27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx │ 2020-08-20
Serie PCD7.D450WTPx and PCD7.D570WTPx
Wide Screen Micro-Browser Panels
Manual
B
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
0-1
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Content
0
0 Content
0 Content
0.1 Document versions ............................................................................... 0-4
0.3 Brands and trademarks ........................................................................ 0-4
1 Quickstart
1.1 Introduction ........................................................................................... 1-1
1.2 Denition of the connectors ................................................................... 1-2
1.3 Voltage supply of the panel ................................................................... 1-3
1.4 Dimensions and cut-out [in mm] ............................................................ 1-4
1.4.1 5" panel ................................................................................................. 1-4
1.4.2 7" panel ................................................................................................. 1-4
1.5 Installation of the panels ....................................................................... 1-5
1.5.1 Installation in control cabinet ................................................................. 1-5
1.6 Operation and handling of the touchscreen .......................................... 1-6
1.7 Setting up communications for displaying a website ............................. 1-7
1.7.1 HTTP Direct over ethernet RJ-45 connector ......................................... 1-7
1.7.2 USB port as service port ....................................................................... 1-8
1.7.3
Accessing the web editor on the Micro Browser Panel PCD7.D4xx ............. 1-8
2 Technical data for the two panel types
2.1 Technical data of the WVGA MicroBrowser panel ................................. 2-1
3 Operating the setup menu of the WVGA MB panel
3.1 Open the Setup menu ........................................................................... 3-1
3.2 Customising the start screen ................................................................. 3-2
3.3 Changing the password ........................................................................ 3-2
3.4 Saving and exiting ................................................................................. 3-3
4 Structure and description of the Setup menu
4.1 Network ................................................................................................. 4-2
4.1.1 DCHP On .............................................................................................. 4-2
4.1.2 TCP/IP address ..................................................................................... 4-2
4.1.3 Subnet Mask ......................................................................................... 4-2
4.1.4 Default Gateway .................................................................................... 4-2
4.1.5 Primary DNS Server .............................................................................. 4-2
4.1.6 Secondary DNS Server ......................................................................... 4-2
4.2 Web Connection .................................................................................... 4-3
4.2.1 Connection ............................................................................................ 4-3
4.2.2 Edit connection ...................................................................................... 4-3
4.2.2.1 Connection name .................................................................................. 4-3
4.2.2.2 Start page .............................................................................................. 4-3
4.2.2.3 Remote Host IP ..................................................................................... 4-3
4.2.2.4 Remote port .......................................................................................... 4-3
4.2.2.5 Remote password ................................................................................. 4-3
4.2.3 Default password .................................................................................. 4-3
0-2
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Content
04.2.4 Search ................................................................................................... 4-4
4.2.4.1 Range Start ........................................................................................... 4-4
4.2.4.2 Range Size ............................................................................................ 4-4
4.2.4.3 TCP Ports .............................................................................................. 4-4
4.2.4.4 Result List ............................................................................................. 4-4
4.2.4.5 Search ................................................................................................... 4-4
4.2.4.6 Clear ...................................................................................................... 4-4
4.2.5 Connection List ..................................................................................... 4-5
4.3 System .................................................................................................. 4-6
4.3.1 Info ........................................................................................................ 4-6
4.3.2 Production data ..................................................................................... 4-6
4.3.3 Settings ................................................................................................. 4-7
4.3.4 Special Settings .................................................................................... 4-8
4.3.5 Log ........................................................................................................ 4-9
4.3.6 Firmware download ............................................................................... 4-9
4.3.7 Restart ................................................................................................... 4-9
4.4 Display .................................................................................................. 4-10
4.4.1 Brightness ............................................................................................. 4-10
4.4.2 Backlight [min] ....................................................................................... 4-10
4.4.3 Rotation ................................................................................................. 4-10
4.4.4 Calibrate Touchscreen ........................................................................... 4-10
4.5 Keyboard ............................................................................................... 4-11
4.5.1 SIP (Virtual Keyboard) ........................................................................... 4-11
4.5.2 Name of the rst keyboard .................................................................... 4-11
4.5.3 Width of the Focus (in Pixels) ............................................................... 4-11
4.6 Password .............................................................................................. 4-12
4.7 Language .............................................................................................. 4-12
5 Localles/localserver
5.1 Connecting via FTP access................................................................... 5-1
5.2 INTFLASH/WEBPAGES ........................................................................ 5-2
6 Updating and special settings
6.1 Firmware update ................................................................................... 6-1
6.1.1 Additional information on downloading FW ........................................... 6-1
6.1.2 Secure Firmware Download via USB .................................................... 6-1
6.2 Reset / Resetting the device to factory settings .................................... 6-2
6.3 Backlight ................................................................................................ 6-2
6.4 Typefaces supported by MB panel PCD7.D4xx .................................... 6-3
6.5 Special Unicode fonts ........................................................................... 6-5
6.5.1 General information ............................................................................... 6-5
6.5.2 Multi-languages: Example ..................................................................... 6-7
6.5.3 Analysing incorrect fonts, font sizes or format templates ...................... 6-9
6.5.4 Web Editor ............................................................................................. 6-9
6.6 Internal special functions ....................................................................... 6-10
6.6.1 Container variable for WVGA MB panel ................................................ 6-10
6.6.2 uBT_BackLight Containerdiagramm ..................................................... 6-15
6.6.3 Additional uBTerminal container for "Save logs to File” function ........... 6-15
6.7 List of message box messages ............................................................. 6-16
0-3
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Content
0
7 Handling: precautionary measures
7.1 Glass touchscreen ................................................................................ 7-1
7.2 Information on the LCDs of the MB panel display ................................. 7-1
7.3 Care ...................................................................................................... 7-1
8 General recommendations for the Web Editor 5
8.1 In the "Project congurations" ............................................................... 8-1
8.2 In the Web Editor project (general information) ..................................... 8-1
8.3 Denition of an object in the Web Editor ............................................... 8-2
8.4 Handling ................................................................................................ 8-2
8.5 Some rules regarding gif images .......................................................... 8-2
8.5.1 Decompression in the video cache at startup using the Gif list ............. 8-3
8.5.2 Decompression of Gif les in the video cache at startup
using a dummy start screen .................................................................. 8-4
8.5.3 Decompression of Gif les: analysis/calculation ................................... 8-4
8.6 Expanded error messages for the WVGA panel ................................... 8-5
8.7 Extended alarm macros ........................................................................ 8-5
8.8 Trend macros for MB panels with "save logs to les" ........................... 8-5
A Appendix
A.1 Icons ......................................................................................................A-1
A.2 Safety information .................................................................................A-2
A.3 Waste of Electrical and Electronic Equipment (WEEE) disposal ..........A-3
A.4 Contact ..................................................................................................A-4
0-4
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Document versions | Brands and trademarks
Content
00.1 Documentversions
Version Published Redactor Remarks
ENG01 2013-06-21 ErDa First version of manual
ENG02 2013-07-31 HaMa Small changes
ENG03 2015-05-18 HaMa New translation from German
ENG04 2016-01-22 HaMa Changes for new xation set
ENG05 2018-07-20 HaMa Removed «uBT_Buzz..» from the table «uBT»
ENG06 2020-02-24
2020-03-06
HaMa
HaMa
New dimensions after “Value Engineering”
Last page - Partner Channel
ENG07 2020-08-19 HaMa Removed the Buzzer
0.3 Brands and trademarks
Saia PCD®and Saia PG5®
are registered trademarks of Saia-Burgess Controls AG.
Technical modications are based on the current state-of-the-art technology.
Saia-Burgess Controls AG, 2020. © All rights reserved.
1-1
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Introduction
Quickstart
1
1 Quickstart
1.1 Introduction
This manual describes the technical aspects of the PCD7.D4xxWTPx Wide Screen
MB Panel. The objective of the “Quick Start” chapter is the quick installation of the
PCD7.D4xxxT5F components. You will nd information on:
■ Denition of the connectors
■ Power supply and consumption
■Dimensions
■Possible communications modes
Other chapters contain additional details regarding:
■ Hardware
■ Software (Setup menu step-by-step and conguration)
■ Usage, rmware update, etc.
■Maintenance
Supplementary manuals:
■PG5 2.0 User guide | 26-732
■ File System and FTP Server | 26-855
■ Ethernet TCP/IP | 26-766
■ Smart RIO PCD3.T665 | 26-892
■ Serial interface modules PCD7.F1xxx | 27-664
1-2
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Denition of the connectors
Quickstart
1
1.2 Denitionoftheconnectors
PCD7.D450WTPx
Ethernet USB Power supplyReset button
Ground using screw M4 (cable lug)
or mounting plate 6.3 mm (FastOn) Fixation set
PCD7.D470WTPx
Ethernet USB Power supplyReset button
Ground using screw M4 (cable lug)
or mounting plate 6.3 mm (FastOn) Fixation set
Protective earth must be connected
Power supply Ground/Earth (-) / 24V (+) Connector, 2-pole
Communications 1× Ethernet 1× RJ 45 with LED display
USB Standard USB slave
Reset button Pushbutton
1-3
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Voltage supply of the panel
Quickstart
1
1.3 Voltage supply of the panel
Pin Signal
124V (+)
2Earth (-)
Power supply:
→ 24 VDC +30% / –20%
or
→ 19 VAC ±15% current supply with full-wave rectier
Current consumption Power output without backlight
PCD7.D450WTPF
PCD7.D450WTPZ11
PCD7.D450WTPZxx
Max 350 mA 8 W
PCD7.D470DTPF
PCD7.D470DTPZ11
PCD7.D470DTPFZxx
Max 350 mA 8 W
Current supply with jack plug for cable of max. 1.5 mm2.
1-4
Saia-Burgess Controls AG
27-621 ENG07 – Manual – Web Panel MB - PCD7.D450WTPx and PCD7.W470WTPx
Dimensions and cut-out [in mm]
Quickstart
1
1.4 Dimensions and cut-out [in mm]
1.4.1 5" panel
40 5.6
Front panel W × H, 166 × 126
Display 5.0" W × H, 109.4 × 66.2
Cut-out W × H, 157 × 117
1.4.2 7" panel
44 5
Front panel W × H, 204 × 157
Display 7.0" W × H, 154.08 × 85.92
Cut-out W × H, 189 × 142
Ce manuel convient aux modèles suivants
7
Table des matières
