Sauder 414764 Manuel utilisateur
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-22
Français p 23-25
Español p 26-28
Lot # 373380 05/26/15
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
Dresser
414764
Don't et cauht with
your pants on the
round.
Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
2-3
4-5
6-22
23-25
26-28
29-30
31
414764 www.sauder.com/servicesPae 2
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
Part Identification
A RIGHT END (1)
B LEFT END (1)
C UPRIGHT (1)
D TOP (1)
E BOTTOM (2)
F BACK (1)
G RIGHT FRONT LEG (1)
H LEFT FRONT LEG (1)
I REAR LEG (2)
M73 END MOLDING (2)
K2 SMALL RIGHT DRAWER FRONT (1)
L2 SMALL LEFT DRAWER FRONT (1)
Q2 RIGHT DRAWER FRONT (2)
R2 LEFT DRAWER FRONT (2)
M65 DRAWER BRACE (6)
SS BRACE (1)
D10 SMALL RIGHT DRAWER SIDE (2)
D11 SMALL LEFT DRAWER SIDE (2)
D132 RIGHT DRAWER SIDE (4)
D138 LEFT DRAWER SIDE (4)
D166 SMALL DRAWER BACK (2)
D167 DRAWER BACK (4)
D975 DRAWER BOTTOM (6)
Part Identification
414764www.sauder.com/services Pae 3
A
B
C
D
E
F
G
H
I
E
I
SS
D10
D11
D132
D138
D166
D167
D975
K2
L2
M65
R2
Q2
D975
D975
D975
D10
D11
D166
D167 D132
D138
M65
M65
M65
M73
M73
Hardware Identification
414764 www.sauder.com/servicesPae 4
AA2 HIDDEN CAM - 22
CC2 CAM DOWEL - 10
BB2 CAM SCREW -12
40CB CABINET LEFT - 6
40CA CABINET RIGHT - 6 40CC DRAWER RIGHT - 6
40CD DRAWER LEFT - 6
EE PULL - 8 KNOB - 4
FF
METAL PIN - 4
GG SLIDE CAM - 12
HH JJ WARNING LABEL - 1
(Refer to step 15 for proper
location and application)
WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Place heaviest items in the lowest drawers.
• Unless specifically desined to accommodate, do not
set TVs or other heavy objects on top of this product.
• Never allow children to climb or han on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
• If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce, but not
eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
04/10 332296
FOOT - 1
TT FOOT BASE - 1
UU WW SAFETY BRACKET - 1
Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
414764www.sauder.com/services Pae 5
BLACK 1-1/8" MACHINE SCREW - 4
MM SILVER 3/4" MACHINE SCREW - 16
NN
BLACK 9/16" LARGE HEAD SCREW - 1
XX
BLACK 1-1/4" FLAT HEAD SCREW - 4
VV
BLACK 1-7/8" FLAT HEAD SCREW - 3
LL
GOLD 5/16" FLAT HEAD SCREW - 48
QQ NAIL - 47
RR
BLACK 9/16" FLAT HEAD SCREW - 4
OO
BLACK 2-1/4" FLAT HEAD SCREW - 6
KK
30S BLACK 1-9/16" FLAT HEAD SCREW - 30
Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å Push twenty-two HIDDEN CAMS (AA2) into the
ENDS (A and B), UPRIGHT (C), BOTTOMS (E), and
DRAWER BRACES (M65). Then, insert ten CAM
DOWELS (CC2) into the HIDDEN CAMS.
414764 www.sauder.com/servicesPae 6
A
B
C
E
M65
E
Do not tihten the HIDDEN CAMS in this step.
(22 used)
(10 used)
Arrow
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not insert CAM
DOWELS into these edes.
Do not insert CAM
DOWELS into these parts.
AA2
CC2
M65
M65
M65
M65
M65
Arrow
AA2
Step 2
å Turn twelve CAM SCREWS (BB2) into the FRONT LEGS (G
and H) and DRAWER FRONTS (K2, L2, Q2, and R2).
414764www.sauder.com/services Pae 7
G
H
K2
L2
Q2
Q2
R2
R2
BB2
(12 used)
å Fasten the REAR LEGS (I) to the ENDS (A and B). Use six
BLACK 2-1/4" FLAT HEAD SCREWS (KK).
Step 3
414764 www.sauder.com/servicesPae 8
A
I
B
I
Surface without
HIDDEN CAMS
Surface without
HIDDEN CAMS
Flat ede
BLACK 2-1/4" FLAT HEAD SCREW
(6 used in this step)
KK
Remember:
Rihty tihty.
Lefty loosey.
Step 4
414764www.sauder.com/services Pae 9
A
B
å Turn four BLACK 9/16" FLAT HEAD SCREWS (OO) into
the ENDS (A and B) until the shoulder of the SCREWS
rest on the surface of the ENDS.
å Slide the END MOLDINGS (M73) onto the ENDS (A and B).
Line up the roove in the MOLDINGS over the head of the
SCREWS in the ENDS.
These edes
should be even.
These edes
should be even.
Shoulder
Apply pressure with your hands
as you uide the MOLDINGS over
the SCREWS and onto the ENDS.
BLACK 9/16" FLAT HEAD SCREW
(4 used in this step)
OO
Surface without
HIDDEN CAMS
Surface without
HIDDEN CAMS
M73
M73
Step 5
414764 www.sauder.com/servicesPae 10
A
G
B
H
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
å Fasten the FRONT LEGS (G and H) to the other surface of
the ENDS (A and B). Tihten six HIDDEN CAMS.
1
2
Anled ede
