SCHUNK EDF Series Instructions d'utilisation

Assembly and Operating Manual

Electrical Feed-Through for SRU Type EDF

1 Print date 01.07.2010

Dear Customer,

Congratulations on choosing a SCHUNK product. By choosing SCHUNK, you have opted for

the highest precision, top quality and best service.

You are going to increase the process reliability of your production and achieve best

machining results –to the customer's complete satisfaction.

SCHUNK products are inspiring.

Our detailed assembly and operation manual will support you.

Do you have further questions? You may contact us at any time –even after purchase. You can

reach us directly at the mentioned addresses in the last chapter of these instructions.

Kindest Regards,

Your SCHUNK GmbH & Co. KG

Precision Workholding Systems

Bahnhofstr. 106 - 134

D-74348 Lauffen/ Neckar

Tel. +49-7133-103-2503

Fax +49-7133-103-2189

automation@de.schunk.com

www.schunk.com

Document last updated: 04.03.2008

Edition: 01-A

EDF FOR SRU

ELECTRICAL

FEED-THROUGH

Assembly and Operating Manual

Electrical Feed-Through for SRU Type EDF

2 Print date 01.07.2010

Contents

1. SAFETY.................................................................................................................................................3

1.1. SYMBOL KEY....................................................................................................................................3

1.2. APPROPRIATE USE...........................................................................................................................3

1.3. SAFETY NOTES ................................................................................................................................3

2. WARRANTY..........................................................................................................................................4

3. SCOPE OF DELIVERY.........................................................................................................................5

4. TECHNICAL DATA...............................................................................................................................5

4.1. CONNECTION OPTIONS:....................................................................................................................5

4.2. DATA...............................................................................................................................................5

5. ASSEMBLY AND INSTALLATION ......................................................................................................6

5.1. INSTALLATION OF THE ELECTRICAL CABLE FEED-THROUGH IN THE SRU ROTARY ACTUATOR................6

5.2. CABLE ASSIGNMENTS.......................................................................................................................7

5.3. PIN ASSIGNMENT EDF FOR SRU20-35:............................................................................................8

5.4. PIN ASSIGNMENT EDF FOR SRU40-60:............................................................................................8

5.5. ASSEMBLY OF SRU WITH EDF.........................................................................................................9

6. MAINTENANCE AND SERVICING ....................................................................................................11

7. ASSEMBLY DRAWINGS....................................................................................................................11

8. BILL OF MATERIALS.........................................................................................................................13

9. CONTACT ...........................................................................................................................................18

Assembly and Operating Manual

Electrical Feed-Through for SRU Type EDF

3 Print date 01.07.2010

1. Safety

1.1.Symbol key

You will find this symbol wherever hazards for persons or damage to the product

are possible.

This symbol indicates important information on the product or its handling.

1.2.Appropriate use

The unit must only be used within the scope of its technical data. Appropriate use also includes

compliance with the conditions the manufacturer has specified for commissioning, assembly,

operation, the environment and maintenance. Using the unit with disregard to even a minor

specification will be deemed inappropriate use. The manufacturer assumes no liability for any

injury or damage resulting from inappropriate use.

1.3.Safety notes

There are potential risks associated with the unit, for example if:

the unit is improperly used, installed or serviced.

the unit is used other than for the intended purpose.

the EC Machine Directive, the accident prevention regulations, the VDE guidelines or the

safety and installation instructions are not observed.

All personnel who are responsible for installation, commissioning and servicing must have

read and understood the entire operating manual, in particular the chapter on »Safety«. It is

recommended to have this confirmed in writing.

Installation and dismantling, mounting of the proximity switches, connections and

commissioning may be carried out only by authorized personnel.

Work procedures that impair the correct functioning and operational safety of the product

are prohibited.

Do not move any parts by hand when the unit is connected to the power supply.

Do not reach into the open mechanical parts and the area of motion of the rotary unit.

The power supply cables must be removed for assembly, modification, maintenance and

adjustment of the unit.

Carry out all maintenance, modifications or attachments outside of the danger zone.

During installation, connection, adjusting, commissioning and testing, measures must be

taken to prevent the risk of inadvertent activation of the unit by the fitter or other persons.

Assembly and Operating Manual

Electrical Feed-Through for SRU Type EDF

4 Print date 01.07.2010

Protective covers must be provided for the use of all handling modules in accordance with

EC Machine Directive, Section 1.4.

There is a danger due to falling or ejected objects. Preventive measures must be

taken to prevent the falling or ejection of potentially dangerous objects (machined

workpieces, tools, chips, debris, waste, etc.).

Additional bore holes, threads or attachments not offered by SCHUNK as accessories may

be mounted only after obtaining the approval of SCHUNK.

Rotary units with internal springs can have parts that are under spring tension. Therefore,

special care is necessary when dismantling such a unit.

In the event of emergency shut-down the rotary unit can still move due to a drop in

pressure. If such movement is not desired, the position of the unit in the event of

emergency shut-down can be secured in any end position with the use of SCHUNK SDV-P

valves.

In addition, the applicable safety regulations and accident prevention regulations must be

observed.

2. Warranty

The warranty period is 24 months after delivery date from the factory, provided that the

specified maintenance and lubrication intervals were observed. Components coming into

contact with workpieces and wearing parts are never included in the warranty. In this context,

please also see our General Terms and Conditions.

Assembly and Operating Manual

Electrical Feed-Through for SRU Type EDF

5 Print date 01.07.2010

3. Scope of delivery

The EDF is normally supplied together with an SRU unit and then bears the product name “SRU

...-EDF...”. In this case, parts of the scope of delivery described below are installed in the overall

unit.

The scope of delivery of the EDF consists of:

-Distributor plate with spiral cable, integrated circuit board and housing sockets

-Connecting flange

-2 securing screws

EDF 20: M 2 x 12 –EDF 40: M 3 x 14

EDF 45: M 3 x 14 –EDF 57: M 3 x 14

and the following small components:

-O-rings for air feed-through

-4 x for EDF 20 / 25 / 35 –8 x for EDF 40 / 50 / 60

-O-rings for direct air connections

-6 for SRU without center position –7 x for SRU with center position

-Locking screw M5 / G1/8”

-4 x for EDF 20 / 25 / 35 –8 x for EDF 40 / 50 / 60

-2 guide sleeves for screwing on SRU with EDF

-2 guide sleeves for screwing on adapter plate

-Jumpers for switching sensors to BUS feed-through

-Cable plug M16 (for self-assembly)

4. Technical data

4.1.Connection options:

Output side:

- 4x/8x sensor M5 / M8 / M12 (3-pin) or alternatively:

- 1x BUS M12 (5-pin)

Screw connection side:

- Supply cable: M16 (12-pin)

4.2.Data

Umax: 60 V

Imax (per wire): 2 A

Transfer rate for Profibus: max. 1.5 Mbaud

Assembly and Operating Manual

Electrical Feed-Through for SRU Type EDF

6 Print date 01.07.2010

5. Assembly and installation

5.1.Installation of the electrical cable feed-through in the SRU rotary actuator

You require these instructions only if you would like to retrofit an EDF on an existing SRU unit.

SRU units can already be ordered equipped with EDF ex-works.

1. Feed the cable through the hole in the flat seal and position it in the recess in the distributor

plate.

2. Screw the thread reducer (item 7) into the pinion in the thread below the flat recess and

secure with Weicon 302-22. (Not for EDF for SRU20/25)

3. In order to position the distributor plate, place the two corresponding guide sleeves in the flat

recesses.

4. Pull the cable through the center bore of the SRU rotary actuator until the distributor plate is

just in front of the pinion.

5. Place the O-rings in the recesses of the air feed-throughs in the pinion.

6. Pull the cable through fully and position the distributor plate correctly on the pinion.

IMPORTANT

Damage to the cable connection of the adapter plate is possible!

–Do not pull on the cable too strongly!

7. Now fasten the distributor plate on the pinion with the two screws (item 28).

8. Check the tightness of the air feed-throughs.

9. Turn the rotary actuator and place it on the distributor plate.

10. Swivel the SRU counter-clockwise up to the stop.

11. Knock the clamping pins into the bores on the pinion.

12. Pull the cable end through the bore in the flange.

13. Solder the cable onto the flange connector (item 22) in accordance with specifications

(see chapter 5.2).

14. Align the cable spiral and shape into original form. Spiral diameter approx. 27 mm.

15. Using a paint brush, grease the flange (inside) and the cable spiral with milk fat.

16. Place the cable in the clamping groove in the flange.

17. Fit the O-ring (item 47) at the connector flange.

18. Screw the connector onto the cover plate.

19. Screw the cover plate onto the flange with the oval head screws.

20. Fasten the flange on the SRU with two screws and secure with Weicon 302-22

21. Place the O-ring (item 43) in the MDF media feed-through flange.

22. Fasten the cover plate (item 6) on the flange with 2 countersunk screws.

Disassembly is carried out in reverse order.

Assembly and Operating Manual

Electrical Feed-Through for SRU Type EDF

7 Print date 01.07.2010

5.2. Cable assignments

Cable outlet of the rotating distributor plate

Unit

Cable connection, rotating adapter plate

SRU 20

4 x M5

1 x M12
