Important Safeguards and warnings

1.Electrical Safety

all installation and operation here should conform to your local electri-

cal safety codes.

e power shall conform to the requirement in the SELV(Safety Extra

Low Voltage) and the Limited power source is rated 12V DC (24V AC)

in the IEC60950-1.

We assume no liability or responsibility for all the res or electrical

shock caused by improper handling or installation.

2.Transportation Security

Heavy stress, violent vibration or water splash are not allowed during

transportation, storage, and installation.

3.Installation

Do not apply power to the camera before completing installation.

Please install the proper power cut-o device during the installation

connection.

Always follow the instruction guide the manufacturer recommended.

If this product is installed in the ceiling, please make sure this installa-

tion position can sustain the min 50N.

4.Qualied Engineers needed

All the examination and repair work should be done by the qualied

service engineers.

We are not liable for any problems caused by unauthorized modica-

tions or attempted repair.

5.Environment

is series camera should be installed in a cool, dry place away from di-

rect sunlight or strong light, inammable, explosive substance and etc.

Important Safeguards and Warnings

is series camera be used in the specied working tem-

perature. Please keep it away from electromagnetic radia-

tion objects and environments.

Please keep the sound ventilation.

Do not allow water and other liquid from falling into the

camera.

6.Accessories

Be sure to use all the accessories recommended by the man-

ufacturer.

Before installation, please open the package and check all

the components that are included.

Contact your local retailer ASAP if something is broken in

your package.

7.Daily Maintenance

Please shut down the device and then unplug the power ca-

ble before you begin daily maintenance work.

Use the dry so cloth to clean the device.

If there is too much dust, please use water to dilute the mild

detergent rst and then use it to clean the device. Finally

use the dry cloth to clean the device.

Please put the dust-proof cap on to protect the CCD

(CMOS) component when you do not use the camera.

1General Introduction

1.1 Overview

is series megapixel HD camera conforms to the HDCVI standard. It sup-

ports video signal high-speed long distance transmission without any delay.

It can be controlled by the DVR conforming to the HDCVI.

1.2 Features

•High-performance CMOS image sensor, megapixel denition.

•Support HD video and control signal coaxial transmission.

•Supports 75-3 coaxial cable transmission without any loss. 720P series

transmission distance over 500m, 1080p series transmission distance

300m.

•High speed, long distance real-time transmission

•Support HDCVI HD and along SD switch output.

•720p series supports 720p@25, 720p@30, 720p@50, 720p@60.

•1080p series support 1080p@25, 1080p@30

•Supports high performance 3D noise reduction, excellent

performance in low illumination.

•Support ICR switch to realize surveillance both in the daytime and at

night.

•3.6mm xed lens (2.8mm, 6mm, 8mm optional)

•Support OSD(on-screen display), suitable for user self-dened setup.

•Supports DC12V power supply.

•IP66 compliance.

•Supports intelligent IR function.

2 Dome Framework and Dimensions

Please refer to the following gures for Dimension infor-

mation. e unit is mm(millimeter).

Important

Dimensions of Cameras may vary depending on your

model. If you are having trouble nding the dimensions

you can nd the measurements by using a caliper or try

your best using a ruler. To nd the circumference of the

bottom of the camera use the following formula: Diame-

ter of circle x 3.14(pi)

1 HD-CVI Metal Housing

Lens

Dome Body

Decoration Ring

Power

Video

SD/HD switch control cable

2 HD-CVI Plastic Housing

Lens

Dome Body

Decoration Ring

3 HD-CVI Glass Housing

Dome Cover

Dome Enclosure

IR Light

Dome Module

Dome Pedestal

Power Input Port

Video Output Port

SD/HD Switch Cable

When the Standard denition/high denition switch control cable is short

circuit, systems outputs standard denition video. Otherwise, when the cir-

cuit is open, system outputs the high denition video.

3Dome Installation

Important

Before the installation, please make sure the installation surface can sustain

at least 3X weight of the bracket and the camera.

3.1 HD-CVI glass housing

e dome camera usually uses the ceiling installation. It can be installed on

the ceiling or the wall.

•For the side exit cable installation, please make sure the side exit cable

direction is the same as shown in the installation position map.

•Before you secure the screws on the pedestal, please put the cable

through the cable exit of the pedestal.

•Before you complete the installation and debug, do not remove the

electrostatic lm. Aer you remove the lm, do not touch the enclo

sure in case there are any scratches.

Ceiling or Wall

Installation Position Map

Expansion Bolts

Self-Tapping Screw

Enclosure fastening screw

Inner Hex Wrench

Step 1

Take the installation position map from the accessories bag and them put it on

the surface of the ceiling or the wall according to the cable exit position. Dig

three holes according to the installation position map and then take three ex-

pansion bolts from the accessories bag and put them to the holes you just dug.

Step 2

Use inner hex wrench to remove the three enclosure fastening screws and then

remove the dome enclosure.

Step 3

Adjust the pedestal position according to the cable exit move(ceiling/side).

Pull the cable through the cable side exit at the installation surface and the

pedestal (Please skip this step if you want to use ceiling exit mode). Line up

the screw holes at the bottom of the pedestal to the expansion bolts in the in-

stallation surface. Put three self-tapping screws to expansion bolts and then

secure rmly. Now the pedestal is on installation surface.

Step 4

Adjust the camera module angle to a proper position and then x the screws

to fasten.

Step 5

Use three enclosure fastening screws to secure the dome housing on

the pedestal.

Fastening Screw

HDCVI Plastic Housing

Step 1

Please take the installation position map in the accessories bag, and then

paste it on the ceiling or the wall according to your monitor area require-

ments. Draw and then dig three holes in the installation surface and then

insert three expansion bolts in the holes. Secure these three bolts rmly.

Step 2

Turn counter clockwise to remove the decoration ring. Please dig a “cable

exit hole” in the surface according to the installation position map if you

want to draw out the cable from the top of the installation surface. You need

to draw out the cable from the cable channel side port of the pedestal if you

want to draw out the cable from the side port of the cable channel. Adjust

the device installation pedestal to the proper position and then draw the

cable through the cable exit. Line up the three screw holes in the installation

position. Put the three self-tapping screws in the three plastic expansion

bolts rmly. Now the dome camera is secure in the installation surface.

3.2

Ceiling or Wall

Expansion Bolt

Dome Camera Body

ST3 Self-tapping Screws

Decoration Ring
