Scorpio Ride secure Manuel utilisateur

SECURE

To get started with Ride, install the Core

device on your bike using this guide.

When installing modules, refer to the

respective guides.

For more info, log on to ridescorpio.com/help

Download the app and sign up for

an account. Then, scan your ID and

activate your subscription account.

Ready to ride.

Log on with the app and Rider Dash

at ridescorpio.com/dash.

TABLE OF CONTENTS

Components List

Plan an Install

Mounting

Switched Power

Attach GPS

Plug in Core

Mount the Components

Encoding the Remote

Testing the Installation

Accelerometer Programming

Adjusting Perimeter Sensor

Troubleshooting

10–11

13–14

14–16

18–19

20–21

Quick

Connector

Siren

Perimeter

Sensor

Remote

Hook & Loop /

Cable-ties

Harness

COMPONENTS

Make sure that the motorcycle battery is

fully charged. Verify that no moving parts

will interfere with the components.

Do not route wires near sharp edges

which could cut wires and create a short.

Do not mount components near high heat

sources such as the exhaust pipes. Do not

install the Ride Module under any metal.

The internal antenna can transmit through

ﬁberglass, leather, or plastic.

PLAN AN INSTALL

TECH TIP

RIDE has an internal cellular

and external GPS antenna.

Do not mount in a location where the

unit will be completely blocked by metal

(such as under the fuel tank).

Ideal locations are under the seat

or in the tail section.

Select a suitable location under the seat

or side cover that the module can lay as

ﬂat as possible.

MOUNTING

The Ride Core harness has three wires.

You’ll need to connect these to your bike.

Red: Install the terminal ring of this wire

directly to the battery positive post.

Black: Install the terminal ring of this wire

directly to the battery negative post.

TECH TIP

RIDE requires proper installation of

the switched power wire to function

correctly. Switched power is hot

(12 volts) when the ignition is on, zero

volts when off. Common switched

power sources are the tail light, (NOT

the brake light), the license plate light,

and some accessory plugs.

SWITCHED POWER

Common tail light power wire colors

Honda Brown or White w/black stripe

Kawasaki Red

Suzuki Brown

Yamaha Blue w/Red stripe

Harley-Davidson Blue

Ducati Yellow

White: Install this wire to a 12 volt

switched source using the provided

Quick Connector.

For example: the tail light or license plate

light power wire.

Locate the 12 volt switched wire source

on your vehicle. The most common

applications are the tail light power wire

(not the brake light) or the license plate

light power wire. Do not attach the RIDE

white wire to any LED light sources, LED

lights operate at a lower voltage.

Remove the cap on the open end of the

Quick Connector attached to the white

wire of the installation harness. Insert

the switched power wire of the vehicle

into the slot in the cap. Tighten the cap

back on to the Quick Connector.

Plug the installation harness into the

Ride module. Secure the module with

the included hook & loop/cable ties.

PLUG IN CORE

Attach the GPS antenna to the RIDE

module. Secure the GPS antenna in a safe

location where it is not blocked by metal

and pointed toward the sky. The antenna

is magnetic, but also secure it with the

included hook & loop/cable ties.

ATTACH GPS

GPS
