SPEEDIBOIL
Installation and User Instructions
Models: SP2.5, SP5.0, SP7.5
Please read and understand these instructions before starting work.
Please leave this leaet with the user following installation.
WARNING
This Boiling Water Heater must only be installed by
qualied persons.
36006034 Issue 2.
2
Thank you for purchasing a Santon Speediboil . The Boiling water heater is manu-
factured to the highest standards and has been designed to meet all the latest relevant
safety specications.
This Santon water heater must be installed (Sections 1-5), commissioned (Section
6) and maintained (Sections 7-8) by a competent person. Please read and understand
these instructions prior to installing your Santon water heater. Following installation
and commissioning the operation of the heater should be explained to the user (Section
10) and these instructions left with them for future reference.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of the appliance by
a person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance.
COMPONENT CHECKLIST
Before commencing installation check that all the following components have been
supplied with your Speediboil heater.
Wall mounting bracket•
No.12 x 2” screws (2 off)•
No.8 x 1” screw (1 off)•
No.12 x 2” wall plug (2 off)•
No.8 x 1” wall plug (1 off)•
15mm x 15mm straight push-t connector (tted)•
15mm x 15mm 90 ° elbow push t connector (tted)•
INTRODUCTION
Multipoint
3
3
CONNECTIONS
Inlet connection -15mm ext. diameter
Water entry point - bottom and rear
Cable entry point - bottom and rear
ELECTRICAL
Model numbers
2.5kW - Speediboil 2.5ltr - 94 200 001
2.5kW - Speediboil 5.0ltr - 94 200 002
2.5kW - Speediboil 7.5ltr - 94 200 003
Electrical rating 2.3/2.5kW@230/240V
Nominal capacities Model SP2.5 2.5 litres
Model SP5.0 5.0 litres
Model SP7.5 7.5 litres
Weight (full) Model SP2.5 8.4kg
Model SP5.0 11.8kg
Model SP7.5 15.4kg
Rated pressure
Minimum supply pressure 0.05MPa (0.5 bar)
Maximum supply pressure 1.0MPa (10 bar)
Enclosure rated IP X2
Nominal commissioning times (minutes) to temperature ready
Model SP2.5 16
Model SP5.0 24
Model SP7.5 32
STANDARDS AND APPROVALS
Complies with the requirement of EN 60335-2-35.
British Electromechanical Approvals Board (BEAB) approved.
Complies with European Community Directives (CE).
Complies with UK water regulations, kiwa approved.
TECHNICAL SPECIFICATION
4
1.1 The Speediboil stores and dispenses water at or close to boiling point at all
times it is switched on. Due caution must be taken when choosing a location
for the product to minimise misuse. Locate the unit over a draining board
NOT over the sink or basin.
1.2 Push t connectors DO NOT grip chromed or stainless pipe.
1.3 The Speediboil is a vented water heater. The vent pipe must never be
blocked or obstructed, it must be a minimum of 15mm outside diameter
pipe. Where the vent pipe length exceeds 3m the pipe diameter should be
increased. The vent pipe must be laid to a continuous fall and discharge in
a safe and visible position; it must discharge via a tundish or nish a
minimum of 20mm above a draining board. The vent pipe material must
be capable of conveying boiling water. The vent pipe must never be
connected directly to a soil pipe.
1.4 Wherever possible the Speediboil should be supplied directly from a rising
main. If fed from a cold water feed cistern, the cistern must comply with the
Water Regulations Guide (clause R27.2). It should be noted that water
quality may be reduced when supplied from a cistern and additional forms of
water pretreatment may be necessary.
1.5 In hard water areas, heated water will produce lime scale which will be
deposited within the heater. If this is not regularly removed it will impair the
operation of the heater. Where rapid and excessive scale build up is likely to
occur the use of a proprietary scale reducing device may be benecial.
1.6 The installation must be carried out in accordance with the relevant
requirements of:
• The appropriate Building Regulations either The Building
Regulations (England & Wales), The Building Regulations (Scotland) or
Building Regulations (Northern Ireland).
• The Water Fittings Regulations or Water Byelaws in Scotland.
1.7 The Speediboil will adjust for ambient (room) temperatures of between 1°c and
40°c.
1.8 When not in use care must be taken to prevent it freezing; if thought to be
frozen it must not be switched on. It must be left to thaw and must then be
thoroughly inspected to ensure it is totally thawed and undamaged.
1.9 The unit is not suitable for installation in an area where a water jet could be
used.
1.0 IMPORTANT INSTALLATION POINTS
Multipoint
5
5
2.1 The Speediboil must be vertically wall mounted using the bracket supplied.
2.2 Fig.1 details the outside dimensions of the Speediboil unit. It is recommended
that the unit is positioned above the draining board. If this is not possible
consideration should be given to any spillages that may occur under the
appliance. The heater should be positioned at a height to suit the items being
lled (asks, pans, cups etc.). This is likely to position the base of the unit
250mm above the work surface.
2.3 Sufcient room should be left around the heater for access for maintenance
and servicing. The top should not be covered as this will reduce the efciency
of the Speediboil.
2.4 Ensure that the wall can support the full weight of the unit (see TECHNICAL
SPECIFICATIONS) and that there are no hidden services (electricity, gas or
water) below the surface of the wall.
2.5 Using the backplate mark the xing positions and water and vent entry points.
Drill and plug the xing positions. Fix the mounting bracket to the wall using
the two No. 12x2” screws provided (conrm suitability of all screws and plugs
for use with the wall, if unsuitable due to wall type provide alternative xings)
2.6 If rear entry services are to be used the necessary holes for these should be
prepared prior to hanging the unit onto its bracket.
2.7 Remove the front cover by: unscrewing the top and bottom cover xing screws
bottom and top. Hang the Speediboil onto the wall mounting bracket. Secure
anchor point to the wall with the No.8 x 1” screw (provided).
2.0 INSTALLATION - MOUNTING
6
30
C
G
F
E
D
B
A
250mm approx
Worktop
Figure 1
H
J
I
L
M
N
MODEL
A B C D E F G H
INLET VENT
INLET/
VENT
CABLE
ENTRY
SP2.5 445 290 190 85 115 101 49 46
SP5.0 510 335 200 103 133 101 49 69
SP7.5 510 335 262 103 133 101 49 69
DIMENSIONS (mm)
Fixing
Bracket
Fixing
Hole
INLET/
VENT
K
O
Multipoint
7
7
3.1 Select appropriate push t connector for chosen entry position:
Bottom entry water - 15mm x 15mm 90º elbow.
Rear entry water - 15mm x 15mm straight.
Note: stainless or chromed pipes DO NOT provide secure connections with
push t ttings (use copper pipe at joints).
3.2 Push the connector fully home (28mm engagement) onto the solenoid valve
inlet spigot. To remove a push t connector the collar (collet) should be pushed
towards the body of the tting whilst pulling the connector off the pipe.
3.3 If the inlet pipe run is horizontal and beneath the unit ensure it does not prevent
access to the case screws.
3.4 Connect the inlet pipe to the push t connector ensuring it is fully pushed home
(28mm engagement). After connection DO NOT make soldered joints in the
pipe work close to the heater, as the heat may damage the connector or the water
heater itself.
3.5 A WRAS listed isolating valve should be tted to the cold supply to facilitate
servicing the heater.
3.6 Push t connectors are supplied to allow either bottom or rear entry of services.
3.0 INSTALLATION - WATER SUPPLY
4.0 INSTALLATION - VENT PIPE
4.1 Select appropriate push t connector for chosen entry position:
Bottom entry vent - 15mm x 15mm straight
Rear entry vent - 15mm x 15mm 90º elbow
4.2 Push the connector fully home (28mm engagement) onto the vent pipe
connection.
4.3 Connect the vent pipe to the push t connector ensuring it is pushed fully
home (28mm engagement). Refer to the vent pipe requirement detailed in
IMPORTANT INSTALLATION POINTS. If a bottom entry vent pipe is used
the pipe must terminate below the unit, in a safe visible position. After
connection DO NOT make soldered joints in the pipe work close to the heater,
as the heat may damage the connector or the water heater itself.
FIXING
POINT
SP2.5
SP5.0
SP7.5
CABLE
ENTRY
FIXING
POINT
IJ
BRACKET BRACKET BRACKET OUTLET
KLMNO
59
61
61
96
117
117
50
67
67
342
401
401
52.5
84
84
169
217
217
152
163
225
8
5.0 INSTALLATION - ELECTRICAL REQUIREMENTS
WARNING:
5.1 This appliance must be earthed.
5.2 The installation, supply cable and circuit protection must conform to the latest
BS7671 ‘Requirements for electrical installations’ (IEE Wiring Regulations).
5.3 The appliance must only be connected to a 230/240 V ac supply. A double pole
isolating switch, with a contact separation of at least 3mm in both poles, must
be incorporated in the electrical supply. The supply should be fused 13Amp.
5.4 If the Speediboil is to be unused for signicant periods of time running
costs can be reduced by switching the unit off. It is recommended that this is
done automatically by incorporating a suitable timeswitch in the supply to the
unit. The use of a accessory No. 95 970 124 is recommended. The timeswitch
can then be set to switch the unit on for a suitable period to allow it to heat up
before it is next to be used. NOTE:A timeswitch must be capable of switching
13 Amps resistive load.
2.5 kW
ELEMENT 'A'
LL N
S
PRIMARY
CUTOUT 'A'
SOLENOID
VALVE
LOWER
SENSOR
EARTH
UPPER
SENSOR
EARTH
UPPER LEVEL SENSOR
LOWER LEVEL SENSOR
SCALE
CONDITIONING
FIELD WINDING
'AT TEMP' LED ANODE
'AT TEMP' LED CATHODE
'POWER ON' LED ANODE
'POWER ON' LED CATHODE
WIRING SCHEMATIC
H
N
W
L1
L2
L3
J5
1
2
STEAM THERMISTOR
WATER THERMISTOR
6
5
7
8
9
10
J7
ELECTRONIC CONTROL
TERMINAL BLOCK
1
1
Figure 2: Wiring Diagram
Multipoint
9
9
6.1 The electronic control system of the Speediboil has a self commissioning and
calibration function. Once the heater is installed and all services have been
connected the appliance should require no further adjustment before use.
6.2 Check that all electrical, water and vent pipe connections have been made and
are secure.
6.3 Replace the cover and secure with the xing screws. Ensure the tank discharge
tube is centrally located in the outlet spout. Turn on water then electrical supply.
6.4 The READY indicator will ash to indicate the unit is in its “self
commissioning” mode. The water in the unit will not be hot enough to use at
this stage (do not draw water off).
6.5 The READY indicator will continue to ash until the unit has reached boiling
and has “self-calibrated”. At this point the READY indicator will remain
illuminated. If for any reason the calibration procedure is interrupted it will
restart after a short delay but may result in the calibrated temperature being to
low. If this occurs switch the electrical supply OFF for several seconds and
then switch ON. The calibration sequence will reset. Wait for the READY
indicator to remain illuminated.
6.6 The unit is now ready to use, however, it is recommended that the rst few lls
be drawn off and discarded to ensure the freshness of the water.
6.7 The tap sealing washer pressure has been already set. If the tap drips after
commissioning adjust the spring tension so that the handle is just loose.
a) Remove the tap bezel after removing the two screws securing it. Note:
to remove the bezel the handle will have to be operated. This will cause water to
discharge from the outlet (see Page 13 item 10).
b) Tighten the tap headwork nut (turn clockwise) until the handle is just loose.
Replace bezel and securing screws. Note: excessive adjustment will dismantle
the tap, if heated this would result in the uncontrollable release of boiling water
(see Page 13 item 7).
6.8 Check for leaks.
6.9 IMPORTANT NOTE: each time the unit is switched off then switched on it will
always go through the same cycle 6.4-6.5. Water should never be drawn off the
6.0 COMMISSIONING
10
8.0 FAULT FINDING
YOUR SANTON SPEEDIBOIL SHOULD GIVE TROUBLE FREE OPERATION,
HOWEVER SHOULD A FAULT OCCUR THE TABLE BELOW SHOULD ALLOW
MOST FAULTS TO BE IDENTIFIED. FAULT FINDING SHOULD ONLY BE CAR-
RIED OUT BY A COMPETENT PERSON.
SYMPTOM POSSIBLE CAUSE ACTION
No indicator light 1. If no water or heat - no power to
unit
2. If no water available - no power to
indicator diodes
1. Check power supply is correctly
connected and switched on and that
primary cutout has not operated
2. Check connections to indicators at
4 way plug
Unit does not fill on commisioning 1. If “ON” indicator not illuminated
no power to unit
2. Solenoid valve fault
3. Low water pressure
1. Check power supply is correctly
connected and switched on and that
primary cutout has not operated
2. Check operation of solenoid valve,
replace if necessary
3. Check supply is turned on
Unit does not heat on commisioning 1. If “ON” indicator not illuminated
no power to unit
2. Solenoid valve fault
3. Low water pressure
4. Element fault
1. Check power supply is correctly
connected and switched on and that
primary cutout has not operated
2. Check operation of solenoid valve,
replace if necessary
3. Check supply
4. Check element continuity. If faulty
replace
NOTE: Maintenance must be carried out by competent persons.
Competent - i.e. Trained, experienced, qualied.
Disconnect the electrical supply before removing the cover.
WARNING: Electronics control by switching ‘n’ (neutral), in some instances neutral
terminations will be at 230 volts with respect to earth.
7.1 The Speediboil incorporates an electronic scale conditioning function which
will reduce the rate of scale deposition in hard water areas. However, some
deposits may still occur in the storage tank; these should be periodically
removed.
7.2 The amount of usage of the unit will also determine the quantity of scale build
up. A regular inspection of the tank every 6 to 12 months will provide longer
life of the product and optimum performance (removal of the steam plate
assembly will give access to the storage tank) .
7.3 The front cover and spout will require a periodic wipe to clean any marks/
splashes from use.
7.0 MAINTENANCE
Autres manuels pour SP2.5
1
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels Santon Chauffe-eau
Santon
Santon PowerPack Mode d’emploi
Santon
Santon A7/3 Mode d’emploi
Santon
Santon AH7/2.2 Mode d’emploi
Santon
Santon PREMIER PLUS Guide de l'utilisateur
Santon
Santon PremierPlus Guide de l'utilisateur
Santon
Santon AL07/3 Mode d’emploi
Santon
Santon SP2.5 Mode d’emploi
Santon
Santon Aquarius AU7/3 Mode d’emploi
Santon
Santon Aquarius AU7/3 Mode d’emploi
Santon
Santon PowerPack Manuel utilisateur
Santon
Santon Aquarius A7/3 Mode d’emploi
Santon
Santon R25 Mode d’emploi
Santon
Santon Aqualine ALK02 Manuel utilisateur
Santon
Santon PremierPlus 100 Guide de l'utilisateur
Santon
Santon PES170D Guide de l'utilisateur
Santon
Santon Aquaheat AH30V Mode d’emploi
Santon
Santon Aquaheat SS V 100 Mode d’emploi
Santon
Santon Premier Plus 120 Guide de l'utilisateur
Santon
Santon EV 2008 Mode d’emploi
Santon
Santon AH10/2.2 Mode d’emploi
Manuels Chauffe-eau populaires d'autres marques
Kenmore
Kenmore 153.582400 Manuel utilisateur
Applimo
Applimo Edel AIR Manuel utilisateur
STIEBEL ELTRON
STIEBEL ELTRON Eltronom SHU 5 S Manuel utilisateur
clage
clage E-Mini Series Manuel utilisateur
Toyotomi
Toyotomi Oil Miser OM-180 Manuel utilisateur
Bradford White
Bradford White EF Series Manuel utilisateur
