Samsung HW-J650 Manuel utilisateur
Wireless Audio - Soundbar
Imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register your product at
www.samsung.com/register
User manual
'This Nanum Gothic Eco font is provided by NAVER'
HW-J650
HW-J651
Wireless Subwoofer
(PS-WJ650 / PS-WJ651)
32
GETTING STARTED
FEATURES
GETTING STARTED
Streaming Music Services
The Soundbar makes diving into all your favorite
music easier than ever before, thanks to its Wi-Fi
capabilities. Simply access the Samsung Multiroom
App to experience the best of the internet’s
subscription streaming music services.
Surround Sound Expansion
The Surround Sound Expansion feature adds depth
and spaciousness to your listening experience.
TV SoundConnect
Listen to TV audio through the Soundbar by
connecting your TV and the Soundbar via Bluetooth
with TV SoundConnect. Easy connectivity and the
absence of trailing wires between the Soundbar and
TV allows you to showcase the slim and sleek design
of both systems, while maintaining a clean look in
your living environment. Easily control the Soundbar
and TV from a single TV remote.
Music Source Sharing (= Multiroom Play)
Controlling and sharing one music source across
multiple audio devices in various locations is made
easy with Multiroom Link. The mobile app remotely
controls volume and music on your system across
different devices, including your TV, Soundbar, Home
Entertainment System and Blu-ray Disc Player. Enjoy
the audio you want, where you want.
HDMI
HDMI transmits digital video and audio signals
simultaneously, and provides a clearer picture.
The unit is also equipped with the ARC function
which lets you listen to sound from your TV through
the Soundbar via an HDMI cable. This function is
only available if you connect the unit to an ARC
compliant TV.
USB Host Support
You can connect and play music files from external
USB storage devices such as MP3 players, USB flash
memory, etc. using the Soundbar's USB HOST
function.
Bluetooth Function
You can connect a Bluetooth device to the Soundbar
and enjoy music with high quality stereo sound, all
without wires!
LICENSES
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing
Limited. DTS, the Symbol, & DTS and the Symbol
together are registered trademarks, and DTS 2.0
Channel is a trademark of DTS, Inc. © DTS, Inc. All
Rights Reserved.
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
3
ENG
GETTING STARTED
SAFETY INFORMATION
●The following also applies to the Wireless Subwoofer (PS-WJ650, PS-WJ651).
SAFETY WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
The lighting flash and arrowhead within the
triangle indicates that there is dangerous
voltage Inside the product.
The explanation point within the triangle
indicates that there are important instructions
accompanying the product.
WARNING
• To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
• To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
• This product contains chemicals known to the State of California to cause cancer and reproductive toxicity.
CAUTION
• Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the apparatus.
• To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power plug
must be easily and readily accessible at all times.
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other equipment.
To prevent electromagnetic interference with electric appliances, such as radios and televisions, use shielded cables and
connectors for connections.
FCC NOTE (for U.S.A):
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorienting or relocating the receiving antenna.
• Increasing the separation between the equipment and receiver.
• Connecting the equipment to an outlet that is on a different circuit than the radio or TV.
• Consulting the dealer or an experienced radio/TV technician for help.
Caution : FCC regulations state that any unauthorized changes or modifications to this equipment may void the user's
authority to operate it.
Important Safety Instructions
Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these
operating instructions handy for future reference.
1) Read these instructions.
2) Keep these Instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachment/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13) Unplug this apparatus during lightning
storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any
way, such as when the power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
54
GETTING STARTED
PRECAUTIONS
Ensure that the AC power supply in your house complies with the power requirements listed on the
identification sticker located on the back of your product. Install your product horizontally, on a suitable base
(furniture), with enough space around it for ventilation (3~4 inches). Make sure the ventilation slots are not
covered. Do not place the unit on amplifiers or other equipment which may become hot. This unit is designed
for continuous use. To fully turn off the unit, disconnect the AC plug from the wall outlet. Unplug the unit if
you intend to leave it unused for a long period of time.
3.9 inch 3.9 inch
2.7 inch
3.9 inch
During thunderstorms, disconnect the AC plug from
the wall outlet. Voltage peaks due to lightning could
damage the unit.
Protect the product from moisture (i.e. vases), and
excess heat (e.g. a fireplace) or equipment creating
strong magnetic or electric fields. Unplug the power
cable from the AC wall socket if the unit
malfunctions. Your product is not intended for
industrial use. It is for personal use only.
Condensation may occur if your product has been
stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until
the unit has reached room temperature before using.
Do not expose the unit to direct sunlight or other
heat sources. This could lead to overheating and
cause the unit to malfunction.
The battery used with this product contains
chemicals that are harmful to the environment. Do
not dispose of the battery in the general household
trash. Do not expose the battery to excess heat,
direct sunlight, or fire. Do not short circuit,
disassemble, or overheat the battery. Danger of
explosion if the battery is replaced incorrectly.
Replace only with the same or equivalent type.
WARNING: DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD. The remote control supplied
with this product contains a coin/button cell battery. If the coin/button cell battery is swallowed,
it can cause severe internal burns in just 2 hours and can lead to death. Keep new and used
batteries away from children. If the battery compartment does not close securely, stop using the
remote and make sure to keep it away from children. If you think the battery might have been swallowed or
placed inside any part of the body, seek immediate medical attention.
5
ENG
GETTING STARTED
Figures and illustrations in this User Manual are
provided for reference only and may differ from
actual product appearance.
CONTENTS
2 GETTING STARTED
2 Features
3 Safety Information
6 What’s Included
7 DESCRIPTIONS
7 Top / Front Panel
8 Rear / Bottom Panel
9 Remote Control
11 INSTALLATION
11 Installing the Wall Mount
11 Installation Precautions
12 Installing the Bracket without Referring to
the Wall-Mount Installation Guide
13 Detaching the Soundbar from the Wall
Mount
14 CONNECTIONS
14 Connecting the Subwoofer
16 Connecting to a TV
16 Connecting to a TV Using a Digital Optical
Cable
17 Connecting to a TV Using an HDMI (Digital)
Cable
17 TV SoundConnect
19 Connecting to External Devices
19 HDMI Cable
19 Optical or Analog Audio Cable
20 USB
22 FUNCTIONS
22 Input Mode
23 Bluetooth
25 Using the Multiroom App
26 Using the Network Standby On Function
27 Software Update
29 TROUBLESHOOTING
29 Troubleshooting
30 APPENDIX
30 Specifications
76
GETTING STARTED
WHAT’S INCLUDED
BEFORE READING THE USER’S MANUAL
Note the following terms before reading the user manual.
+Icons used in this manual
Icon Term Definition
Caution
Indicates a situation where a function does not operate or settings may be
canceled.
Note
Indicates tips or instructions on the page that help you operate a function.
Check for the supplied accessories shown below.
Remote Control /
Lithium Battery (3V : CR2032)
(AH59-02692A / 4301-001042)
Power Cord : 2EA
(3903-000599)
DC Adapter
(BN44-00799A)
Optical Cable
(AH39-00779A)
(Wall Mount L)
(Wall Mount R)
USB Cable
(AH39-01178B)
User Manual /
Quick Guide
(AH68-02832A) /
(AH68-02826E)
Bracket-Wall Mount
(L : AH61-03833A / R : AH61-03834A)
Holder-Screw 1: 2EA
(AH61-03342A)
Holder-Screw 2: 2EA
(6001-001961)
Wall Mount Guide
(AH63-03710D)
●The appearance of the accessories may differ slightly from the illustrations above.
●Use the dedicated USB cable to connect external USB devices to the unit.
7
ENG
DESCRIPTIONS
TOP / FRONT PANEL
(Power) Button
Turns the power on and off.
VOL. - / +
Controls the volume level.
The numeric value of the volume level
appears in the front panel display.
Display
Displays the current mode.
(Source) Button
Selects the D.IN, AUX, HDMI, BT, TV, or USB
input.
●While the unit is powered on, pressing
the
(Source) button for more than 3
seconds sets the button to act as the
(Mute) button. To cancel the
(Mute)
button setup, press the
(Source)
button for more than 3 seconds again.
●When you plug in the AC cord, the power button will begin working in 4 to 6 seconds.
●When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.
●If you want to enjoy sound only from the Soundbar, you must turn off the TV's speakers in the
Audio Setup menu of your TV. Refer to the owner's manual supplied with your TV.
DESCRIPTIONS
98
DESCRIPTIONS
REAR / BOTTOM PANEL
AUX IN OPTICAL IN
HDMI IN HDMI OUT
(TV-ARC)
AUXIN
HDMIIN HDMIOUT
(TV-ARC)
OPTICALIN
LAN 5V0.5A
LAN 5V 0.5A
DC 24V
SPK ADDWi-Fi SETUP
DC 24V
SPK ADDWi-Fi SETUP
DC 24V (Power Supply In)
Connect the DC power adaptor to the power
supply jack, and then connect the AC power
adaptor plug to a wall outlet.
HDMI IN
Inputs digital video and audio
signals simultaneously using
an HDMI cable. Use when
connecting a supported
external device.
HDMI OUT (TV-ARC)
Outputs digital video and
audio signals
simultaneously using an
HDMI cable.
OPTICAL IN (D.IN)
Connect to the digital
(optical) output of an
external device.
AUX IN
Connect to the Analog output of an
external device.
LABEL
SPK ADD
Press this button to
connect the
Soundbar to a
Samsung HUB.
(not supplied)
Wi-Fi SETUP
Press this button to
connect your Soundbar
to your network using
Wi-Fi setup. (Requires a
smart device and the
Samsung Multiroom app.
See page 25.)
LAN
Lets you connect to a network using
a LAN cable.
(USB Port)
Connect USB devices here to play
files on the devices.
●When disconnecting the power cable of the AC power adaptor from a wall outlet, pull the plug.
Do not pull the cable.
●Do not connect this unit or other components to an AC outlet until all connections between
components are complete.
9
ENG
DESCRIPTIONS
REMOTE CONTROL
Anynet+
Press the Anynet+ button to turn the Anynet+ function on or off.
(Default : Auto Power Link OFF, ON - ANYNET+ / OFF - POWER LINK or OFF
- ANYNET+ / ON - POWER LINK). The Anynet+ function lets you control the
Soundbar with the remote from an Anynet+ compatible Samsung TV. The
Soundbar must be connected to the TV via an HDMI cable.
* Auto Power Link
Synchronizes the Soundbar to a connected Optical source via the
Optical jack so it turns on automatically when you turn on your TV.
(See page 16)
You can also activate Wi-Fi SETUP function by pressing and holding
Anynet+ button on the remote for over 7 seconds.
Repeat
Press to set the Repeat function during music playback from a USB device.
OFF - REPEAT : Cancels Repeat Playback.
TRACK - REPEAT : Repeatedly play a track.
ALL - REPEAT : Repeatedly play all tracks.
RANDOM - REPEAT : Plays tracks in random order.
(A track that has already been played may be played again.)
Mute
You can turn the volume down to 0 with the push of a button.
Press again to restore the sound to the previous volume level.
SOURCE
Press to select a source connected to the Soundbar.
Skip Forward
If there is more than one file on the device you are playing, and you
press the ] button, the next file is selected.
SOUND CONTROL
Press to select TREBLE, BASS, or AUDIO SYNC. Then, use the
[
,
]
buttons to adjust the Treble or Bass volume from -3 to +3.
Press and hold the SOUND CONTROL button for about 5 seconds to adjust
the sound for each frequency band. 150Hz, 300Hz, 600Hz, 1.2KHz,
2.5KHz, 5KHz, and 10KHz are selectable and each can be adjusted to a
setting between -6 and +6.
If the Soundbar is connected to a digital TV and the video appears out of
sync with the audio, press the SOUND CONTROL button to sync the audio
with the video. Use the
[
,
]
buttons to set the audio delay between
0 ms and 300 ms. In USB mode, TV mode, and BT mode, the Audio Sync
function may not available.
●Soundbar is a Samsung proprietary name.
●Operate the TV using the TV's remote control.
1110
DESCRIPTIONS
STREAMING MUSIC
Press STREAMING MUSIC button to listen to an Internet radio station.
Each time you press this button, the Soundbar switches to the next default
station, cycling through the 3 default stations.
To use the STREAMING MUSIC function, the Soundbar must be connected
to the Internet. (See page 26)
DRC (Dynamic Range Control) *
Lets you apply dynamic range control to Dolby Digital, Dolby Digital Plus,
and Dolby TrueHD audio.
Press and hold the STREAMING MUSIC button to toggle the DRC
(Dynamic Range Control) function ON and OFF.
WOOFER
Press the WOOFER button. Then, use the
[
,
]
buttons to adjust the
Subwoofer volume from -12, -6 to +6.
You can also activate SPK ADD function of the soundbar by pressing and
holding WOOFER button of the remote for over 5 seconds.
SOUND
Surr.Sound adds depth and spaciousness to the sound. Pressing the
SOUND button repeatedly cycles through the Surr.Sound settings :
ON - SURROUND SOUND, OFF - SURROUND SOUND
Volume
Adjusts the volume level of the unit.
Power
Turns the Soundbar on and off.
SOUND EFFECT
You can select the sound modes - STANDARD (Original Sound), MUSIC,
VOICE, SPORTS, CINEMA, and NIGHT MODE - depending on the content
you want to listen to.
Select the STANDARD mode if you want to enjoy the original sound.
Play / Pause
Press the
p
button to pause a file temporarily.
Press the
p
button again to play the selected file.
Skip Back
If there is more than one file on the device you are playing, and you press
the
[
button, the previous file is selected.
INSTALLING THE BATTERY IN THE REMOTE CONTROL
1. Use a suitable coin to turn the
remote control's battery cover
counterclockwise to remove it
as shown in the figure above.
2. Insert a 3V lithium battery. Keep the
positive (+) pole facing up when
inserting the battery. Put the battery
cover on and align the '●' marks side
by side as shown in the figure above.
3. Use a suitable coin to
turn the remote control
battery cover clockwise
as far as it will go to fix
it in place.
Autres manuels pour HW-J650
2
Ce manuel convient aux modèles suivants
3
Table des matières
Autres manuels Samsung Système audio sans fil
