Soft Starter SSXB/SSXA Series
Instrukcja obsługi
2
1. Function and Feature ……………………………………………………………………………… 5
2. Product Type and Inspection……………………………………………………………………… 6
3. Environment and Installation…………………………………………………………………… 7
3.1 Environment…………………………………………………………………………………………… 7
3.2 Installation…………………………………………………………………………………………… 8
4. Operating Principle………………………………………………………………………………… 9
5. Terminals and Wiring………………………………………………………………………………… 10
5.1 Wiring Diagram………………………………………………………………………………………… 10
5.2 External Terminal…………………………………………………………………………………… 11
5.3 Main Circuit Wiring………………………………………………………………………………… 12
5.4 Control Circuit Wiring …………………………………………………………………………… 12
6. Control Mode ………………………………………………………………………………………… 13
6.1 Voltage Ramp………………………………………………………………………………………… 13
6.2 Current Limit………………………………………………………………………………………… 13
6.3 Jogging ……………………………………………………………………………………………… 14
6.4 Heavy Load ……………………………………………………………………………………… 14
6.5 Stopping ………………………………………………………………………………………… 15
7. Operating keyboard………………………………………………………………………………… 16
7.1 Keyboard Description……………………………………………………………………………… 16
7.2 Key Function………………………………………………………………………………………… 16
8. Parameter Table………………………………………………………………………………………… 17
9. Special Parameter…………………………………………………………………………………… 19
10. Display Current Calibration……………………………………………………………………… 20
11. Parameter Details…………………………………………………………………………………… 21
12. Working State………………………………………………………………………………………… 24
13. Fault…………………………………………………………………………… ……………………… 25
14.1 Fault Display and Solutions…………………………………………………………………… 25
14.2 Overload …………………………………………………………………………………………… 26
15. Test running……………………………………………………………………………………… … 27
Appendix1：Specification and Type …………………………………………………………………… 28
SANYU Soft starter SSXB/SSXA serie User Manual
SANYU Soft starter SSXB/SSXA serie User Manual
3
Appendix2：SSXA Series Structure Size（Built-in bypass contactor）………………………… 29
Appendix3：SSXB Series Structure Size（bypass up）……………………………………………… 30
Appendix4：Keyboard Shape and Dimension…………………………………………………………… 31
Appendix6：SSXB Series Typical Wiring Diagram …………………………………………………… 32
Appendix7：SSXA Series Typical Wiring Diagram ……………………………………………………… 33
Appendix9：Communicate protocol………………………………………………………………………… 36
4
Manual File Number:SSXB /SSXA-V3.7.3
Version Number: V3.7
Revision Number:314
Issuance Date: 2019-10-15
1. Overview
This manual is applicable to SSXA/SSXB series products.
This manual is intended to guide qualified personnel in the installation and operation of
this product.
In the case of a registered trademark and business ownership, final interpretation right to
this manual is belonged to SANYU . Any unreasonable application, especially in
reproduction and release by the third parties, is not allowed
Although the information in this manual is checked carefully, but there may be some mistakes.
If you find them, please phone us as soon as possible.
Because this product is improved continuously, so user should regard this manual as the
reference.
The parameters in the manual are only used to describe the product.In order to meet the needs
of the customers, we will improving our products continuously to meet the latest technical
criteria.
2. Safety
Pay attention to the note, warning and tips mentioned in this manual.
Only professional technician can be permitted to install or guide the installation of this
product.
Ensuring the power and specification of the motor is matched to those of this product;
The capacitor is prohibited strictly to be connected with the output terminal (U.V.W) of this
production
The cables connecting to the input and output terminals of this product should be packed well
by insulating tape;
The shell of this product must be connected to the ground reliably;
Make sure the power of this product must be cut off before it is maintained.
This manual is packed with the product. Operator must take it as the guide of this product.
Please read it carefully before using this product.
3. Safety Mark
Attention, Warning and Notes
◆ Attention Something can lead to personal injury or death.
◆ Warning Something can lead to damage of the device or software.
◆ Note Remind user something related.
SANYU Soft starter SSXB/SSXA serie User Manual
5
1.Function and Feature
SSXA/SSXB series LED AC motor soft starter is new type starting equipment with advanced
international level. This equipment designed and manufactured by the technique of power
electronics microprocessor and modern control theory. This equipment can limit the start current
efficiently when the asynchronous motor starts. It is widely applied in the field such as winding
machine, pump, transition and compressor etc. It is the ideal product to replace the traditional
voltage dropping start equipment such as star/triangle conversion, self-coupling voltage dropping,
magnetic control dropping voltage etc.
Function
◆ Reduce the starting current of motor; reduce capacity of power distribution; reduce the
investment cost；
◆ Reduce the start stress; prolong the operation lifetime of the motor and correspond equipment；
◆ Smooth and steady starting and soft stopping; The Water hammer and surge can be avoid；
◆ Several sorts of starting mode, wide range setting of the current and voltage. It can be used
in a lot of load conditions, so the technic can be improved；
◆ Perfect and reliable protection; The safeguard of the motor and relative equipment can be
achieved effectively；
◆ It can be used in the state in which motor should star and stop frequently。
Feature
◆ Starting Mode：Based on the load characteristics, different starting mode can the related
parameters can be selected. So the best starting effect can be gained；
◆ Technical Performance：The higher performance microprocessor and software are used, so the
control circuit is simplified. The best perform speed can gained without the adjustment of the
circuit parameters；
◆ Reliability：All the electronic components of this product are selected strictly. Additionally,
the main control board is tested in high temperature environment above seventy-two hours. The
reliability of this product can be guaranteed
◆ Structure：The modularization structure and up-in-down-out wiring mode are adopted. It is
easy to used and integrated；
◆ Multi-Protection：The motor protection circuit is not be added if the single product is in
used. Because of this product have multiple protection functions (Such as over-current,
overload, phase-fault, overheat and so on). So the cost can be reduced, the circuit can be
simplified.
◆ Keyboard：Operation of the keyboard is easy. User can set and modify the parameters (for
example: starting, stopping, running, protection) by this keyboard according to different load
SANYU Soft starter SSXB/SSXA serie User Manual
6
conditions.
◆ Analog signal output：4-20mA analog sign output l is provided；
◆ RS485 provide RS485( Modbus communication protocol)communication；
◆ Actual power setting：When the rate power of Soft Starter is higher than the power of actual
load, soft starter can be matched to the actual load by modifying the actual current parameter.
So the parameters about starting、running and protection are correct
2.Product Type and Inspection
Each SSXA/SSXB series soft starter is tested. Only the starter that passes the function and
running test can leave the factory. After receiving the equipment, the user should inspect it
according the steps described below. Please notify the supplier immediately if you find any problem
◆ Check the nameplate：Check the item(s) nameplate catalog number against the purchase order.
Make sure that the equipment you received is matched with the product you ordered。
◆ Inspect whether or not the product is damaged through the delivery, for example: Inner parts
fall off, She11 is deformed or depressed, the wires are loose etc.
◆ Quality certificate and user manual: The package of each soft start includes quality
certificate and user manual.
◆ SSXA series soft starter has built-in bypass contactor.
series motor soft starter
Type:
Voltage: 3φAC380V
Motor Power: KW
Rated Current：A
Factory Number：
SANYU Soft starter SSXB/SSXA serie User Manual
SSXA/SSXB
SSXA/SSXB
7
3. Environment and Installation
3.1 Environment
The environment is important to the equipment life. So please install the soft starter on the
site described below
◆Operation Condition for the standard products
Power Supply: Urban power, self-provided substation, diesel generating sets
Three-phase AC: 380V or 660V or 1140V (-10%, +15%), 50Hz.
(note：voltage level should be matched to the rate voltage of the actually motor, user should
explain the voltage level in the purchase order if it is special.)
Motor: Squirrel cage asynchronous motor. (Please explain in the purchase order if it is special)
Start frequency: less than 20 times per hour for Standard products (Please explain in the purchase
order if the motor should be start more frequent)
Cooling: Natural air-cooled or Fan air cooling
IP Code: IP20
Environment condition: If the altitude is above 2000 M, user should select the higher power
product.
Environment Temperature: -25℃ to +40℃.
Relative humidity: ≤95% (20℃士5℃) non-condensing, no inflammable，explosive gases, no
conducive dust.
Install in an enclosure with good ventilation. The vibration is less than 0.5G
Structure Form: For the SSXB series product, bypass contactor should be allocated by user
For the SSXA series product, there is inner bypass contactor
◆Special conditions
If unconventional products using in the special conditions is needed, please explain in the
purchase order
SANYU Soft starter SSXB/SSXA serie User Manual
8
3.2 Installation
◆Direction and Distance
The product must be vertically installed. There should be enough space to dissipate the heat,
as shown in figure 3-1. For the cabinet product, there should be a certain distance between back
door of the product and wall. Therefore it is easy to maintain.
3030
120
120
Figure 3 1-
S
V
A
FU NC TI ON DA TA UN ITU
I
%
PR G
ST OP
RU N
◆Cabinet installation
If the product is installed in the cabinet, make sure there are good ventilation in the cabinet.
The products can be installed vertically or horizontally. Horizontal layout shows in Figure 3-2.
Vertical layout shows in Figure 3-3. User can adopt any of them.
Note: If the vertical layout is adopted (especial in fan air cooling mode), clapboard should be
installed between them to avoid that the upper starter is affected by heat generated by the lower
starter.
Hot airHot air Hot airHot air
Cool air
Ventilation
Figure3-2
Horizontal layout
Figure3-3
Vertical layout
Soft Starter Soft Starter
SANYU Soft starter SSXB/SSXA serie User Manual
9
4. Operating principle
There are three pairs of anti-parallel thyristors connected to the stator of motor. Using
the electric switch feature of the thyristors, the voltage of the motor can be controlled by
changing the triggering angel of the thyristors. The triggering angel of the thyristors is
controlled by microprocessor. So the motor can be started softer and smooth. After the equipment
is up to full voltage, it outputs a bypass signal. User can use this signal to control the bypass
contactor to supply the motor. See figure4-1.
Moter
R.S.T
3-phase AC power supply
AC 380V/660V/1140V
KM
Votage
detecting drive circuit Current
detecting
Computer fuzzy control
Keyboard 、display
U.V.W
Figure 4-1
SANYU Soft starter SSXB/SSXA serie User Manual
10
5. Wiring and terminal
5.1 Wiring diagram
Note:
1. There are two wiring ways to control starting and stopping the starter externally. They are three-line and
two-line wiring. (See ①and② in the figure above).Start signal is given by connecting terminal RUN and COM.
Stop signal is given by disconnecting terminal RUN and COM
Connect according the figure①，free stop
Connect according the figure②，soft stop
2. In the SSXA series product, there is no terminals U1,V1,W1.Because there is built-in bypass contactor.
3. In the SSXA series product dose no have the output terminal（K22/K24）.It can be replaced by the programmable
control terminals (K32/K34).The parameter “K3” should be set “bypass”.
4. SSXA series product needs external AC220V power supply. SSXB series product dose not have external AC power
terminals (L/N).
SANYU Soft starter SSXB/SSXA serie User Manual
