SCIWIL M61 Manuel utilisateur
1
USERS GUIDE
M61
No.：
XSW-J-04-0003-2023
Name：
User Manual M61
Issued on：
28th Aug, 2023
Version
A/0
Page 1 of 31
Written By: Zhang Pei Rev.：Liu Jian Apprv.：Luo Zhenrong
Changzhou Sciwil E-Mobility Technology Co., Ltd.
9th Huashan Road, Changzhou, Jiangsu, China- 213022
Fax: +86 519-85602675 Tel: +86 519-85600675
2
Contents
1. Product Introduction .......................................................................................................................... 6
1.1 Product Name and Model ......................................................................................................... 6
1.2 Specifications ................................................................................................................................. 6
1.3 Functions ......................................................................................................................................... 6
1.4 Exterior Look and Size ................................................................................................................ 7
1.5 Assembly ......................................................................................................................................... 7
1.6 Cable Connection ..........................................................................................................................8
1.7 Extended Function ........................................................................................................................9
2. Display Guide........................................................................................................................................ 9
2.1 Interface Introduction ................................................................................................................. 9
2.1.1 Display Interface (Speed Switch) ............................................................................. 9
2.1.2 Setting Interface .............................................................................................................10
2.2 Key Pad Operation ..................................................................................................................... 10
2.2.1 Key Pad Introduction ................................... 11
3. General Operations........................................................................................................................... 11
3.1 Switch On/Off ................................................................................................................................ 11
3.2 Assist Level .................................................................................................................................... 12
3.3 Interface Switching...................................................................................................................... 13
3.3.1 Item Switching (Range/Voltage/Riding Time).................................................... 13
3.3.2 Speed Mode Switching (AVG/MAX Speed)......................................................... 13
3.4 Front Light On/Off ..................................................................................................................... 14
3.5 6km/h Walk Assist Mode ........................................................................................................ 15
3
4. Settings .......................................................................................................................................................15
4.1 Key Operations ..................................................................................................................................15
4.2 System Unit .........................................................................................................................................16
4.3 Backlight Brightness .........................................................................................................................16
4.4 Auto-Off ................................................................................................................................................16
4.5 Auto-Lamp On/Off ............................................................................................................................17
4.6 Battery Indication ..............................................................................................................................17
4.7 Wheel Size ...........................................................................................................................................18
4.8 Voltage Level ......................................................................................................................................19
4.9 Low Battery Level ..............................................................................................................................19
4.10 Boot Password ................................................................................................................................ 20
4.11 Advanced Settings ........................................................................................................................ 21
4.12 Speed Limit ...................................................................................................................................... 21
4.13 Controller Current Limit .............................................................................................................. 21
4.14 Auto-Cruise ..................................................................................................................................... 22
4.15 Assist Levels .................................................................................................................................... 22
4.16 Torque Level Range ..................................................................................................................... 23
4.17 Magnet Steel Number for Speed Test .................................................................................. 23
4.18 Start Mode ...................................................................................................................................... 24
4.19 Drive Mode ..................................................................................................................................... 24
4.20 PAS Sensor Type ........................................................................................................................... 25
4.21 Start Sensitivity .............................................................................................................................. 25
4.22 Start Strength ................................................................................................................................. 26
4.23 Factory Reset .................................................................................................................................. 26
4
4.24 Information ...............................................................................................................................27
5. Error Code ..........................................................................................................................................28
5.1 Error Code Definition ............................................................................................................ 28
6. Serial Code ....................................................................................................................................... 29
7. Safety Notes .................................................................................................................................... 30
8. Quality and Warranty ................................................................................................................. 31
8.1 Warranty Term ........................................................................................................................ 31
8.2 Warranty Exclusions .............................................................................................................. 31
9. Version .............................................................................................................................................. 31
5
Changzhou Sciwil E-
Mobility Technology Co., Ltd.
9th Huashan Road, Changzhou, Jiangsu, China- 213022
Fax: +86 519-85602675 Tel: +86 519-
85600675
1. Product Introduction
Congratulations on purchasing your e-bike smart display. Before use, please read
through this manual. It is important to acknowledge all the
WARNINGS, SAFETY
NOTES AND INSTRUCTIONS
. This manual will walk you through assembly, settings
and operations of Sciwil display products in easy steps, to facilitate operations on
your e-bike.
6
Changzhou Sciwil E-
Mobility Technology Co., Ltd.
9th Huashan Road, Changzhou, Jiangsu, China- 213022
Fax: +86 519-85602675 Tel: +86 519-
85600675
1.1 Product Name and Model
Product Name: E-Bike Display
Product Model: M61
1.2 Specifications
①
Working Voltage: DC 24V/36V/48V/60V/72V
②
Rated Working Current: 12mA
③
Leakage current: <1uA
④
Screen Size: 3.5” OLED (480*320 dots)
⑤
Communication Type: UART (by default) / CAN
⑥
Working Temperature: -20°C ~ 70°C
⑦
Storage Temperature: -30°C ~ 80°C
⑧
Waterproof Rating: IP65
1.3
Functions
1.3.1 Boot password
1.3.2 System unit switch (km/h or mph)
1.3.3 Speed display：
real-time speed (SPEED), max speed (MAX), average speed (AVG)
1.3.4 Assist Level Control
1.3.5 Battery indication: battery capacity, low voltage indication, BMS info
display
1.3.6 Front light indication: front light status sPlusported by controller
1.3.7 Distance：single-trip distance (TRIP), total travel distance (ODO)
1.3.8 Riding Time: TIME
1.3.9 Communications port connection, for system maintenance and specs
settings
7
Changzhou Sciwil E-
Mobility Technology Co., Ltd.
9th Huashan Road, Changzhou, Jiangsu, China- 213022
Fax: +86 519-85602675 Tel: +86 519-
85600675
1.3.10 Walk assist mode
1.3.11 Bluetooth communication, support OTA upgrade via mobile phone
1.3.12 Error code indication Simple key pad for easy & clear operation
1.4
Exterior Look and Size
1.5
Assembly
1.5.1 Open the holder ring/rubber spacer of the display and fix the display on the
handlebar, adjust it to a proper facing angle. Use a M4 Hex Wrench to fix and
tighten the screws. Standard fixing torque: 0.8N·m.
8
Changzhou Sciwil E-
Mobility Technology Co., Ltd.
9th Huashan Road, Changzhou, Jiangsu, China- 213022
Fax: +86 519-85602675 Tel: +86 519-
85600675
*Damage due to extra fixing torque is not covered by warranty.
1.5.2 Make sure your e-bike is powered off, then plug the connector on the display
to the connector on the controller (bus) to finish standard assembly.
1.6
Cable Connection
Display to Controller Controller to Display Controller Connector
Sequence No. Wire Color Functions
1 Red（VCC）Display Power Cable
2 Blue（DS）Controller Power Cable
3 Black（GND）Display Ground Cable
4 Green（RX）Display Data Receiving Wire
5 Yellow（TX）Display Data Sending Wire
9
Changzhou Sciwil E-
Mobility Technology Co., Ltd.
9th Huashan Road, Changzhou, Jiangsu, China- 213022
Fax: +86 519-85602675 Tel: +86 519-
85600675
1.7
Extended Function:
Front Light: Brown Wire (Front Light Power+)
White Wire (Front Light GND)
2. Display Guide
2.1
Interface Introduction
2.1.1 Display Interface
10
Changzhou Sciwil E-
Mobility Technology Co., Ltd.
9th Huashan Road, Changzhou, Jiangsu, China- 213022
Fax: +86 519-85602675 Tel: +86 519-
85600675
①Real-Time Speed (RT SPEED)：current riding speed
②Average Speed (AVG SPEED)：average riding speed
③Maximum Speed (MAX SPEED)：the max speed during ride
④Total Travel Distance (ODO)：total riding distance, max value 99999.9
⑤Assist Level and Walk Mode：Assist Level 3/5/9 levels, can be changed.
⑥Current Speed and Unit：current riding speed, unit: km/h or mph
⑦Single-Trip Distance and Unit：with accuracy of 0.1，max value 99999.9
⑧Battery Indication：the current battery level
⑨Front Light Indication：shows icon when the front light is turned on by display
⑩Power Indication：real-time motor output power
2.1.2 Setting Interface
2.2
Key Pad Operation
