Scytek electronic Precision Blue Manuel utilisateur

PRECISION BLUE

BLUE TOOTH KEYLESS ENTRY

VEHICLE SECURITY SYSTEM

PRODUCT MANUAL

Limited

Lifetime

Warranty

This vehicle security system is warranted to the original purchaser, to be free from defects in

material and workmanship. The manufacturer will repair or replace at its option, and free of

charge for the first twelve (12) months, any part that proves defective in material or workmanship

under normal installation, use, and service, provided the product is returned to the manufacturer

freight prepaid. After the first 12 month warranty period there will be a maximum service charge

of $35.00 per calendar year (if required) for repair and/or replacement of any defective parts.

A copy of the original purchase and installation receipt must accompany any products

returned for warranty service. Warranty is limited to defective parts and/or replacement parts

only and excludes any incidental, and consequential damages connected therewith.

The manufacturer of this theft deterrent system makes no warranty against the theft of the vehicle

or its contents. This warranty is not to be construed as an insurance policy against loss.

WARRANTY OF INSTALLATION LABOR, REMOVAL AND RE-INSTALLATION CHARGES ARE

NOT THE RESPONSIBILITY OF THE MANUFACTURER.

Note: This Warranty is voided if the product was not installed by an

Authorized ScyTek Dealer.

1. Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 1

Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 1

Emergency Override . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 1

Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 1

2. Adding/Replacing Bluetooth Phones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 2

3. Programming table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 2

4. System Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3

5. Default Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3

6. Entering System Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3

7. Default Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3

8. Resedence Valet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3

9. Drive Off Valet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 3

10. System Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 4

11. Mounting the Bluetooth Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 4

12. System Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 5

13. Jumper setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 5

14. Door Lock Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 6

15. Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Page

Table

Contents

About

Your

System

Congratulations on your purchase of this state-of-the-art vehicle security system from ScyTek

Electronics. With proper installation this system will provide superior protection and performance

for many years to come.

System Contents:

•Main Unit

•Blue Tooth Transceiver Antenna

•Status LED

•8 Pin Main Harness

•6 Pin Blue Tooth Antenna Harness

• Emergency Override/ Valet Switch

Options and Accessories*

This ScyTek system includes several optional inputs and outputs allowing the creation of a

completely personalized security and convenience system by offering many optional features

such as: Car Alarms, Remote Engine Starter, GPS Tracking Systems.

*May require additional parts and/or labor, see store for details.

PLEASE NOTE:

Some of the features described in this manual may require additional parts and/or labor, and may not be included

as part of the standard installation of this unit. Additionally, many features of this security system have

selectable options that must be activated or programmed during the system’s installation. These items will be

identified in the following sections. Please discuss these features and any questions you may have regarding the

installation of this product with Your Authorized Dealer.

Precision Blue - Page 1

Cell Phone with Blue Tooth

All ScyTek systems with Cnet capability combined with Precision Blue will arm and disarm the Alarm

Arming

To Arm the System:

The system arms itself automatically, each time the ignition is turned off and the Cell Phone is

out of range.

To start the Arming Process:

1. Turn off the ignition.

2. Open the door and exit the vehicle.

Once the cell phone is out of range, the LED will begin flashing rapidly.

3. After 10 seconds.

· The horn will honk.

· The doors will lock.

· The status LED will begin flashing.

4. The system is now armed.

Once Armed, the alarm will trigger when any of the following occurs:

·The ignition is turned to On position.

When the alarm triggers, the horn will honk for 30 seconds.

Disarming

To Disarm the System:

The system disarms itself automatically, when the Cell Phone within range

· The Horn will Honk twice.

· The doors will unlock.

· The LED will turn off.

Emergency Override

If the Cellphone becomes lost or inoperable, the system can still be disarmed using the following

procedure. Before beginning this procedure be sure to have the ignition key ready and know the

location of the override switch.

To Emergency Override the system:

1. Unlock the door using the key.

2. Enter the vehicle.

3. Turn the ignition key on.The system will trigger and the horn will sound.

4. Press and hold the override switch until the system disarms.

5. The vehicle will now be able to start.

Page 2 - Precision Blue

Adding/Replacing Bluetooth Phone (2 Phones maximum)

1- Set the BlueTooth enabled phone name to ScyTek.

2- Turn on the ignition key On, Off, and back On. 10 times.

3- The LED will illuminate.

4- Set the BlueTooth enabled phone to discoverable mode.

5- Turn Ignition Off.

6- The LED will start Flashing.

7- Once the Phone has been detected the LED will turn Off.

8- Change the BlueTooth enabled phone name to original name other than

ScyTek.

Programming Table

Adding a second Bluetooth cellphone

connect a second Precision Blue module to the first ( master) unit with a 3 pin Cnet

connector.

Set the second Precision Blue module to slave mode by Removing the master/slave jumper inside the module.

1- Set the BlueTooth enabled phone name to ScyTek.

2- Turn on the ignition key On, Off, and back On. 10 times.

3- The LED will illuminate.

4- Press and release the valet switch one time.

5- Set the BlueTooth enabled phone to discoverable mode.

6- Turn Ignition off.

7- The LED will start Flashing.

8- Once the Phone has been detected the LED will turn Off.

9- Change the BlueTooth enabled phone name to original name other than

ScyTek.

Branch Feature Ignition OFF/ON Ignition OFF/ON Ignition OFF/ON

1 Time (default) 2 Times 3 Times

1. Exit Delay (Seconds) 10 15 20

2. Ignition Controlled Lock On Off

3. Ignition Controlled Unlock On Off

4. Door Lock Pulse Length 1 Second 3 Seconds 0.1 Second

5. Door Unlock Pulse Single Double

6. Horn/Sidelight Option Horn Sidelight

7. Extended Parking Lights On Off

8. Horn Pulse Duration Normal Extended

Precision Blue - Page 3

Entering System Programming

To enter System Programming:

1. Turn on ignition.

2. Within 5 seconds, press the valet switch 5 times.

· The Horn will provide three chirps, indicating that you have entered Programming.

3. Press the valet switch the number times equal to the System Option you want to change.

· The siren will chirp each time the valet switch is pressed.

4. Within 5 seconds, turn ignition OFF and ON corresponding to the desired operating mode for

that System Option.

· The Horn will Honk to indicate the setting.

1 Honk = Ignition OFF/ON 1 Time

2 Honks = Ignition OFF/ON 2 Times

3 Honks = Ignition OFF/ON 3 Times

5. When you are finished, turn off the ignition to save the changes.

Default Reset

Following this procedure will set all Programmable System Options to factory default settings.

1. Enter System Programming.

2. Turn The Ignition OFF/On 3 Times.

· The siren will chirp 6 times indicating that the reset signal was received.

· All Programmable System Options are now set to factory default settings.

· The Valet Mode is off.

3. Turn off ignition.

Resedence valet (Home Garage)

1. with ignition in Off position Press Valet switch 3 times

2- LED will start flashing once every 5 seconds doors will not lock automaticaly

until ignition turns on and off again.

Drive off valet

1. with ignition in On position Press Valet switch 3 times

2- LED will flash once.

3- when ignition turns back to Off position the LED will flash rapidly and doors will lock automaticaly.

at this time the Bluetooth Phone will be ignored until ignition is turned On again.

Page 4 - Precision Blue

1. Thoroughly read and become familiar with the installation instructions before beginning the

installation.

2. Review system contents:

Main Unit

1 Precision Blue Main Module

1 Main Harnesses ( 7 wires)

•6-Pin Antenna Receiver harness

•LED harness

•Valet Switch harness

•Receiver Harness

3. Verify with the owner, the mounting locations for all visible components, including the LED

and Override switch.

4. Verify with the owner, the optional features of the Precision Blue and the functions that must

be programmed during installation.

5. Inspect and perform a function test of all vehicle systems before and after the installation.

6. Always use a Volt / Ohm meter for testing vehicle circuits. Never use a test light.

7. Always look before drilling any holes or mounting self-tapping screws. Be sure fuel lines and

exterior wiring looms are clear as they are often close to the chassis and difficult to see.

8. Protect all wires running from the engine compartment to the interior of the vehicle by

covering with electrical tape and split loom tubing. Be sure to use a grommet when routing

wires through the firewall.

9. Properly fuse any additional accessories such as window modules, door lock actuator, etc.,

making sure to power them separate from the alarm module. This will ensure the

functionality of the security system in the event of an accessory failure.

Mounting Bluetooth Antenna

Mount the antenna on the top center of the windshield for maximum range.

System

Installation

Precision Blue - Page 5

System

Wiring

8-Pin Main Harness

Pin 1 GREEN WIRE: negative lock output (-) 500mA.

Pin 2 BLUE WIRE: negative Unlock output (-) 500mA.

Pin 3 ORANGE: Armed Output (-) 500mA. The ORANGE wire provides a ground output while armed to

activate an optional starter defeat relay or other device such as a power window control module.

Pin 4 BROWN/WHITE WIRE: Horn Output (-) 500mA. Connect to the vehicle’s horn, this wire can be

programmed to become parking light output (-) 500mA.

Pin 5 BLACK WIRE: Ground Input (-). The BLACK wire must connect to a solid chassis ground. Clean away

any paint or dirt to insure the best possible ground.

Pin 6 Empty: N.A

Pin 7 YELLOW WIRE: +12V Ignition Input. The YELLOW wire must connect to a main ignition wire at the

ignition harness. This wire must show +12V when the ignition is on. This wire will trigger the horn

for 30 seconds when the system is armed.

Pin 8 RED: +12V Battery Input (15A Fuse). The RED wire must be connected to a clean source of

continuous +12V power.

Plug-in Connectors

2-Pin Red Connector: Plug-in connector port for LED. Mount the LED in an area where it may be easily

seen from either side of the vehicle.

2-Pin Blue Connector: Plug-in connector port for valet switch. Mount the valet switch in an area that is

easily accessible from the driver’s position.

6-Pin Black Connector : Plug-in connector port for Bluetooth Antenna.

2- 3 Pin Blue Connectors : Cnet (network) connectors for optional Accessories.

Master/Slave Jumper

Jumper On = Master Mode. (stand alone mode)

Jumper Off= Slave mode. ( connected to other ScyTek products through Cnet port)

Page 6 - Precision Blue

Follow the diagrams below for connecting basic door lock systems.

Door

Lock

Diagrams

Negative Trigger Positive Trigger

Reverse Polarity Vacuum

Adding Actuator

Table des matières

Autres manuels Scytek electronic Démarreur à distance

Scytek electronic

Scytek electronic Astra 1000RS Series Manuel utilisateur

Scytek electronic

Scytek electronic 2100RS Series Manuel utilisateur

Scytek electronic

Scytek electronic GALAXY G40RS Manuel utilisateur

Scytek electronic

Scytek electronic Galaxy 2000RS-MDL Manuel utilisateur

Scytek electronic

Scytek electronic ASTRA 300RS Manuel utilisateur

Scytek electronic

Scytek electronic ASTRA 300RS Manuel utilisateur

Scytek electronic

Scytek electronic Galaxy G35RS Manuel utilisateur

Scytek electronic

Scytek electronic Galaxy 2000RS Plus SERIES Manuel utilisateur

Scytek electronic

Scytek electronic ASTRA 100RS Manuel utilisateur

Scytek electronic

Scytek electronic Galaxy 2000RS-2W Manuel utilisateur

Scytek electronic

Scytek electronic Astra 1000RS Series Manuel utilisateur

Scytek electronic

Scytek electronic Astra 50 Manuel

Scytek electronic

Scytek electronic A777 Manuel utilisateur

Manuels Démarreur à distance populaires d'autres marques

AstroStart

AstroStart 803U Manuel utilisateur

Durite

Durite 0-649-20 Manuel

EINHELL

EINHELL BT-PS 1000 Manuel

Linear

Linear ACCESS AK-21 Caractéristiques techniques

Soundstream

Soundstream TARANTULA RS.2 Manuel utilisateur

Jaycar Electronics

Jaycar Electronics MB3752 Manuel utilisateur

Ultra Start

Ultra Start 72 Series Manuel utilisateur

ADS

ADS FLASHLOGIC FLRSVW1 Manuel utilisateur

Selecta

Selecta JS012 Manuel utilisateur

Black Widow Security

Black Widow Security BW RAS 400 Manuel utilisateur

Vector

Vector Power City DK080706 Supplément

Code Alarm

Code Alarm CA-535 Manuel utilisateur

Ozito

Ozito OJS-800 Manuel utilisateur

Profi-Partner

Profi-Partner 46387 Manuel utilisateur

EZ STARTER

EZ STARTER EZ-45 Manuel utilisateur

Viper

Viper 4204 Manuel utilisateur

Essex Electronics

Essex Electronics KE-1701 Manuel utilisateur

EINHELL

EINHELL EGS 3600 Manuel
