand:

20 seconds

Tachymeter

scale:“180”

“180” (tachymeter scale ﬁgure) x 1 job

= 180 jobs/hour

Ex. 2: If 15 jobs are completed in 20 seconds:

“180” (tachymeter scale ﬁgure) x 15 jobs = 2700 jobs/hour

English

TELEMETER

(for models with telemeter scale)

l The telemeter can provide a rough indication of the distance to the source of

light and sound.

l The telemeter indicates the distance from your location to an object that emits

both light and sound. For example, it can indicate the distance to the place

where lightning struck by measuring the time elapsed after you see a ﬂash of

lightning until you hear the sound.

l A ﬂash of lightning reaches you almost immediately while the sound travels to

you at a speed of 0.33 km/second. The distance to the source of the light and

sound can be calculated on the basis of this difference.

l The telemeter scale is so graduated that the sound travels at a speed of 1 km

in 3 seconds.*

*Under the condition of temperature of 20°C (68°F).

CAUTION

The telemeter provides only a rough indication of the distance to the

place where lightning struck; therefore, the indication cannot be used

as a guideline to avoid the danger of lightning. It should also be noted

that the speed of sound differs depending on the temperature of the

atmosphere where it travels.

HOW TO USE THE TELEMETER

Before beginning, check that the stopwatch has been reset.

START

(Flash of light)

STOP

(Crash of thunder)

Press Button A to start the

stopwatch as soon as you

see the light.

When you hear the sound,

press Button A to stop the

stopwatch.

Read the telemeter scale

t h a t t h e S T O P W AT C H

second hand points to.

Approx. 3 km

* Please note that the STOPWATCH second hand moves in 1-second increments and does not always

point exactly at the graduations of the telemeter scale. The telemeter scale can be used only when

the measured time is less than 60 seconds.

English

lBattery life indicator

When the battery nears its end, the small second hand moves at 2-second

intervals instead of the normal 1-second intervals. In that case, have the

battery replaced with a new one as soon as possible.

* The watch remains accurate while the small second hand is moving at 2-

second intervals.

The miniature battery which powers your watch should last

approximately 5 years. However, because the battery is inserted at the

factory to check the function and performance of the watch, its actual

life once in your possession may be less than the specified period.

When the battery expires, be sure to replace it as soon as possible to

prevent any malfunction. For battery replacement, we recommend that

you contact an AUTHORIZED SEIKO DEALER and request a SEIKO

SR927SW battery.

* If the stopwatch is used more than 2 hours per day, the battery life may be less

than the speciﬁed period.

Years

BATTERY CHANGE

WARNING

lDo not remove the battery from the watch.

lIf it is necessary to take out the battery, keep it out of the reach of children. If a

child swallows it, consult a doctor immediately.

CAUTION

Never short-circuit, tamper with or heat the battery, and never expose it to ﬁre. The

battery may burst, become very hot or catch ﬁre.

lThe battery is not rechargeable. Never attempt to recharge it, as this may cause

battery leakage or damage to the battery.

English

SPECIFICATIONS

1 Frequency of crystal oscillator ............... 32,768 Hz (Hz = Hertz...Cycles per second)

2 Loss/gain (Monthly rate) ....................... Less than 15 seconds when used on the wrist

within normal temperature range (5 ºC - 35 ºC)

3 Operational temperature range.... .......... Between –10 ºC and +60 ºC

4 Driving system ....................................... Step motor 3 pieces

5 Display system

Time.................................................... 24-hour, hour, minute and small second hands in

1-second increments

Stopwatch........................................... Stopwatch second hand in 1-second increments(60

seconds/ 360 degrees)

Stopwatch minute hand in 1-minute increments(60

minutes/ 360 degrees)

Stopwatch hour hand (interlocked with the STOP-

WATCH minute hand.12 hours/ 360 degrees)

6 Battery .................................................... SEIKO SR927SW, 1 piece

7 Battery life .............................................. Approximately 5 years

If the stopwatch is used less than 2 hours per day

8 IC (Integrated Circuit) ............................. C-MOS-IC: 1 piece

* The speciﬁcations are subject to change without prior notice for product improvements.

Table des matières

Autres manuels Seiko Montre

Seiko

Seiko Cal. V172 Manuel utilisateur

Seiko

Seiko Essentials SSA346 Manuel utilisateur

Seiko

Seiko 5M62 Manuel utilisateur

Seiko

Seiko S06 Manuel utilisateur

Seiko

Seiko KINETIC 7D48 Manuel utilisateur

Seiko

Seiko ANALOGUE QUARTZ SOLAR V145 Manuel utilisateur

Seiko

Seiko Cal. V198 Manuel d'installation

Seiko

Seiko S064 Manuel utilisateur

Seiko

Seiko 7C17B Guide de démarrage rapide

Seiko

Seiko KINETIC 5M43 Manuel utilisateur

Seiko

Seiko SSJ015J Manuel utilisateur

Seiko

Seiko SNJ Series Manuel utilisateur

Seiko

Seiko V110 Manuel utilisateur

Seiko

Seiko Y739A Guide de démarrage rapide

Seiko

Seiko SPC244P1 Manuel utilisateur

Seiko

Seiko SKA896P1 Manuel utilisateur

Seiko

Seiko 5Y63 Manuel utilisateur

Seiko

Seiko 7T86 Manuel utilisateur

Seiko

Seiko 5Y75 Manuel utilisateur

Seiko

Seiko 4R57 Manuel utilisateur

Seiko

Seiko V110A Manuel de l'installateur

Seiko

Seiko Cal. V17 Manuel utilisateur

Seiko

Seiko Conceptual SSB415P Manuel utilisateur

Seiko

Seiko H024A Guide de démarrage rapide

Manuels Montre populaires d'autres marques

Pandora

Pandora WATCH2 Manuel utilisateur

Casio

Casio QW-4343 Manuel utilisateur

Suunto

Suunto X6 Manuel utilisateur

MotionX

MotionX 365 Manuel utilisateur

Garmin

Garmin VENU SQ 2 Manuel utilisateur

QCY

QCY Watch GTC Manuel utilisateur

Canyon

Canyon Cindy CNE-KW41WP Manuel utilisateur

Esq

Esq Watches Guide d'installation

Crane

Crane AA5-CDSM-3A Manuel utilisateur

Timex

Timex W-214 Manuel utilisateur

DETOMASO

DETOMASO MATERA Manuel utilisateur

Geemarc

Geemarc Watch N Shake Manuel utilisateur

LORUS

LORUS W590 Manuel utilisateur

STENLILLE

STENLILLE Actío Manuel utilisateur

Casio

Casio 5594 Manuel utilisateur

Sinn

Sinn HUNTER'S WATCH 3. Edition Manuel utilisateur

Slazenger

Slazenger SLZ800 Manuel utilisateur

iTOUCH

iTOUCH 3360 Manuel utilisateur
