SC&T SP006PH Manuel utilisateur
Smart Cabling & Transmission Corp. V1.0
V1.0
Surge Protector Series
User Manual
Model : SP006PH
High Performance 1G PoE Surge Protector
1
User Manual
SP006PH
Introduction
SP006PH is an in-line surge protector designed to protect PoE (Power over Ethernet) devices from high
voltage surges, with network bandwidth up to 1000Mbps.
Features
Supports bandwidth up to 1000 Mbps.
Supports IEEE 802.3af, 802.3at, 802.3bt PoE standard.
Supports Mid-Span and End Span PoE.
Response time less than 1 ns.
Installation View
Panel Review
Connection
Connect the device that needs to be protected to the Equipment End; the Ethernet cable to the Cable
End To ensure the surge protector well-performs, please also make sure the ground wire connects to the
earth.
Note:
The cable must be connected to ground in
order to ensure the protection.
2
User Manual
SP006PH
RJ45 Pinout: (TIA/EIA-568-B)
Application
Computer Control Rooms
Educational Institutions
Server Farms
Commercial Offices
Manufacturing Facilities
Transmitter and Receiver Stations
(PIN TIA/EIA-568B)
PIN
Wire Color
1
Orange-white
2
Orange
3
Green-white
4
Blue
5
Blue-white
6
Green
7
Brown-white
8
Brown
3
User Manual
SP006PH
Specification
ITEM NO.
SP006PH
Support
Compliance
IEEE 802.3af, 802.3at, 802.3bt, IEC 61000-4-2, IEC 61000-4-5
Network Bandwidth
10/100/1000 Mbps
Response Time
Less than 0.7nS
ESD Protection
30KV (Air), 30kV Contact)
Lightning Protection
10KA (8/20 us), 20KV (8/20 us)
Ports & Interfaces
Equipment End
1 x RJ45
Cable End
1 x RJ45
Ambient Temperature
Operation
-40 to 70℃
Storage
-40 to 90℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
67 x 87 x 27mm
Weight
160g
