Scotsman CU0415 Guide d'installation

Technical Training

CU0415, CU0715, CU0920

Essential Ice

Presentation Topics

•Introduction

•Installation

•Operation

•Cleaning

•Diagnostics

•Service

Introduction

•Three basic models

– Air cooled, 15 inch wide, 58 lb – CU0415

– Air cooled, 15 inch wide, 80 lb – CU0715

– Air cooled, 20 inch wide, 100 lb – CU0920

•Three electrical configurations

– 1 or 115 60 Hz

– 32 or 208-230 60 Hz

– 6 or 230 50 Hz

•Warranty – 3 years parts and labor

Ice Type

•Medium cube / full dice

•Inverted grid evaporator

•Dedicated spray jet per

cube cell

•45 cubes per cycle

– Cubes harvest as a unit

Evaporator

•Nickel Plated Copper

•Mounted inverted above

spray platform

Refrigeration System

•R-134a

•Cap tube

•Air cooled only

– Air in the front and out the front

– Fan pressure control switch

•No access valves

•Common evaporator on all three

Water System

•Batch type – single fill per cycle

– Inlet water solenoid valve

• .275 GPM

• On during harvest

– Standpipe in reservoir

•Water pump

– Off during harvest

•Spray platform

•Same parts on all models (non electrical)

Control System

•Temperature initiated, timed cycle

– Thermistor on suction line

• For freeze and harvest

– Controller

– Bin thermostat

• Opens on temperature fall

• Capillary tube in sensing tube in bin

– Thermistor in pump hose

• For anti-slush mode

Installation

•Unit supplied with 6 inch legs

– 8 inch available – 02-4731-02, set of 4

•Can be floor mounted

– Has bumpers on base to keep from damaging floor

– Kit available to make sealing to floor easier

• KUFM15 or KUFM20

– Can fit under 34” high ADA counter

• 32” high w/out legs, including space for bumper or floor

mounting kits

Floor Mounting Kits

•Kits provide plastic glides

and trim strips to attach

to base in place of legs

•Fills in the half inch of

space at the bottom

•Allow sealing to the floor

•Will fit under 34 inch

ADA countertop height ½ inch

31 ½

inches
