Sanyo DP23845 Manuel utilisateur

Specifications
Power Rating . . . . . . . . . . . . . . . . . . . . . . . . 120VAC
92W (Avg), 1.6A (Max)
Antenna Input Impedance . . . . . . . . . . . . . . . . . 75Ω
UHF/VHF/CATV
Receiving Channel . . . . . . . . . . . . . . . . 2 - 13 (VHF),
14 - 69 (UHF),
01, 14-94, 95-125 (CATV)
Remote Ready . . . . . . . . . . 25 Key Remote Control
Sound Output . . . . . . . . . . . . . . . . . . . . . . 2.0 W/CH
Intermediate Frequency
Picture IF Carrier. . . . . . . . . . . . . . . . . . 45.75MHz
Sound IF Carrier . . . . . . . . . . . . . . . . . . 41.25MHz
Color Sub Carrier . . . . . . . . . . . . . . . . . 42.17MHz
LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . V230W1-L02
Cabinet Dimensions
Width. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 692mm
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . 385mm
Depth including base . . . . . . . . . . . . . . . . 181mm
REFERENCE No. SM780108
DP23845, N2TF, PRODUCT CODE 111377005
Contents
Safety Instructions . . . . . . . . . . . . . . . . . . 2
Service Adjustments . . . . . . . . . . . . . 3 - 14
Power Failure Circuit . . . . . . . . . . . . . . . 15
Mechanical Disassemblies. . . . . . . 16 – 17
Chassis Electrical Parts List . . . . . . 18 - 33
Cabinet Parts List . . . . . . . . . . . . . . . . . . 34
Component and Test Point
Locations . . . . . . . . . . . . . . . . . . . 35 – 39
Block Diagrams . . . . . . . . . . . . . . . . 40 – 45
Trouble Shooting Flow Charts . . . . 46 – 48
Control Port Functions. . . . . . . . . . . 49 – 50
Schematic Notes . . . . . . . . . . . . . . . . . . . 51
Pin Layouts. . . . . . . . . . . . . . . . . . . . . . . . 51
Capacitor and Resistor Codes . . . . . . . . 52
Schematic Diagrams . . . . . . . . . . . . 53 - 64
AS
FILE NO.
SERVICE MANUAL Remote Control Digital
Color Television DP23845 (U.S.A.)
(CANADA)
ORIGINAL VERSION
Chassis No. 23845-00
NOTE: Match the Chassis No. on
the unit’s back cover with
the Chassis No. in the
Service Manual.
If the Original Version
Service Manual Chassis
No. does not match the
unit’s, additional Service
Literature is required. You
must refer to “Notices” to the
Original Service Manual
prior to servicing the unit.

— 2 —

SAFETY INSTRUCTIONS

SAFETY PRECAUTIONS

1. Comply with all caution and safety-related notes provided

on the side of the cabinet, inside the cabinet, and on the

chassis,

2. When replacing a chassis in the cabinet, always be certain

that all the protective devices are installed properly, such

as control knobs, adjustment covers, shields and barriers.

3. Before replacing the back cover of the set, thoroughly

inspect the inside of the cabinet to see that no stray parts

or tools have been left inside.

ANTENNA COLD CHECK

Remove AC plug from the 120 VAC outlet and place a

jumper across the two blades. Connect one lead of an ohm-

meter to the jumpered AC plug, and touch the other lead to

each exposed antenna terminal (UHF and VHF antenna ter-

minals). The resistance must measure between 1M ohm and

5.2M ohm. Any resistance value below or above this range

indicates an abnormality which requires corrective action.

LEAKAGE CURRENT CHECK

Plug the AC line cord directly into a 120 VAC outlet. (Do not

use an isolation transformer for this check.) Use an AC volt-

meter, that has 5000 ohms per volt or more sensitivity.

Connect a 1500 ohm 10 watt resistor, paralleled by a 0.15 µF

150 VAC capacitor, between a known good earth ground

(water pipe, conduit, etc.) and all exposed metal parts of the

cabinet (antennas, handle bracket, metal cabinet, screw

heads, metal overlays, control shafts, etc.). Measure the AC

voltage across the 1500 ohm resistor. The AC voltage

should not exceed 750 mV. A reading exceeding 750 mV

indicates that a dangerous potential exists. The fault must

be located and corrected. Repeat the above test with the

receiver power plug reversed.

NEVER RETURN A RECEIVER TO THE CUSTOMER

WITHOUT TAKING THE NECESSARY CORRECTIVE ACTION.

PRODUCT SAFETY NOTICE

When replacing components in a receiver, always keep in

mind the necessary product safety precautions. Pay special

attention to the replacement of components marked with a

star () in the parts list and in the schematic diagrams. To

ensure safe product operation, it is necessary to replace

those components with the exact same PARTS.

0.15 µF 150V AC

1500 ohm

10 watt

Good earth ground

such as a water pipe,

conduit, etc.

AC OUTLET

TELEVISION

RECEIVER

READING SHOULD NOT EXCEED 750 mV.

AC VOLTMETER

(5000 ohms per volt or more sensitivity)

To be touched to all of exposed metal parts.

Voltmeter Hook-up for Leakage Current Check.

1 2 3

4 5 6

7 8 9

MUTE

CAPTION SLEEP

RECALL

RESETINPUT POWER

DISPLAY

V-GUIDE

123

456

789

VOL VOL

PIX SHAPE

GENERAL

This set has an On-screen Service Menu system included in

the CPU that allows remote operation for most of the ser-

vice adjustments.

ON-SCREEN SERVICE MENU SYSTEM

1. Enter the Service Menu:

•While pressing the Volume (–) button on the televi-

sion, press the Number Key 1 on the remote control

unit. The Service Menu will now appear.

2. Service Adjustments:

•Press the or key to select the desired service

menu item you want to adjust. See page 4 for the

On-screen Service Menu.

Note: Press the Mute key to skip up 16 items.

•Use the + or – key or number keys to adjust the data.

The + or – keys will increase or decrease the data

sequentially. The number keys (0 ~ 7) toggle only

their respective bits between 1 and 0 and are used to

change the Sub-Address. For example to change bit

5 press the number 5 key. See below.

Note: Using the + or – is not recommended due to possi-

ble rapid changes.

3. Exit from the Service Menu:

•Press the MENU key to turn off

the Service Menu display.

255_ 255

255 / 255 / 255

255 : 255 : 255__00000

M016___S0A __TV____RC00

V_ENH__GAIN__TV

000____01__00000001

Item No.Hexadecimal

Data Binary Data

Title

— 3 —

SERVICE ADJUSTMENTS

Service Menu Display

(b7) (b6) (b5) (b4) (b3) (b2) (b1) (b0)

0 1 0 1 0 1 1 0 BINARY DATA

(8 bit)

Menu:

Exit Service Menu

 :Select Item

Volume + / –:

Adjust Service Menu

Mute:

Skip Next 16 items

Numeric:

Enter Service Menu

0, 1, 2, 3, 4, 5, 6, 7:

Change Binary Data

1, 3, 4, 6, 7, 9:

Adjust White Balance

POWER VOL



Volume – :Enter Service Menu

000 V ENH GAIN TV 01h RF input

001 V ENH GAIN OTHER 01h Except RF

002 V ENH MAX POINT TV 03h RF input

003 V ENH MAX POINT OTHER 03h Except RF

004 V ENH SLICE LEVEL TV 00h RF input

005 V ENH SLICE LEVEL OTHER 00h Except RF

006 FENH TV 01h RF input

007 FENH OTHER 01h Except RF

008 SHARPNESS GAIN TV 01h RF input

009 SHARPNESS GAIN OTHER 01h Except RF

00A SHARPNESS SLICE LEVEL TV 00h RF input

00B SHARPNESS SLICE LEVEL OTHER 00h Except RF

00C FBCLMPEX 01h

00D NOISE CANCEL TV 00h RF input

00E NOISE CANCEL OTHER 00h Except RF

00F SET DELAY–TV 0Dh RF input

010 SET DELAY–Video 0Bh Composite Video input

011 SET DELAY–OTHER 08h Except RF and Composite Video input

012 LTI GAIN TV 03h RF input

013 LTI GAIN OTHER 03h Except RF

014 LTI SLICE LEVEL TV 00h RF input

015 LTI SLICE LEVEL OTHER 00h Except RF

016 CTI GAIN TV 03h RF input

017 CTI GAIN OTHER 03h Except RF

018 CTI SLICE LEVEL TV 00h RF input

019 CTI SLICE LEVEL OTHER 00h Except RF

01A CONTRAST TV 30h RF input, (See Service Adjustments)

01B CONTRAST AV 30h Video1/2, Composite, S input

01C CONTRAST 480i/p 30h 480i/p input

01D CR OUTPUT GAIN TV 03h RF input

01E CR OUTPUT GAIN AV 03h Video1/2, Composite, S input

01F CR OUTPUT GAIN 480i/p 03h 480i/p input

020 CB OUTPUT GAIN TV 03h RF input

021 CB OUTPUT GAIN AV 03h Video1/2, Composite, S input

022 CB OUTPUT GAIN 480i/p 03h 480i/p input

023 CR OFFSET–TV 00h RF input

024 CR OFFSET–AV 00h Video1/2, Composite, S input

025 CR OFFSET–480i 01h 480i input

026 CR OFFSET–480p 00h 480p input

027 CB OFFSET–TV 00h RF input

028 CB OFFSET–AV 00h Video1/2, Composite, S input

029 CB OFFSET–480i 00h 480i input

02A CB OFFSET–480p 01h 480p input

02B HUE–TV 00h RF input

02C HUE–AV 00h Video1/2, Composite, S input

— 4 —

ON-SCREEN SERVICE MENU

No. Name Initial Data Note

•All data except in gray box area is fixed. Do not change for correct operation.

•Data in gray box is initial. Can be set according to adjustment information.

02D HUE–480i/p 00h 480i/p input

02E TOF TV 01h RF input

02F TOF OTHER 01h Except RF

030 Y–CLAMP–MAIN 00h Except 480i/p

031 Y–CLAMP–480i 6Dh 480i input

032 Y–CLAMP–480p 6Dh 480p input

033 C–CLAMP–MAIN 00h Except 480i/p

034 C–CLAMP–480i 00h 480i input

035 C–CLAMP–480p 80h 480p input

036 C–CLAMP F–MAIN 00h Except 480i/p

037 C–CLAMP F–480i 6Fh 480i input

038 C–CLAMP F–480p 6Dh 480p input

039 COL–KILLER TV 07h RF input

03A COL–KILLER AV 07h Video1/2, Composite, S input

03B ACC TV 08h RF input

03C ACC AV 08h Video1/2, Composite, S input

03D PLL–TV AMP1 00h RF input

03E PLL–TV AMP2 04h ↓

03F PLL–TV AMP3 05h ↓

040 PLL–TV GAIN1 0Eh ↓

041 PLL–TV GAIN2 05h ↓

042 PLL–TV GAIN3 06h ↓

043 PLL–AV AMP1 00h Video1/2, Composite, S input

044 PLL–AV AMP2 04h ↓

045 PLL–AV AMP3 05h ↓

046 PLL–AV GAIN1 0Eh ↓

047 PLL–AV GAIN2 05h ↓

048 PLL–AV GAIN3 06h ↓

049 PLL–480i/p AMP1 00h Video3, Component(480i/p) input

04A PLL–480i/p AMP2 04h ↓

04B PLL–480i/p AMP3 05h ↓

04C PLL–480i/p GAIN1 0Eh ↓

04D PLL–480i/p GAIN2 05h ↓

04E PLL–480i/p GAIN3 06h ↓

04F HDPH COMP 00h RF, Composite input

050 HDPH S 02h S input

051 HDPH 480i 0Eh 480i input

052 HDPH 480p 00h 480p input

053 Y NOISE LIM TV 00h RF input

054 Y NOISE LIM OTHER 00h Except RF

055 Y NOISE GAIN TV 01h RF input

056 Y NOISE GAIN OTHER 00h Except RF

057 Y NOISE TV 01h RF input

058 Y NOISE OTHER 00h Except RF

059 COL–KILLER GAIN TV 01h RF input

05A COL–KILLER GAIN OTHER 01h Except RF

05B C NOISE LIM TV 01h RF input

05C C NOISE LIM OTHER 01h Except RF

05D C NOISE GAIN TV 00h RF input

05E C NOISE GAIN OTHER 00h Except RF

05F C NOISE TV 01h RF input

— 5 —

No. Name Initial Data Note

060 C NOISE OTHER 00h Except RF

061 480i SUB–CONT 00h Component (480i) input (Difference)

062 480i SUB–BRIGHTNESS 00h ↓

063 480i SUB–COLOR 00h ↓

064 480i SUB–TINT 00h ↓

065 480i SUB–SHARP 00h ↓

066 480p SUB–CONT 00h Component (480p) input (Difference)

067 480p SUB–BRIGHTNESS 00h ↓

068 480p SUB–COLOR 0Ch ↓

069 480p SUB–TINT 00h ↓

06A 480p SUB–SHARP 00h ↓

06B AV SUB–CONT 00h Composite Video input (Standard)

06C AV SUB–BRIGHTNESS 0Fh ↓

06D AV SUB–COLOR 08h ↓

06E AV SUB–TINT 08h ↓

06F AV SUB–SHARP 10h ↓

070 S SUB–CONT 00h S Video input (Difference)

071 S SUB–BRIGHTNESS 00h ↓

072 S SUB–COLOR 00h ↓

073 S SUB–TINT 00h ↓

074 S SUB–SHARP 00h ↓

075 RF SUB–CONT 00h RF input (Difference)

076 RF SUB–BRIGHTNESS 00h ↓

077 RF SUB–COLOR 00h ↓

078 RF SUB–TINT 00h ↓

079 RF SUB–SHARP 00h ↓

07A 720p SUB-CONT 00h Component(720p) input (Difference)

07B 720p SUB-BRIGHT 00h ↓

07C 720p SUB-COLOR 00h ↓

07D 720p SUB-TINT 00h ↓

07E 720p SUB-SHARP F8h ↓

07F 1080i SUB-CONT 00h Component(1080i) input (Difference)

080 1080i SUB-BRIGHT 00h ↓

081 1080i SUB-COLOR 00h ↓

082 1080i SUB-TINT 00h ↓

083 1080i SUB-SHARP F8h ↓

084 480i D SUB-CONT 00h DVI(480i) input (Difference)

085 480i D SUB-BRIGHT 00h ↓

086 480i D SUB-COLOR 00h ↓

087 480i D SUB-TINT 00h ↓

088 480i D SUB-SHARP 00h ↓

089 480p D SUB-CONT 00h DVI(480p) input (Difference)

08A 480p D SUB-BRIGHT 00h ↓

08B 480p D SUB-COLOR 00h ↓

08C 480p D SUB-TINT 00h ↓

08D 480p D SUB-SHARP 00h ↓

08E 720p D SUB-CONT 00h DVI(720p) input (Difference)

08F 720p D SUB-BRIGHT 00h ↓

090 720p D SUB-COLOR 00h ↓

091 720p D SUB-TINT 00h ↓

092 720p D SUB-SHARP 00h ↓

— 6 —

No. Name Initial Data Note

— 7 —

No. Name Initial Data Note

093 1080i D SUB-CONT 00h DVI(1080i) input (Difference)

094 1080i D SUB-BRIGHT 00h ↓

095 1080i D SUB-COLOR 00h ↓

096 1080i SUB-TINT 00h ↓

097 1080i SUB-SHARP 00h ↓

098 AUTO CONTRAST 0Ah Composite, S, Component input, Picture: Auto

099 AUTO TINT 22h ↓

09A AUTO COLOR 28h ↓

09B AUTO BRIGHT 20h ↓

09C AUTO SHARP 10h ↓

09D MANUAL AV CONTRAST 2Fh Composite, S, Component input, Picture: Manual

09E MANUAL AV TINT 20h ↓

09F MANUAL AV COLOR 28h ↓

0A0 MANUAL AV BRIGHT 20h ↓

0A1 MANUAL AV SHARP 10h ↓

0A2 GAME AV CONTRAST 10h Composite, S, Component input, Picture: Game

0A3 GAME AV TINT 20h ↓

0A4 GAME AV COLOR 10h ↓

0A5 GAME AV BRIGHT 20h ↓

0A6 GAME AV SHARP 07h ↓

0A7 WHITE-RF R 00h RF(TV) input, White Balance (Difference)

0A8 WHITE-RF G 00h ↓

0A9 WHITE-RF B 00h ↓

0AA BLACK-RF R 00h RF(TV) input, Black Balance (Difference)

0AB BLACK-RF G 00h ↓

0AC BLACK-RF B 00h ↓

0AD WHITE-AV R 52h Composite (AV) input, White Balance (Standard)

0AE WHITE-AV G 44h ↓

0AF WHITE-AV B 40h ↓

0B0 BLACK-AV R 30h Composite (AV) input, Black Balance (Standard)

0B1 BLACK-AV G 30h ↓

0B2 BLACK-AV B 30h ↓

0B3 WHITE-S R 00h S(AV) input, White Balance (Difference)

0B4 WHITE-S G 00h ↓

0B5 WHITE-S B 00h ↓

0B6 BLACK-S R 00h S(AV) input, Black Balance (Difference)

0B7 BLACK-S G 00h ↓

0B8 BLACK-S B 00h ↓

0B9 WHITE-480i R 00h 480i(Component) input, White Balance (Difference)

0BA WHITE-480i G 00h ↓

0BB WHITE-480i B 00h ↓

0BC BLACK-480i R 00h 480i(Component) input, Black Balance (Difference)

0BD BLACK-480i G 00h ↓

0BE BLACK-480i B 00h ↓

0BF WHITE-480p R 00h 480p(Component) input, White Balance (Difference)

0C0 WHITE-480p G 00h ↓

0C1 WHITE-480p B 00h ↓

0C2 BLACK-480p R 00h 480p(Component) input, Black Balance (Difference)

0C3 BLACK-480p G 00h ↓

0C4 BLACK-480p B 00h ↓

— 8 —

No. Name Initial Data Note

0C5 WHITE-720p R 00h 720p (Component) input, White Balance (Difference)

0C6 WHITE-720p G 00h ↓

0C7 WHITE-720p B 00h ↓

0C8 BLACK-720p R 00h 720p (Component) input, Black Balance (Difference)

0C9 BLACK-720p G 00h ↓

0CA BLACK-720p B 00h ↓

0CB WHITE-1080i R 00h 1080i (Component) input, White Balance (Difference)

0CC WHITE-1080i G 00h ↓

0CD WHITE-1080i B 00h ↓

0CE BLACK-1080i R 00h 1080i (Component) input, Black Balance (Difference)

0CF BLACK-1080i G 00h ↓

0D0 BLACK-1080i B 00h ↓

0D1 WHITE-480i D R 00h 480i (DVI) input, White Balance (Difference)

0D2 WHITE-480i D G 00h ↓

0D3 WHITE-480i D B 00h ↓

0D4 BLACK-480i D R 00h 480i (DVI) input, Black Balance (Difference)

0D5 BLACK-480i D G 00h ↓

0D6 BLACK-480i D B 00h ↓

0D7 WHITE-480p D R 00h 480p (DVI) input, White Balance (Difference)

0D8 WHITE-480p D G 00h ↓

0D9 WHITE-480p D B 00h ↓

0DA BLACK-480p D R 00h 480p (DVI) input, Black Balance (Difference)

0DB BLACK-480p D G 00h ↓

0DC BLACK-480p D B 00h ↓

0DD WHITE-720p D R 00h 720p (DVI) input, White Balance (Difference)

0DE WHITE-720p D G 00h ↓

0DF WHITE-720p D B 00h ↓

0E0 BLACK-720p D R 00h 720p (DVI) input, Black Balance (Difference)

0E1 BLACK-720p D G 00h ↓

0E2 BLACK-720p D B 00h ↓

0E3 WHITE-1080i D R 00h 1080i (DVI) input, White Balance (Difference)

0E4 WHITE-1080i D G 00h ↓

0E5 WHITE-1080i D B 00h ↓

0E6 BLACK-1080i D R 00h 1080i (DVI) input, Black Balance (Difference)

0E7 BLACK-1080i D G 00h ↓

0E8 BLACK-1080i D B 00h ↓

0E9 CT-COOL R F6h Color Enhancer: Cool

0EA CT-COOL G FBh ↓

0EB CT-COOL B 00h ↓

0EC CT-NORM R 00h Color Enhancer: Normal

0ED CT-NORM G 00h ↓

0EE CT-NORM B 00h ↓

0EF CT-WARM R 00h Color Enhancer: Warm

0F0 CT-WARM G F2h ↓

0F1 CT-WARM B 00h ↓

0F2 SHARP F0 RF 02h RF input, Sharpness: Center

0F3 SHARP F0 OTHER 02h Other input, Sharpness: Center

0F4 SHARP F0 480p 02h 480p input, Sharpness: Center

0F5 GAMMA1 01h Under APL setting value

0F6 GAMMA2 01h Beyond APL setting value

— 9 —

No. Name Initial Data Note

0F7 GAMMA APL 00h Gamma Threshold

0F8 NOSIG 00h Select Sync.

0F9 BSCB 00h Cut of Sub-Bass or Setup of Boost

0FA BSCT 00h Cut of Sub-Treble or Setup of Boost

0FB SUB-BASS 00h Setup of Cut Level of Sub Bass and Boost Level

0FC SUB-TREBLE 00h Setup of Cut Level of Sub Treble and Boost Level

0FD BBE-LOW 0Ah Setup of Low-Pass Boost Level (Lo contour)

0FE BBE-HIGH 08h Setup of High Region Boost Level (Process)

0FF AGC 00h AGC ON/OFF

100 AGC LEVEL 00h AGC Level Setup

101 WB ** White Balance Adjustment

102 BB ** Black Balance Adjustment

103 AUTO B-BRIGHT 00h Back Light Auto Bright (Absolute value)

104 BLIGHT-BRIGHT F0h Back Light Bright (PWM value)

105 BLIGHT-MID B0h Back Light Middle (PWM value)

106 BLIGHT-DARK 60h Back Light Dark (PWM value)

107 APL-SW 01h APL Switch

108 APL-PER 10h AI Cycle (8ms/step)

109 APL-LO 36h APL Low-Pass and Inside Region Threshold

10A APL-HI 48h APL Inside and High Region Threshold

10B APL-MIN 10h Gamma Minimum Value (Table No.)

10C APL-CEN 24h Gamma Center Value (Table No.)

10D APL-MAX 48h Gamma Maximum Value (Table No.)

10E APL-READ-NUM 05h Number of APL Read-out Times

10F APL-READ-PER 01h APL Read-out Cycle

110 APL-0 70h APL Read-out Value (APL=0%: Black)

111 APL-100 E0h APL Read-out Value (APL=100%: White)

112 POWER ERR 00h Power Failure History

113 OPTION **h Option Monitor (Read-out)

114 PANEL TIME1 **h Used Time of LCD Panel

115 PANEL TIME2 **h Used Time of Unit

116 OSD HP 00h OSD H-Phase

117 CCD HP 14h CCD H-Phase

118 CCD SLICER LEVEL 0Bh CCD Slicer Level

119 PASSWORD **h Password

11A VUP FULL 01h

11B VUP JUST 01h

11C VUP ZOOM 01h

11D VUP NORMAL 01h

11E VSC FULL 0Fh

11F VSC JUST 07h

120 VSC ZOOM 04h

121 VSC NORMAL 0Fh

122 HSC1 N FULL 10h

123 HSC1 N JUST 0Fh

124 HSC1 N ZOOM 0Fh

125 HSC1 N NORMAL 0Bh

126 HSC1 D FULL 1Fh

127 HSC1 D JUST 08h

128 HSC1 D ZOOM 1Eh

— 10 —

No. Name Initial Data Note

129 HSC1 D NORMAL 10h

12A HSC2 N FULL 13h

12B HSC2 N JUST 07h

12C HSC2 N ZOOM 07h

12D HSC2 N NORMAL 0Ch

12E HSC2 D FULL 0Fh

12F HSC2 D JUST 0Fh

130 HSC2 D ZOOM 0Fh

131 HSC2 D NORMAL 11h

132 HST FULL 0Ah

133 HST JUST 0Fh

134 HST ZOOM 0Fh

135 HST NORMAL 04h

136 VST FULL 34h

137 VST JUST 54h

138 VST ZOOM 7Eh

139 VST NORMAL 34h

13A VUP FULL 480p 01h

13B VUP JUST 480p 01h

13C VUP ZOOM 480p 01h

13D VUP NORMAL 480p 01h

13E VSC FULL 480p 0Fh

13F VSC JUST 480p 07h

140 VSC ZOOM 480p 04h

141 VSC NORMAL 480p 0Fh

142 HSC1 N FULL 480p 10h

143 HSC1 N JUST 480p 0Fh

144 HSC1 N ZOOM 480p 07h

145 HSC1 N NORMAL 480p 0Bh

146 HSC1 D FULL 480p 1Fh

147 HSC1 D JUST 480p 08h

148 HSC1 D ZOOM 480p 0Eh

149 HSC1 D NORMAL 480p 10h

14A HSC2 N FULL 480p 13h

14B HSC2 N JUST 480p 07h

14C HSC2 N ZOOM 480p 07h

14D HSC2 N NORMAL 480p 0Ch

14E HSC2 D FULL 480p 0Fh

14F HSC2 D JUST 480p 0Fh

150 HSC2 D ZOOM 480p 0Fh

151 HSC2 D NORMAL 480p 11h

152 HST FULL 480p 12h

153 HST JUST 480p 18h

154 HST ZOOM 480p 16h

155 HST NORMAL 480p 0Ah

156 VST FULL 480p 3Dh

157 VST JUST 480p 5Ch

158 VST ZOOM 480p 89h

159 VST NORMAL 480p 3Dh

15A VUP 480i D 01h

15B VUP 480p D 01h

Autres manuels pour DP23845

Table des matières

Autres manuels Sanyo TV

Sanyo

Sanyo DS19204 Manuel utilisateur

Sanyo

Sanyo CZP2900TX Manuel utilisateur

Sanyo

Sanyo DP42840 - 42" Diagonal LCD FULL HDTV 1080p Manuel utilisateur

Sanyo

Sanyo CA21XS2 Manuel utilisateur

Sanyo

Sanyo CE25DN9-B Manuel utilisateur

Sanyo

Sanyo CE14AT3-C Manuel utilisateur

Sanyo

Sanyo CE19LD95-B Manuel utilisateur

Sanyo

Sanyo CA21KF3 Manuel utilisateur

Sanyo

Sanyo CE15LC4-B Manuel utilisateur

Sanyo

Sanyo C29LF34 Manuel utilisateur

Sanyo

Sanyo CP21VF1 Manuel utilisateur

Sanyo

Sanyo AVM-2751S Manuel utilisateur

Sanyo

Sanyo CP21SE1(V) Manuel utilisateur

Sanyo

Sanyo AVM-27D6 Manuel utilisateur

Sanyo

Sanyo CP29FS1 Manuel utilisateur

Sanyo

Sanyo DP37647 - 37" Vizzon LCD TV Manuel utilisateur

Sanyo

Sanyo C21ZM45 Guide d'installation

Sanyo

Sanyo CE21D5-C Manuel utilisateur

Sanyo

Sanyo DP46142 Guide de l'utilisateur

Sanyo

Sanyo CP14SE1K Manuel utilisateur

Sanyo

Sanyo CP29FS2 Manuel utilisateur

Sanyo

Sanyo CE14SA4 Manuel utilisateur

Sanyo

Sanyo CE21BN4-C Manuel utilisateur

Sanyo

Sanyo C14LT77M Manuel utilisateur

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur
