Saveo Scan SAVEO-SCAN-R11D-BH Manuel utilisateur
Scanning with Simplicity
SAVEO-SCAN-R11D-BH
www.saveoscan.com
Table of Contents
Product Information 3
Getting Started 4
Operating Elements 5
Connecting via USB OTG 8
Connecting to iOS via Bluetooth 9
Connecting to Android via Bluetooth 12
Unpairing your device 15
Operating Modes 16
Reset to Defaults 18
LED Indicator 19
Battery Level Status 19
Power Saving Mode 20
Further Information 21
3
Delivery contents
* SAVEO-SCAN-R11D-BH scanner x 1
* Charging Cradle x 1
* Micro USB cable x 1
* Quick instructions x 1
Limited Warranty
Saveo Scan provides a one year limited warranty.
This warranty does not cover any product which has been
subject to improper use, neglect or unauthorized repair or
installation.
This warranty does not cover consumable parts. (Cables &
batteries are consumables.)
Safety instructions
Read the operating instructions carefully and pay special
attention to the safety information. If you do not follow the
safety instructions and information on proper handling in this
manual, we assume no liability for any resulting personal injury
or damage to property.
* The product is equipped with a laser (for aiming use).
* Never look into the laser beam and never point it at
people or animals. Laser radiation can seriously
damage your eyes.
* Do not point the laser beam at mirrors or other
reective surfaces. The uncontrolled, reected beam
may strike people or animals.
* Don’t put scanner in places of excessively high
temperature, such as exposure to direct sunlight
* Don’t use scanner in extremely humid conditions or in
conditions of extreme temperature change
* The rechargeable battery is permanently built into the
product and cannot be replaced.
* Never damage the rechargeable battery. Damaging
the casing of the rechargeable battery might cause
explosion or re!
Product Information
4
Getting Started
Power Switch
Power switch is located on the
underside of the scanner.
On the underside of the scanner you will nd a small recessed
button.
Use a pen or paper clip to push the button until you hear a
notication sound.
Ensure power switch remains depressed after you release it.
Power on Saveo Scan
Switch on and Charge your Scanner
Please switch on your scanner (as illustrated) and place it in
the cradle to charge for 3~4 hours before rst use.
If you want to charge smartphone and scanner simultaneous-
ly, please switch scanner to “Charge Mode” before placing it in
the cradle.
5
*Please remove the protective sticker from window
before use
Trigger/Power
On button
Wrist Strap
Universal Holder
Exit Window
Operating Elements
LED indicator
Charging Cradle
Switch for Operation Mode
and Charge Mode/Bluetooth
Mode
Micro USB Cable
Use Micro USB cable to connect
to smartphone/tablet
6
Extend retractable
arm
Press button and slide
outwards to extend the
arm
Attaching your smartphone to scanner using the
universal holder
Extend the retractable arm before placing phone in holder and
then pushing it rmly back against the phone.
Secure phone in
holder
Retract the arm until
phone is held rmly in
place
Insert phone
7
Connect phone to scanner with Micro USB cable
As USB connection locations vary on dierent models of
smartphone, the cable can be congured for your specic
model.
8
Connecting via USB OTG
Switch scanner to Operation Mode (Data transmis-
sion via USB OTG)
Conrm scanner is connected
Saveo Scan is detected by your smartphone as an external
keyboard. A message will appear on screen to notify you that a
USB device has been connected.
You are now connected. Start scanning.
Scan the Wired OTG Communication barcodes
below
Demo
%W%I%R
Demo
%E%R%A
Switch to left:
Operation Mode/
