Sanyo Xacti VPC-GH1EX Instructions de montage
VPC-GH1EX
VPC-GH1GX
VPC-GH1PX
VPC-GH1TA
VPC-GH2
GUIDE FOR
BASIC OPERATION
Dual Camera
Please read these instructions carefully before using the camera.
Make sure to read and understand the separate booklet “SAFETY MANUAL”.
Keep this manual in a safe place for later reference.
Important note
This manual explains how to safely operate the VPC-GH1EX, VPC-GH1GX,
VPC-GH1PX, VPC-GH1TA and VPC-GH2.
Any information regarding only one of these products will be labeled as such.
iEnglish
HOW TO READ THIS MANUAL
For first-time users
Please read this manual to familiarize yourself with your camera’s
operation.
↓
To use the various camera features
The Instruction Manual that explains the features in detail can be
obtained from our website (page 45).
↓
To use additional features
Visit the Sanyo website to learn how to adjust the camera settings for
various shooting scenes. There you’ll also find information about the
software for playing back data recorded with your camera and for
burning (recording) DVDs (page 45).
You may find the answers to questions or problems concerning camera
operation in the sections “COMMONLY ASKED QUESTIONS” (page 52).
Symbols used in this manual
HINT Points giving some extended instructions or special points to pay
attention to.
CAUTION Points that require special attention.
(page xx) Refer to the page indicated for detailed information.
English ii
SHOOT, PLAY BACK AND SAVE
Preparing the camera
1 Insert the battery pack.
About saving your recorded data
hIf you wish to use an SD Memory Card, refer to page 15 to install the
card in the camera.
hAn SD Memory Card is not included with your camera. Please
purchase a commercially sold card.
hThis camera has an internal memory, so you can shoot and record
without an SD Memory Card installed.
▲
▲
2Open
3Insert the battery pack.
4Close the battery cover.
Battery cover
1Push out
iii English
Shooting
1 Press the ON/OFF button
for at least 1 second to turn
the camera on.
hIf the screen to set the
date and time appears,
press the MENU button 2
times to cancel it.
For how to set the date
and time, see page 23.
2 Record.
To record a video clip:
hPress the [ ] button to
begin recording a video
clip.
hPress the [ ] button
again to end the
recording.
To take a photo:
hPress the [ ] button.
hA still image is captured.
15 000:00:17
Full-HD
14
M
-
S
ON/OFF button
[ ] button
[]
button
MENU button
English iv
Before capturing those important shots, be sure to first take a
test shot to confirm that your camera is set up and ready to go
i
Sanyo declines any claim for compensation for recorded contents etc. in case
of photographing or recording failure due to a chance camera or card flaw.
Playback
1
Press the REC/PLAY
button.
h
The display changes to
the Playback Screen.
2
Select the image to play
back.
hUse the arrow keys to
move the orange frame
to the image you wish to
play back.
hThe image information
for the framed image is
shown in the bottom part
of the monitor.
3
Press the SET button.
hPlayback begins.
<To return to the
recording mode>
hPress the REC/PLAY
button.
Deleting files
1 On the screen in step 2,
move the orange frame to
the file you wish to delete,
and press the MENU
button.
2
Select “DELETE”,
and
press the SET button.
Full-HD
100-0006
00:00:05
6.5MB
OK
REC/PLAY button
Remaining battery
power indication
Orange frame
SET button
Arrow keys
vEnglish
3 Select “DELETE SINGLE”, and press the SET button.
4
Select “DELETE”,
and press the SET button.
hIf you press [G] or [H], the screen to delete a different file will appear.
5 When you are finished deleting files, press the MENU button.
hPressing the MENU button 3 times will return you to the screen in step
2.
When you are finished using the camera...
Press the ON/OFF button for at least 1 second to turn the camera off.
English vi
Copy data from your camera to the computer
Connect your camera to a computer, and copy the desired data to the
computer.
1 Turn on the computer, and use the supplied dedicated USB interface
cable to connect your camera to the computer.
hConnect the cable between the camera’s USB/AV terminal and the
computer’s USB connector.
2 Turn on the camera (page 20).
hThe USB Connection Screen appears on the camera’s monitor.
SET
USB CONNECTION
COMPUTER
PRINTER
CANCEL
CANCELOK
To USB/AV terminal
Supplied dedicated USB interface cable
To USB connector
vii English
3 Select “COMPUTER”, and press the SET button.
hThe screen to select the
computer connection mode
appears.
4 Select “CARD READER”, and press the SET button.
hThe message [Found New Hardware] appears in the task tray,
showing that the camera is recognized as a drive.
hThe card is recognized (mounted) as a disk, and the [XACTI (E:)] icon
appears in the [My Computer] window.
hThe drive name (E:) may be different on your computer.
<If the access menu (page 50) appears>
hClick on [Exit] to cancel the access menu.
5 Select an action.
hIf the [XACTI (E:)] window appears automatically, select the desired
procedure from the window.
6 Copy files from the camera to a computer.
USB CONNECTION
MTP
CARD READER
SCREEN CAPTURE
PC CAMERA
CANCEL
OK
English viii
Dismounting the camera
CAUTION
iTo disconnect your camera, be sure to follow the procedure below. Failure
to follow this procedure may cause faulty operation of your computer or
corrupt the files in your camera.
1 Left-click on the icon for safely removing hardware in the task tray.
hA list appears showing the devices connected to the computer’s USB
connector.
2 Left-click on the camera drive (E:).
hThe camera can now be disconnected.
hThe drive name (E:) may be different on your computer.
No software is included with this camera. Please visit our website to
obtain the available software.
1English
CONTENTS
HOW TO READ THIS MANUAL ............................................................. i
CHECKING THE INCLUDED ACCESSORIES ...................................... 3
How to use the accessories ............................................................ 5
ABOUT THE CARD ............................................................................... 9
Media cards that can be used with this camera .............................. 9
What “card” means in this manual .................................................. 9
SETUP
PARTS NAMES ................................................................................... 10
CHARGING THE BATTERY PACK ..................................................... 12
Charging the battery pack ............................................................. 13
INSTALLING THE CARD ..................................................................... 15
INSTALLING THE BATTERY PACK .................................................... 17
About the temperature alert icon \........................................... 19
TURNING THE CAMERA ON AND OFF ............................................. 20
Turning on the camera .................................................................. 20
Turning off the camera .................................................................. 20
Turning on the camera when the power save (sleep) mode is
active ........................................................................................ 21
DATE AND TIME SETTING ................................................................. 23
SWITCHING BETWEEN THE RECORDING MODE AND
PLAYBACK MODE .......................................................................... 26
SWITCHING THE OPERATING MODE .............................................. 27
Switching between the SIMPLE and NORMAL modes ................ 27
Accessing/exiting the SIMPLE/NORMAL Mode Menu Screen ..... 28
SHOOTING
VIDEO CLIP RECORDING .................................................................. 32
SHOOTING SINGLE SHOTS .............................................................. 33
SHOOT A STILL IMAGE WHILE RECORDING A VIDEO CLIP .......... 35
MACRO-PHOTOGRAPHY (ZOOM) .................................................... 37
