SC&T CD1632A Manuel utilisateur
Smart Cabling & Transmission Corp. V1.0
HD-TVI/ AHD/ HD-CVI/ CVBS Distributor Series
User Manual
Model : CD1632A
16 x 32 HD-TVI/AHD/HDCVI/CVBS Video Distribution Amplifier
in 1U Rack
1
User Manual
CD1632A
Introduction
CD1632A is a video distribution amplifier that can split 16 CVBS signals into 32 ones and extend the signals
for up to 1000M over coaxial cables. The device can apply to CCTV cameras, multiplexer, VCR, DVR…etc.
Features
Extend and split 16 CVBS signal into 32 ones
Signal extension up to 1000M over RG59 coaxial cables.
HF compensation.
10dB image gain.
Sharpness and brightness adjustable.
Installation View
Panel View
2
User Manual
CD1632A
Specifications
ITEM NO.
CD1632A
Support
Video Format
HD-TVI, AHD, HDCVI, 960H, NTSC, PAL
Max. Transmission Distance
1000M over RG59 coaxial cable
Video Bandwidth
10 to 10MHz
Ports & Interfaces
Video Input
16 x BNC (0.8~1.2Vp-p, 75Ω)
Video Output
32 x BNC (0.8~1.2Vp-p, 75Ω)
Power
Power Supply
DC 12V 1A
Power Consumption
780mA (Max)
Ambient Temperature
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
483 x 62 x 88.4mm
Weight
1610g
