Scantech LIBRA L-7050 Mode d’emploi

Installation & User’s Manual

Scantech-ID LIBRA L-7050

Multi-purpose. Omni-directional scanner.

whole or in part, be copied, photocopied, reproduced, translated or converted to any electronic medium or

machine readable form without prior written consent of Scantech-ID BV.

Limited Warranty

Under all circumstances this manual should be read attentively, before installing and/or using the product.

In no event shall Scantech-ID BV be liable for any direct, indirect, special, consequential or incidental

damages arising out of the use or inability to use this docum entation or product, even if advised of the

possibility of such dam ages. In particular, Scantech-ID BV shall not be liable for any hardware, software,

or data that is stored or used with the product, including the cost of repairing, replacing or recovering the

above. Scantech-ID BV reserves the right to change parts of the device at any time without preceding or

direct announcem ent to the client.

Scantech-ID BV reserves the right to revise this m anual, and to make changes in the contents without

obligation to notify any person or entity of the revision or change. A serial number appears on the product.

Make sure that this official registration number has not been removed. It should be used whenever

servicing by Scantech-ID BV or an authorized Scantech dealer is necessary.

Important

This equipm ent has been tested and found to comply with the limits for a Class B digital device, pursuant

to EN55022, and with the limits for a class A digital device, pursuant to part 15 of the FCC rules. These

limits are designed to provide reasonable protection against harmful interference when the equipm ent is

operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the user‟s manual, may cause harmful interference

to radio communications. Operation of the equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense. Any

unauthorized changes or m odifications to this equipment could void the user‟s authority to operate

this equipment.

For CE-countries:

–LIBRA is in conformity with the CE standards. Please note that a Scantech CE-marked power supply

unit should be used to conform to these standards.

V2.0 Oct. 2013

Table of contents

iii

Preface .....................................................................................1

Chapter 1 Product Safety ..............................................................3

1.1 LASER SAFETY............................................................................ 4

1.2 DECLARATION OF CONFORMITY............................................... 5

Chapter 2 Installation ...................................................................7

2.1 UNPACKING................................................................................. 8

2.2 CONNECTING............................................................................. 10

2.3 ADJUSTING................................................................................ 11

2.4 POWERING................................................................................. 12

2.5 INITIALIZING............................................................................... 13

Chapter 3 Using LIBRA............................................................... 15

3.1 SCANNING BARCODES............................................................. 16

3.2 CONTROLLING........................................................................... 17

3.3 MAINTAINING............................................................................. 17

Chapter 4 Applications ............................................................... 19

Appendices.............................................................................. 21

A. CONNECTOR TYPES AND PIN DEFINITIONS........................... 22

B. TECHNICAL SPECIFICATIONS.................................................. 23

C. TROUBLESHOOTING................................................................. 25

Preface

Scantech ID LIBRA is a high performance, multi-interface, and omni-directional

scanner. The unit comes with powerful reading sensitivity which allows hands-

free bar code scanning. Bar code labels are read by presenting the label

towards the scanner. Scanning labels with LIBRA hardly requires any arm

movement.

LIBRA reads all popular bar code symbologies. An important feature of LIBRA

is its auto-sense mode. If the scanner is not used within a programmable period

of time, the scanner switches off automatically. The scanner can be reactivated

by placing a barcode towards the window of the LIBRA.

LIBRA is designed with a specific size for all kinds of store applications and

ideal to use in check out services.

Features

Integrability

The compact design allows the unit to be mounted with ease on a host system

with minimum space requirement.

Quality and Durability

The components are of top quality and the case is solid, moist and dust

resistant. All of these secure a long and service free operation time.

Durable characteristic with IP42 rating and drop resistance.(with cable).

Automatic sleep and wake-up mode which saves power and improves life

time.

Flexibility and Connectivity

The multiple connection interfaces (RS232, Keyboard Wedge, USB, and

Powered USB) allow the unit to communicate with the host system with

considerable flexibility.

Decoding Capability

The barcode decoding capability is up-to-date, including GS1 DataBar and

all major 1D barcode symbologies.

The Scantech-ID STAR reconstruction software enables the reading of

fragmented and damaged barcodes.

About this manual

This manual contains four chapters and three appendices:

The first chapter provides the product safety information. The second

chapter describes LIBRA's general features and installation. The third and

forth chapters account for the use of LIBRA.

The connector types and pin definitions, technical specifications, and

troubleshooting can be found in the appendices.

Chapter 1

Product

Safety

Product Safety

1.1LASER SAFETY

English:

LIBRA scanner complies with safety standard IEC60825-1 (2001) for a Class I

laser product. It also complies with U.S. 21CFR1040 as applicable to a Class

IIa laser product. Avoid long term viewing of direct laser light.

Optical:

The use of optical instruments with this product will increase eye hazard.

Optical instruments include binoculars, microscopes and magnifying glasses

but do not include eye glasses worn by the user.

Radiant Energy:

LIBRA uses a low-power laser diode operating at 650 nm in an opto-

mechanical scanner resulting in less than 0.6 mW peak output power. Laser

light observed at 13 cm (5.1 in.) above the window through a 7 mm (0.28 in.)

aperture and averaged over 1000 seconds is less than 3.9 µW per CDRH

Class IIa specification. Do not attempt to remove the protective housing of the

scanner, as unscanned laser light with a peak output up to 0.8 mW could be

accessible inside.

Laser Light Viewer:

The scanner window is the only aperture through which laser light may be

observed on this product. A failure of the scanner motor, while the laser diode

continues to emit a laser beam, may cause emission levels to exceed those for

safe operation. The scanner has safeguards to prevent this occurrence. If,

however, a stationary laser beam is emitted, the failing scanner should be

disconnected from its power source immediately.

Adjustments:

Do not attempt any adjustments to or alteration of this product. Do not remove

the scanner‟s protective housing. There are no user-serviceable parts inside.

WARNING!

Use of controls or adjustments or performance of

procedures other than those specified herein may result in

hazardous laser light exposure.
