496330 Issue 1 1 of 10

9452/9453

Installation and User Guide

Compatible Equipment

9425 Remote Keypad

9040 InternalSounder

660 Speech Communicator

8440 4-Channel ‘Minicom’

2 of 10 496330 Issue 1

Introduction

The 9452 and 9453 are fully programmable 4 zone control units designed to

meet the requirements of both domestic and small commercial installations.

The basic 9452 system comprises a main control panel complete with built-in

keypad, while the 9453 system comprises a blank end station and one

remote keypad. The 9452 control unit and 9453 end station both house the

system electronics, power supply, battery and remote signalling device (if

fitted). A numeric keypad and row of indicators (LEDs) are provided only on

the 9452 control unit, from which the user and installer perform the system

operation.

Remote keypads provide the user with the facility to set and unset the system

from strategic locations within the premises and allow the installer to pro-

gramme the system. Up to TWO remote keypads may be connected to the

9452/3. A numeric keypad and row of indicators (LEDs) are also provided on

the keypads to perform the system operation. The keypads also have an

optional key press PA facility, if required.

Technical Specification

Zones Four plus PA, Entry/Exit and global tamper.

Display LED.

Keypads One built-in (9452 only) plus up to two remote keypads

(9425).

Expansion None.

BS 4737 Full Spec.

Log 15 events.

Panel Siren Yes.

Extension Spkr 9040, 2 max if Internal Speaker is disconnected.

Battery 1.9Ah.

12 Volt Power Quiescent Panel 70mA.

9425 RKP = 40mA.

12 V Aux Output 350mA.

Dimensions Panel: h x w x d 163 x 257 x 72mm.

RKP: h x w x d 115 x 115 x 28mm.

Weight Panel 1.2Kg.

Comms Output PA, Intruder, Open/Close.

Input Line fault.

Outputs SAB/SCB, Strobe, Prog O/P (PIR set latch or SD reset).

9452/3

496330 Issue 1 3 of 10

Wiring

Figure 1. 9452/3 PCB Layout

Communicator Output Pins

Pin on panel Function Colour Pin on communicator

Pin 1 PA Red ST2

Pin2 Line Monitor Input Blue O/P

Pin 3 Intruder Yellow ST3

Pin 4 Open/Close Black ST4

Pin 5 +12V Brown 12V

Pin 6 0V Orange 0V

Notes:1. Pins 1, 3 and 4 are removal of positive in alarm to trigger.

2. Pin 2 is a 12V +ve input for Line Fault.

3. If a communicator is fitted and has an output for line fault, connecting a +ve

to the Line Monitor Input will reduce any programmed bell delay to zero and

give a visual indication on the panel LED (LF).

4. If a communicator is not fitted remove the communicator wiring harness from

the main pcb.

9452/3

4 of 10 496330 Issue 1

Keypad Wiring

Figure 2. Keypad Connection.

Notes:1. Maximum cable distance: Daisy chain = 300m, Star Wire = 100m per leg.

2. Do not wire the extension speaker or circuit wiring within the same cable as

the remote keypad.

Programming

Initial Start Up

Before applying power to the control panel or end station, ensure that all used

circuits are connected. The control panel or end station lid switch should be

defeated or closed and NO power connections to detectors, sounders or

battery should be made at this stage.

Note: If connections to the bell and AUX power are made when the system is

powered up, damage to the main pcb may occur.

1. Apply mains to the control panel or end station. The green “Power” and

“Day” LED will illuminate and the internal sounder will sound.

2. Key-in the factory default customer code “1234”. The internal sounder

will stop and the “Tamper”, “Service” and “Fault” LEDs will be flashing.

Programming 9452/3

496330 Issue 1 5 of 10

3. Key-in the factory default engineer code, “0” followed by “ENTER” then

“7890”. The “Fault” and ”Service” LEDs will flash and the internal

sounder will be bleeping.

4. Open the control panel or end station lid. The internal sounder stops

bleeping and the “Service” LED will be steady. Make connections to

AUX power, stand-by battery and connections to SAB. Proceed to

program the system.

Note: If an SAB/SCB module is fitted within the bell, it will continue to ring until the

panel supply is connected and until the bell cover lid tamper switch is closed.

Programming Commands

To change the factory default program, use the commands listed in this

section as follows:

1. Enter the command number.

2. Enter one or more digits to give the new program.

3. Press ENTER.

The panel will give a double bleep to show that it has accepted the

command. If you enter the command incorrectly the panel gives a single

tone.

Default Settings

When delivered from the factory, the panel is programmed as follows:

Zone 1, Entry Route Part Set zone. 01 36

Zone 2, Normal alarm, active in Part Set, Omit allowed. 02 16 OMIT

Zone 3, Normal Alarm, active in Part Set, Omit allowed. 03 16 OMIT

Zone 4, Normal Alarm, active in Part Set, Omit allowed. 04 16 OMIT

Zone 7(E/E) part set. 07 6

User code 1234

Engineering Program Commands

To change Key in: Followed by + ENTER

Zones 1-4 01-04 0 = Not used

1 = Normal Alarm

2 = 24 Hour Alarm

3 = Entry Route

4 = Double Knock

5 = Chime

6 = Part set zone

OMIT = Omit Allowed

9452/3 Programming Commands

6 of 10 496330 Issue 1

To change Key in: Followed by + ENTER Default

Entry/exit zone options 07 0 = Reset to none

5 = Chime

6 = Part set zone

Programmable Output 11 18 = PIR set latch y

29 = Shock sensor reset

Engineer Access 20 Any 4 digit code 7890

Bell output type 21 0 = SAB y

1 = SCB

Internal sounder 22 1 = Follows strobe y

0 = Follows bell

PA 30 0 = Audible Alarm y

1 = Silent Alarm

System Reset 31 0 = Customer Reset y

1 = Engineer Reset

Abort facility 32 0 = Disabled y

1 = Enabled

KeypadPA 33 0 = Disabled y

1 = Enabled

System status 34 0 = LEDs ON when set and part set

1 = LEDs OFF when set and part set. y

Exit Mode 35 0 = Timed or Terminated y

1 = Final Door Set

Rearm 40 0 = Never y

1 = Once

2 = Twice

3 = Three times

4 = Always

External sounder delay 41 0 = Nil y

1 = 1.5 mins

2 = 3 mins

3 = 5 mins

4 = 10 mins

5 = 15 mins

6 = 20 mins

7 = No duration

Ext. sounder duration 42 0 = Nil

1 = 1.5 mins

2 = 3 mins y

3 = 5 mins

4 = 10 mins

5 = 15 mins

6 = 20 mins

7 = No duration

Engineering Program Commands 9452/3

496330 Issue 1 7 of 10

To change Key in: Followed by + ENTER Default

Entry Time 43 0 = Continuous

1 = 10s

2 = 20s y

3 = 30s

4 = 60s

5 = 90s

6 = 120s

Exit Time 44 0 = Continuous

1 = 10s y

2 = 20s

3 = 30s

4 = 60s

5 = 90s

6 = 120s

CSID code 50 nnnn (key in four digit code)

Part Set Entry/Exit 60 0 = As Final Exit y

1 = Normal Alarm

Part Set Entry Response 61 0 = As Entry Route

1 = Start Entry Timer y

Part Set Exit Mode 62 0 = As Full Set

1 = 10 Second Set y

2 = Instant Set

Part Set Alarm Response 63 0 = Local (No comms) y

1 = Full Alarm

Engineer Log 90 1 see earlier events.

3 to see more recent events.

ENTER to quit log. (15 events max.)

External Sounder 91 ENTER to stop test.

Strobe 92 ENTER to stop test.

InternalSounder 93 ENTER to stop test.

Test keypad LEDs 94 ENTER to stop test

Output 1 95 ENTER to stop test.

Walk Test 97 ENTER to stop test.

Load Factory Defaults 98

Leave Engineering Mode 99

Refresh NVM (System Memory Chip)

The 9452/3 control panels have a Non Volatile Memory chip which retains all

programmed information and access codes. If the system suffers a total

power failure, the NVM will retain all information and the panel will only

require powering up and resetting. However, if the end user forgets the user

access code or the installer wants to return the panel to the factory pro-

grammed settings, continue as follows:

9452/3 Refresh NVM (System Memory Chip)

8 of 10 496330 Issue 1

1. Power down the control panel, mains and battery.

2. Find the RST pins, located to the middle of the control pcb.

3. Place a small screwdriver blade to short between the “RST” pins. With

the blade still across the pins, power up the control panel battery first,

then Mains.

All the LEDs will flash.

4. Remove the screwdriver blade.

The control panel loads the factory default codes.

5. Key-in 1234, then press 0 Enter 7890. Momentarily close, then open up

control panel lid. Re-program the system.

Engineer Reset

An engineer can reset the system without opening the control panel or end

station lid.

1. Press 0 then Enter.

2. Key in the Engineer Access Code.

3. Key in 99.

To Re-Enter Programming Mode

1. Press 0 then Enter.

2. Key in the Engineer Access Code.

The “Fault” and “Service” LEDs flash and the internal sounder starts

bleeping.

3. Open the control panel or end station lid.

The internal sounder stops bleeping and the Service LED glows stead-

ily. The system is now in programming mode.

To Leave Programming Mode

1. Close the panel or end station lid.

2. Key in 99.

Fault Finding

Under normal conditions, the “Fault”, “Service” and “Alarm” LEDs will not be

illuminated. Only the “Mains”, “Day” “Full” and “Part Set” LEDs should be

illuminated during normal use of the system. Any other LEDs which are

illuminated or flashing, signify a fault or alarm condition.

Note: The “Mains” LED will be illuminated permanently.

Any condition indicated by a combination of the “Fault”, “Service” or “Alarm”

LEDs are to be considered an abnormal condition, as shown on the opposite

page:

Fault Finding 9452/3

496330 Issue 1 9 of 10

9452/3 Fault Finding

10 of 10 496330 Issue 1

User Commands

Full Set System 1 + ENTER + User code

Part Set System 2 + ENTER + User code

Unset/Reset System User code

Omit zone 1 (or 2) + ENTER + User code + OMIT + zone

number (repeat OMIT + zone number for other

zones as required).

Omit 24 hr zone OMIT + ENTER + User code + zone number (+

zone number for other zones as required)

Change User code 4 + ENTER + Old code + Old code (the system

beeps twice)+ New code (the system beeps twice)

Read Log 5 + ENTER + User code

1 to read earlier events

3 to read later events

ENTER to leave the log

Chime On/Off 7 + ENTER + User code

Bell Test 8 + ENTER + User code

Walk Test 9 + ENTER + User code

ENTER to end the test

9452/3

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Scantronic Système de sécurité

Scantronic

Scantronic 601 Manuel utilisateur

Scantronic

Scantronic 9800 Manuel utilisateur

Scantronic

Scantronic 808 Guide d'installation

Scantronic

Scantronic 9448+ Manuel utilisateur

Scantronic

Scantronic i-on Series Manuel utilisateur

Scantronic

Scantronic 760ES Manuel utilisateur

Scantronic

Scantronic 4601 Manuel utilisateur

Scantronic

Scantronic KEY-RAS Manuel utilisateur

Scantronic

Scantronic DET-RSDC Manuel utilisateur

Scantronic

Scantronic KEY-RAS Manuel utilisateur

Scantronic

Scantronic 8136UK-50 Manuel utilisateur

Scantronic

Scantronic Spartan 650F Manuel utilisateur

Scantronic

Scantronic i-on Security System Manuel utilisateur

Scantronic

Scantronic i-on30R+ Manuel utilisateur

Scantronic

Scantronic 515r Manuel utilisateur

Scantronic

Scantronic HOMELINK EXTRA Mode d'emploi

Scantronic

Scantronic 500r+ Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
