AUTOMATIC BREAD MAKER

User Manual

Model: MBF-016

PARTS IDENTIFICATION

1. Viewing window

2. Steel lid

3. LCD screen

4. Control panel

5. Handle

6. Steel housing

7. Plastic bottom

8. Bread pan

(Dishwasher-safe)

9. Stirring blade

(Dishwasher-safe)

10. Measuring cup

(Dishwasher-safe)

11. Measuring spoon

(Dishwasher-safe)

12. Hook

(Dishwasher-safe)

910 11 128

Measuring Cup:

1. Liquid ingredients: After ﬁ lling the measuring cup, place it on

a ﬂ at surface and view it at eye level to make sure the

amount of liquid is exact.

2. Dry ingredients: Use a spoon to place ingredients into the

measuring cup then “level off” the measurement with a small

spatula to make sure the measurement is exact or,

shake the cup lightly in order to ﬂ atten the surface of powder.

Please do not shake the cup for a long time or sharply,

otherwise the powder might be lower than the desired amount.

Tips: One cup of ﬂ our is about 160g.

Measuring Spoon:

Double-ended teaspoon/tablespoon measuring spoon is used for measuring ingredients.

Stirring Blade: Used for stirring the ingredients.

Hook: Used for taking the stirring blade out from bread.

AUTOMATIC BREAD MAKER

1. "MENU":

Press the "Menu" button to adjust the bread setting. Pressing and holding the "Menu"

button helps to navigate through the Menu quicker.

2. "LOAF": Three loaf sizes (500g/750/g/1000g) to choose from. The "LOAF" function

works only on Menu settings 1 – 10.

NOTE: 1.10 lb = 500 g, 1.65 lb = 750g, 2.20 lb = 1000g

3. "COLOR": Three available crust color settings: Light, Medium and Dark. The color will

display at the bottom of the screen. The "COLOR" function does not work on Menu

settings 11, 12, 13, 14, 16 and 17.

4. "START/"PAUSE": Press to start or pause the operation. Once the "START/PAUSE"

button has been pressed, the only buttons that will function are "STOP" and "START/

PAUSE".

NOTE: When the appliance is operating, press the "START/PAUSE" button to pause

the bread maker to add ingredients. The readout will show that the countdown timer is

paused. Press the button again to restart the appliance.

5. "STOP": Press and hold the button for 3 seconds to end the current program. The unit

will "beep" once and the bread setting will return to Menu 1 automatically.

6. "GLUTEN-FREE": Press to advance directly to Menu 9 (Gluten-Free). The machine will

begin to operate if the button is held for 3 seconds.

7. "KNEAD": Press to advance directly to Menu 13 (Pasta Dough). The machine will begin

to operate if the button is held for 3 seconds.

8. "+ / -" Reservation Time: Press to activate the Reservation time (see below for speciﬁ c

Menu settings). Time will increase or decrease in 10-minute increments. Press and hold

to increase or decrease time quickly. The readout will ﬂ ash. Press the "START/PAUSE"

button and the readout will display ":" and will stop ﬂ ashing. Press "START/PAUSE" a

second time to begin the operation. Time displayed will vary by Menu selection as shown

below.

Menu Settings 1-10, 13 and 14 only: Press the "+" or "- " button to activate the•

Reservation time. The time displayed will increase "+" or decrease "-" in 10-minute

increments. Press and hold to add or decrease time quickly. The maximum combined

CONTROL PANEL

1 - Soft Bread 2 - Sweet Bread 3 - Natural sourdough 4 - French Bread

5 - Whole Wheat 6 - Quick Bread 7 - Sugar-free 8 - Multigrain

9 - Gluten-free 10 - Buttermilk Bread 11 - Bread Dough 12 - Pizza Dough

13 - Pasta Dough 14 - Leaven Dough 15 - Cake 16 - Jam

17 - Yogurt 18 - Bake 19 - Custom Mode

AUTOMATIC BREAD MAKER

time is 15 hours.

Time displayed will be delayed start + cycle time.

Menu Settings 17, 18, and 19 only: Press the "+" or "- " button to add cooking time to•

the cycle. It does not delay the start time of the cycle.

Time displayed will be the adjusted cycle time.

Try a simple recipe: Soft Bread at 750 g and medium color (Menu 1)

1. Clean the bread pan, stirring blade, measuring cup and measuring spoon.

2. Secure the stirring blade into the revolving axle in the bread pan.

3. Please follow the Soft Bread recipe in the Recommended Recipes on page 14. Yeast

powder should be added last. (on top of the ﬂ our) Do not allow the yeast powder to get

wet.

4. Position the bread pan into the bread maker and secure it by turning it clockwise. Close

the lid.

5. Plug the bread maker into the electrical outlet, the unit will "beep" and the screen will

display the Default Menu immediately: 750 g / Medium Color / Soft Bread (Menu 1)

6. Press the "START / PAUSE" button, the appliance will "beep" and the bread maker will

begin to operate.

7. The bread is ready when the timer has expired. At this time, "Keep warm" will appear in

the LCD screen for one hour and then the bread maker will automatically turn off.

8. Press and hold the "STOP" button for 3 seconds to turn the appliance off and the

appliance will "beep". "Keep warm" does not function after the "STOP" button has been

pressed.

9. After the bread is ﬁ nished, the bread pan may be hot. To avoid a burn hazard, use heat

resistant gloves while handling the bread or any parts of the bread maker. Turn the

bread pan counter-clockwise to release it from the bread maker and then lift it out. Turn

the bread pan upside down to allow the bread to slide out onto a cooling rack.

10. Allow the bread maker to cool completely before cleaning and storing.

Tips

If the stirring blade is difﬁ cult to remove from the bread

pan after the bread has been removed, please use the

hook as follows:

1) Insert the hook into opening in the top of the stirring

blade (Fig. A)

2) Gently lift the stirring blade out of the bread pan (Fig. B)

Caution:

Make sure the power cord, outlet and fuse box are not damaged.•

Place the bread maker on a dry, ﬂ at, level and heat resistant surface.•

Bread maker must be grounded while in use. To reduce the risk of electrical shock, this•

appliance is equipped with a cord with a 3-prong grounding-type plug for insertion with a

proper grounding-type receptacle.

How to make bread:

1. Remove the bread pan from the appliance by twisting the pan counter-clockwise and

insert the stirring blade into bread pan.

OPERATING GUIDE

FOR THE FIRST USE

The appliance may emit a small amount of smoke which will dissipate quickly

during the ﬁ rst use. This is normal for appliances with a heating element due to the

manufacturing process. Ensure adequate ventilation by making sure the appliance is

at least 4" away from any obstruction.

1. Please make sure all parts and accessories are complete and free of damage.

2. Clean all the parts as shown in the Cleaning and Maintenance section.

3. Set the bread maker on Bake mode (Menu 18) and bake empty for about 10

minutes to burn off the residue from manufacturing. Allow it to cool and clean all the

parts again.

4. Dry all parts thoroughly and assemble them, the appliance is ready for the ﬁ rst use.

Secure the stirring blade into the

rotation axle inside the bread pan.

2. Add the ingredients per your recipe. (refer to Recommended Recipes in this manual)

3. Place the bread pan into the bread maker and lock it into position by twisting it clockwise;

close the lid.

4. Plug bread maker to the electrical outlet and the unit will "beep". The default Menu 1

750g/Medium Color/ soft bread will show in the LCD screen.

5. Select your desired bread setting by pressing "MENU".

6. Select your Bread Color and Loaf Size

7. Set "Reservation" Time

If you do not wish to delay the start time, please skip this step.

Please refer to "Reservation function" in SPECIFIC FUNCTIONS DESCRIPTION in this

manual for more detail.

AUTOMATIC BREAD MAKER

Yeast powder will not work if it gets

wet. Be sure to add the yeast powder

last so it is on top of the ﬂ our.

Press " + "

Press "LOAF" to set the

desired loaf size

Press "COLOR" to set

the desired crust color

Press " - "

Yeast powder

Dry ingredients

Wet ingredients

8. Press "START/PAUSE" button and the bread maker begins operating.

9. When the timer counts down to 0:00, the unit will "beep", indicating the bread is done.

1) Keep warm will appear in the LCD screen for one hour and then the unit will

automatically turn off. Please unplug.

2) To skip Keep warm and end manually:

Press and hold "STOP" for 3 seconds. Please unplug.

10. Remove bread from the pan:

Using heat resistant gloves, open lid and twist the bread pan counter-clockwise to

release it. Lift the pan out of the bread maker and turn the pan upside down to release

bread onto a cooling rack. If needed, gently shake pan or run a thin spatula around the

edges to loosen the bread.

MENU Operating Instructions

Step 1: Add all ingredients per your recipe (see Recommended Recipes in this manual)

and press the "MENU" button to select one of the following settings, and begin operation:

Menu 11: Bread dough

Designed to make raw bread dough. Stir 1 will appear in the LCD screen. The default time

is 23 minutes. Time cannot be adjusted. The unit will "beep" when all time has elapsed.

Menu 12: Pizza dough

This is designed to make raw pizza dough. Stir 1 will appear in the LCD screen. The default

time is 1 hour and 25 minutes. Time cannot be adjusted. The unit will "beep" when all time

has elapsed.

Menu 13: Pasta dough

Use this setting to make raw pasta dough. Stir 1 will appear in the LCD screen. The default

time is 23 minutes. The unit will "beep" when all time has elapsed.

Menu 14: Leaven dough

This setting allows you to make raw leaven dough. Stir 1 will appear in the LCD screen. The

default time is 1 hour and 24 minutes. Time cannot be adjusted. The unit will "beep" when

all time has elapsed.

Menu 15: Cake

Stir 1 will appear in the LCD screen. The default time is 1 hour and 33 minutes. Time

cannot be adjusted. The unit will "beep" when all time has elapsed.

Menu 16: Jam

Please prepare and measure the desired fruits according to your recipe. Clean, peel and

cut the fruit into small pieces (approximately 3 cm). Add prepared fruit into the bread pan

and press "MENU" to select Menu 16 and begin operation. Stir 2 will appear in the LCD

screen. The default time is 1 hour and 4 minutes. Time cannot be adjusted. The unit will

AUTOMATIC BREAD MAKER

"beep" when all time has elapsed. Use heat resistant gloves when removing the pan from

the bread maker. Allow to cool before pouring the jam out of the pan.

Caution: Please keep children away from the heated jam to avoid burns.

Menu 17: Yogurt

Press "MENU" to select Menu 17 and begin operation. Ferment 3 will appear in the LCD

screen. The default time is 8 hours. Time can be adjusted from 30 minutes to 12 hours. The

unit will "beep" when all time has elapsed.

Menu 18: Bake

This setting is designed to bake pre-made dough. It can also be used to add baking time at

the end of another Menu setting if the crust color is lighter than desired. The default time is

10 minutes. The time can be adjusted from 10 minutes to 1 hour and 10 minutes. The unit

will "beep" when all time has elapsed.

Menu 19: Custom mode

This setting allows you to adjust the time of each step within a cycle, The default time is 3

hours and 1 minute. The default crust color is medium. Press the "LOAF" button to adjust

the Stir 1 working time by pressing the "+" or "-" button as needed. Press the "LOAF" button

again to adjust the Rest time. Press the "START/PAUSE" button to operate the appliance

after adjusting the cycles.

NOTE: Each step and the corresponding time is shown in the table below.

Working status cycles:

Reservation (Optional) – Preheat – Stir 1 (lower) – Rest – Stir 2 (faster) – Ferment 1, 2, 3 –

Bake – Keep warm – Complete

The appliance will "beep" to remind you to add ingredients (nuts, raisins etc.) at the Stir 2

cycle. At that time, you can open the lid and add the ingredients into the bread pan.

Step

Default time

Stir 1

(min)

Rest

(min)

Stir 2

(min)

Ferment 1

(min)

Ferment 2

(min)

Ferment 3

(min)

Bake

(min)

Keep warm

(min)

Reservation

(h)

Default time 7 1 25 58 0 60 30 60 0

Min time 0 0 0 0 0 0 0 0 0

Max time 30 30 30 120 120 120 120 60 15h

NOTE: The last custom mode setting can be saved in memory for the next use.

SPECIFIC FUNCTIONS DESCRIPTION

Using Reservation to delay start time:

This function will delay the start of your cycle time for Menu settings 1-10, 13 and 14

For example, if the current time is 8:30 PM and you wish to have a fresh loaf of bread ready

by 7:00 AM you will need a Reservation time of 10 hours and 30 minutes.

1. Calculate the Reservation time needed

In the example above, it is 10 hours and 30 minutes from 8:30 PM to 7:00 AM.

2. Set Reservation time

Press the "+" or "- " button to set the Reservation time to 10:30 and press the "START/

PAUSE" button. "Reservation:" will ﬂ ash and the time will begin to count down.

NOTE: The time displayed of 10 hours and 30 minutes includes the time to make the

bread. Freshly baked bread will be ready at 7:00 AM.

3. Cancel the Reservation time

Press the "STOP" button to cancel the Reservation function. The unit will "beep" and the

bread setting will return to Menu 1 automatically. The Reservation time is cancelled, and

the unit remains on.

Reservation function tips:

1. Do not use recipes with ingredients that can spoil such as eggs or milk.

2. Cover the yeast under ﬂ our to preserve the activity of the yeast.

The appliance will "beep" when:

1. The power cord has been plugged into a working electrical outlet

2. The buttons on the control panel are pressed

3. The operation is complete

4. The Keep warm cycle ends

5. During the Stir 2 cycle, the unit will "beep" to remind you to add additional

ingredients.

Memory function after power loss:

The unit will resume working if power is restored within 15 minutes of power loss. After

reconnecting electricity, the timer will resume counting down.

Keep warm:

This is designed to keep the bread fresh and at the perfect temperature if the bread cannot

be removed from the pan immediately after baking. Once the Menu function is complete,

the unit will switch to Keep warm automatically and remain warm for 1 hour. To cancel the

Keep warm function, press and hold the "STOP" button for 3 seconds. The unit will "beep"

and turn off.

Autres manuels pour MBF-016

Table des matières

Autres manuels Secura machine à pain

Secura

Secura MBF-016 Manuel utilisateur

Manuels machine à pain populaires d'autres marques

Aroma

Aroma BREADCHEF ABM-220 Manuel utilisateur

Unold

Unold 68415 Manuel utilisateur

Princess

Princess TYPE 151938 Manuel utilisateur

Gorenje

Gorenje BM 900 ND Manuel utilisateur

Tesco

Tesco BMS10 Manuel utilisateur

Sunbeam

Sunbeam 5891-33 Caractéristiques techniques

Kenwood

Kenwood BM300 series Guide produit

Moulinex

Moulinex abke Manuel utilisateur

Regal

Regal K6724 Manuel utilisateur

Lumina

Lumina Signature 102550 Manuel utilisateur

UFESA

UFESA PN5000 Manuel utilisateur

Breadman

Breadman TR2700 Instructions d'installation

Noxxa

Noxxa BM325SC Manuel utilisateur

Linea 2000

Linea 2000 Domo B3956 Manuel utilisateur

Moulinex

Moulinex Uno Manuel utilisateur

Saturn

Saturn ST-EC0124 Manuel utilisateur

Gemini

Gemini GBM550 Manuel utilisateur

Breville

Breville LBM200 Manuel utilisateur
