Sauder New Grange 420021 Manuel utilisateur
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-24
Français p 25-28
Español p 29-32
Lot # 391194 06/07/16
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
4-Drawer Chest
New Grane Collection | Model 420021
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.
Table of Contents Assembly Tools Required
3
4-5
6-24
25-28
29-32
33-34
35
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
420021 www.sauder.com/servicesPae 2
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (1)
D30 DRAWER RIGHT SIDE (4)
D31 DRAWER LEFT SIDE (4)
D183 DRAWER BACK (4)
D988 DRAWER BOTTOM (4)
E SIDE SKIRT (2)
F BRACE (1)
G TOP FRONT MOLDING (1)
H TOP LEFT MOLDING (1)
I TOP RIGHT MOLDING (1)
J BACK (1)
K BOTTOM FRONT MOLDING (1)
L BOTTOM LEFT MOLDING (1)
M BOTTOM RIGHT MOLDING (1)
M67 DRAWER BRACE (4)
N LARGE BACK (1)
O DRAWER FRONT (4)
P LEFT PLINTH (1)
Q RIGHT PLINTH (1)
Now you know
our ABCs.
420021www.sauder.com/services Pae 3
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
E
D30
M67
D31
D988
D183
Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
5L WARNING LABEL - 1
(Refer to the last step for proper
location and application)
WA RNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
•Place heaviest items in the lowest drawers.
• Unless specifically desined to accommodate, do not
set TVs or other heavy objects on top of this product.
• Never allow children to climb or han on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
• If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce, but not
eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
04/10 332296
31G CORNER BRACKET - 4
SAFETY STRAP - 1
Locate this nylon SAFETY
STRAP (60M) to be used
later in assembly. Do not
accidentally throw away.
60M
SAFETY DRYWALL
ANCHOR - 1
61M
35AA UNIVERSAL CABINET RAIL - 8 35AC DRAWER RIGHT - 4 35AD DRAWER LEFT - 4
HIDDEN CAM - 12
1F CAM DOWEL - 10
2F CAM SCREW - 2
8F MOLDING
CONNECTOR - 2
17F
METAL BRACKET - 4
4G 127K KNOB SET - 8
WASHER - 1
13M
NAIL - 26
1N METAL PIN - 2
1R
420021 www.sauder.com/servicesPae 4
Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
BLACK 9/16" LARGE HEAD SCREW - 31
1S 3S GOLD 5/16" FLAT HEAD SCREW - 32
12S BROWN 1" FLAT HEAD SCREW - 3 BROWN 1-1/2" FLAT HEAD SCREW - 7
14S
BLACK 2-1/4" FLAT HEAD SCREW - 4
26S 30S BLACK 1-9/16" FLAT HEAD SCREW - 20
SILVER 1/2" MACHINE SCREW - 8
38S
420021www.sauder.com/services Pae 5
Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å Push ten HIDDEN CAMS (1F) into the ENDS (A and B),
BRACE (F), and DRAWER BRACES (M67). Then, insert the
metal end of a CAM DOWEL (2F) into each HIDDEN CAM.
420021 www.sauder.com/servicesPae 6
A
B
F
M67
M67M67
M67
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
(10 used)
Arrow
1F
2F
Do not tihten the HIDDEN CAMS in this step.
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1801
to watch a video on how to assemble your unit.
StepStep 2
å Push two HIDDEN CAMS (1F) into the BACK (J) with the
arrows in the HIDDEN CAMS pointin toward the edes
of the BACK.
å Turn two CAM SCREWS (8F) into the exact holes shown
in the ENDS (A and B).
420021www.sauder.com/services Pae 7
A
B
J
Arrow
1F
8F
1F
Arrow
Some assembly
(and snacks) required.
Step
å Fasten the UNIVERSAL CABINET RAILS* (35AA) to
the ENDS (A and B). Use sixteen GOLD 5/16" FLAT
HEAD SCREWS (3S) throuh holes #1 and #3.
å *patent pendin lide system
Step 3
420021 www.sauder.com/servicesPae 8
GOLD 5/16" FLAT HEAD SCREW
(16 used in this step)
3S
3
2
1
1
2
3
VIEW THE DRAWER GLIDE VIDEO
3
2
13
2
13
2
1
1
2
31
2
31
2
3
Glide end
Glide end
A
B
StepStep 4
å Fasten two METAL BRACKETS (4G) to the BACK (J). Use
two BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the METAL BRACKETS are even with the
edes of the BACK.
å Fasten the BACK (J) to the LEFT END (B). Tihten one
HIDDEN CAM and use one BLACK 9/16" LARGE HEAD
SCREW (1S) throuh the METAL BRACKET and into the
LEFT END.
420021www.sauder.com/services Pae 9
BLACK 9/16" LARGE HEAD SCREW
(3 used in this step)
1S
4G
4G
1
2
B
J
J
Surface with HIDDEN CAMS
Surface
with
HIDDEN
CAMS
Surface with HIDDEN CAMS
Ede with
CAM DOWELS
Step
å Insert two METAL PINS (1R) into the exact holes shown in
the ENDS (A and B).
å Fasten the BRACE (F) to the LEFT END (B). Tihten one
HIDDEN CAM.
å NOTE: Be sure the METAL PIN in the LEFT END inserts
into the BRACE.
Step 5
420021 www.sauder.com/servicesPae 10
B
A
F
Surface with HIDDEN CAMS
Start Tighten
Arrow
Minimum
190 derees
Caution
Risk of damae or
injury. HIDDEN CAMS
must be completely
tihtened. HIDDEN
CAMS that are not
completely tihtened
may loosen, and parts
may separate. To
completely tihten:
Arrow
Maximum
210 derees
1R
1R
Do not stand the unit upriht
without the LARGE BACK
fastened. The unit may collapse.
Caution
