Schiit MODI MULTIBIT Manuel utilisateur

DIGITAL TO ANALOG CONVERTER

IN NORsE myThOLOGy, mODI wAs ONE Of ThOR’s sONs.

hERE, mODI mULTIBIT Is ONE Of sChIIT’s mODIs.

IT’s QUITE sImILAR TO A BIfROsT mULTIBIT.

BUT wIThOUT ALL ThAT CONfUsING UPGRADABILITy.

ENJOy OUR COmBOBURRITO fILTER AND AD5547 DAC!

MODI MULTIBIT

OwNER’s mANUAL

CONNECTIONs

1 Connect the supplied 16VAC wall-wart.

Don’t use any other power adapter.

2Connect your USB source to the Modi

Multibit’s USB input with a USB 2.0-rated cable,

2M or less in length.

3 Connect your optical source to the optical input

jack, using a good Toslink cable, 3M or less.

4 Connect your coax digital source to the coax

input jack, using a good RCA cable, 75 ohm

preferred.

12345

5 Connect the two RCA jacks, labeled “R” and

“L”, to your amplier, preamplier, or receiver.

You may use long cables—Modi Multibit’s active

output stage drives them with ease.

For USB, select the Modi as the audio output

device in Control Panel (Windows) or System

Preferences (Mac) AND in your music player

software. Windows users may have to install

drivers from schiit.com/drivers

6Turn it on and enjoy your music!

CONTROLs

1 Press the button to cycle through the three

inputs. Just like on Bifrost Multibit. But hey, this

is a heck of a lot cheaper. And USB is standard.

Did we say this was a great deal?

2 This light turns on when you’ve selected a USB

source. If no USB source is connected, Modi

Multibit will skip this input.

3 This light turns on when you’ve selected an

optical source. Simple enough.

4 This light turns on when you’ve selected a

coaxial digital source. But you already knew that.

Note: Modi Multibit flashes all three lights (2, 3,

and 4) in sequence for about 20 seconds after you

rst turn it on to prevent any thumps, bumps, or

other weird noises. Once the lights stop flashing,

you’re ready to use the Modi Multibit.

And that’s it. This is a really simple device. Why

don’t you have a listen now?

sChIIT.COm

[email protected]

Schiit Audio warrants to the original purchaser that this product shall be free from defects in material

and workmanship for two (2) years from the date of purchase. If a defect covered by this warranty oc-

curs during this period, Schiit Audio will repair the defective product, free of charge. Date of purchase

will be based on customer receipts, otherwise date of manufacturing will be used.

If you believe you need warranty service, contact us rst. Schiit Audio products sent back to us

without a Return Authorization (RA) will be returned to the sender without repair. To contact us and

obtain an RA, email [email protected].

Warranty Limitations. This warranty shall not apply if a product: (a) is modied or tampered with;

(b) is damaged by negligence, accident, unreasonably use, or other causes unrelated to defective

materials or workmanship, or (c) has had the serial number altered or removed.

Any implied warranties, including warranties of merchantability and tness for a particular purpose,

are hereby limited in duration to the warranty period of 2 years. In no event shall Schiit Audio be liable

for consequential or incidental damages resulting from the breach of any implied or expressed

warranties. Some states do not allow these limitations, so they may not apply to you. You may also

have other rights which vary from state to state or province to province.

2-year LIMITeD warranTy In THe BOX

(1) Modi Multibit

(1) Wall-Wart

(4) Stick-On Feet

Application for Council Directives 72/23/EEC, 89/336 EEC

Conformity declared for EN60065, EN55022 Class B, EN50082-1

This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules.
