VI. FAQ
Q: There is no output on screen when all connections are correct?
A: 1) Please make sure the HDMI cables support the resolution of the output signal from the
source device.
2) Please check and make sure the network cable inserts to the RJ45 port well.
3) Restart the transmitter or receiver by pressing the reset button.
Q: Black screen happened on the display/monitor?
A: 1) Check if the length of the cable is within the specified range.
2) Reset the transmitter to re-built the connection.
Q: The display shows unusual color or no sound?
A: 1) Reset the transmitter or receiver to re-built the connection.
2) Check if the HDMI cables are connected well.
3) Reconnect the network cable.
VII. Specification
Items Specification
Power supply Voltage/Current DC 5V/1A
Power consumption TX<2.5W RX<2.5W
HDMI
Performance
And Interface
HDMI compliance HDMI 1.3
HDCP compliance HDCP 1.4
HDMI resolution
800x600, 1024x768, 1280x720, 1280x960,
1366x768, 1440x900, 1680x1050, 1920x1080,
480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz,
720p@50/60Hz, 1080i@50/60Hz,
1080p@24/25/30/50/60Hz
Supports audio formats PCM, LPCM, DTSHD, DTSAudio
Input and output TMDS signal 0.7~1.2Vp-p(TMDS)
Input and output DDC signal 5Vp-p(TTL)
Input cable length ≤8m(AWG24)
