Sea Eagle Fold cat 375FC Guide de démarrage rapide

Sea Eagle® FoldCat™

375FC

Instruction & Owner’s Manual

For video instructions visit SeaEagle.com/Instructions

Sea Eagle Boats Inc.

19 N. Columbia Street, Suite 1

Port Jefferson, NY 11777

1-800-748-8066

November 2018

scan this code

or visit

http://sea.gl/vifc

VIDEO

INSTRUCTIONS

Sea Eagle Warranty

All Sea Eagle products come standard with a 3 year warranty against manufacturing defects The warranty begins the

date that your product is delivered. Sea Eagle must inspect equipment in order to determine if there is a defect. In

the event that an item must be shipped back to us, Sea Eagle will only reimburse the standard return shipping charge

through FedEx, UPS, or U.S.P.S. at published shipping rates. Fees charged by retail shipping outlets, like The UPS Store,

will not be reimbursed and you are responsible for handling and packing charges.

Sea Eagle will refuse delivery on packages without a valid return authorization number and will not be responsible for

shipping or handling charges. To obtain a return authorization number, please contact Sea Eagle directly, unless you

purchased from an authorized dealer/reseller in which case contact them for more information.

If you receive a damaged item, please call the shipping carrier to report the issue. Do not return damaged

merchandise until it has been inspected by the carrier. Sea Eagle will be notied by the carrier when they have

completed their inspection and if necessary, Sea Eagle will arrange for the repair or replacement of damaged

merchandise.

See complete warranty details at SeaEagle.com/Warranty.

Decals, Stickers & Registration

Always contact your state boating authorities for information on boating registration and regulations. Most states

require you to register your boat if you are using a motor.

Upon registration it may be required to provide the Manufacturer’s Statement of Origin. Purchases made through an

authorized dealer or reseller may require for you to contact them directly in order to obtain this. You may be charged

your own state sales tax if you were not charged sales tax at the time of purchase.

Registered boats generally require for the registration number to be applied to the boat. We do not recommend the

use of decals or stickers as they tend to crack and peel over time with the repeated inflation and deflation of your

Sea Eagle. Instead we suggest applying these numbers to a small piece of hard plastic or marine plywood and

hanging it from your boat like a license plate if permitted by your state. Another method is to apply the numbers to

the hull using either PVC based paint or permanent marker.

Unlike many other companies today we pride ourselves on answering the phone and helping you with any concerns,

questions or special ordering needs that you may have!

Feel free to give us a call at 1-800-748-8066 and we will be happy to talk with you! Our business hours are Monday to

Friday from 9-5 (EST).

Sea Eagle Boats Inc.

19 N. Columbia Street, Suite 1

Port Jefferson NY 11777

1-800-748-8066

[email protected]

Congratulations on purchasing a Sea Eagle!

With over 45 years of experience in designing, selling and using these quality

inflatables, we’re confident that you are going to love your Sea Eagle and we’re

ready to proudly stand behind them.

OPERATING YOUR SEA EAGLE

MOTORING

The Fold Cat pontoons are large diameter which gives the boat plenty of otation. Large pontoons raise the height of

the motor mount, we therefore recommend a using a 20” long shaft gas motor with the boat for maximum

performance. The motor mount should be installed in the lowest position.

Any power rating under 3 hp is recommended. Adding more power will not increase speed, in fact the motor can

only be used up to approximately one-third throttle. More throttle will cause the motor to sound like it is straining

and cause it to shake. Overpowering will also waste fuel. Gas motors typically have a much greater range than electric

motors.

Trolling motor power is measured in pounds of thrust and battery draw. A motor rated at 30 lbs thrust consumes

approximately 30 amps at full throttle. They typically are far less powerful than a gas motor but provide adequate

power for a light weight inatable boat such as the FoldCat. Most trolling motors have a maximum speed of about

4 mph. The propeller is pitched to maintain this speed and not faster. A larger trolling motor, a 55 lb thrust motor for

example, will push a boat faster in a headwind, but not faster in calm water or against a current. Most trolling motors

consume much less than 30 amps at lower throttle settings. We measured the Watersnake Venom at 12.4 amps at the

number 3 setting for example.

To calculate the range that can be expected from a battery, divide the amp hour rating of the battery by the

amperage rating of the motor. For example a Group 24, 77Ah battery paired with a Minn Kota 30: 77 Ah divided by 30

amps yields 2.5 hours at full throttle.

A 12v deep cycle marine battery, lithium ion battery, personal watercraft battery or electric vehicle battery is

acceptable. The important parameter is the battery’s ampere hour (Ah) rating. A Group 27 battery or smaller is

recommended.

• Charge battery after each use. Lead acid batteries like to be kept charged.

• Running the battery all the way down will shorten its life.

• Exposure to excessive heat will shorten battery life.

• Cranking amps (CCA) are not a consideration.

• 12v automobile, lawn tractor and motorcycle batteries can be used but are not designed for deep discharge so will

wear out more quickly.

• A battery box is recommended especially around aluminum crossbenches or oar shafts which could cause an

electrical short.

• A circuit breaker or fuse is recommended (required in some areas) to prevent damage in the event the motor wires

are placed on the wrong terminals. Reversing the polarity can cause the wires to heat up, melt the insulation, and

cut through the boat.

• A 12v battery charger will be needed. Chargers are widely available.

• If available, choose gel cell over wet cell. Wet cell batteries have liquid acid inside them.

• Marine batteries are heavy, choose one you can carry without injury.

• Expensive batteries can weigh less and last longer because of their superior internal architecture.

• Battery can be secured to the aluminum crossbenchs or placed on the black PVC oor.

Follow manufacturer's safety procedures.

DISPLACEMENT HULL

In addition to motor type, there are factors that regulate how fast a boat can go. Two important factors are boat length

at the waterline and planing. Under most conditions the FoldCat cannot plane, it is considered a displacement hull.

The FoldCat’s length limits the hull speed to below 8 mph. For further information, search the internet for

“displacement hull speed.”

On a river or in a tidal inlet, if the current exceeds approximately 8 mph, you will not be able to make progress

relative to land and in fact will be swept backwards. Adding a larger motor will not make a displacement hull exceed

its hull speed, steer to calmer water, portage, or await a tide change.

WEIGHT BALANCE

Distribute the weight of passengers and gear evenly in the boat. The boat should not be leaning side to side nor fore

and aft (front to back). This may require moving some items, like a trolling motor battery forward as much as possible.

Note: the oor can easily support the weight of passengers or a battery. The “No Standing” label is to prevent tripping

on the crossbenches.

DANGER

To avoid injury if you or a passenger falls overboard, approach the boat on the side opposite the motor. See

re-entering instructions on page 15. Do not smoke around open gasoline containers. Avoid spilling gas.

Gas powered motors produce carbon monoxide which can cause asphyxiation. Avoid breathing exhaust.

ROWING

Due to it’s light weight, the FoldCat is surprisingly easy to row. Clearance is limited so you must have your legs straight

or the oars will hit your legs. If you are new to rowing it may seem easy enough, but it will take some practice to

coordinate the strokes. There are many online articles and videos to aid in learning.

The boat can be rowed in either direction, but rowing is most ecient when pulling on the power stroke which

propels the rower backwards. Make it a habit to look behind you frequently to check for hazards and to make course

corrections.

The FoldCat is not intended for rowing in at water such as lakes and bays. Always bring the oars even if you have a motor.

(????)

DAMAGE

The FoldCat is tough and durable but it can be damaged. Sticks and rocks typically don’t puncture the FoldCat, but

discarded metal, nails in oating docks and oyster beds can puncture.

A lot of damage can be done dragging the boat. This is true while it is in the bag too. It is better to carry than to drag a

Fold Cat, but especially avoid dragging the FoldCat on concrete or asphalt. The boat can be pushed o the shore and

return to shore and pulled aground. This should not damage the FoldCat, but care should be taken to avoid hazards

that could cut or puncture.

Fish hooks rarely puncture a boat because they are recurved, but sh spines can make small punctures. Hold sh o

the pontoons and land sh on the black oor.

OPERATING YOUR SEA EAGLE

Safety

In a manual of this type it is impossible to give adequate space to the topic of water safety. For further information on

boating safety, visit USCGBoating.org or enroll in a water safety course given by a local provider.

It is your responsibility to be aware of and comply with all relevant safety regulations. For all water recreation or sport you

should have a reasonable swimming ability. Just as swimmers have a cardinal rule about not swimming alone, it is strongly

advised that you should never go boating alone.

Boating Safety Tips

• Always wear a USCG approved PFD (life vest) at all times while on the water.

• Be aware of your local boating rules and regulations and abide by them accordingly.

• Check inflation levels each time before you go out and inflate your boat for a full 24 hours before undertaking long trips.

• DO NOT allow children to use Sea Eagle unsupervised.

• DO NOT consume alcohol while boating or operating a boat while under the influence of alcohol or drugs.

• DO NOT drag your Sea Eagle over rocks or gravel if it can be avoided.

• DO NOT exceed the certified maximum capacities of this boat under any circumstance.

• DO NOT go boating alone.

• DO NOT use compressors, CO2 or compressed air for inflation, only use Sea Eagle recommended pumps.

• DO NOT use your Sea Eagle Boat as a personal flotation device as they are designed for leisure/recreation in mind.

• DO NOT sleep inside of your Sea Eagle while on the water.

Safety Equipment

The type of water conditions you are on should determine the type of safety equipment that you should have on board. For

all types of boating we strongly recommend that every passenger wear a USCG approved PFD (personal flotation device)

like a life vest. In most places this is a requirement by law, but from our point of view it is also an exercise of good judgment

to have a PFD for all passengers.

Other important items to consider for all types of boating…

Drinking Water & Snacks: Kayaking is a physical activity that can work up both a thirst and a sweat and especially on a hot or

warm day it is a good idea to have drinking water readily available to you to prevent dehydration. Bring a good amount of

water for all passengers as you want to avoid drinking the water you’re kayaking in which may be full of contaminants.

Extra Clothes/Layers: You never know when the weather can change and it’s a good idea to come prepared with extra

clothing. If you have a dry (waterproof) bag than we recommend storing them inside so they’re not damp in case of

emergency.

First Aid-Kit: The contents of the kit may vary depending upon your preferences, but make sure to carry a kit that reflects the

possible dangers for the conditions you are in.

Foot Pump/Repair Kit: Although our boats are both durable and rugged, it may be possible that you need to make a repair

while on the water in which case you’ll need the repair kit and the foot pump to re-inflate the boat. If this is your first repair,

you may also want to bring this instruction manual with you.

Sun/Rain Protection: A hat can protect both your face and head from the rain or sun. You may also want to carry sunscreen

with you as both the sun and the sun’s reflection from the water can do serious damage to your skin. If you are out for

prolonged periods of time you may need to reapply sunscreen as needed.

Whistle: Having a whistle readily available to you in case of emergency is a great way to attract the attention of others if

assistance is needed.

Float Plan: Similar to a pilot’s Flight Plan, consider having a Float Plan (www.floatplancentral.org). Always tell someone

where you are going to be boating and what time you plan to return. Keep a cell phone in a waterproof container that will

float if it falls in the water.

SAFETY

Recessed Air Valves

Remove the cap and press

and turn the valve stem

counterclockwise so that

the stem is in the UP

position. When the stem

is in the up position the

valve will retain air. Turn

the stem clockwise and

down to valve for

deflation.

When ready to inflate,

insert valve adapter and

twist clockwise to lock in.

The adapter has a bar that

will hold the valve open

for easy pumping. Do not

inflate until underbars are

installed.

A-41 Foot Pump

Unwrap the hose and press

the two halves to release

the clip. Screw the hose

into the OUT port. Foot

pump rapidly inflates boat.

Cannot not over inflate

boat with foot pump.

Recessed Adapter

The recessed valve adapter

is located inside of the

orange repair kit canister.

Insert the ribbed end of the

valve adapter into the hose

on the foot pump.

Also included are a cluster

of seven valve adapters,

with raised numbers on

each arm of the cluster.

The adapter marked

number 1 is the only

adapter needed for your

Sea Eagle.

INFLATION, VALVES & PUMPS

BTP Turbo & BP12

Electric Pumps

(OPTIONAL)

These electric pumps

come with a nylon

shoulder carry bag, 12V

DC power cord, hose and

adapters.

WARNINGS: Keep out

of the reach of children.

Don’t leave running

unattended. Do not use

inflator for more than 20

minutes continuously as

this can cause overheating

and damage.

Locate the gray adapter

with red gasket. Press

and twist this adapter

firmly onto the gray tube

at the end of the black

hose.

The tube is glued in, do

not try to remove it.

Take adapter number 1

from the cluster and firmly

push it into the grey tube

that is already connected

to the end of the hose. To

ensure that the adapter

is on as tight as possible,

push it past the raised

ring that is inside of the

adapter.

BTP Turbo Pump

Connect the other end

of the hose to the red

inflation port at the top

of the pump, located near

the ON and OFF buttons.

PSI numbers are red.

BP12 Electric Pump

Connect the hose to

the red inflation port in

the end of the pump.

PSI numbers are

yellow.

Adjust the pressure dial

to read 3.2 PSI which is

the operating pressure

of your Sea Eagle. PSI

is marked in red on the

dial. Never turn the

dial when the device is

under pressure as this

will immediately cause

the instrument to break.

Connect the cord at the

end of the power supply

into the end of the cord

attached to the pump.

Connect the Turbo Pump

to a 12V battery (car or

marine) using the

alligator clips at the end

of the extension cord.

Connect the red clip to

the positive pole and the

black clip to the negative

pole.

Press the ON button to

begin inflation. The pump

operates in two stages

which can be identified by

the noise of the turbine at

the start, followed by the

piston. The pump

automatically stops once

the pressure is reached.

Warning:

Air compressors that

are designed for other

uses like tire inflation

(usually around 50 PSI)

can easily harm your Sea

Eagle which works at a

much lower pressure of

3.2 PSI. For this reason

we recommend only

using Sea Eagle pumps.

INFLATION, VALVES & PUMPS

Locate an area large

enough to unfold the

boat. Avoid hazards that

could damage the boat or

injure you. If out of

alignment, slide

crossbenches so they are

centered on the

hold-downs.

Stabilizer Underbars

Insert underbars under the

crossbenches, two in the

front, two in the rear.

Align the ends of the

underbars in line with the

triangular markings on

each pontoon.

Note: Bars might not touch

markings.

ASSEMBLY & INFLATION

When properly aligned,

the underbars should line

up underneath the center

crossboard. Bars may not

touch under crossboards.

Once they are in place,

finish inflating the boat to

full capacity.

Swivel Seat

The 375FC has two basic

seating positions with one

at the rear and the other

at the front.

Insert the adapter into the

valve, turn it to the right

until it locks in the

opening. Valve stem must

be in the UP position.

Note: if adapter it too tight

to turn, stretch rubber

gasket until pliable and

retry.

Pump until very firm.

Pontoon should be very

tight with almost no

wrinkles. Floor will be

stretched tight between

pontoons. Use firm even

strokes, do not stomp on

pump. Finished when very

firm resistance from foot

pump is felt.

Quick Release Seat Mount

comes with four 2” bolts

and four wing nuts. A

Phillips head screwdriver

(not included) is needed

to complete installation.

The mount can remain

attached when being

folded for storage and is a

one-time assembly.

Position the mount over

the pre-drilled holes

designated for it and

bolt the mount to the

floorboard using the bolts

and wing nuts.

Locking tongue should

point to side of boat.

Now slide base of the

swivel seat (or base of

the pedestal) into the

mounts. Make sure that

the spring loaded lever

mechanism locks into

place (up position).

Bolt the pedestal directly

to the bottom of the swivel

seat. Four 1/2” screws and

wingnuts are provided.

Pedestal (OPTIONAL)

The pedestal is included

in several FoldCat boat

packages and includes

four 1/2” bolts and four

wingnuts. The 375FC can

be fitted with up to two

pedestals.

Note: Make sure that

all hardware is secured

tightly before every use.

Scotty Rod Holder

Holds a bait caster reel in

a cushioned cradle. Slot in

the front allows for a

spinning reel to be

securely held in place.

Includes side/deck

mount. A Phillips Head

screwdriver (not included)

is needed.

Scotty Rod Holder consists

of a surface mount base,

adjustable rod holder

and four #6 x 1” phil truss

stainless steel screws. A #2

phillips head screwdriver is

needed (not included).

Orient the base so the

“Inboard” arrow is

pointing toward the center

of the boat. Secure base

to the crossboard with the

screws. This is a one-time

installation.

Oars & Oarlocks

Each oarlock includes one

oarlock pin, two bolts,

two knurled knobs and

two washers. First, attach

the oarlock to the middle

floorboard.

ASSEMBLY & INFLATION

Bolt the raised oarlock

bases at both ends of the

aluminum bench through

the pre-drilled 3/8” holes

(2 at each end) using

knurled nuts

Slide the oarlock pin over

the shaft of the oars, snap

the oars shafts together

and then insert the oarlock

pin into the top of the

oarlock. Tighten the clamp

with the wingnut.

Once the oar pins are

inserted place, lock them

in place using the slide

rings as shown.

375FC Motormount

Includes a motor mount

block, two brackets, four

bolts, knurled knobs and

washers.

Secure the brackets to the

motor mount block using

one set of bolts. Orient the

block so it hangs about

1/2” below the floorboard.

Then use the remaining

bolts to secure the mount

to the floorboard.

To prevent cavitation

when using a short shaft

gas motor. The completed

setup should hang slightly

below the floorboard,

as shown. Tighten the

knurled nuts and bolts

before securing a motor.

Casting Bar (OPTIONAL)

Adds safe and secure

support for stand-up

casting and doubles as

a convenient hand-hold

while stepping aboard.

Includes crossbar with

padded cover, two

upright leg bases, and two

4mm hex keys (one spare).

Insert the uprights into the

crossbar. The height of the

casting bar can be

adjusted to one of three

positions using the

pre-drilled holes on the

uprights.

ASSEMBLY & INFLATION

Table des matières

Autres manuels Sea Eagle Bateau

Sea Eagle

Sea Eagle Stealth Stalker STS10 Guide de démarrage rapide

Sea Eagle

Sea Eagle FoldCat 375FC Guide de démarrage rapide

Sea Eagle

Sea Eagle 9 Guide de démarrage rapide

Sea Eagle

Sea Eagle RazorLite 393RL Guide de démarrage rapide

Sea Eagle

Sea Eagle RazorLite 393RL Guide de démarrage rapide

Sea Eagle

Sea Eagle FoldCat 325FC Guide de démarrage rapide

Sea Eagle

Sea Eagle Explorer 380x Guide de démarrage rapide

Sea Eagle

Sea Eagle 8.10YT Guide de démarrage rapide

Sea Eagle

Sea Eagle FishSkiff FSK16 Guide de démarrage rapide

Sea Eagle

Sea Eagle SE-9 Guide de démarrage rapide

Sea Eagle

Sea Eagle HB96 Guide de démarrage rapide

Sea Eagle

Sea Eagle RIB11 Guide de démarrage rapide

Sea Eagle

Sea Eagle PaddleSki 435ps Guide de démarrage rapide

Sea Eagle

Sea Eagle FoldCat 375FC Guide de démarrage rapide

Sea Eagle

Sea Eagle PaddleSki 395ps Guide de démarrage rapide

Sea Eagle

Sea Eagle Stealth Stalker 10 Guide d'installation

Sea Eagle

Sea Eagle FastTrack 385FTG Guide de démarrage rapide

Sea Eagle

Sea Eagle SailCat 14SC Manuel utilisateur

Sea Eagle

Sea Eagle 8.10YT Guide de démarrage rapide

Sea Eagle

Sea Eagle Fish-n-Troll Guide de démarrage rapide

Sea Eagle

Sea Eagle TC16 Guide de démarrage rapide

Sea Eagle

Sea Eagle Stealth Stalker 10 Guide de démarrage rapide

Sea Eagle

Sea Eagle NeedleNose SUP NN116 Guide de démarrage rapide

Sea Eagle

Sea Eagle RazorLite 393RL Guide de démarrage rapide

Manuels Bateau populaires d'autres marques

Raymarine

Raymarine ST70 Instrument Manuel utilisateur

Pro-Line Boats

Pro-Line Boats Pro Line 19 Sport Manuel utilisateur

Jeanneau

Jeanneau CAP CAMARAT 8.5 CC Manuel utilisateur

Tiara Yachts

Tiara Yachts C49 2024 Manuel utilisateur

Monterey Boats

Monterey Boats Sport Yacht 330 Manuel utilisateur

J 105 Manuel utilisateur

PURSUIT

PURSUIT OS 335 Manuel utilisateur

Boston Whaler

Boston Whaler CONQUEST 345 Manuel utilisateur

Jeanneau

Jeanneau SUN ODYSSEY 41 DS Manuel utilisateur

Meridian

Meridian 490 Pilothouse Manuel utilisateur

Advanced Elements

Advanced Elements AdvancedFrame Expedition AE1009 Manuel utilisateur

Robo Marine Indonesia

Robo Marine Indonesia GEOMAR Manuel utilisateur

Swallow Boats

Swallow Boats BayRaider Manuel utilisateur

Intex

Intex Excursion 5 Set Manuel utilisateur

X SHORE

X SHORE EELEX 8000 Manuel utilisateur

ISLAND PACKET

ISLAND PACKET 370 Manuel utilisateur

Sea Ray

Sea Ray 175 Sport Manuel utilisateur

Regal

Regal 2300 Manuel utilisateur

Sea Eagle fold cat 375FC Guide de démarrage rapide

Manuels Bateau populaires d'autres marques
